GENERAL INFORMATION
Note: Do not operate fireplace without the eyebrow installed in its normal
position. See Figure 1 for models with louvers or Figure 2 for
models with clean face panel.
Step 1.Grasp the existing eyebrow and pull it forward away from the
fireplace (it is held in place by spring tension). See Figure 1.
Step 2.Slightly lift and pull the existing top louver assembly away from
the fireplace.
Step 3.Slide the existing eyebrow into the slots on the lower edge of the
top radiant replacement panel.
Step 4.Hang the top radiant panel/eyebrow assembly in the opening
previously occupied by the top louver assembly. See Figure 2.
Step 5.Open the bottom louver assembly by pushing in simultaneously
the left and right sides of the louver assembly (the assembly is
hinged at the bottom).
Step 6.Merit Series Units - Remove the assembly from the fireplace by
removing the hinge screw and spacer on each end of it.
Merit Plus and Elite Series Units - Remove the assembly from the
fireplace by sliding the hinge pin, located at the door’s left side,
to the right until it disengages from the left corner post hole. Pull
the door diagonally to the left, away from the fireplace.
Step 7. Snap the replacement Lennox nameplate logo into the 2 holes
provided in the replacement panel.
Step 8. Merit Series Units - Install the replacement bottom radiant panel
using the existing hinge screws and spacers.
Merit Plus and Elite Series Units - Install the replacement bottom
radiant panel by inserting the right side locating pin into the right
cabinet corner post and then the left side spring-loaded pin into
the left cabinet corner post.
These clean face panel kits may be used with Merit™, Merit Plus™or
Elite®series gas fireplaces listed in Table 1.
INSTALLATION INSTRUCTIONS FOR CLEAN FACE PANEL KITS FOR USE WITH
MERIT ™, MERIT PLUS ™OR ELITE®SERIES GAS FIREPLACES
INSTALLATION INSTRUCTIONS
CLEAN FACE PANEL KITS
(PAINTED FINISH)
P/N 504,223M
REV. F 03/2008
LENNOX HEARTH PRODUCTS
KITS AND ACCESSORIES
Printed in U.S.A. © 2001 by Lennox Hearth Products
P/N 504,223M REV. F 03/2008
NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
Lennox Hearth Products
1110 West Taft Avenue • Orange, CA 92865
Figure 2 - Clean Face
Hood must be installed as shown.
Top of Appliance
Louver Assembly
Top of Door Frame
Figure 1 - Louvered Face
CAT. NO. MODEL WHERE USED
88L36 RAD35C-2 EDV3530, ED3530 front-open, MPD3530,
MPD35ST/PF, MPB35ST
88L37 RAD40C-2
EDV4035, ED4035-2, MPD4035 front open,
EDVST, EDST-2, EDVPF, EDPF-2, EDVCR,
EDCR-2, EDVCL, EDCL-2, EBST-2, EBVPF,
EBPF-2, EBVCR, EBCR-2, EBVCL, EBCL-2
multi-open (long panel)
88L38 RAD45C-2 EDV4540, ED4540-2, MPD4540 front-open
88L35 RAD24C-2
EDVPF, EDPF-2, EDVCR, EDCR-2, EDVCL,
EDCL-2, EBVPF, EBPF-2, EBVCR, EBCR-2,
EBVCL, EBCL-2 multi-open (short panel)
98L12 RAD33C MDR3328, MDT3328, MPDT3328,
MPDR3328
26M47 RAD33MC MPD3530, MPD35ST
H7019 RAD22C-2 MPD35PF
Table 1 - Painted Panel Kits
KIT CONTENTS: TOOLS REQUIRED:
1 ea. Top Radiant Panel
1 ea. Bottom Radiant Panel
1 ea. Lennox Nameplate
1 ea. Instruction Sheet
None
CAUTION
INSTALL ONLY WHEN THE
FIREPLACE IS OFF AND COLD!
Hood must be installed as shown.
Top of Appliance
Top Radiant Panel
Top of Door Frame
Top Radiant Panel
Bottom Radiant Panel
Lennox Hearth Products reserves the right to make changes at any time, without notice, in design, materials, specifications, prices and the discontinuance of colors, styles and products.
Consult your local distributor for fireplace code information.
