Lenze E82ZAFCC210 User manual

Montageanleitung
Mounting Instructions
Instructions de montage
EDK82ZAFCC-210
.ñP^
Ä.'P^ä
CAN-I/O PT

E82ZAFCC210
Funktionsmodul
Function module
Module de fonction

EDK82ZAFCC-210 DE/EN/FR 2.0
30 
legende_kopfzeile-TIP_download
Legend for fold-out page See
Function module E82ZAFCC210
DIP switch for
znode address
zBaud rate
QT
Plug connector X3.1, connection for CAN bus
QO
Plug connector X3.2, connection for digital inputs
Plug connector X3.3, connection for
zController inhibit (CINH)
zController inhibit internal supply
Nameplate PN
Tip!
Current documentation and software updates for Lenze products can be found
on the Internet in the ”Downloads” area under
http://www.Lenze.com

EDK82ZAFCC-210 DE/EN/FR 2.0 31

-M5-einsetzbarkeitAFCC210
Validity
These Instructions are valid for
ƒ Function modules E82ZAFCC210, CAN-I/O PT, as of version 3A
These Instructions are only valid together with the Operating Instructions for the basic
devices permitted for the application.
Identification
E82AF000P0B201XX

APPLICATION
010 / 3A22

A22A22
APPLICATION
010 / 3A22

L
Type
Id.-No.
Prod.-No.
Ser.-No.
E82ZAFX005
c d e
E82ZAF C C 210 3A
Series
CAN
Generation
Variant 210: PT version
Hardware version
Software version
Function
The function module connects the basic device to the serial communication system CAN
(Controller Area Network).
Application range
The function module E82ZAFCC210 (CAN I/O PT) can be used
with the following basic devices
As of version
Frequency inverter 8200 vector Vx21

iContents
EDK82ZAFCC-210 DE/EN/FR 2.0
32 
Inhalt
1 Safety instructions 33.................................................
Definition of notes used 33.............................................
Residual hazards 34...................................................
2 Scope of supply 35....................................................
3 Mechanical installation 36.............................................
4 Electrical installation 37...............................................
Wiring to a host 37....................................................
Wiring according to EMC 38............................................
Connection terminals 39..............................................
Terminal assignment 41...............................................
Bus cable length 43...................................................
5 Commissioning 46....................................................
Before switching on 46................................................
Baud rate and node address (node ID) setting 47...........................
Address 48...........................................................
Baud rate 49.........................................................
Initial switch-on 50...................................................
Basic identifiers of the CAN objects 52...................................
6 Technical data 53.....................................................
General data and operating conditions 53.................................
Protective insulation 54...............................................
Dimensions 55.......................................................

Safety instructions
Definition of notes used
1
EDK82ZAFCC-210 DE/EN/FR 2.0 33

H1sic_EN-restgef
1 Safety instru ctions
Definition of notes used
The following pictographs and signal words are used in this documentation to indicate
dangers and important information:
Safety instructions
Structure of safety instructions:
Danger!
(characterises the type and severity of danger)
Note
(describes the danger and gives information about how to prevent dangerous
situations)
Pictograph and signal word Meaning
Danger!
Danger of personal injury through dangerous electrical voltage.
Reference to an imminent danger that may result in death or
serious personal injury if the corresponding measures are not
taken.
Danger!
Danger of personal injury through a general source of danger.
Reference to an imminent danger that may result in death or
serious personal injury if the corresponding measures are not
taken.
Stop!
Danger of property damage.
Reference to a possible danger that may result in property
damage if the corresponding measures are not taken.
Application notes
Pictograph and signal word Meaning
Note! Important note to ensure troublefree operation
Tip! Useful tip for simple handling
Reference to another documentation

1 Safety instructions
Residual hazards
EDK82ZAFCC-210 DE/EN/FR 2.0
34 
H1sic_EN-restgef
Residual hazards
Danger!
Observe the safety instructions and residual hazards included in the
Instructions for the basic device.

Scope of supply 2
EDK82ZAFCC-210 DE/EN/FR 2.0 35

H1_LIF-Liefumfg
2 Scope of supply




E82ZAFC300B/AFX007,016-019
Pos. Item Info
Function module E82ZAFCC210
Mounting Instructions
Terminal strip with double screw connection, 3-pole For connection see 42
Terminal strip with spring connection, 2-pole
Terminal strip with spring connection, 4-pole
Mounting clip For usage see operating
instructions/mounting
instructions for
8200 vector
Two bus terminating resistors (120 Ωeach) 38

3Mechanical installation
EDK82ZAFCC-210 DE/EN/FR 2.0
36 
H1_MechINS-MechInst
3 Mechanical installation
Please see the Mounting Instructions for the basic device for the mechanical installation of
the function module.
The Mounting Instructions for the basic device
ƒ are part of the scope of supply and are enclosed with each device.
ƒ provide tips for avoiding damage through improper handling.
ƒ describe the obligatory order of installation steps.

Electrical installation
Wiring to a host
4
EDK82ZAFCC-210 DE/EN/FR 2.0 37

H1_E_INST-leitungsspez
4 Electricalinstallation
Wiring to a host
77GND
8200 vector 8200 vector SPS/PC
E82ZAFCCxxx E82ZAFCCxxx
120
120
LO LO LO
HI HI HI
+++
E82ZAFC013
Fig. 2 Basic structure
System bus cable specification
Total length ≤300 m ≤1000 m
Cabletype LIYCY2x2x0.5mm
2
(twisted in pairs with shield)
CYPIMF2x2x0.5mm
2
(twisted in pairs with shield)
Cable resistance ≤80 Ω/km ≤80 Ω/km
Capacitance per unit length ≤130 nF/km ≤60 nF/km
Connection Pair 1 (white/brown):
Pair 2 (green/yellow):
LOW and HIGH
GND

4Electrical installation
Wiring according to EMC
EDK82ZAFCC-210 DE/EN/FR 2.0
38 
H2_EMV_Verdraht-EMV
Wiring according to EMC
Please observe the following for wiring according to EMC guidelines:
Note!
ƒSeparate control cables from motor cables.
ƒConnect the shields of the control or data cables as follows:
ÓAt both ends for cables with digital signals.
ƒPotential differences between thenodescanbeavoidedbyusingan
equalizing conductor with a large cross-section (reference: PE).
ƒPlease observe the further notes concerning EMC-compliant wiring given
in the Instructions of the basic devices.
General wiring information
1. Do not change the bus topology, i.e. do not use stubs.
2. Connect the bus terminating resistors of 120 Ωeach (scope of supply):
zbetween CAN-LOW and CAN-HIGH
zonly to the physical beginning and end of the cable
3. Use bus cable according to the specification on 37.
4. Do not exceed the permissible bus cable length (see 43).

Electrical installation
Connection terminals
4
EDK82ZAFCC-210 DE/EN/FR 2.0 39

H2 DatenAnschlKlemmen-steckerleiste
Connection terminals
Plug connector with double threaded connection
Possible connections rigid: 1.5 mm2(AWG 16)
flexible:
without wire end ferrule
1.5 mm2(AWG 16)
with wire end ferrule, without plastic sleeve
1.5 mm2(AWG 16)
with wire end ferrule, with plastic sleeve
1.5 mm2(AWG 16)
Tightening torque 0.5 ... 0.6 Nm (4.4 ... 5.3 lb-in)
Bare end 10 mm
Plug connector with spring connection
Possible connections rigid: 1.5 mm2(AWG 16)
flexible:
without wire end ferrule
1.5 mm2(AWG 16)
with wire end ferrule, without plastic sleeve
1.5 mm2(AWG 16)
with wire end ferrule, with plastic sleeve
0.5 mm2(AWG 20)
Bare end 9mm

4Electrical installation
Connection terminals
EDK82ZAFCC-210 DE/EN/FR 2.0
40 
H2 DatenAnschlKlemmen-steckerleiste
Use of plug connectorss
Stop!
Observe the following to prevent any damage to plug connectors and
contacts:
ƒOnly plug on / remove if the controller is disconnected from the mains !
ƒFirst wire the plug connectors, then connect them!
ƒAlso connect unassigned plug connectors.
Use of plug connector with spring connection
E82ZAFX013

Electrical installation
Terminal assignment
4
EDK82ZAFCC-210 DE/EN/FR 2.0 41

H2 BelegungAnschlKlemmen-INS_Klembesch
Terminal assignment
Supply via the internal voltage source (X3.3/20)
zX3.3/28, controller inhibit (CINH)
zX3.2/E1 and X3.2/E2, digital inputs
E1 E2
+20V
GND2
39 28
HI 720
CAN-GND
CAN-LOW
CAN-HIGH
7LO HI
X3.1 X3.2 X3.3
GND1
E82ZAFC335
Supply via an external voltage source
zX3.3/28, controller inhibit (CINH)
zX3.2/E1 and X3.2/E2, digital inputs
+
_
24V
ext.
E1 E2
+20V
GND2
39 28
HI 720
CAN-GND
CAN-LOW
CAN-HIGH
7LO HI
X3.1 X3.2 X3.3
GND1
E82ZAFC331
Minimum wiring required for operation

4Electrical installation
Terminal assignment
EDK82ZAFCC-210 DE/EN/FR 2.0
42 
H2 BelegungAnschlKlemmen-INS_Klembesch
X3.1/ Designation Function Level
7GND1 Reference potential 1
LO CAN-LOW System bus LOW (data line)
HI CAN-HIGH System bus HIGH (data line)
X3.2/ Designation Function Level
E1
Digital input
User-defined,
can alternatively be used as a frequency
input (see ”Technical data”)
0 = LOW (0 ... +3 V)
1 = HIGH (+12 ... +30 V)
Reference: GND2
E2 Digital input User-defined
X3.3/ Designation Function Level
7GND1 Reference potential 1
39 GND2 Reference potential 2 for controller
inhibit (CINH) at X3.3/28
28 CINH Controller inhibit zStart = HIGH (+12 V ... +30 V)
zStop = LOW (0 V ... +3 V)
20 DC voltage source for internal supply of
controller inhibit (CINH)
+20V(Ref:GND1)

Electrical installation
Bus cable length
4
EDK82ZAFCC-210 DE/EN/FR 2.0 43

H2 BusLeitgsLaenge-Leitungslaenge_3
Bus cable length
It is absolutely necessary to comply with the permissible cable lengths.
1. Check the compliance with the total cable length in Tab. 3.
The total cable length is defined by the baud rate.
Baud rate [kbps] Max. bus length [m]
20 3900
50 1500
125 590
250 250
500 80
Tab. 3 Total cable length
2. Check the compliance with the segment cable length in Tab. 4.
The segment cable length is defined by the cable cross-section used and the number of
nodes. Without any repeaters, the segment cable length corresponds to the total cable
length.
Node
Cable cross-section
0.25 mm20.5 mm20.75 mm21.0 mm2
2 240 m 430 m 650 m 940 m
5 230 m 420 m 640 m 920 m
10 230 m 410 m 620 m 900 m
20 210 m 390 m 580 m 850 m
32 200 m 360 m 550 m 800 m
63 170 m 310 m 470 m 690 m
Tab. 4 Segment cable length

4Electrical installation
Bus cable length
EDK82ZAFCC-210 DE/EN/FR 2.0
44 
H2 BusLeitgsLaenge-Leitungslaenge_3
3. Compare both values.
If the value given in Tab. 4 is smaller than the required total cable length given in Tab. 3,
repeaters must be used. Repeaters divide the total cable length into segments.
Note!
ƒPlease note the reduction of the total cable length due to the signal delay
of the repeater (see example 45).
ƒMixed operation
ÓWith mixed operation, different node devices are connected to the same
mains.
ÓIfthetotalcablelengthsofthenodes are different at the same baud
rate, the smaller value must be used to determine the max. cable
length.
Example: Selection help
Given:
zCable cross-section: 0.5 mm2(according to cable specification 37)
zNumber of nodes: 63
zRepeater: Lenze repeater, type 2176 (cable reduction: 30 m)
At maximum number of nodes (63) the following cable lengths/number of repeaters must
be complied with:
Baud rate [kbps] 20 50 125 250 500
Max. cable length [m] 3900 1500 590 250 80
Segment cable length [m] 310 310 310 250 80
Number of repeaters 13 5 1 - -

Electrical installation
Bus cable length
4
EDK82ZAFCC-210 DE/EN/FR 2.0 45

H2 BusLeitgsLaenge-Leitungslaenge_3
Check repeater application
Given:
zBaud rate: 125 kbps
zCable cross-section: 0.5 mm2
zNumber of nodes: 28
zCable length: 450 m
Procedure Cable length See
1. Total cable length at 125 kbps: 590 m Tab. 3
2. Segment cable length for 28 nodes and a cable cross-section
of 0.5 mm2:
360 m Tab. 4
3. Comparison: The value under point 2 is smaller than the required cable length of 450 m.
Conclusion
zIt is not possible to use a cable length of 450 m without using a repeater.
zAfter 360 m (point 2.), a repeater must be installed.
Result
zThe Lenze repeater type 2176 is used (cable reduction: 30 m)
zCalculation of the maximum cable length:
First segment: 360 m
Second segment: 360 m (according to Tab. 3) minus 30 m (cable reduction when a repeater is
used)
ÆMaximum possible cable length with repeater: 690 m.
ÆNow it is possible to use the required cable length.
Note!
The use of a further repeater is recommended as
ƒService interface
Advantage: Trouble-free connection during bus operation is possible.
ƒCalibration interface
Advantage: Calibration/programming unit remains electrically isolated.

5Commissioning
Before switching on
EDK82ZAFCC-210 DE/EN/FR 2.0
46 
H1inbet-bevor
5 Commissioning
Before switching on
Stop!
Please check the following before you switch on the controller together with
the function module connected to the system bus network CAN:
ƒCompleteness of the wiring, earth fault and short circuit.
ƒWhether the bus system is terminated at the physically first and last node
through the bus terminating resistor.

Commissioning
Baud rate and node address (node ID) setting
5
EDK82ZAFCC-210 DE/EN/FR 2.0 47

H2_NodeID+Baud_einstell-Hinweis_AdresBaud
Baud rate and node address (node ID) setting
ON
OFF
16
ON
27 3849
510
Note!
ƒIf S1 ... S6 ≠OFF, node address and baud rate are overwritten with the
corresponding values resulting from the switch positions.
ƒThere is no function assigned to the DIP switch S10.

5Commissioning
Address
EDK82ZAFCC-210 DE/EN/FR 2.0
48 
H2_Adress-Adress
Address
Setting the node address with the switches
For addressing the controllers, an unambiguous address (between 1 and 63) must be
assigned to every node in the CAN network with the switches S1 - S6. All values of the
switches in ON position added result in the node address wanted.
Switch S1 S2 S3 S4 S5 S6
Value 32 16 8 4 2 1
Example: Setting the node address 25
Setting OFF ON ON OFF OFF ON
Address = 25 0 16 8 0 0 1
Tip!
Please note that for accepting the changes, the controller must be switched off
andthenonagain.
Setting the node address via the CAN master
Precondition: Switches S1 ... S6 = OFF
1. Change the node address with C0350.
2. Acceptance of changes:
ƒ Switchthecontrolleroffandthenonagainor
ƒ Execute the command “Reset Node” (C0358 = 1) via the CAN master.
