Let's Go Aero BlackBox PRO Installation instructions

PAGE 1 OF 2
BlackBox PRO Two Bike Mounts
Custom Fit Accessory For Black Box PRO Enclosed Carrier
(Sold Separately #B02196)
Part No. H02240
For More Information & Accessories,
Visit our Website - www.LetsGoAero.com
Contact Us at 877-474-2376 or 719-630-3800
Email [email protected]
ASSEMBLY AND OPERATION
PARTS LIST
Qty Description
PRO BIKE MOUNT
5/16 X 18 HEXHEAD BOLT
PINS
RUBBER STRAPS
A
B
C
D
2
4
8
4
[Fg. 1]
[Fg. 2]
Starting on one side of the Carrier. Remove the existing two (2) outer
oor bolts as shown. [Fg. 1]
Set the existing washers and nuts aside; the bolt may be discarded.
Secure the PRO Bike Mount [A] into the carrier using the
supplied 5/16 x 18 Hexhead Bolts [B] and the existing washers
and Nuts removed in Step 1. [Fg. 2]
STEP 1:
STEP 2:
TOOL: METRIC ALLEN TOOL #5, 3mm SOCKET WRENCH
Copyright© 2021, Lets Go Aero, Inc., All rights reserved.
H02240-122021rev
Revision Date: 12/20/21
BUTTON HEAD
BOLT
A
B
B

PAGE 2 OF 2
To secure a bike, place each tire in-between two (2)
Pins [C] as shown.
Adjust the ‘Handles’ on the PRO Bike Mounts [A]
and move the Pins [C] so they rest as tightly as
possible against tire
sidewall.
Adjust foam bumpers
to protect bike tires.
Stretch Rubber
Straps [D] tightly to
the adjacent Pin [C]
to secure the tire as
shown. [Fg. 6 & 7]
[Fg. 3]
[Fg. 5]
[Fg. 6]
[Fg. 7]
Install one (1) Pin [C] into each
available location on the PRO Bike
Mount [A] by pulling the ‘Knobs’
out and inserting the Pins. [Fg. 3
& 4]
TIP: Pins should ‘click’ when fully
seated.
Add Rubber Straps [D] to two (2) of the Pegs as shown. [Fg. 5]
Repeat STEPS 1-4 on the opposite side of the carrier to install the second PRO Bike Mount [A].
STEP 3:
STEP 4:
STEP 5:
BIKE MOUNTING
C
[Fg. 4]
KNOB
HANDLE C
C
C
D
CA
D
