Let's Go Aero WingMan BVK093 User manual

User Manual
Description Qty
WingMan Base 1
Hat Brackets 2
Carriage Bolts & Hard-
ware sets
4
Wing with Pads 2
Wire Lock Pin 2
Double Toggles 4
Wheel Cradle Assembly
Wheel Cradle 4
Toggle Balls 4
Hair Pin Clip 4
Parts List
Assembly
Locate the WingMan base, the two Hat brackets and the four
5/16” carriage bolts, washers and locking nuts.
Position the WingMan base on the top surface of the tubing
mount and attach the two Hat brackets around the tubing and
onto the bottom of the WingMan base with the locking nuts and
washers.
Tighten the four bolt/nut combinations so that even amounts
of bolt thread appear below each of the locking nuts, as the
Hat Bracket compresses the WingMan base plate against the
top surface of the tubing. Tighten the nuts until the tabs on the
Hat bracket start to defect, or until 12 foot pounds of torque is
achieved.
Step 1: Attachment of WingMan Base Plate to 2” Square
Tube Surfaces
Wing with
Pads
Wheel Cradle
Assembly
Double
Toggles
WARNING
Periodically check the carriage bolt tension in the event any
loosening has occurred.
WingMan™ 2-Bike Carrier
Wire Lock Pins
Hat Brackets
Part No. BVK093
U.S. Patent No: D684917
BVK093 090815

Loading TIP: Load bicycle onto the carrier with the bicycle chain facing outward from the Wings and the inside pedal positioned
downward. This helps keep chain lube off the carrier, and provides open space in the lower, center portion of the “V” for the
inside pedal(s) to t easily. Load the second bike so its handle bars face in the opposite direction of the rst bicycle for clearance.
Securing Bicycles on Carrier
Set bike(s) on wheel cradles. Secure bike(s) to rack starting with the Wheel Toggles. Finish securing with the Double
Toggles.
Determine the approximate center-to-center distance
between the hubs of the bike wheels and attach the wheel
cradles to the Wings with the Hair Pin Clips to match this
distance.
Step 3: Attach Wheel Cradle AssemblyStep 2: Assemble Wings
Slide Wings into the Base pockets and secure the
Wings to the Base with the Wire Lock Pins.
Double Toggles TIP: The Double Toggles provide a number of ways to achieve Constant Tension™ of your bicycle to the carrier,
using one or both double toggles to capture the fork, chain stay, or seat stay. Loop the Toggle over the pedal, crank, or other
position on bicycle, allowing the elastic feature to pull the bike both down and inward against the Wing pads. The Constant Ten-
sion™ removes both “front to back” and “side-to-side” sway, rmly seating the bicycle during transit.
Operation
The WingMan™ V2 Base plate has a Toggle pocket (upwardly
angled groove) on each of the four corners for Double Toggle at-
tachments.
To prevent theft, the Base plate includes four holes for padlock lo-
cations for locking bicycles (bike locks not included with WingMan
Bike Rack).
WingMan™2-Bike Carrier

For assistance, contact Let’s Go Aero:
Mail: 2120 Naegele Road, Colorado Springs, CO 80904
Phone: [phone] or 719-630-3800
Email: [email protected].
Visit our website at www.LetsGoAero.com
WINGMAN V2 RACK GUIDELINES
The WingMan™ V2 bicycle carrier’s maximum load weight is 100 lbs. Do not exceed this carrying capacity.
Do not use this rack and accessories for purposes other than those for which they were designed. Failure to follow the
guidelines of the product’s instructions will void the warranty.
Keep bicycle tires away from vehicle’s hot exhaust ow by at least 6 inches.
Before Transit:
Attempt to shake the carrier to verify the carriage bolts are tight.
Verify that the safety pins are indeed locking the Wings to the Base Pockets.
Verify the Toggles are securing your bicycles wheels and frame to the carrier as explained earlier.
ONE-YEAR LIMITED WARRANTY
We warrant all LGA brand rack systems and its accessories manufactured by LGA during the time that an original retail
purchaser owns the product. This warranty terminates if a purchaser transfers the product to any other person.
Let’s Go Aero warrants this product to be free from defect in material and workmanship for one year (retain your sales receipt
for your records). Any product or part thereof found to be defective within that period will be replaced without charge provided
that: (1) the product was not misused; (2) no alterations or modications were made; (3) its failure was not a result of normal
wear expected in the use of the product; (4) the product or part is delivered, freight prepaid, to Let’s Go Aero.
Manufacturers only obligation shall be to replace such products or parts proved to be defective. A Return Merchandise
Authorization is required prior to return. Please contact Let’s Go Aero toll-free, at 877-464-2376 or 719-630-3800, or via email
to [email protected] to get an RMA number.
No warranty is given for LGA products purchased outside of the United States and Canada.
Product Registration:
To expedite any produce service needs and streamline the
warranty process if you ever had a claim, we encourage
your to register you product with us.
Register online at www.LetsGoAero.com/register
WingMan™2-Bike Carrier
Learn about our line of trailers, hitch carriers. and other cargo
management solutions at www.LetsGoAero.com
U.S. Patent No: D684917
Copyright © 2013 Let’s Go Aero, Inc.
