Let's Go Aero HideOut Package H01564 User manual

HideOut Package™
Covered Bicycle Storage and Transport Accessory System
Part No. H01564
PARTS LIST
QTY. DESCRIPTION
A1 U-TUBE
B2 HORIZONTAL LEG
C4 LOCK NUT
D4 HEX BOLT
E2 WIRE LOCK PIN
F 4 SMALL COTTER PIN
G2 WING WITH PADS
H 4 WHEEL CRADLE
J 4 WHEEL STOPS
K 4 RUBBER STRAPS
L4 FOAM CUSHIONS
M2 RATCHET STRAP
1/2” (13mm) WRENCH
REQUIRED TOOLS:
A
B
L
G
H
K
J
F
C
For More Information & Accessories,
Visit our Website - www.LetsGoAero.com
Contact Us at 877-474-2376 or 719-630-3800 | Email [email protected]
E
M
D
HOMANUAL 021317

STEP 2
STEP 1
Attach Adjustable Rubber Straps [N]
to the Wheel Cradles [L] and Wheel
Stops [M] With the hammerhead
end facing away Peg. [DETAIL 5]
To attach Cradle Assembly [L] to
wing [K], remove small cotter pin
[J], insert through hole, and reattach
small cotter pin [J] as shown in
[DETAIL 6].
NOTE: Pad position is not xed.
You can slide pads on wing [K] to
expose additional holes. Where
you choose to attach each cradle
assembly will depend on the size
and shape of the bicycle(s) to be
transported. Attach one cradle assembly to each side of each wing [K], two
cradle assemblies per wing.
Loosen and slip Wheel Stops [M] onto the Wing from below the Rubber
Bummers with each Peg matching the direction of the Cradles Assembly as
Shown [DETAIL 7].
J
DETAIL 7
WARNING:
ALWAYS MAKE SURE EACH
CRADLE ASSEMBLY IS HELD IN
PLACE WITH A SMALL COTTER PIN
[J] AS SHOWN IN DETAIL 6.
K
H
DETAIL 5
K
H
G
PADS
J
F
KFH
DETAIL 6 K
Connect the U-Tube [A] to the
Horizontal Legs using 13 mm Hex
Bolts [D] and 13 mm Lock Nuts [C]
as shown [Detail 1].

STEP 3
Install wing [D] onto V-Base [A]
using wire lock pin [E].
Open wire lock pin [E] as shown
in DETAIL 7. Insert wire lock pin
[E] through hole and out the other
side. (You may need to slide
wing [D] up slightly to align the
holes). Close wire lock pin [E] by
positioning the loop end of the
wire over the pin and allowing it to
spring back against the wing [D] as
shown in DETAIL 8.
Install the remaining three wings
[D] using the remaining wire lock
pins [E].
DETAIL 7
E
G
A
E
GDETAIL 8

CARRIER INSTALLATION [CARGO RACK NOT INCLUDED]
DETAIL 9
DETAIL 11
DETAIL 10
DETAIL 12
STEP 1: Install Foam
Cushions [L] on ends of
Horizontal Legs [B] as
shown. [DETAIL 9 & 10]
STEP 2: Center and
place the BikeTree inside
the Carrier with the
Horizontal Legs [B] running
perpendicular to the length
of the carrier. [DETAIL 11 &
12]
STEP 3: Remove the End Cap and the highest
Wheel Cradle located at the top of each Wing. On
the inside of the Wing, slip the looped end of the
Ratchet Strap [M] around the Wheel Cradle and
reconnect the Cradle with Cotter Pin. Reinstall
End Cap over Ratchet Strap. Complete for both
Wings. [DETAIL 13 & 14]
STEP 4: Connect the
Quick Link End of the
Ratchet Strap to the
Carrier’s provided tie down
position. Fully tighten
Ratchet Straps [M] evenly
on both sides to remove
shifting. [DETAIL 15 & 16]
DETAIL 13
DETAIL 15 DETAIL 16
DETAIL 14
B
M
M
H
L

One cradle assembly should be attached
to each side of each Wing as instructed in
STEP 4.
Lift the bicycle and hang it on the
BikeTree rack with the drive-train of the
bicycle facing away from the rack for a
closer t. Secure each wheel to cradles
as shown [DETAILS 17]. Loosen and
adjust Wheel Stops until they are ush
and resting against the bottom of the tire
[DETAIL 18]. [Removing the Wing and
rearranging the Wheel Stops and Wheel
Cradles may be necessary depending
on your bicycles size and style.] Once
the Cradles and Wheel Stops have been
t to size, stretch the adjustable Rubber
Straps over the tire and reconnect to the
hole position that is one hole tighter than
necessary with the wheel sandwiched at the end of the Peg away from the Wing [DETAIL 19].
Note: Bike Tire can be adjusted in and out to remove contact with the BikeTree Rack. The pads should be positioned as
necessary for added protection to the nish of the bicycle.
To attach a second bicycle follow the same procedure using the two remaining cradles and wheel stops attached to the
back side of the wings. Position the second bicycle with the handlebars towards the back of the rst bicycle.
ATTACHMENT OF BICYCLES
RUBBER
STRAP
CRADLE
BICYCLE
WHEEL
DETAIL 17
DETAIL 18 DETAIL 19
CRADLE
RUBBER
STRAP
RUBBER
STRAP
RUBBER
STRAP
BICYCLE
WHEEL
WHEEL
STOP
WARNING:
IMPORTANT FOR SAFETY! AFTER ATTACHING BIKETREE
AND BICYCLE(S), BUT BEFORE DRIVING THE VEHICLE,
DOUBLE CHECK ALL POINTS OF ATTACHMENT TO BE SURE
THAT THEY ARE TIGHT AND SECURE!

Assembly and Installation:
Unfold your BossHog HideOut Cover and drape over top of your BossHog Carrier, assembled BikeTree, and
customer supplied bicycles. Fit the thick Waist-Band of the HideOut Cover snuggly over the corners of the
carrier. Locate the adjustable Release Buckle underneath the velcro Storm Flaps and tighten the Waist-Band
until taut around the carrier. Once the Waist-Band is secured, tighten and connect the 2nd Horizontal Support
Strap located above the Waist-Band. Pull the Vertical Support Straps around the underside of the carrier and
back to meet at the top. Connect the Release Buckle and pull tight to secure your HideOut Cover and cargo to
the carrier.
Unfold the included DragNet and drape over top the secured HideOut Cover. Fasten all Molded Clips by
securing and evenly spacing them to anchor points located on the underside of the carrier.
Daily Operation:
Remove your DragNet and completely loosen and disconnect all Release Buckles except for the Waist-Band.
Locate the Coiled Zipper spanning along the top of the HideOut Cover and unzip. Remove or store any
needed cargo or Bicycles, re-zip the HideOut Cover, and reconnect and tighten all release buckles. Reconnect
DragNet.
HideOut Cover & DragNet devices are a weather-
resistant (not water-proof) cargo protectant
system, and not a cargo restraint.
Be sure to remove your DragNet and
completely loosen and disconnect all
HideOut Cover Release Buckles rst before
removing the Cover off your cargo carrier to
avoid damage to your product.
WARNING WARNING
PARTS LIST
Qty Description
1 HideOut Cover
1 DragNet Cargo Netting With Clips
Always check that HideOut Cover, DragNet & stored cargo are fully secured to the carrier before
transit to avoid loss or damage to your product & cargo. Multiple tie-down and strap positions are
located along the BossHog Cargo Carrier for supplemental ratchet and tie-down restraints when
necessary.
WARNING
HIDEOUT COVER & DRAGNET INSTALLATION

ONE YEAR LIMITED WARRANTY
Let’s Go Aero warrants this product to be free from defect in material and workmanship for one year (retain your sales re-
ceipt for your records). Any product or part thereof found to be defective within that period will be replaced without charge
provided that: (1) the product was not misused; (2) no alterations or modications were made; (3) its failure was not a
result of normal wear expected in the use of the product; (4) the product or part is delivered, freight prepaid, to Let’s Go
Aero. Manufacturers only obligation shall be to replace such products or parts proved to be defective. A Return Merchan-
dise Authorization is required prior to return. Please contact Let’s Go Aero toll-free, at 877-464-2376 or 719-630-3800, or
via email to [email protected] to get an RMA number. This warranty terminates if a purchaser transfers the product
to any other person. No warranty is given for LGA products purchased outside of the United States and Canada.
To register your product, visit the Let’s Go Aero website at www.LetsGoAero.com
For assistance with this product, please contact Let’s Go Aero:
4474 Barnes Rd, Colorado Springs, CO 80917
Phone: [phone] or 719-630-3800
Email: [email protected]
To learn more about our line of bicycle carriers for vehicle, home storage, and accessory options for carrying fat bikes,
snowboards/skis, and more, be sure to visit our website: www.LetsGoAero.com
U.S. Patent No: D717716; D717717; D684917; 8,889,456; D722289; Patents Pending
