Ceiling Mount PoE
Wireless Access Point WAP-3101
Discreet and Powerful
The LevelOne Ceiling Mount PoE Wireless
Access Point delivers fast wireless speeds to your
home or ofce network. Following the 802.11g
standard, you can take advantage of Super-G
108 Mbps throughput for all of your data, voice
and video streaming needs.
Greater Coverage and Easy Installation
Mostly access points are placed into the ceiling,
restricting the performance of wireless signal.
WAP-3101 is more exible than others as it
resembles a smoke detector. It is strategically
mounted to maximize the reach of the 4
dBi antenna. This way the signal remains
unobstructed, offering solid coverage of the
entire room. With the easy to install mounting
kit included, you will have this Access Point
plugged in and ready to go in under 10 minutes.
Advanced Features
WAP-3101 offers WEP, WPA, WPA2 for advanced
wireless security options. And with QoS (WMM),
you will be able to prioritize the most important
trafc for your specic needs. Moreover,
WAP-3101 supports multi-SSID (up to 4 SSIDs)
which manager could assign different polices
and functions for each SSID through a single
access point.
Key Features
- Complies with the IEEE 802.11b/g 2.4GHz
specication
- Compliants with IEEEP 802.3af PoE PD
(Powered Device) standard
- Supports WEP, WPA, WPA2 and IEEE 802.1x for
high level security
- Browser-based interface conguration and
management
- Supports QoS (WMM) to enhance user
performance and density
- Supports Multi-SSID function (4 SSID) in AP
mode
- Embedded 2 x 4dBi Directional Antennas in
MIMO Conguration
WNC-0306USB
108Mbps Wireless USB Adapter
Related Prodoucts
1. LED Indicators
2. Reset Button
3. Power Port
4. LAN Interface
PIS-3000
Normal Power PoE Kit
H/W Version: 1
1 3 42

Wireless Bridges/Access Points
www.level1.com
I
one world_one brand_one level_
Technical Specication
Product Diagram
Internet
WAP-3101
ADSL + Router
PoE Switch
Standards
Super G, IEEE 802.11g, IEEE 802.11b, 802.3af PoE, 802.1x
Network Interface
1x10/100Mbps LAN
Radio Operation
Data Transfer Rate
Super G: up to 108Mbps
802.11g: up to 54Mbps
802.11b: up to 11Mbps
Modulation
802.11g: OFDM
802.11b: CCK, QPSK, BPSK
Media Access Control
CSMA/CA with ACK
Frequency Band
2.4GHz ~ 2.484GHz
Number of Channels
Channel 1 ~ 11 North America
Channel 1 ~ 13 Europe
Channel 1~14 Japan
Antenna
Built-in 2 x 4dBi Directional Antennas
Peak Gain = 4dBi
Receiver Sensitivity(Typical)
802.11g: -74dBm @ 108Mbps
-92dBm @ 6Mbps
802.11b: -89dBm @ 11Mbps
-97dBm @ 1Mbps
Transmitter Output Power(Typical)
802.11b/g: 16 ~ 18dBm
Operation Mode
- AP Mode
- Repeater Mode
- WDS repeater Mode
Network Security
- WEP-64/128 bit
- WPA
- WPA-PSK
- WPA2
- WPA2-PSK
- 802.1x Authenticator
- Disable SSID Broadcast
- MAC address ltering
Management
- Web-based conguration
- OS Supported: Windows 2000/XP/Vista
- SNMP v1/v2c
Other Features
-Supports Multiple SSID (up to 4 SSIDs)
-Supports WMM
Physical Specications
LED
-Power
-LAN
-WLAN
Power Adapter
DC 12V, 1A
Temperature
Operating: 0 ~ 45°C
Storage: -20 ~ 70°C
Humidity
5% ~ 95% (Non-condensing)
Dimensions
120mm(diameter) x 50mm(H)
Ceiling Mountable
Certications
CE, FCC
WAP-3101
SSID1 SSID2
10/100Mbps
10/100Mbps
Excellent Range
and Coverage
Repeater
mode
Hotel
Ethernet Cable (RJ 45)
Phone Line (RJ 11)
PoE

V1.0
All mentioned brand names are registered trademarks and property of their owners. Technical specications are subject to change without notice.
© Copyright 2009 Digital Data Communications GmbH. All Rights Reserved.
Order Information WAP-3101: Ceiling Mount PoE Wireless Access Point
Package Content WAP-3101
Power Adapter
LAN Cable
Quick Installation Guide
CD Manual
Radiation Pattern
Azimuth Elevation
