OWNER’S MANUAL
AIR CONDITIONER
Please read this manual carefully before operating
your set and retain it for future reference.
www.lg.com
TYPE : WALL MOUNTED
P/NO : MFL67482001
ENGLISH ITALIANO ESPAÑOL FRANCAIS DEUTSCH
ΕΛΛΗΝΙΚΆ
PORTUGUESE
NEDERLANDS
POLSKI MAGYAR

2TIPS FOR SAVING ENERGY
ENGLISH
TIPS FOR SAVING ENERGY
Here are some tips that will help you minimize the power consumption when you use the air
conditioner. You can use your air conditioner more efficiently by referring to the instructions
below:
• Do not cool excessively indoors. This may be harmful for your health and may consume more
electricity.
• Block sunlight with blinds or curtains while you are operating the air conditioner.
• Keep doors or windows closed tightly while you are operating the air conditioner.
• Adjust the direction of the air flow vertically or horizontally to circulate indoor air.
• Speed up the fan to cool or warm indoor air quickly, in a short period of time.
• Open windows regularly for ventilation as the indoor air quality may deteriorate if the air con-
ditioner is used for many hours.
• Clean the air filter once every 2 weeks. Dust and impurities collected in the air filter may block
the air flow or weaken the cooling / dehumidifying functions.
For your records
Staple your receipt to this page in case you need it to prove the date of purchase or for warranty
purposes. Write the model number and the serial number here:
Model number :
Serial number :
You can find them on a label on the side of each unit.
Dealer’s name :
Date of purchase :

SAFETY PRECAUTIONS
IMPORTANT SAFETY INSTRUCTIONS
READ ALL INSTRUCTIONS BEFORE USING THE APPLIANCE.
Always comply with the following precautions to avoid dangerous situations and ensure peak
performance of your product
WARNING
It can result in serious injury or death when the directions are ignored
CAUTION
It can result in minor injury or product damage when the directions are ignored
WARNING
• Installation or repairs made by unqualified persons can result in hazards to you and others.
• Installation work must be performed in accordance with the National Electric Code by quali-
fied and authorized personnel only.
• The information contained in the manual is intended for use by a qualified service technician
familiar with safety procedures and equipped with the proper tools and test instruments.
• Failure to carefully read and follow all instructions in this manual can result in equipment mal-
function, property damage, personal injury and/or death.
Installation
• Do not use a defective or underrated circuit breaker. Use the correctly rated breaker and fuse.
There is risk of fire or electric shock.
• For electrical work, contact the dealer, seller, a qualified electrician, or an Authorized Service
Center. Do not disassemble or repair the product by yourself. There is risk of fire or electric
shock.
• Always ground the product as per the wiring diagram. Do not connect the ground wire to gas
or water pipes lightening rod or telephone ground wire. There is risk of fire or electric shock.
• Install the panel and the cover of control box securely. There is risk of fire or electric shock
due to dust , water etc.
• Use the correctly rated breaker or fuse. There is risk of fire or electric shock.
• Do not modify or extend the power cable. If the power cable or cord has scrathes or skin
peeled off or deteriorated then it must be replaced. There is risk of fire or electric shock.
• For installation, removal or reinstall , always contact the dealer or an Authorized Service Cen-
ter. There is risk of fire, electric shock, explosion, or injury.
• Do not install the product on a defective installation stand. Be sure that the installation area
does not deteriorate with age. It may cause product to fall.
• Never install the outdoor unit on a moving base or a place from where it can fall down.
The falling outdoor unit can cause damage or injury or even death of a person.
• In outdoor unit the step-up capacitor supplies high voltage electricity to the electrical compo-
nents. Be sure to discharge the capacitor completely before conducting the repair work.
An charged capacitor can cause electrical shock.
• When installing the unit, use the installation kit provided with the product. Otherwise the unit
may fall and cause severe injury.
• Indoor/outdoor wiring connections must be secured tightly and the cable should be routed
properly so that there is no force pulling the cable from the connection terminals. Improper or
loose connections can cause heat generation or fire.
!
!
!
3
ENGLISH

4SAFETY PRECAUTIONS
ENGLISH
• Safely dispose off the packing materials. Like screws, nails, batteries, broken things etc after
installation or svc and then tear away and throw away the plastic packaging bags. Children
may play with them and cause injury.
• Be sure to check the refrigerant to be used. Please read the label on the product. Incorrect re-
frigerant used can prevent the normal operation of the unit.
Operation
• When the product is soaked (flooded or submerged) in water , contact an Authorized Service Center
for repair before using it again. There is risk of fire or eletric shock.
• Be sure to use only those parts which are listed in the svc parts list. Never attempt to modify the
equipment. The use of inappropriate parts can cause an electrical shock, excessive heat generation
or fire.
• Do not touch , operate, or repair the product with wet hands. Hold the plug by hand when taking
out. There is risk of electric shock or fire.
• Do not place a heater or other heating appliances near the power cable. There is risk of fire and elec-
tric shock.
• Do not allow water to run into electric parts. Install the unit away from water sources. There is risk
of fire, failure of the product, or electric shock.
• Do not store or use or even allow flammable gas or combustibles near the product. There is risk of
fire.
• Do not use the product in a tightly closed space for a long time. Perform ventilation regularly. Oxy-
gen deficiency could occur and hence harm your health.
• Do not open the front grille of the product during operation. (Do not touch the electrostatic filter, if
the unit is so equipped.) There is risk of physical injury, electric shock, or product failure.
• If strange sound, smell or smoke comes from product.Immediately turn the breaker off or discon-
nect the power supply cable. There is risk of electric shock or fire.
• Ventilate the product room from time to time when operating it together with a stove, or heating el-
ement etc. Oxygen deficiency can occur and hence harm your health.
• When the product is not to be used for a long time, disconnect the power supply plug or turn off
the breaker. There is risk of product damage or failure, or unintended operation.
• Take care to ensure that nobody especially kids could step on or fall onto the outdoor unit. This
could result in personal injury and product damage.
• Take care to ensure that power cable could not be pulled out or damaged during operation. There is
risk of fire or electric shock.
• Do not place ANYTHING on the power cable. There is risk of fire or electric shock.
• When flammable gas leaks, turn off the gas and open a window for ventilation befor turning on the
product. Do not use the telephone or turn switches on or off. There is risk of explosion or fire.
• Make sure to ventilate sufficiently when this air conditioner and a heating appliance such as a heater
are used simultaneously. Failure to do so may result in fire, serious injury, or product failure.
CAUTION
Installation
• Two or more people must lift and transport the product. Avoid personal injury.
• Do not install the product where it will be exposed to sea wind (salt spray) directly. It may cause cor-
rosion on the product.
• Install the drain hose to ensure that the condensed water is drained away properly. A bad connec-
tion may cause water leakage.
• Keep level even when installing the product. To avoid vibration or noise.
!

SAFETY PRECAUTIONS
• Do not install the product where the noise or hot air from the outdoor unit could damage or disturb
the neighborhoods. It may cause a problem for your neighbors and hence dispute.
• Always check for gas (refrigerant) leakage after installation or repair of product. Low refrigerant lev-
els may cause failure of product.
Operation
• Do not use the product for special purposes, such as preserving foods, works of art, etc. It is a con-
sumer air conditioner, not a precision refrigeration system. There is risk of damage or loss of prop-
erty.
• Do not block the inlet or outlet of air flow. It may cause product failure.
• Use a soft cloth to clean. Do not use harsh detergents, solvents or splashing water etc. There is risk
of fire, electric shock, or damage to the plastic parts of the product.
• Do not touch the metal parts of the product when removing the air filter. There is risk of personal in-
jury.
• Do not step on or put anyting on the product. (outdoor units) There is risk of personal injury and fail-
ure of product.
• Always insert the filter securely after cleaning. Clean the filter every two weeks or more often if
necessary. A dirty filter reduces the efficiency.
• Do not insert hands or other objects through the air inlet or outlet while the product is operating.
There are sharp and moving parts that could cause personal injury.
• Be cautious when unpacking and installing the product. Sharp edges could cause injury.
• If the refrigerant gas leaks during the repair, do not touch the leakaing refrigerant gas. The refriger-
nat gas can cause frostbite (cold burn).
• Do not tilt the unit when removing or uninstalling it. The condensed water inside can spill.
• Do not mix air or gas other than the specified refrigerant used in the system. If air enters the refrig-
erant system, an excessively high pressure results, causing equipment damage or injury.
• If the refrigerant gas leaks during the installation, ventilate the area immediately. Otherwise it can be
harmfull for your health.
• Dismantling the unit, treatment of the refrigerant oil and eventual parts should be done in accor-
dance with local and national standards.
• Replace the all batteries in the remote control with new ones of the same type. Do not mix old and
new batteries or different types of batteries. There is risk of fire or product failure.
• Do not recharge or disassemble the batteries. Do not dispose off batteries in a fire. They may burn
or explode.
• If the liquid from the batteries gets onto your skin or clothes, wash it well with clean water. Do not
use the remote if the batteries have leaked. The chemicals in batteries could cause burns or other
health hazards.
• If you swallow the battery fluid from a leak, wash out the inside of your mouth thoroughly and then
consult a doctor. Failure to do so may result in serious health complications.
• Do not let the air conditioner run for a long time when the humidity is very high and a door or a win-
dow is left open. Moisture may condense and wet or damage furniture.
• Do not expose your skin or kids or plants to the cool or hot air draft. This could harm to your health.
• Do not drink the water drained from the product. It is not sanitary and could cause serious health is-
sues.
• Use a firm stool or ladder when cleaning, maintaining or repairing the product at an height. Be care-
ful and avoid personal injury.
5
ENGLISH

TABLE OF CONTENTS
2 TIPS FOR SAVING ENERGY
3IMPORTANT SAFETY
INSTRUCTIONS
7BEFORE USE
7Components
8Using the remote control
10 - Inserting batteries
10 - Installing the remote control holder
11 BASIC FUNCTIONS
11 Cooling your room
11 Heating your room
11 Removing humidity
12 Airing your room
12 Adjusting the fan speed
12 Adjusting the air flow direction
12 Setting the timer
12 - Setting the current time
13 - Turning on the air conditioner
automatically at a set time
13 - Turning off the air conditioner
automatically at a set time
13 - Canceling the timer setting
13 - Setting sleep mode
14 ADVANCED FUNCTIONS
14 Changing room temperature quickly
14 Indoor air purification
14 - Auto Clean operation
15 Plasma Purification operation
15 Auto operation
16 Energy saving cooling mode
16 Display screen brightness
16 Operating the air conditioner without the
remote control
17 Restarting the air conditioner
automatically
18 MAINTENANCE
19 Cleaning the air filter
19 Cleaning the anti-allergy filter and triple
filter
19 Cleaning the plasma filter
20 TROUBLESHOOTING
20 Self-diagnosis function
20 Before requesting service
TABLE OF CONTENTS
6
ENGLISH

BEFORE USE
Components
Anti-allergy filter
Operation lamp Signal Receiver
ON/OFF button
Air intake
Plasma filter
(option)
Air filter
Front grille
Vertical louver
Air outlet Horizontal vane
Horizontal vane
Horizontal vane
Triple filter
Front grille
Air filter
Air inlet
On/ Off button
Signal receiver
Operation lamp
Air outlet
Air deflector
(Vertical louver & Horizontal vane)
NOTE
!
The number of operation lamps and their locations may vary, depending on the model of the
air conditioner.
7
BEFORE USE
ENGLISH
Indoor unit
* The feature can be changed according a type of model.

Using the remote control
You can operate the air conditioner more conveniently with the remote control. You will find the
buttons for the additional functions under the cover of the remote control.
Wireless remote control
Display
screen
Control
panel
* Some functions may not be supported, depending on the
model.
BEFORE USE
8
ENGLISH
Control
panel
Display
screen Description
aF
Plasma button*:Plasmaster filter purifies
the air by removing mites, micro dust and
pet fur. Plasmaster Ionizer sterilize the aerial
bacteria and other harmful substances.
l
=
Sleep mode auto button*: Sets the
sleep mode auto operation.
e
y
Temperature adjustment buttons: Ad-
justs the room temperature when cool-
ing and heating.
d-On/Off button: Turns the power on/off.
g
7 v
Indoor fan speed button: Adjusts the
fan speed.
fAC
DBE
Operation mode selection button*: Se-
lects the operation mode.
Cooling operation (A) / Auto operation
(C) / Dehumidifying operation (D) /
Heating operation (B) / Air circulation
(E)
hNJet cooling/heating button*: Warms up
or cools down the indoor temperature
within a short period of time.
ij : ; Air flow direction button: Adjusts the air
flow direction vertically or horizontally.
kS
Temperature display button: Displays
the room temperature. Press key and
hold it for longer than 5 second.
Display change °C/°F
mn
z
Timer button: Sets the current time and
the Start/end time.
c
b
uJG
Navigation and functions button*:
Adjusts the time and sets the special
functions.
J: Auto clean / G: Operates energy
saving cooling / LIGHT: Adjusts the
brightness of the indoor unit display
p-Set/clear button: Sets or cancels func-
tions.
r-Reset button: Resets the air condi-
tioner settings.

BEFORE USE 9
ENGLISH
Wireless remote control
Display
screen
Control
panel
* Some functions may not be supported, depending on the
model.
Control
panel
Display
screen Description
/E
AIR CIRCULATION BUTTON
Used to circulate the room air without cooling
or heating.
l
=
Sleep mode auto button*: Sets the
sleep mode auto operation.
e
y
Temperature adjustment buttons: Ad-
justs the room temperature when cool-
ing and heating.
d-On/Off button: Turns the power on/off.
g
7 v
Indoor fan speed button: Adjusts the
fan speed.
fAC
DB
Operation mode selection button*: Se-
lects the operation mode.
Cooling operation (A) / Auto operation
or auto changeover (C) / Dehumidify-
ing operation (D) / Heating operation
(B)
hNJet cooling/heating button*: Warms up
or cools down the indoor temperature
within a short period of time.
i:
Air flow direction button*: Adjusts the air
flow direction vertically.
kS
Temperature display button: Displays the
room temperature. Also changes unit
from °C to °F if pressed for 5 seconds.
mn
z
Timer button: Sets the current time and
the start / end time.
c
b
|JG
Navigation and functions button*: Ad-
justs the time and sets the special
functions.
J: Auto clean / G: Operates energy
saving cooling / LIGHT : Adjusts the
brightness of the indoor unit display
p-Set/clear button: Sets or cancels func-
tions.
r-Reset button: Resets the air condi-
tioner settings.

10 BEFORE USE
ENGLISH
Inserting batteries
Insert batteries before using the remote
control. The battery type used is AAA (1.5 V).
1 Remove the battery cover.
2Insert the new batteries and make sure
that the + and - terminals of the batteries
are installed correctly.
3Reattach the battery cover.
Installing the remote control holder
Install the holder where there is no direct sun-
light to protect the remote control.
1Choose a safe and easily-accessible place.
2Fix the holder by fastening the 2 screws
firmly with a screwdriver.
3Slide the remote control into the holder.
Point the remote control towards the signal
receiver at the bottom of the air conditioner to
operate it.
NOTE
!
If the display screen of the remote control
starts to fade, replace the batteries.
NOTE
!
• The remote control may operate other
electronic devices if pointed towards
them. Make sure to point the remote
control towards the signal receiver of
the air conditioner.
• For proper operation, use a soft cloth to
clean the signal transmitter and receiver.
Operating method

BASIC FUNCTIONS 11
ENGLISH
BASIC FUNCTIONS
Cooling your room
(Cooling operation)
1 Press dto turn on the power.
2 Press frepeatedly to select the cooling
operation.
- Ais displayed on the display screen.
3Press uor vto set the desired tempera-
ture.
- The temperature range is 18°C - 30°C.
Heating your room
(Heating operation)
1 Press dto turn on the power.
2 Press frepeatedly to select the heating
operation.
- Bis displayed on the display screen.
3 Press uor vto set the desired tempera-
ture.
- The temperature range is 16°C - 30°C
Removing humidity
(Dehumidifying operation)
This mode removes excess moisture from an
environment with high humidity or in the rainy
season, in order to prevent mold from setting
in. This mode adjusts the room temperature
and the fan speed automatically to maintain
the optimal level of humidity.
1 Press dto turn on the power.
2 Press frepeatedly to select the dehu-
midifying operation.
- Dis displayed on the display screen.
NOTE
!
• In this mode you cannot adjust the room
temperature, as it is adjusted automati-
cally. Also, the room temperature is not
displayed on the display screen.
NOTE
!
Cooling-only models do not support this
function.

12 BASIC FUNCTIONS
ENGLISH
Airing your room
(Air Circulation operation)
This mode only circulates the indoor air
without changing the room temperature.
1 Press dto turn on the power.
2 Press frepeatedly to select the air circu-
lation operation.
Or press /to select the air circulation op-
eration.
- Eis displayed on the display screen.
3Press gto adjust the fan speed.
Adjusting the fan speed
1Press grepeatedly to adjust the fan
speed.
- Select 5if you want natural air.
The fan speed adjusts automatically.
Adjusting the air flow direc-
tion
1 To adjust the direction of the air flow verti-
cally, press irepeatedly and select the
desired direction.
- Select :to adjust the direction of the air
flow automatically.
2 To adjust the direction of the air flow hori-
zontally, press jrepeatedly and select
the desired direction.
- Select Ito adjust the direction of the
air flow automatically.
Setting the timer
You can use the timer function to save energy
and to use the air conditioner more efficiently.
Setting the current time
1Press pand hold it for longer than 3 sec-
onds.
- The AM/PM icon flickers at the bottom of
the display screen.
NOTE
!
• Adjusting the air flow direction horizon-
tally may not be supported, depending
on the model.
• Adjusting the air deflector arbitrarily may
cause product failure.
• If you restart the air conditioner, it starts
to operate with the previously set direc-
tion of air flow, so the air deflector may
not match the icon displayed on the re-
mote control. When this occurs, press
ior jto adjust the direction of the
air flow again.

BASIC FUNCTIONS 13
ENGLISH
2Press o or q to select the minutes.
3Press pto finish.
Turning on the air conditioner auto-
matically at a set time
1Press m.
- The icon below flickers at the bottom of
the display screen.
2Press o or q to select the minutes.
3Press pto finish.
Turning off the air conditioner auto-
matically at a set time
1Press n.
- The icon below flickers at the bottom of
the display screen.
2Press o or q to select the minutes.
3Press pto finish.
Canceling the timer setting
1Press m.
2Press mor nto select the timer setting
to cancel.
3Press p.
- To cancel all timer settings, press p.
Setting sleep mode
Use the sleep mode to turn off the air condi-
tioner automatically when you go to sleep.
1Press dto turn on the power.
2Press l
3Press o or q to select the hour
(up to 7 hours).
4Press pto finish.
- Tis displayed on the display screen in
sleep mode.
NOTE
!
In the Cooling and Dehumidifying modes,
the temperature increases by 1°C after 30
minutes and by a further 1°C after another
30 minutes for a more comfortable sleep.
The temperature increases with up to 2°C
from the preset temperature.

14 ADVANCED FUNCTIONS
ENGLISH
ADVANCED FUNCTIONS
The air conditioner offers some additional ad-
vanced functions.
Changing room temperature
quickly
(Jet Cool/Heat operation)
This mode allows you to cool indoor air quickly
in summer or warm it quickly in winter.
1Press dto turn on the power.
2Press h.
- In jet cooling mode, strong air blows out
at a temperature of 18°C for 30 minutes.
- In jet heating mode, strong air blows out
at a temperature of 30°C for 30 minutes.
Indoor air purification
Auto Clean operation
In the cooling and dehumidifying operations,
moisture is generated inside the indoor unit.
Use the auto cleaning function to remove
such moisture.
1Press dto turn on the power.
2Press c.
- Jis displayed on the display screen.
- If you turn off the power, the fan oper-
ates for 30 minutes and cleans the inside
of the indoor unit.
NOTE
!
• In Air Circulation, Auto, or Auto
Changeover mode, this function cannot
be used.
• This function may not be supported, de-
pending on the model.
NOTE
!
Some buttons cannot be used while the
auto cleaning function is in operation.

ADVANCED FUNCTIONS 15
ENGLISH
Plasma Purification operation
The plasma filter developed by LG removes
microscopic contaminants from the intake air
completely to supply clean and fresh air.
1Press dto turn on the power.
2Press a.
- Fis displayed on the display screen.
Auto operation
(Artificial intelligence)
You can set desired temperature and indoor
fan speed. Setting Temp. Range : 18~30℃
1Press dto turn on the power.
2Press frepeatedly to select auto opera-
tion.
NOTE
!
• You can use this function by pressing
awithout turning the air conditioner
on.
• Both the plasma lamp and the cooling
lamp light up while plasma purification is
in operation.
• This function may not be supported, de-
pending on the model.
NOTE
!
• In this mode, you can set the air deflec-
tor to rotate automatically.
• This function may not be supported, de-
pending on the model.

16 ADVANCED FUNCTIONS
ENGLISH
Energy saving cooling mode
This mode minimizes power consumption dur-
ing cooling and increases the set temperature
to the optimal level for a more comfortable en-
vironment.
1Press dto turn the power on.
2Press frepeatedly to select the cooling
operation.
3Press b.
- Gis displayed on the display screen.
Display screen brightness
You can adjust the brightness of the indoor
unit display screen.
1Press uor |repeatedly to set the
brightness to the desired level.
Operating the air conditioner
without the remote control
You can use the On/Off button of the indoor
unit to operate the air conditioner when the
remote control is unavailable. However, the
fan speed is set to high.
1Open the front cover.
- Lift up both sides of the cover slightly.
2Press the On/Off button.
- For cooling and heating models, the oper-
ation mode changes, depending on the
operation mode of outdoor unit.
NOTE
!
This function may not be supported,
depending on the model.
NOTE
!
This function may not be supported,
depending on the model.
ON/OFF
button
* The feature can be changed according a
type of model.
* The feature can be changed according a
type of model.

ADVANCED FUNCTIONS 17
ENGLISH
Restarting the air conditioner
automatically
When the air conditioner is turned on again
after a power failure, this function restores the
previous settings. This function is a factory de-
fault setting.
1Open the front cover.
- Lift up both sides of the cover slightly.
2Press the On/Off button and hold it for 6
seconds.
- The unit will beep twice and the lamp will
blink 6 times.
- To re-enable the function, press the On/
Off button and hold it for 6 seconds. The
unit will beep twice and the blue lamp will
blink 4 times.
ON/OFF
button
Disabling auto restart
NOTE
!
If you press and hold the On/Off button
for 3 – 5 seconds instead of 6 seconds,
the unit will switch to the test operation.
In the test operation, the unit blows out
strong air for cooling for 18 minutes and
then returns to the factory default set-
tings.
* The feature can be changed according a
type of model.
* The feature can be changed according a
type of model.

18MAINTENANCE
ENGLISH
MAINTENANCE
Clean the product regularly to maintain optimal performance and to prevent possible breakdown.
* This may not be provided, depending on the model.
Item Cleaning interval Cleaning method
Air filter 2 weeks See "Cleaning the air filter"
Anti-allergy filter / Triple filter 3 months See
"Cleaning the anti-allergy filter and triple fil-
ter"
Plasma filter* 3 months See “Cleaning the plasma filter.”
Indoor unit surface Regularly Use a soft, dry cloth. Do not use bleach or
abrasives.
Outdoor unit Regularly Use steam to clean the heat exchanger coils
and the panel vents (consult with technician).
Anti-allergy filter
Plasma filter(option)
Air filter
Triple filter
Air filter
Anti-allergy filter
+ Triple filter
Plasma filter
CAUTION
• Turn off the power and unplug the power cord before you perform any maintenance; other-
wise it may cause electric shock.
• Never use water that is hotter than 40°C when you clean the filters. It may cause deforma-
tion or discoloration.
• Never use volatile substances when you clean the filters. They may damage the surface of
the product.
!
NOTE
!
• The location and shape of the filters may differ, depending on the model.
• Make sure to clean the heat exchanger coils of the outdoor unit regularly, as dirt collected
in the coils may decrease the operational efficiency or increase energy costs.
* The feature can be changed according a type of model.

MAINTENANCE 19
ENGLISH
Cleaning the air filter
Clean the air filter once every 2 weeks or
more if necessary.
1Turn off the power and unplug the power
cord.
2Open the front grille.
- Lift up both sides of the cover slightly.
3Hold the knob of the air filter, lift it up
slightly and remove it from the unit.
4Clean the filter with a vacuum cleaner or
with warm water.
- If dirt is difficult to remove, wash the filter
in lukewarm water with detergent.
5Dry the filter in the shade.
Cleaning the anti-allergy filter
and triple filter
1Turn off the power and unplug the power
cord.
2Open the front grille and remove the air fil-
ter (see “Cleaning air filter”).
3Pull out the anti-allergy filter and the triple
filter.
4Dry the filter in direct sunlight for 2 hours.
Cleaning the plasma filter
1Turn off the power and unplug the power
cord.
2Open the front grille and remove the air fil-
ter (see “Cleaning the air filter”).
3Remove the plasma filter in 10 seconds.
4Use a vacuum cleaner to remove any dirt.
- If dirt is difficult to remove, wash the filter
with lukewarm water.
5Dry the filter in the shade.
NOTE
!
• The location and shape of the filters may
differ, depending on the model.
• The feature can be changed according a
type of model.
NOTE
!
• The location of the filters may differ, de-
pending on the model.
• The plasma filter may not be included in
some models.
• The feature can be changed according a
type of model.

20 TROUBLESHOOTING
ENGLISH
TROUBLESHOOTING
Self-diagnosis function
This product has a built-in self-diagnosis function. If an error occurs, the lamp of the indoor unit
will blink in 2 second intervals. If this occurs, contact your local dealer or service center.
Before requesting service
Please check the following before you contact the service center. If the problem persists, contact
your local service center.
Problem Possible causes Corrective action
Abnormal operating condi-
tions.
• There is a burning
smell and a strange
sound coming from
the unit.
• Turn off the air conditioner, unplug the
power cord and contact the service cen-
ter.
• Water leaks from
the indoor unit even
when the humidity
level is low.
• The power cord is
damaged or gener-
ating excessive
heat.
• A switch, a circuit
breaker (safety,
ground) or a fuse is
not operated properly.
The air conditioner does not
work.
• The air conditioner
is unplugged.
• Check whether the power cord is
plugged into the outlet.
• A fuse is blown or
the power supply is
blocked.
• Replace the fuse or check if the circuit
breaker has tripped.
• A power failure has
occurred.
• Turn off the air conditioner when a power
failure occurs.
• When the power is restored, wait 3 min-
utes, and then turn on the air conditioner.
• The voltage is too
high or too low. • Check if the circuit breaker has tripped.
• The air conditioner
turned off automati-
cally at a preset
time.
• Press the power button again.
• Battery setting is
wrong in the remote
controller.
• Is the battery inserted in Remoted con-
troler? Is the battery inserted with the
correct terminal (+)(-)?
• Even if you check the upper lists, the air-
conditioner does not operate. Please re-
place new batteries.
