Life Gear Classic User manual

CLASSIC,
MAGNETIC RECUMBENT BIKE
ITEM NO: 26380
OWNER’S MANUAL
IMPORTANT: Read all instructions carefully before using this product. Retain this
owner’s manual for future reference.
The specifications of this product may vary from this photo, subject to change without notice.

1
TABLE OF CONTENTS
WARRANTY ------------------------------------------------------------------------------- 1
SAFETY INSTRUCTIONS ------------------------------------------------------------- 2
PARTS LIST ------------------------------------------------------------------------------- 3
HARDWARE PACKING LIST --------------------------------------------------------- 5
TOOLS -------------------------------------------------------------------------------------- 5
OVERVIEW DRAWING -----------------------------------------------------------------6
ASSEMBLY INSTRUCTIONS --------------------------------------------------------- 7
OPERATING THE COMPUTER ------------------------------------------------------ 13
ADJUSTMENTS -------------------------------------------------------------------------- 16
MAINTENANCE -------------------------------------------------------------------------- 17
TROUBLESHOOTING ------------------------------------------------------------------ 17
WARM UPAND COOL DOWN ROUTINE ----------------------------------------- 18
ONE YEAR LIMITED WARRANTY
LifeGear Inc. warrants to the original purchaser that this product is free from defects in
material and workmanship when used for the purpose intended, under the conditions that it
has been installed and operated in accordance with LifeGear's Owner's Manual. LifeGear's
obligation under this warranty is limited to replacing or repairing, free of charge, any parts
which may prove to be defective under normal home use. This warranty does not include
any damage caused by improper operation, misuse or commercial application.
From the date of purchase, the frame is warranted to be free from defects for 1 (one) year.
This warranty is extended only to the original owner and is not transferable.
When ordering replacement parts please have the following information ready:
1. Owner's Manual
2. Model Number
3. Description of Parts
4. Part Number
5. Date of Purchase

2
SAFETY INSTRUCTIONS
Basic precautions should always be followed, including the following safety
instructions when using this equipment: Read all instructions before using this
equipment.
1. Read all the instructions in this manual and do warm up exercises before using this
equipment.
2. Before exercise, in order to avoid injuring the muscle, warm-up exercise of every
position of the body is necessary. Refer to Warm Up and Cool Down Routine page.
After exercise, relaxation of the body is suggested for cool-down.
3. Please make sure all parts are not damaged and fixed well before use. This
equipment should be placed on a flat surface when using. Using a mat or other
covering material on the ground is recommended.
4. Please wear proper clothes and shoes when using this equipment; do not wear clothes
that might catch any part of the equipment; remember to tighten the pedaling straps.
5. Do not attempt any maintenance or adjustments other than those described in this
manual. Should any problems arise, discontinue use and consult an Authorized
Service Representative.
6. Do not use the equipment outdoors.
7. This equipment is for household use only.
8. Only one person should be on the equipment while in use.
9. Keep children and pets away from the equipment while in use. This machine is
designed for adults only. The minimum free space required for safe operation is not
less than two meters.
10. If you feel any chest pains, nausea, dizziness, or short of breath, you should stop
exercising immediately and consult your physician before continuing.
11. The maximum weight capacity for this product is 110 kgs.
WARNING:Before beginning any exercise program consult your physician.
This is especially important for the persons who are over 35 years old or who have
pre-existing health problems. Read all instructions before using any fitness
equipment.
CAUTION:Read all instructions carefully before operating this product.
Retain this Owner’s Manual for future reference.

3
PARTS LIST
No. Description Qty No. Description Qty
001 Front Stabilizer End Cap 2 028 Computer (RD-93232) 1
002 Front Stabilizer 1 029 Bolt M5x10 4
003 Cap Nut M10 4 030 Tension Control Knob 1
004 Curve Washer Ø10 4 031 Tension Cable L=750mm 1
005 Screw ST4.2x25 10 032 Big Washer Ø5xØ20x1 1
006 Bolt M10x57 4 033 Bolt M5x20 1
007 Front Handlebar Post Cover 1 034 Front Handlebar Post 1
008 Middle Section Hand Pulse
Sensor Wire L=1000mm 1 035 Bolt M8x10 5
009 Pan Head Phillips Self Drilling
Screw ST4.2x25 6 036 Washer Ø8xØ16x1.5 18
010 Right Cover 1 037 Bolt M8x30 3
011 Belt 330J6 1 038 Rear Stabilizer End Cap 2
012 Right Foot Pedal YH-30X 1 039 Idle Wheel Bracket 1
013 Crank 1 040 Curve Washer Ø8xØ20x2 3
014 Washer Ø34.5xØ23x2.5 1 041 Washer Ø6xØ12x1 1
015 Bearing Nut II 7/8" 1 042 Washer Ø10.2xØ14x1 2
016 Bearing 2 043 Bearing 6000ZZ 2
017 Bearing Cup 2 044 Bolt M6x10 1
018 Bearing Nut I 15/16" 1 045 Big Washer Ø8xØ20x2 2
019 Hexagon Nut 7/8" 1 046 Rear Main Frame 1
020 Flywheel Ø230 1 047 Seat Cushion 250x345x40 1
021 Front Main Frame 1 048 Back Cushion 310x345x40 1
022 Left Cover 1 049 Bolt M6x15 8
023 Triangle Knob M12x55 1 050 Big Washer Ø6xØ18x1.5 8
024 Round End Cap for Handlebar
Ø25x1.5 4 051 Back and Seat Support Bracket End Cap 23x53x2 1
025 Front Handlebar Foam Grip
Ø30xØ24x160 2 052 Seat Sliding Tube 1
026 Extension Sensor Wire
L=500mm 1 053 Back and Seat Support Bracket 1
027 Extension Hand Pulse Sensor
Wire I L=500mm 2 054 Handlebar Foam Grip Ø30xØ24x510 2

4
PARTS LIST
No. Description Qty No. Description Qty
055 Screw ST4.2x20 2 069 Left Foot Pedal YH-30X 1
056 Hand Pulse Sensor with Wire
L=750 2 070 Extension Hand Pulse Sensor Wire II L=1000mm 2
057 Bolt M8x45 2 071 Sensor with Wire L=450mm 1
058 Wire Plug Ø12.1 2 072 Bolt M8x15 13
059 Nut M6 2 073 Washer Ø40xØ24x3 1
060 Round Knob M16x1.5 1 074 Nut M10x1 2
061 Bushing 2 075 Eyebolt M6x36 2
062 Right Rear Main Frame Cover 1 076 Screw ST2.9x12 2
063 Left Rear Main Frame Cover 1 077 Cap Nut M8 2
064 Rear Stabilizer Ø50x1.5x430 1 078 Spring Washer Ø6xØ11.2x2 2
065 Bolt M6x48 2 079 Tension Bracket 2
066 Transport Wheel Ø23xØ6x32 2 080 Rubber Bolt 1
067 Nylon Nut M6 2 081 Nut M8 1
068 Handlebar 1 082 Cover Cap Ø40xØ25x10 2

5
HARDWARE PACKING LIST
TOOLS
(3) Cap Nut M10
4 PCS (4) Curve Washer Ø10 4 PCS (6) Bolt M10x57 4 PCS
(40) Curve Washer
Ø8xØ20x2
2 PCS
(45) Big Washer Ø8xØ20x2
2 PCS (57) Bolt M8x45 2 PCS
(77) Cap Nut M8
2 PCS
Allen Wrench S6
1 PC Multi Hex Tool with Phillips Screwdriver S10, S13, S14, S15
1 PC
Multi Hex Tool
1 PC

6
OVERVIEW DRAWING
8
82
82
8
29
5
81
28
72
40
80
79
79
29
31
71
70
27
26
44
41
43
42
35
78
55
55
58
58
76
65
66
67
67
66
65
38
38
77
45
45
77
62
63
9
9
5
5
40
36 72
72
78 36
36
36
36
36
75
75
74
74
72
72
72
72
69
68
64
61
61
59
59
57 56
56
24
24
25
25
54
53
52
51
50
50
50
50
50
49
49
49
49
49
48
47
46
37
7
39
37
36
36
35
35
34
33
32
30
54
24
24
22
21
20
73
19
18
16
17
17
16
15
14
13
12
11
10
9
9
9
9
6
6
5
5
4
3
4
3
4
4
3
32
1
1
60
23

7
ASSEMBLY INSTRUCTIONS
1. Rear Main Frame Installation
Remove two M8x30 Bolts (37), four M8x15 Bolts (72), and six Ø8xØ16x1.5 Washers (36)
from the Rear Main Frame (46). Remove bolts with the S6 Allen Wrench provided.
Connect the Middle Section Hand Pulse Sensor Wires (8) from the Rear Main Frame (46)
to the Extension Hand Pulse Sensor Wires II (70) from the Front Main Frame (21).
Attach the Rear Main Frame (46) into the Front Main Frame (21) with two M8x30 Bolts (37),
four M8x15 Bolts (72), and six Ø8xØ16x1.5 Washers (36) that were removed. Tighten
bolts with the S6 Allen Wrench provided.
Allen Wrench S6
Tool:
70
21
46
71
31
70
8
36 72
72 36
37

8
2. Front and Rear Stabilizers Installation
Position the Front Stabilizer (2) in front of the Front Main Frame (21) and align bolt holes.
Attach the Front Stabilizer (2) onto the front curve of the Front Main Frame (21) with two
M10 Cap Nuts (3), two Ø10 Curve Washers (4), and two M10x75 Bolts (6). Tighten nuts
with the Multi Hex Tool provided.
Position the Rear Stabilizer (64) behind the Rear Main Frame (46) and align bolt holes.
Attach the Rear Stabilizer (64) onto the rear curve of the Rear Main Frame (46) with two
M10 Cap Nuts (3), two Ø10 Curve Washers (4), and two M10x75 Bolts (6). Tighten nuts
with the Multi Hex Tool provided.
You may turn the Rubber Bolt (80) and M8 Nut (81) on the Rear Main Frame (46) as needed
to level the recumbent bike.
Hardware:
4 Cap Nuts (M10) 4 Curve Washers (Ø10) 4 Bolts (M10x57)
Multi Hex Tool
Tool:
81
80
6
4
3
43
6
4
4
3
3
46 21
2
64

9
3. Front Handlebar Post and Foot Pedal Installation
Remove one Ø8xØ20x2 Curve Washer (40), one M8x15 Bolt (72), four M8x10 Bolts (35)
and four Ø8xØ16x1.5 Washers (36) from the Front Main Frame (21). Remove bolts with
the S6 Allen Wrench provided.
Slide the Front Handlebar Post Cover (7) up to the Front Handlebar Post (34).
Insert the Tension Cable (31) through into the bottom hole of Front Handlebar Post (34) and
pull it out from the square hole of Front Handlebar Post (34).
Connect the Sensor Wire (71) and Extension Hand Pulse Sensor Wires II (70) from the Front
Main Frame (21) to the Extension Sensor Wire (26) and Extension Hand Pulse Sensor Wires
I (27) from the Front Handlebar Post (34).
Insert the Front Handlebar Post (34) onto the tube of the Front Main Frame (21) and secure
with one Ø8xØ20x2 Curve Washer (40), one M8x15 Bolt (72), four M8x10 Bolts (35) and
four Ø8xØ16x1.5 Washers (36) that were removed. Tighten bolts with the S6 Allen Wrench
provided. Slide the Front Handlebar Post Cover (7) down to the Front Main Frame (21).
Remove the Ø5xØ20x1 Big Washer (32) and M5x20 Bolt (33) from the Tension Control Knob
(30). Remove bolt with the Multi Hex Tool with Phillips Screwdriver provided.
Put the cable end of resistance cable of Tension Control Knob (30) into the spring hook of
Tension Cable (31) as shown in drawing A of figure 3. Pull the resistance cable of Tension
Control Knob (30) up and force it into the gap of metal bracket of Tension Cable (31) as
shown in drawing B of figure 3. Attach the Tension Control Knob (30) onto the Front
Handlebar Post (34) with the Ø5xØ20x1 Big Washer (32) and M5x20 Bolt (33) that were
removed. Tighten bolt with the Multi Hex Tool with Phillips Screwdriver provided.
12
69
21
72
40
36
35
71
31
70
27
26
7
36
35
34
33
32
30
31
26
27
13
30
31
30
31
BA
Multi Hex Tool with Phillips Screwdriver
S10, S13, S14, S15
Tool:
Allen Wrench S6
