Life Gear 20145HP User manual

MAGNETIC UPRIGHT BIKE
ITEM NO.: 20145HP
OWNER’S MANUAL
IMPORTANT: Read all instructions carefully before using this product. Retain this
owner’s manual for future reference.
The specifications of this product may vary from this photo, subject to change without notice.
2013, April

1
TABLE OF CONTENTS
WARRANTY ------------------------------------------------------------------------------- 1
SAFETY INSTRUCTIONS ------------------------------------------------------------- 2
ADJUSTMENTS -------------------------------------------------------------------------- 3
OPERATING THE COMPUTER ------------------------------------------------------ 3
TOOLS -------------------------------------------------------------------------------------- 4
PARTS LIST ------------------------------------------------------------------------------- 5
OVERVIEW DRAWING -----------------------------------------------------------------6
ASSEMBLY INSTRUCTIONS --------------------------------------------------------- 7
MAINTENANCE -------------------------------------------------------------------------- 11
TROUBLESHOOTING ------------------------------------------------------------------ 11
WARM UPAND COOL DOWN ROUTINE ----------------------------------------- 12
ONE YEAR LIMITED WARRANTY
LifeGear Inc. warrants to the original purchaser that this product is free from defects in
material and workmanship when used for the purpose intended, under the conditions that it
has been installed and operated in accordance with LifeGear's Owner's Manual. LifeGear's
obligation under this warranty is limited to replacing or repairing, free of charge, any parts
which may prove to be defective under normal home use. This warranty does not include
any damage caused by improper operation, misuse or commercial application.
From the date of purchase, the frame is warranted to be free from defects for 1 (one) year.
This warranty is extended only to the original owner and is not transferable.
When ordering replacement parts please have the following information ready:
1. Owner's Manual
2. Model Number
3. Description of Parts
4. Part Number
5. Date of Purchase

2
SAFETY INSTRUCTIONS
Basic precautions should always be followed, including the following safety
instructions when using this equipment: Read all instructions before using this
equipment.
1. Read all the instructions in this manual and do warm up exercises before using this
equipment.
2. Before exercise, in order to avoid injuring the muscle, warm-up exercise of every
position of the body is necessary. Refer to Warm Up and Cool Down Routine page.
After exercise, relaxation of the body is suggested for cool-down.
3. Please make sure all parts are not damaged and fixed well before use. This
equipment should be placed on a flat surface when using. Using a mat or other
covering material on the ground is recommended.
4. Please wear proper clothes and shoes when using this equipment; do not wear clothes
that might catch any part of the equipment; remember to tighten the pedaling straps.
5. Do not attempt any maintenance or adjustments other than those described in this
manual. Should any problems arise, discontinue use and consult an Authorized
Service Representative.
6. Do not use the equipment outdoors.
7. This equipment is for household use only.
8. Only one person should be on the equipment while in use.
9. Keep children and pets away from the equipment while in use. This machine is
designed for adults only. The minimum free space required for safe operation is not
less than two meters.
10. If you feel any chest pains, nausea, dizziness, or short of breath, you should stop
exercising immediately and consult your physician before continuing.
11. The maximum weight capacity for this product is 110 kgs.
WARNING:Before beginning any exercise program consult your physician.
This is especially important for the persons who are over 35 years old or who have
pre-existing health problems. Read all instructions before using any fitness
equipment.
CAUTION:Read all instructions carefully before operating this product.
Retain this Owner’s Manual for future reference.

3
ADJUSTMENTS
Adjusting the Tension Control Knob
To increase the load, turn the tension control knob in a clockwise direction.
To decrease the load, turn the tension control knob in a counterclockwise direction.
Adjusting the Rear Stabilizer End Cap
Turn the rear stabilizer end cap on the rear stabilizer as needed to level the bike.
Adjusting the Seat Height
Turn the round knob in a counterclockwise direction until the seat post can be slid up or
down and then slide the seat post up or down direction to the suitable position. Lock the
seat post in place by tightening the round knob in a clockwise direction.
NOTE: When adjusting the height of seat post, the maximum insert depth mark line
cannot higher than the edge of seat post bushing.
OPERATING THE COMPUTER
SPECIFICATION:
TIME: 0:00-99:59 MIN:SEC
SPD (SPEED): 0.0-999.9 KM/H
DST (DISTANCE): 0.00-99.99 KM
CAL (CALORIES): 0.0-999.9 KCAL
PUL (PULSE): 40-240 BEATS/MIN
FUNCTIONS AND OPERATIONS:
AUTO ON /OFF: When you start pedaling or press the MODE button on the computer, the
computer will turn on. If you leave the equipment for 4 minutes, the power will turn off
automatically.
SCAN: Press the MODE button until the arrow points to SCAN; the monitor will automatically
scan each function of TIME, SPD (SPEED), DST (DISTANCE), and CAL (CALORIES) in
sequence with change every 6 seconds.
TIME: Press the MODE button until the arrow points to TIME; the monitor will display your
elapsed workout time in minutes and seconds.
SPD (SPEED): Press the MODE button until the arrow points to SPD; the monitor will
display the current training speed.

4
DST (DISTANCE): Press the MODE button until the arrow points to DST; the monitor will
display the accumulative distance traveled during workout.
CAL (CALORIES): Press the MODE button until the arrow points to CAL; the monitor will
display the total accumulated calories burned during workout.
PUL (PULSE): Press MODE button until the arrow points to PUL and then hold both two
hands on handlebar grip sensors, the screen will display your current heart rate figures and
a heart symbol. To ensure the pulse readout is more precise, please always hold on to the
handlebar grip sensors with two hands instead of just with one hand only when you try to test
your heart rate figures.
RESET: Press the MODE button over 4 seconds, all functional values will reset to zero.
HOW TO INSTALL THE BATTERIES:
1. Remove the battery cover at the rear of computer.
2. Place two "SIZE-AA" batteries into the battery housing.
3. Insure batteries are correctly positioned and battery springs are proper contact with
batteries.
4. Re-install the battery cover.
5. If the display is illegible or only partial segment appear, remove batteries and wait 15
seconds before reinstalling.
TOOLS
Allen Wrench (S6)
1 PC Multi Hex Tool with Phillips Screwdriver S13, S14, S15
1 PC

5
PARTS LIST
No. Description Qty No. Description Qty
001 Main Frame 1 028 Tension Control Knob L=320 1
002 Front Stabilizer End Cap 2 029 Hex Nut M10 1
003 Rear Stabilizer End Cap 2 030 Pressing Belt Wheel 1
004 Front Stabilizer Ø50x1.5 1 031 Bearing 6000-2Z 2
005 Left Foot Pedal YH-4X 1 032 Washer Ø10.2xØ14x1.0 2
006 Right Foot Pedal YH-4X 1 033 Washer Ø6 1
007 Flywheel 1 034 Bolt M6x10 1
008 Screw ST4.2x15 1 035 Nut M10x1.0x10 2
009 Belt Pulley with Crank 200J6 1 036 Washer Ø30xØ10.5x2 2
010 Sensor Wire 1 037 Bolt M8x18 1
011 Axle Bush 2 038 Ball Bearing 2
012 Tension Cable L=500 1 039 Axle Sleeve 7/8” 1
013 Middle Section Sensor Wire
L=750 1 040 Screw ST4.8x15 1
014 Bolt M10x60 1 041 Bolt M8x15 14
015 Belt PJ290/J4 1 042 Washer Ø34.5xØ23x2.5 1
016 Rear Stabilizer Ø50x1.5 1 043 Nut 7/8" 2
017 Left Cover 1 044 Post Cover 2
018 Right Cover 1 045 Locknut M8 4
019 Round Knob M10 1 046 Big Curve Washer Ø20xØ8 12
020 Seat Cushion DD-28T 1 047 Washer Ø40xØ24x3.0 1
021 Seat Post 1 048 Washer Ø8 4
022 Bushing 1 049 Screw ST4.2x25 8
023 Handlebar Foam Grip
Ø20xØ30x450 2 050 Axle Sleeve 15/16” 1
024 Handlebar End Cap 2 051 Curve Washer Ø8 2
025 Handlebar Ø22x1.5 1 052 Hand Pulse Sensor with Wire
L=750mm 2
026 Computer XLG-707HP 1 053 Screw ST4.2x20 2
027 Handlebar Post Ø50x1.5 1

6
OVERVIEW DRAWING
9
26
49
49
49
46
46
41
41
28
40
48
44
46
46
46
51
41
41
41
41
41
36
36
35
35
43
47
42
50
39
38
38
37
48
45
34
33
31
32
31 30
28
27
25
24
23
23
22
21
20
19
18
17
16
4
15
14
10
13
13
12 11
11
10
87
6
5
2
2
3
1
45
44
29
41
46
52
53
52
53

7
ASSEMBLY INSTRUCTIONS
1. Install the Front/Rear Stabilizers and Foot Pedals
Remove four M8x15 Bolts (41) and four Ø20xØ8 Big Curve Washers (46) from the Front
Stabilizer (4). Position the Front Stabilizer (4) in front of Main Frame (1) and align bolt
holes. Attach the Front Stabilizer (4) onto the front tube of the Main Frame (1) with four
M8x15 Bolts (41) and four Ø20xØ8 Big Curve Washers (46) that were removed. Tighten
bolts with the Allen Wrench provided.
Remove four M8x15 Bolts (41) and four Ø20xØ8 Big Curve Washers (46) from the Rear
Stabilizer (16). Position the Rear Stabilizer (16) behind of Main Frame (1) and align bolt
holes. Attach the Rear Stabilizer (16) onto the rear tube of the Main Frame (1) with four
M8x15 Bolts (41) and four Ø20xØ8 Big Curve Washers (46) that were removed. Tighten
bolts with the Allen Wrench provided.
The Pedal Shafts and Pedal Straps are marked “R” for Right and “L” for Left.
Insert the pedal shaft of Left Foot Pedal (5) into threaded hole in the left Crank (9).
Turn the pedal shaft by hand in the counter-clockwise direction until snug.
Note: DO NOT turn the pedal shaft in the clockwise direction, doing so will strip the
threads.
Tighten the pedal shaft of Left Foot Pedal (5) with the Multi Hex Tool with Phillips
Screwdriver provided.
Insert pedal shaft of Right Foot Pedal (6) into threaded hole in right Crank (9).
Turn the pedal shaft by hand in the clockwise direction until snug.
Tighten pedal shaft of Right Foot Pedal (6) with the Multi Hex Tool with Phillips Screwdriver
provided.
46
41
46
41
46
41
46
5
4
16
1
6
9
41
Allen Wrench (S6)
Multi Hex Tool with Phillips Screwdriver
S13, S14, S15
Tool:

8
2. Install the Seat Cushion and Seat Post
Remove three M8 Locknuts (45) and three Ø8 Washers (48) from underside of the Seat
Cushion (20).
Guide bolts on underside of the Seat Cushion (20) through holes on top of the Seat Post (21),
attach with three removed M8 Locknuts (45) and three Ø8 Washers (48). Tighten locknuts
with the Multi Hex Tool with Phillips Screwdriver provided.
Insert the Seat Post (21) into the Bushing (22).
Adjust the seat position and insert the Round Knob (19). Turn the Round Knob (19) in the
clockwise direction to tighten.
NOTE: When adjusting the height of seat post, the maximum insert depth mark line
cannot higher than the edge of bushing.
20
48
45
19
21
1
22
Multi Hex Tool with Phillips Screwdriver
S13, S14, S15
Tool:

9
3. Handlebar Post Installation
Remove four M8x15 Bolts (41) and four Ø20xØ8 Big Curve Washers (46) from the tube of
the Main Frame (1).
Connect the Sensor Wire (10) from the Main Frame (1) to the Middle Section Sensor Wire
(13) from the Handlebar Post (27).
Put the cable end of resistance cable of Tension Control Knob (28) into the spring hook of
Tension Cable (12) as shown in drawing A of figure 3. Pull the resistance cable of Tension
Control Knob (28) up and force it into the gap of metal bracket of Tension Cable (12) as
shown in drawing B of figure 3.
Insert the Handlebar Post (27) onto the tube of the Main Frame (1) and secure with four
M8x15 Bolts (41) and four Ø20xØ8 Big Curve Washers (46) that were removed.
28
12
12
28
13
41
46
46 41
A B
13
10
27
28 12
41
1
Allen Wrench (S6)
Tool:
