LEGO® HEAVY-DUTY TOW TRUCK
#42128 LIGHT KIT
INSTALLATION GUIDE

LEGO HEAVY-DUTY TOW TRUCK 42128 LIGHT KIT INSTALL GUIDE
INSTALLATION GUIDE 2
Light My Bricks
LEGO® HEAVY-DUTY TOW TRUCK
42128 INSTALLATION GUIDE
Hi There!
We’re here to help you get started on the LEGO®
Heavy-Duty Tow Truck 42128 Light Kit.
This PDF details the instructions for the LED light kit only. If
you are wishing to purchase this product, please click here
to view the product page.
If you run into any issues, please refer to the troubleshoot-
ing section towards the end of this guide.
Have fun and enjoy!

LEGO HEAVY-DUTY TOW TRUCK 42128 LIGHT KIT INSTALL GUIDE
v
PACKAGE CONTENTS 3
PACKAGE CONTENTS: ASSORTED BRICKS:
1x Rotating Bit Light
1x White Strip Light
4x Cool White 15cm Bit Light
6x White 30cm Bit Light
2x Warm White Large 30cm Bit Light
11x Orange 30cm Bit Light
2x Blue 30cm Bit Light
3x 6-Port Expansion Board
1x 8-Port Expansion Board
1x 12-Port Expansion Board
1x NC Push Board
1x Multi-Eects Board
6x Adhesive Squares
• 2x Round Plate 1x1 Open Stud - Black
• 2x Round Plate 1x1 - Trans Red
• 6x Round Plate 1x1 - Trans Orange
• 6x Round Plate 1x1 - Trans Clear
• 3x Technic Pin 1/2 - Light Grey
• 1x Cone 1 x 1 W Top Groove - Trans Orange
• 2x Plate 1x1 Mod Rounded w Handle - Black
• 2x Tile 1x1 W Clip Round Edges - Black
• 2x Brick 1x8 - Light Grey
• 2x Bracket 1x2-1x4 – Light Grey
1x 30cm Connecting Cable
3x 15cm Connecting Cable
3x 5cm Connecting Cable
1x USB Power Cable
(Power Source not Included)

LEGO HEAVY-DUTY TOW TRUCK 42128 LIGHT KIT INSTALL GUIDE
CONTENTS 4
Contents
Before You Begin
Blueprint
Instructions
Final Product
Troubleshooting
Contact
5
8
9
42
43
48

LEGO HEAVY-DUTY TOW TRUCK 42128 LIGHT KIT INSTALL GUIDE
BEFORE YOU BEGIN 5
Before You Begin
Laying cables in between
and underneath bricks
Cables can fit in between and underneath
LEGO® bricks, plates, and tiles providing
they are laid correctly between the
LEGO® studs. Do NOT forcefully join
LEGO® together around cables; instead
ensure they are laying comfortably in
between each stud.
CAUTION: Forcing LEGO® to connect over
a cable can result in damaging the cable
and light.
Connecting Cable
Connectors To Expansion
Boards
Take extra care when inserting connectors
to ports of Expansion Boards. Connectors
can be inserted only one way. With the
expansion board facing up, look for the
soldered “=” symbol on the left side of the
port. The connector side with the wires
exposed should be facing toward the
soldered “=” symbol as you insert into the
port. If a plug won’t fit easily into a port
connector, do not force it.
Incorrectly inserting the connector can re-
sult in bent pins inside the port or possible
overheating of the expansion board when
connected.

LEGO HEAVY-DUTY TOW TRUCK 42128 LIGHT KIT INSTALL GUIDE
BEFORE YOU BEGIN 6
Before You Begin
Connecting Cable
Connectors To Strip Lights
Take extra care when inserting connectors
to ports on the Strip Lights. Connectors
can be inserted only one way. With the
Strip Light facing up, ensure the side of
the connector with the wires exposed is
facing down. If a plug won’t fit easily into
a port connector, don’t force it. Doing so
will damage the plug and the connector.
Connecting Micro Cable
Connectors To Micro
Expansion Board Ports
Take extra care when inserting the
micro connectors to micro ports of Micro
Expansion Boards. Connecting Micro Bit
Lights to Micro Expansion Boards is similar
to connecting lights and cables to Strip
Lights. With the expansion board facing
up, ensure the side of the connector with
the wires exposed is facing down. If a plug
won’t fit easily into a port connector, do
not force it. Use your fingernail to push the
plastic part of the connector to the micro
port.

LEGO HEAVY-DUTY TOW TRUCK 42128 LIGHT KIT INSTALL GUIDE
BEFORE YOU BEGIN 7
Before You Begin
Installing Bit Lights Under
Lego® Bricks And Plates
When installing Bit Lights under LEGO®
pieces, ensure they are placed the correct
way up (Yellow LED component exposed).
You can either place them directly on top of
LEGO® studs or in between.

LEGO HEAVY-DUTY TOW TRUCK 42128 LIGHT KIT INSTALL GUIDE
INSTRUCTIONS 8
BLUEPRINT

LEGO HEAVY-DUTY TOW TRUCK 42128 LIGHT KIT INSTALL GUIDE
INSTRUCTIONS 9
INSTRUCTIONS
To ensure a smooth installation of
your light kit, please read and follow
each step carefully. If you run into
any issues, please refer to the online
troubleshooting guide.

LEGO HEAVY-DUTY TOW TRUCK 42128 LIGHT KIT INSTALL GUIDE
INSTRUCTIONS 10
Legend DISCONNECT CONNECT /
RECONNECT TURN / FLIP DIRECTIONAL TWIST / BRAID POWER ON TEST NOTE ICON
1 2
Cool White 15cm Bit Light

LEGO HEAVY-DUTY TOW TRUCK 42128 LIGHT KIT INSTALL GUIDE
INSTRUCTIONS 11
Legend DISCONNECT CONNECT /
RECONNECT TURN / FLIP DIRECTIONAL TWIST / BRAID POWER ON TEST NOTE ICON
Cool White 15cm Bit Light
Round Plate 1x1 - Trans Clear Round Plate 1x1 - Trans Clear
Lightly bend the
led cable to be flat
with the headlight

LEGO HEAVY-DUTY TOW TRUCK 42128 LIGHT KIT INSTALL GUIDE
INSTRUCTIONS 12
Legend DISCONNECT CONNECT /
RECONNECT TURN / FLIP DIRECTIONAL TWIST / BRAID POWER ON TEST NOTE ICON
3
x2
Partially
disconnect the
“Power Tow” piece
enough to allow a
cable to fit through
Partially
disconnect the
“Power Tow” piece
enough to allow a
cable to fit through

LEGO HEAVY-DUTY TOW TRUCK 42128 LIGHT KIT INSTALL GUIDE
INSTRUCTIONS 13
Legend DISCONNECT CONNECT /
RECONNECT TURN / FLIP DIRECTIONAL TWIST / BRAID POWER ON TEST NOTE ICON
46-Port Expansion Board
30cm Connecting Cable
Connect the
cables from the
headlights into the
Expansion Board
Exclude the 30cm
Connecting Cable
when twisting the
wires

LEGO HEAVY-DUTY TOW TRUCK 42128 LIGHT KIT INSTALL GUIDE
INSTRUCTIONS 14
Legend DISCONNECT CONNECT /
RECONNECT TURN / FLIP DIRECTIONAL TWIST / BRAID POWER ON TEST NOTE ICON
5
2x Adhesive Squares

LEGO HEAVY-DUTY TOW TRUCK 42128 LIGHT KIT INSTALL GUIDE
INSTRUCTIONS 15
Legend DISCONNECT CONNECT /
RECONNECT TURN / FLIP DIRECTIONAL TWIST / BRAID POWER ON TEST NOTE ICON

LEGO HEAVY-DUTY TOW TRUCK 42128 LIGHT KIT INSTALL GUIDE
INSTRUCTIONS 16
Legend DISCONNECT CONNECT /
RECONNECT TURN / FLIP DIRECTIONAL TWIST / BRAID POWER ON TEST NOTE ICON
8-Port Expansion Board
6
Connect the
cable from Step 5 to
the Expansion Board

LEGO HEAVY-DUTY TOW TRUCK 42128 LIGHT KIT INSTALL GUIDE
INSTRUCTIONS 17
Legend DISCONNECT CONNECT /
RECONNECT TURN / FLIP DIRECTIONAL TWIST / BRAID POWER ON TEST NOTE ICON
7
Orange 30cm Bit Light
Orange 30cm Bit Light

LEGO HEAVY-DUTY TOW TRUCK 42128 LIGHT KIT INSTALL GUIDE
INSTRUCTIONS 18
Legend DISCONNECT CONNECT /
RECONNECT TURN / FLIP DIRECTIONAL TWIST / BRAID POWER ON TEST NOTE ICON
815cm Connecting CableNC Push Board
White Strip Light
Orange 30cm Bit Light
Connect the 15cm
Connecting Cable to
the “OUT” port of the
NC Push Board

LEGO HEAVY-DUTY TOW TRUCK 42128 LIGHT KIT INSTALL GUIDE
INSTRUCTIONS 19
Legend DISCONNECT CONNECT /
RECONNECT TURN / FLIP DIRECTIONAL TWIST / BRAID POWER ON TEST NOTE ICON
15cm Connecting Cable
9
10 Adhesive Square
Stick the Strip
Light over the cables
Connect the 15cm
Connecting Cable to
the “IN” port of the
NC Push Board

LEGO HEAVY-DUTY TOW TRUCK 42128 LIGHT KIT INSTALL GUIDE
INSTRUCTIONS 20
Legend DISCONNECT CONNECT /
RECONNECT TURN / FLIP DIRECTIONAL TWIST / BRAID POWER ON TEST NOTE ICON
Connect the
cable from the NC
Push Board
Connect the
cables that come
from underneath the
Strip Light
Press down the
Board to ensure it
sticks well
Make sure the
Board is slightly
poking out
