LEGO LIGHTYEAR XL-15 SPACESHIP 76832 LIGHT KIT INSTALL GUIDE
2
Light My Bricks
LEGO LIGHTYEAR XL-15 SPACESHIP 76832
INSTALLATION GUIDE
Hi There!
We’re here to help you get started on the LEGO
Lightyear XL-15 Spaceship Light Kit.
This PDF details the instructions for the LED light kit only.
If you run into any issues, please refer to the
troubleshoot-ing section towards the end of this guide.
Have fun and enjoy!
INSTALLATION GUIDE

LEGO LIGHTYEAR XL-15 SPACESHIP 76832 LIGHT KIT INSTALL GUIDE
v
PACKAGE CONTENTS 3
PACKAGE CONTENTS: ASSORTED BRICKS:
2 x Blue 30cm Large Bit Light
2 x Cool White 30cm Large Bit Light
2 x Green 15cm Micro Bit Light
2 x Red 15cm Micro Bit Light
1 x 6-Port Expansion Board
1 x Micro 4-Port Expansion Board
1 x Flicker Eects Board
•1 x Bar 4L - Trans Red
•1 x Bar 4L - Trans Green
•2 x Round Plate 1x1 Open Stud - Black
•1 x Plate 2x2 W Rounded Bottom - Trans Clear
2 x 5cm Connecting Cable
1x USB Power Cable
(Power Source not Included)
* Indicates components which include spares

LEGO LIGHTYEAR XL-15 SPACESHIP 76832 LIGHT KIT INSTALL GUIDE
CONTENTS 4
Contents
Before You Begin
Blueprint
Instructions
Final Product
Troubleshooting
Contact
5
8
9
22
23
28

LEGO LIGHTYEAR XL-15 SPACESHIP 76832 LIGHT KIT INSTALL GUIDE
BEFORE YOU BEGIN 5
Before You Begin
Laying cables in between
and underneath bricks
Cables can fit in between and underneath
LEGO® bricks, plates, and tiles providing
they are laid correctly between the
LEGO® studs. Do NOT forcefully join
LEGO® together around cables; instead
ensure they are laying comfortably in
between each stud.
CAUTION: Forcing LEGO® to connect over
a cable can result in damaging the cable
and light.
Connecting Cable
Connectors To Expansion
Boards
Take extra care when inserting connectors
to ports of Expansion Boards. Connectors
can be inserted only one way. With the
expansion board facing up, look for the
soldered “=” symbol on the left side of the
port. The connector side with the wires
exposed should be facing toward the
soldered “=” symbol as you insert into the
port. If a plug won’t fit easily into a port
connector, do not force it.
Incorrectly inserting the connector can re-
sult in bent pins inside the port or possible
overheating of the expansion board when
connected.

LEGO LIGHTYEAR XL-15 SPACESHIP 76832 LIGHT KIT INSTALL GUIDE
BEFORE YOU BEGIN 6
Before You Begin
Connecting Cable
Connectors To Strip Lights
Take extra care when inserting connectors
to ports on the Strip Lights. Connectors
can be inserted only one way. With the
Strip Light facing up, ensure the side of
the connector with the wires exposed is
facing down. If a plug won’t fit easily into
a port connector, don’t force it. Doing so
will damage the plug and the connector.
Connecting Micro Cable
Connectors To Micro
Expansion Board Ports
Take extra care when inserting the
micro connectors to micro ports of Micro
Expansion Boards. Connecting Micro Bit
Lights to Micro Expansion Boards is similar
to connecting lights and cables to Strip
Lights. With the expansion board facing
up, ensure the side of the connector with
the wires exposed is facing down. If a plug
won’t fit easily into a port connector, do
not force it. Use your fingernail to push the
plastic part of the connector to the micro
port.

LEGO LIGHTYEAR XL-15 SPACESHIP 76832 LIGHT KIT INSTALL GUIDE
BEFORE YOU BEGIN 7
Before You Begin
Installing Bit Lights Under
Lego® Bricks And Plates
When installing Bit Lights under LEGO®
pieces, ensure they are placed the correct
way up (Yellow LED component exposed).
You can either place them directly on top of
LEGO® studs or in between.

LEGO LIGHTYEAR XL-15 SPACESHIP 76832 LIGHT KIT INSTALL GUIDE
INSTRUCTIONS 8
BLUEPRINT

LEGO LIGHTYEAR XL-15 SPACESHIP 76832 LIGHT KIT INSTALL GUIDE
INSTRUCTIONS 9
INSTRUCTIONS
To ensure a smooth installation of
your light kit, please read and follow
each step carefully. If you run into
any issues, please refer to the online
troubleshooting guide.
LEGENDLEGEND:: DISCONNECTDISCONNECT DIRECTIONALDIRECTIONAL
LEGENDELEGENDE:: TRENNENTRENNEN DIRECTIONALDIRECTIONAL
LÉGENDELÉGENDE:: DÉCONNECTERDÉCONNECTER DIRECTIONNELDIRECTIONNEL
LEGGENDALEGGENDA:: SCOLLEGARESCOLLEGARE
CONNECT / CONNECT / RECONNECTRECONNECT
VERNINDEN VERNINDEN / WIEDERVERBINDEN/ WIEDERVERBINDEN
CONNECTER CONNECTER / RECONNECTER/ RECONNECTER
CONNETTI / RICONNETTICONNETTI / RICONNETTI
TURN TURN / / FLIPFLIP
WENDEN WENDEN / KIPPEN/ KIPPEN
TOUR TOUR / INCLINAISON/ INCLINAISON
ROTARE ROTARE / INCLINARE/ INCLINARE DIREZIONALEDIREZIONALE
TWIST TWIST / BRAID/ BRAID
DREHEN DREHEN / VERDREHEN/ VERDREHEN
TORSION TORSION / TRESSER/ TRESSER
TWIST TWIST / / TRECCIATRECCIA
POWER POWER ON ON / TEST/ TEST
EINSCHALTEN EINSCHALTEN / TESTEN/ TESTEN
POWER POWER ON ON / / TESTTEST
POWER POWER ON ON / / TESTTEST

LEGO LIGHTYEAR XL-15 SPACESHIP 76832 LIGHT KIT INSTALL GUIDE
INSTRUCTIONS 10
Legend DISCONNECT CONNECT /
RECONNECT TURN / FLIP DIRECTIONAL TWIST / BRAID POWER ON TEST NOTE ICON
1

LEGO LIGHTYEAR XL-15 SPACESHIP 76832 LIGHT KIT INSTALL GUIDE
INSTRUCTIONS 11
Legend DISCONNECT CONNECT /
RECONNECT TURN / FLIP DIRECTIONAL TWIST / BRAID POWER ON TEST NOTE ICON
2
Red 15cm Micro Bit Light
3
Bar 4L - Trans Red
Red 15cm Micro Bit Light
Ensure to place
the LED facing
downwards

LEGO LIGHTYEAR XL-15 SPACESHIP 76832 LIGHT KIT INSTALL GUIDE
INSTRUCTIONS 12
Legend DISCONNECT CONNECT /
RECONNECT TURN / FLIP DIRECTIONAL TWIST / BRAID POWER ON TEST NOTE ICON
4
Push the Bar
in until it is secure.
Pushing too far may
result in the LED
breaking

LEGO LIGHTYEAR XL-15 SPACESHIP 76832 LIGHT KIT INSTALL GUIDE
INSTRUCTIONS 13
Legend DISCONNECT CONNECT /
RECONNECT TURN / FLIP DIRECTIONAL TWIST / BRAID POWER ON TEST NOTE ICON
5
4-Port Micro Expansion Board
Green 15cm Micro Bit Light
Ensure to place
the LED facing
downwards

LEGO LIGHTYEAR XL-15 SPACESHIP 76832 LIGHT KIT INSTALL GUIDE
INSTRUCTIONS 14
Legend DISCONNECT CONNECT /
RECONNECT TURN / FLIP DIRECTIONAL TWIST / BRAID POWER ON TEST NOTE ICON
6
Bar 4L - Trans Red
Green 15cm Micro Bit Light

LEGO LIGHTYEAR XL-15 SPACESHIP 76832 LIGHT KIT INSTALL GUIDE
INSTRUCTIONS 15
Legend DISCONNECT CONNECT /
RECONNECT TURN / FLIP DIRECTIONAL TWIST / BRAID POWER ON TEST NOTE ICON
7
Connect to
a 5V USB Power
Bank, 5V USB Wall
Adaptor, or USB to
AA Battery Pack (sold
separately)
If you experience any issues with the lights not working and suspect an issue with a component, please try a dierent port on the expansion board to verify where the fault lies (with the light or
expansion board). To correct any issues with expansion board ports, please view the section addressing expansion board issues in our troubleshooting section.
USB Power Cable

LEGO LIGHTYEAR XL-15 SPACESHIP 76832 LIGHT KIT INSTALL GUIDE
INSTRUCTIONS 16
Legend DISCONNECT CONNECT /
RECONNECT TURN / FLIP DIRECTIONAL TWIST / BRAID POWER ON TEST NOTE ICON
8
Ensure the back
door is still able to
close properly. If not,
continue to push the
Micro Expansion
Board further into
the gap.
5cm Connecting Cable
6-Port Expansion Board

LEGO LIGHTYEAR XL-15 SPACESHIP 76832 LIGHT KIT INSTALL GUIDE
INSTRUCTIONS 17
Legend DISCONNECT CONNECT /
RECONNECT TURN / FLIP DIRECTIONAL TWIST / BRAID POWER ON TEST NOTE ICON
9
Cool White 15cm Large Bit Light Plate 2x2 W Rounded Bottom -
Trans Clear

LEGO LIGHTYEAR XL-15 SPACESHIP 76832 LIGHT KIT INSTALL GUIDE
INSTRUCTIONS 18
Legend DISCONNECT CONNECT /
RECONNECT TURN / FLIP DIRECTIONAL TWIST / BRAID POWER ON TEST NOTE ICON
10
Ensure the LED
is facing towards the
front of the ship
Cool White 15cm Large Bit Light
11

LEGO LIGHTYEAR XL-15 SPACESHIP 76832 LIGHT KIT INSTALL GUIDE
INSTRUCTIONS 19
Legend DISCONNECT CONNECT /
RECONNECT TURN / FLIP DIRECTIONAL TWIST / BRAID POWER ON TEST NOTE ICON
12 Cool White 30cm Large Bit Light
Black Round Plate 1x1
w/ Open Stud

LEGO LIGHTYEAR XL-15 SPACESHIP 76832 LIGHT KIT INSTALL GUIDE
INSTRUCTIONS 20
Legend DISCONNECT CONNECT /
RECONNECT TURN / FLIP DIRECTIONAL TWIST / BRAID POWER ON TEST NOTE ICON
13
Ensure the LED is
fitted perfectly into
the gap by holding
the cable when
pushing the bar in
Ensure not to
push the bar in too
far by applying
minimal force
x2
Flicker Eects Board
5cm Connecting Cable
Connect the two
Blue 30cm Large Bit
Light to the ‘OUT’
ports of the Flicker
Eects Board.
Connect the 5cm
Connecting Cable
to the ‘IN’ port of the
Flicker Eects Board.
