Lightronics FXLE30C4N User manual

Page 1 of 4
FXLE30C4N LED FIXTURE
Version 1.1 OWNER’S MANUAL 02/08/2022
www.lightronics.com
Lightronics Inc. 509 Central Drive, Virginia Beach, VA 23454 757 486 3588
FEATURES AND SPECIFICATIONS
LEDs: 300 Watt 4-in-1 Quad-Color, RGBW array
White Color Temp.: 2950K-10800K
CRI: 93 CQS: 92
Beam Angle: 19º, 26º or 36º
Control System: DMX-512 + Stand Alone
DMX Channels: 4 or 9 channel mode
DMX Connectors: 3 pin XLR I/O
Power Input: 100-230VAC, 50/60Hz
Max. Power Consumption: 330 Watts @ 120VAC
Standby Power Consumption: 6 Watts @ 120VAC
Ingress Protection: IP20 - Indoor Use Only
Body Material: All Metal Construction
Body Color: Black or White Available
Reflector: Glass
Gel Frame and Size "B" Gobo Holder Included
FX Accessory Slot
Sliding Yoke Assembly on 12.75” Track
Size: 28" L x 13.5" W x 20"H (with yoke)
Weight: 23 lbs.
DESCRIPTION
The FXLE30C4N is a four color LED ellipsoidal fixture
that is suitable for stage, houses of worship,
entertainment venues and other artistic applications. It
has automatic stand-alone control modes and can
operate via an external DMX-512 signal.
A mounting yoke enables the fixture to be installed and
operated in various positions and orientations.
INSTALLATION
LOCATION
Locate the unit indoors in a well-ventilated area away
from moisture or heat. Maintain a minimum spacing of
20" between the unit and other objects. The maximum
ambient operating temperature is 40ºC (104ºF). Keep
the vent holes clear. Holes are provided on the yoke to
install a traditional lighting C-clamp for mounting on
batten pipe. Use a safety cable attached to the safety
eye when hanging the fixture.
GOBO/FX SLOT ALIGNMENT
To rotate barrel, loosen the two 3mm hex socket head
screws on both sides of body behind the shutter
handles. Then loosen both adjustment knobs at top
and bottom of fixture behind the shutter handles. Once
GOBO or FX slot is aligned, retighten screws and
knobs.
LENS TUBE ADJUSTMENT
To focus beam, loosen the knobs at top and bottom of
the barrel, extend/retract tube as needed for intended
beam and tighten knobs. Support lens tube in process.
YOKE ADJUSTMENT
To slide yoke along track, loosen 4 screws on both
side brackets with #2 Phillips screwdriver, adjust yoke
and retighten screws once in desired position.
POWER CONNECTIONS
The FXLE30C4N has a blue turn and lock connector
for power input. A compatible power cable is provided
for connection to a 120 VAC, 15 Amp, 60Hz, grounded
service.
Push the blue connector on the cable straight into the
blue connector on the unit and twist approx. 1/8 turn
clockwise to latch it. Do not power the unit from a
dimmer pack. The white turn and lock connector on the
unit is used to pass power on to another FXLE30C4N
unit. A mating white connector is also provided.
The safety ground pin on the power cord must be
used.
When using 120VAC, only connect a maximum of
four FXLE30C4N fixtures together with power
connectors.
DANGER
RISK OF ELECTRIC SHOCK

Page 2 of 4
FXLE30C4N LED FIXTURE
Version 1.1 OWNER’S MANUAL 02/08/2022
www.lightronics.com
Lightronics Inc. 509 Central Drive, Virginia Beach, VA 23454 757 486 3588
DMX CONNECTIONS
A system using DMX control should be connected as a
chain of devices. In other words, the control signal
cable should originate at the controller to the first
receiving device and then to others in one continuous
chain. An optically isolated DMX splitter is recommend
when installing the FXLE30C4N in a system with
various other DMX devices.
The FXLE30C4N has a DMX IN and a DMX OUT
connector which are used to connect the DMX data
chain. The control cable can NOT be split into a Y or
multiple run/star arrangement with a cable running
directly from the controller to each receiving device.
DMX CONNECTOR PIN ASSIGNMENTS
Predominantly two connectors are used for connecting
fixtures and other DMX devices to a DMX control
chain. They are both “XLR type” connectors. Some
units use 3 pin connectors, others use 5 pin
connectors. The FXLE30C4N receives a DMX signal
on the 3 pin MALE connector on the rear of the unit.
The 3 pin FEMALE connector is used to connect to the
next DMX device on the control chain.
If your console uses a 5 pin XLR connector, an adapter
cable can be purchased or fabricated to accommodate
this conversion.The following table shows the pin
assignments for both 3 pin and 5 pin XLR connectors:
PIN #
SIGNAL NAME
1
DMX COMMON
2
DMX DATA -
3
DMX DATA +
4
NOT USED
5
NOT USED
DMX TERMINATION
It is recommended that a DMX data chain be
terminated at the last receiving device on the chain.
This is done by installing a commonly available 1/4
Watt, 120 Ohm resistor across the DATA - and DATA
+ wires at the last device. If you have only a few
fixtures installed very close together and with a short
run of DMX cable to the controller, then you may be
able to operate without the terminator.
OPERATION
Power is applied once the power cord is connected to
a live power source. There is not an on/off switch.
Connect power cord to fixture first, then outlet. A
display and user interface is located on the back of the
unit. This interface is used to set the operating options
and settings. It consists of a backlit LCD display and
four buttons (MODE, DOWN, UP and ENTER).
Use MODE to scroll through the available choices.
The current setting for the option will be shown. Use
UP and DOWN until you reach the desired setting or
mode then push ENTER to lock in the new setting.
In case of loss of power to fixture, the fixture will
return to the last setting that was locked in with
ENTER being pressed.
MENU OPTIONS
MENU
Value
(D:)
Function
DMX - 9CH
001-512
9 channel start address
DMX - 4CH
001-512
4 channel start address
Jump
00-99
Color Change (speed)
Gradient
00-99
Color Fade (speed)
Pulse 00-99
Fast On / Slow fade with
mix of RGBW colors
selected.
Voice
Running
(Sound Mode)
Enter on/
Enter off Color change to audio vibrations.
Color R
000-255
Red intensity
Color G
000-255
Green intensity
Color B
000-255
Blue intensity
Color W
000-255
White intensity
Color 9 Presets
Options from 2000K to
12000K.
DMX - 9 ch: Select the DMX start address and press
ENTER to set 9 Channel DMX mode. Highest starting
address is 504 for full functions. See DMX Operation.
DMX - 4 ch: Select the DMX start address and press
ENTER to set 4 Channel DMX mode. Highest starting
address is 509 for full functions. See DMX Operation.
Once you select the DMX mode and address, press
ENTER to ensure that if power is lost, the fixture
will return to the preset DMX mode and address.
Jump: Colors change with no fade. 15 steps. No color
selection required.
Gradient: Colors change with fade. 15 steps. No color
MODE
ENTER
UP
DOWN
CONTROL PANEL

Page 3 of 4
FXLE30C4N LED FIXTURE
Version 1.1 OWNER’S MANUAL 02/08/2022
www.lightronics.com
Lightronics Inc. 509 Central Drive, Virginia Beach, VA 23454 757 486 3588
selection required.
Pulse: Colors come on quickly and fade out, number
of steps vary based on colors chosen from the RGBW
selections. Set color intensity to 001-255, but actual
value is irrelevant. 2 colors = 12 steps, 3 colors = 14
steps. 4 colors = 15 steps.
Voice Running: The unit responds to sound providing
random pulses of color.
Color R: Varies the RED color intensity (0-255).
Color G:Varies the GREEN color intensity (0-255).
Color B: Varies the BLUE color intensity (0-255).
Color W: Varies the WHITE color intensity (0-255).
Color: Nine preset color temperature options at a
default intensity. (2000K, 2500K, 3000K, 4500K,
5600K, 6500K, 8000K, 9000K, 12000K).
DMX OPERATION
9 CHANNEL DMX MODE
CHANNEL
FUNCTION
1
Overall Intensity (0-255)
2
Strobe (Speed 0-255)
(Color Required)
3 Effect
0-5: Off
6-100: Jump
101-150: Gradient
151-200: Pulse
201-255: Sound Control
4
Effect Speed (0-255)
5
Red Intensity (0-255)
6
Green Intensity (0-255)
7
Blue Intensity (0-255)
8
White Intensity (0-255)
9
Color Temperature
0:Off, 1-255: variable 2000K-12000K
Overall Intensity: Controls overall intensity of LED
array for functions 2 through 9.
Strobe: Flashes light using color selected from
channels 5 through 8 or channel 9.
Effect/Speed:Use channel 3 in conjunction with
channel 4 to select the effect and the rate at which the
effect is performed (Off/Jump/Gradient/Pulse/Sound).
Red Intensity: Control the intensity of the RED LED
array for use alone or when blending with other colors.
Green Intensity: Control the intensity of the GREEN
LED array for use alone or when blending with other
colors.
Blue Intensity: Control the intensity of the BLUE LED
array for use alone or when blending with other colors.
White Intensity: Control the intensity of the COOL
WHITE LED array for use alone or when blending with
other colors.
Color Temperature: Provides a variable color
temperature white LED light. The intensity is controlled
by the ‘Overall Intensity’ setting.
4 CHANNEL DMX MODE
CHANNEL
FUNCTION
1
Red Intensity (0-255)
2
Green Intensity (0-255)
3
Blue Intensity (0-255)
4
White Intensity (0-255)
Red Intensity: Control the intensity of the RED LED
array for use alone or when blending with other colors.
Green Intensity: Control the intensity of the GREEN
LED array for use alone or when blending with other
colors.
Blue Intensity: Control the intensity of the BLUE LED
array for use alone or when blending with other colors.
White Intensity: Control the intensity of the WHITE
LED array for use alone or when blending with other
colors.
MAINTENANCE AND REPAIR
TROUBLESHOOTING
Fixture will not power up.
•Check that you have power applied to the unit.
•Check the fuse located on the back panel.
Unable to control fixture.
•Check that the LCD display indicates the
correct DMX channel mode and is addressed
properly. If not, select the proper channel
mode and address then press ENTER.
•Check the LCD display on the fixture, if there is
a flashing decimal after the DMX value, a valid
DMX signal is present. If no decimal is
showing, then a valid DMX signal is not
present.
•Check the DMX control cable for continuity and

Page 4 of 4
FXLE30C4N LED FIXTURE
Version 1.1 OWNER’S MANUAL 02/08/2022
www.lightronics.com
Lightronics Inc. 509 Central Drive, Virginia Beach, VA 23454 757 486 3588
polarity.
•Remove the fixture from the DMX chain and all
other DMX devices.
•Check the address settings or patch at the
controller.
CLEANING
DISCONNECT THE POWER CORD BEFORE
HANDLING THE UNIT.
A mild detergent can be used sparingly if needed.
Apply to cloth only, do not apply directly to fixture. Do
not use chemicals or solvents when cleaning the
fixture. Ensure that the unit is dry before use.
REPAIR
The only FXLE30C4N user serviceable part is a 5 mm
x 20 mm externally accessible fuse on the rear panel.
DISCONNECT THE POWER CORD BEFORE
CHECKING OR REPLACING THE FUSE.
Replace fuse ONLY with 5.0 Amp, 250VAC, fast acting
fuse. Requires #2 Philips head screwdriver to access.
Use care to not overtighten.
Internal service on the unit by other than Lightronics
authorized agents will void the warranty.
If service is required, contact the dealer from whom
you purchased the item, or contact the Lightronics
Service Department, 509 Central Drive, Virginia Beach,
VA 23454. Tel: [phone].
WARRANTY INFORMATION AND
REGISTRATION – CLICK LINK BELOW
www.lightronics.com/warranty.html
FXLE30C4N PHOTOMETRIC DATA
10 Foot
20 Foot
30 Foot
19°
Beam (ft.) FC Lux Beam (ft.) FC Lux Beam (ft.) FC Lux
Red
3.3
294
3050
6.6
64
682
10.5
27
455
Green 3.3 302 3210 6.6 70 758 10.5 30 508
Blue 3.3 492 5200 6.6 113 1226 10.5 50 840
White
3.3
550
5950
6.6
136
1458
10.5
57
966
All Colors 3.3 1535 16120 6.6 366 3920 10.5 158 2580
10 Foot
20 Foot
30 Foot
26° Beam (ft.) FC Lux Beam (ft.) FC Lux Beam (ft.) FC Lux
Red 4.7 160 1810 9.4 40 443 14.2 18 196
Green
4.7
186
1995
9.4
45
489
14.2
21
228
Blue 4.7 300 3160 9.4 76 824 14.2 34 372
White
4.7
340
3720
9.4
86
936
14.2
39
427
All Colors 4.7 950 10120 9.4 237 2520 14.2 105 1168
10 Foot
20 Foot
30 Foot
36°
Beam (ft.)
FC
Lux
Beam (ft.)
FC
Lux
Beam (ft.)
FC
Lux
Red 6.5 89 960 12.9 23 255 19.5 11 121
Green
6.5
99
1100
12.9
27
294
19.5
12
134
Blue 6.5 170 1835 12.9 45 486 19.5 20 223
White 6.5 192 2050 12.9 51 554 19.5 28 309
All Colors
6.5
532
5590
12.9
140
1530
19.5
77
820
DANGER DO NOT OPEN UNIT
RISK OF ELECTRIC SHOCK
RISK OF FIRE
