FXLE3030W LED FIXTURE
Version 1.1 OWNER’S MANUAL 02/08/2022
www.lightronics.com
Lightronics Inc. 509 Central Drive, Virginia Beach, VA 23454 757 486 3588
FEATURES AND SPECIFICATIONS
LEDs: 300 Watt Array. (Warm White)
Color Temp.: 3000 K
Beam Angle: 19º or 26º or 36º (50º Optional)
Control System: DMX-512 + Stand Alone
DMX Channels: 1 or 2
DMX Connectors: 3 pin XLR I/O
Power Input: 100-230VAC, 50/60Hz
Max. Power Consumption: 300 Watts @ 120VAC
Ingress Protection: IP20 - Indoor Use Only
Body Material: All Metal Construction
Body Color: Black or White Available
Reflector: Glass
Gel Frame and Size "M" Gobo Holder Included
FX Accessory Slot
Sliding Yoke Assembly on 12.75” Track
Size: 28" L x 13.5" W x 20"H (with yoke)
Weight: 23 lbs.
DESCRIPTION
The FXLE3030W is an LED ellipsoidal fixture that is
suitable for stage, houses of worship, entertainment
venues and other artistic applications. It has automatic
stand-alone control modes and can operate via an
external DMX-512 signal.
A mounting yoke enables the fixture to be installed and
operated in various positions and orientations.
INSTALLATION
LOCATION
Locate the unit indoors in a well-ventilated area away
from moisture or heat. Maintain a minimum spacing of
20" between the unit and other objects. The maximum
ambient operating temperature is 40ºC (104ºF). Keep
the vent holes clear. Holes are provided on the yoke to
install a traditional lighting c-clamp for mounting on
batten pipe. Use a safety cable attached to the safety
eye when hanging the fixture.
YOKE ADJUSTMENT
To slide yoke along track, loosen 4 screws on both
side brackets with #2 Phillips screwdriver, adjust yoke
and retighten screws once in desired location.
LENS TUBE ADJUSTMENT
To focus beam, loosen the knobs on the top and
bottom of barrel, extend/retract lens tube as needed
and tighten knobs. Support lens tube in process.
GOBO/FX SLOT ALIGNMENT
To rotate barrel, loosen the two 3mm hex socket cap
screws on both sides of body behind the shutter
handles. Loosen both adjustment knobs at top and
bottom of fixture behind the shutter handles. Once
GOBO or FX slot is aligned, retighten screws and
knobs.
POWER CONNECTIONS
The FXLE3030W has a blue turn and lock connector
for power input. A compatible power cable is provided
for connection to a 120 VAC, 15 Amp, 60Hz, grounded
service.
Push the blue connector on the cable straight into the
blue connector on the unit and twist approx. 1/8 turn
clockwise to latch it. Do not power the unit from a
dimmer pack. The white turn and lock connector on the
unit is used to pass power on to another FXLE3030W
unit. A mating white connector is also provided.
Power is applied once the power cord is connected to
a live power source. There is not an on/off switch.
Connect power cord to the fixture first, then the outlet.
When using 120VAC, only connect a maximum of
four FXLE3030W fixtures together with power
connectors.
THE SAFETY GROUND PIN ON THE POWER CORD
MUST BE USED.
DANGER
RISK OF ELECTRIC SHOCK

Page 2 of 3
FXLE3030W LED FIXTURE
Version 1.1 OWNER’S MANUAL 02/08/2022
www.lightronics.com
Lightronics Inc. 509 Central Drive, Virginia Beach, VA 23454 757 486 3588
DMX CONNECTIONS
A system using DMX control should be connected as a
chain of devices. In other words, the control signal
cable should originate at the controller to the first
receiving device and then to others in one continuous
chain. An optically isolated DMX splitter is recommend
when installing the FXLE3030W in a system with
various other DMX devices.
The FXLE3030W has a DMX IN and a DMX OUT
connector which are used to connect the DMX data
chain. The control cable can NOT be split into a Y or
multiple run/star arrangement with a cable running
directly from the controller to each receiving device.
DMX CONNECTOR PIN ASSIGNMENTS
Predominantly two connectors are used for connecting
fixtures and other DMX devices to a DMX control
chain. They are both “XLR type” connectors. Some
units use 3 pin connectors, others use 5 pin
connectors. The FXLE3030Wreceives a DMX signal
on the 3 pin MALE connector on the rear of the unit.
The 3 pin FEMALE connector is used to connect to the
next DMX device on the control chain.
If your console uses a 5 pin XLR connector, an adapter
cable can be purchased or fabricated to accommodate
this conversion. The following table shows the pin
assignments for both 3 pin and 5 pin XLR connectors:
DMX TERMINATION
It is recommended that a DMX data chain be
terminated at the last receiving device on the chain.
This is done by installing a commonly available 1/4
Watt, 120 Ohm resistor across the DATA - and DATA
+ wires at the last device. If you have only a few
fixtures installed very close together and with a short
run of DMX cable to the controller, then you may be
able to operate without the terminator.
OPERATION
A display and user interface is located on the back of
the unit. This interface is used to set the operating
options and settings. It consists of a backlit LCD
display and four buttons (MODE, DOWN, UP, and
ENTER).
Use MODE to scroll through the available choices.
Push ENTER when you reach the option you want to
check or set. The current setting for the option will be
shown. Push UP and DOWN until you reach the
desired setting or menu then push ENTER to invoke
the new setting. Push ENTER to exit from the sub
menus.
DMX OPERATION
Use the DMX-Addr menu to set the unit DMX starting
address. The range is 001 - 512. A ‘V’ will be
displayed if a valid DMX signal is present, an ‘x’
represents that no valid DMX signal is present.
For this fixture to operate in DMX mode, the mode
needs to be set for “DMX-Addr” on LCD display by
pressing the MODE button.
The fixture has 2 DMX modes. 1 channel and 2
channel: Channel 2 is not active in 1 channel mode.
CHANNEL 1: Fixture Intensity (000 - 255)
CHANNEL 2: Strobe Control (000 - 127, 128-255)
000 is Strobe OFF, starts slow and
increases to fastest at 127. From 128-
255 pattern transitions to short light
pulses with longer duration between
pulses as value rises from 128 to 255.
STAND ALONE MODE
You can operate the unit manually using the R-
DIMMER & P-STROBE menu. Push the UP and
DOWN buttons to change the level, then p ush ENTER
when done. The range is 000 - 255 (See above for
values).
If connecting multiple FXLE3030W fixtures together in
stand-alone mode, set the DMX address on additional
units to d001 to follow the main fixture.
DMX-KEEP: ON/OFF
The DMX-KEEP mode determines the characteristic of
the fixture upon the loss of the DMX input signal. The
PIN #
SIGNAL NAME
1
DMX COMMON
2
DMX DATA -
3
DMX DATA +
4
NOT USED
5
NOT USED
MODE
ENTER
UP
DOWN
CONTROL PANEL

Page 3 of 3
FXLE3030W LED FIXTURE
Version 1.1 OWNER’S MANUAL 02/08/2022
www.lightronics.com
Lightronics Inc. 509 Central Drive, Virginia Beach, VA 23454 757 486 3588
PHOTOMETRIC MEASUREMENTS
LED array will either turn on or off based on the DMX-
KEEP setting when DMX signal is lost.
BK-LIGHT: ON/OFF
The backlight for the LCD display remains on at all
times if this function is set to ON. When BK-LIGHT is
set to OFF, the backlit display will turn off 30 seconds
after the last button push on the control panel.
NOW TEMP
Provides operating temperature in ºC.
MAINTENANCE AND REPAIR
TROUBLESHOOTING
Fixture will not power up.
•Check that you have power applied to the
unit.
•Check the fuse located on the back panel
of the fixture.
Unable to control fixture.
•Check that the LCD display currently
indicates “DMX-addr”.
•Check the LCD display on the fixture, if
there is a ‘V’ after the DMX value, a valid
DMX signal is present. If an ‘x’ is showing,
then a valid DMX signal is not present.
•Verify the fixture is properly addressed.
•Check the DMX control cable for continuity
and polarity.
•Remove the fixture from the DMX chain
and all other DMX devices.
•Check the address settings or patch at the
controller.
CLEANING
DISCONNECT THE POWER CORD BEFORE
HANDLING THE UNIT.
A mild detergent can be used sparingly if needed.
Apply to cloth first, do not apply detergents directly to
fixture. Do not use chemicals or solvents when
cleaning the fixture. Ensure the unit is dry before use.
REPAIR
The only FXLE3030W user serviceable part is a 5 mm
x 20 mm externally accessible fuse on the rear panel.
DISCONNECT THE POWER CORD BEFORE
CHECKING OR REPLACING THE FUSE.
Replace fuse ONLY with 5.0 Amp, 250VAC, fast acting
fuse. Requires #2 Phillips screwdriver, use caution to
not overtighten.
Internal service on the unit by other than Lightronics
authorized agents will void the warranty.
If service is required, contact the dealer from whom
you purchased the item, or contact the Lightronics
Service Department, 509 Central Drive, Virginia Beach,
VA 23454. Tel: [phone].
WARRANTY INFORMATION AND
REGISTRATION – CLICK LINK BELOW
www.lightronics.com/warranty.html
FXLE3030W
10 Foot
20 Foot
30 Foot
Beam
(feet)
FC
Lux
Beam
(feet)
FC
Lux
Beam
(feet)
FC
Lux
19°
2.5
2150
23200
5
537.5
5800
7.5
239
2578
26°
4.75
1039
10960
9
279
2950
13.5
125
1345
36°
6.33
533
5740
12.6
143
1545
19
65.4
704
50°
9
279
3000
18
75
807
27
34
368
