D/N 1080P HD Infrared IP Camera

IMPORTANT SAFEGUARDS
GRAPHIC SYMBOL EXPLANATION
The lightning flash with arrowhead symbol, within an equilateral
triangle, is intended to alert the user to the presence of
uninsulated "dangerous voltage" within the product's enclosure
that may be of sufficient magnitude to constitute a risk of electric
The exclamation point within an equilateral triangle is intended
to alert the user to the presence of important operating and
maintenance (servicing) instructions in the literature
shock to persons.
accompanying the unit.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION：
TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK)
NO USER SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED
SERVICE PERSONNEL.
CAUTION
RISK OF EXPLOSION IF BATTERY IS REPLACED
BY AN INCORRECT TYPE.
DISPOSE OF USED BATTERIES ACCORDING
TO THE INSTRUCTIONS

CAUTION
Do not drop or strike this equipment.
Do not install the equipment near any naked flames or heat
sources.
Do not expose this unit to rain or excessive moisture, avoid
smoke and dust.
Do not cover cloth or to install this unit in poorly ventilated
places.
Do not continue to operate if there appears to be fault.
Do not touch the power connection with wet hands.
Do not damage the power cord or leave it under pressure.
Sensitive electronics inside are vulnerable to excessive shock.
Excessive heat could damage this unit.
Please the camera in an environmental housing for protection.
If the camera gets wet, unplug it and have it checked by
qualified service personnel.
This may lead to overheating.
If the unit ceases to function, contact qualified service
personnel for help.
Risk of short circuit or electric shock.
Risk of fire or shock circuit.

CONGRATULATIONS
Thank you for purchasing this D/N 1080P HD Infrared IP Camera.
You now own one of the many fine network products we
manufactured. This product has been carefully inspected under
rigid quality control and should reach you in perfect condition.
With reasonable care, it will provide years of reliable performance.
We recommend that you read this installation and operation
manual thoroughly before installing and operation your new
system.
Here you will find all the information you need to set up and use
the system. If any questions are not answered in the manual,
please contact your dealer.
Before proceeding, please read and observe all instructions and
warnings contained in this manual. Retain this manual with the
original bill of sale for future reference and, if necessary, warranty
service.
When unpacking your new camera, check for missing or damaged
items. If any item is missing, or if damage is evident,
I . Contact your dealer for
assistance.
DO NOT
NSTALL OR OPERATE THIS PRODUCT

IPR722ES & LR7022E series is an 2 megapixel day&night 1080P
HD Infrared IP Camera, built-in H.264 AVC (Advanced Video
Coding) video compression. H.264 AVC video compression
engine supports high definition video quality, 1080P(1920x1080)
resolution, bandwidth efficiency with PPPoE and DDNS.
Also it provides higher bit rate of internet and diverse alarm
functions such as movement video detection e-mail or FTP.
Moreover, IPR722ES & LR7022E series can do remote
surveillance with iPad, iPhone or Android cell phone. The
software R&D engineer can use HTTP protocol(HTTPAPI) or
ONVIF protocol to develop related software, and integrate them
with existing application software system.
IPR722ES & LR7022E is ideal solution for remote video
monitoring via internet.
Executive Summary

PART DESCRIPTION & DIMENSION
154
101
72.5
67
82
Unit: mm

TOP COVER
BOTTOM CHASSIS
BRACKET
PAN ADJUSTMENT SCREW
TILT ADJUSTMENT SCREW
WINDOW
RJ-45 NETWORK CONNECTOR (Support PoE)
DC POWER INPUT JACK (DC12V 10%)
RESET KEY
To restore the server to factory default setting.
NETWORK INDICATOR LEDS
Green (LINK): While cable of network is connecting the LED is light.
Orange (ACT): When data is communicating, the LED is flashed.
±
INSTALLATION
DC power input
Network cable
FIG. 1 FIG. 2
1. Take out the IP camera from the inner box first. Plug the network cable and
power cable to RJ-45 network connector and DC power input jack of the IP
camera(FIG.1). Then fix bracket to the wall(FIG.2).

4. L-type Hex Key Wrench
FIG. 3
2. Loosen the pan and tilt adjustment screw on the bracket to turn the camera
body to the desired angle and then tighten the screws(FIG.3).
In st r u ct i on M an u al
IPR722ES / LR7022E
D/N 1080P HD Infrared IP Camera
1. D/N 1080P HD Infrared IP
Camera
2. Instruction Manual
3. CD Software Pack
IPD552EX2.2/4.2 N/P
H.264 HD IP Cameras
INSTRUCTION MANUAL
PRODUCTION COMPONENTS

For connecting IPR722ES & LR7022E series to the network, please follow one of the
system architectures:
(1). Use DC12V power adapter and network switch connected to a network.
SYSTEM ARCHITECTURES
PC
LAN LAN / Internet
Non-PoE Switch
HD Infrared
IP Camera
DC12V Adaptor
PoE+(30W)
Switch
PC
LAN LAN / Internet
(2). Use with PoE of the network switch connected to the network.
(3). Use PoE power injector and the network switch connected to the network.
PC
LAN LAN / Internet
AC
Non-PoE Switch
LAN
PoE+(30W)
Power Injector
HD Infrared
IP Camera
HD Infrared
IP Camera

For the convenience of users, restore the factory default settings will revert to the
default IP address 192.168.0.200.
NOTE
EMERGENCY FACTORY DEFAULT
Use hardware to restore factory default settings, follow these steps:
1. Hold "RESET" key 10 seconds, then release.
2. After about 40 seconds, the network LED light is off, and then lit.
3. This camera has completed the factory default settings, and then reboot.
4. Use IPScan software search for this IP device.
5. Using a Internet browser open the IP device.
6. Enter the default username "admin" and password "pass" to operate.

SPECIFICATIONS
IPR722ES (1080P 30fps)
70 (H), 51° °(V), 89 (D)°
Pick Up Element
Effective Pixels
Chip Size
Scanning System
Infrared Cut Filter
Min. Illumination
White Balance
Back Light Compensation
Electronic Shutter
Sense Up
Sense Up Plus
Auto Gain Control
3D Noise Reduction
2D WDR
Privacy Masking
Image Effects
IP Rating
Window
Operating Temperature
Dimension
Weight
Power Supply
Power Consumption
Model No.
Focal Length
Peak Wavelength
Iris
Beam Spread
Angle of View
Radiant Distance
IPR722ES6
6mm
F1.8
1/2.7" CMOS Image sensor
1920(H) x 1080(V) = 2,073,600(pixel)
5.856mm(H) x 3.276mm(V)
Progressive Scan
Auto / Schedule / Day(Color) / Night(Mono)
0.15Lux at F1.6 (Low Light Mode)
/ 0 Lux with IR
Auto / Tungsten / Indoor / Fluorescents1 / Fluorescents2 / Outdoor1 / Outdoor2
Off / On
1/30(25)s ~ 1/8,000s
Off/ 1Frame/ 2Frames/ 3Frames/ 7Frames
Yes
36dB Variable Gain
Off/ 1~32 Selectable
Off/ On
Off/ On (4 zones)
Brightness, Contrast, Hue, Saturation, Sharpness, Mirror, Flip
IP66
ψ65 Heat Resistant Glass
850nm
30°
21M
-35 C ~ +50 C° ° ° °(-31 F ~ 122 F)
Body: 82mm(W) x 72.5mm(H) x 154mm(D) / Bracket: 101mm(L)
600g
DC12V 10%/ PoE (IEEE 802.3af compliant)±
DC12V, 10W / PoE, 11W
Design and specification are subject to change without notice.
D/N 1080P HD INFRARED IP CAMERA
IPR722ES4.3
4.3mm
F1.6
Lens
Infrared
LED
49.3 (H), 35.9° °(V), 64.5 (D)°
0.18Lux at F1.8 (Low Light Mode)
/ 0 Lux with IR

Video Compression
Resolution
Profile #1
Profile #2
Profile #3
Profile #4
CPU, Memory
Network Protocols
Mobile Phone and PDA
PC Requirement
Security
Maintenance
Network Interface
System Integration
CMX
Video Display
OS
H.264, Motion JPEG
H.264: up to 30fps @1280x720, MJPEG: up to 30fps @352x240
H.264: up to 30fps @1920x1080, MJPEG: up to 30fps @1280x720
H.264: up to 30fps @720x480, MJPEG: up to 15fps @1920x1080
H.264: up to 30fps @1920x1080, MJPEG: up to 30fps @720x480
1080P(1920x1080) / 720P(1280x720) / D1(720x480) / CIF(352x240)
Embedded SoC ARM11, 528MHz
256MB DDR2, 256MB flash memory
IP, TCP, UDP, HTTP, SMTP, NTP, DDNS, UPnP, FTP, ARP,
DHCP, PPPoE, DNS, RTSP, RTCP, Telnet, ONVIF
iPad, iPhone and Android support
OS : Windows 2000, Windows XP, Windows Vista, Windows 7
Browser : Windows Internet Explorer 6, 7, 8
CPU : Intel Pentium 4 1.8GHz or above
RAM : 1GB or above, Independent Display Card
Base64 HTTP encryption
Multiple user access levels with password protection
10 user accounts available
Firmware update via HTTP, Firmware available at web site
10Mbps / 100Mbps Base-T, RJ-45
ONVIF & LILIN HTTP API
CMX HD3.6 support
LILIN Universal ActiveX & LILIN Java Applet
Embedded Linux 2.6.32
Design and specification are subject to change without notice.
NETWORK
Multiple profile
Video Streaming
Video Bitrate
RTP/HTTP, RTP/TCP, RTP/UDP
VBR/ CBR/ GOP supported
Frame rate and bit rate controllable on-the-fly
128Kbps ~ 5Mbps
Users
ePTZ & Digital Zoom
OSD
Alarm Functions
8 simultaneous users
Yes, ROI is supported
Text overlay for date, time, and camera name
Image upload over FTP and E-mail by face/ tampering/ motion detection
D/N 1080P HD INFRARED IP CAMERA

LR7022E (1080P 15fps)
62.2 (H), 37.4° °(V), 69.2 (D)°
Pick Up Element
Effective Pixels
Chip Size
Scanning System
Infrared Cut Filter
Min. Illumination
White Balance
Electronic Shutter
Back Light Compensation
Sense Up
Sense Up Plus
Auto Gain Control
3D Noise Reduction
2D WDR
Privacy Masking
Image Effects
IP Rating
Window
Operating Temperature
Dimension
Weight
Power Supply
Power Consumption
Model No.
Focal Length
Peak Wavelength
Iris
Beam Spread
Angle of View
Radiant Distance
LR7022E6
6mm
F1.8
1/2.5" CMOS Image sensor
1920(H) x 1080(V) = 2,073,600(pixel)
5.70mm(H) x 4.28mm(V)
Progressive Scan
Auto / Schedule / Day(Color) / Night(Mono)
0.4Lux at F1.6 (Low Light Mode)
/ 0 Lux with IR
Auto / Tungsten / Indoor / Fluorescents1 / Fluorescents2 / Outdoor1 / Outdoor2
1/30(25)s ~ 1/8,000s
Off / On
Off/ 1Frame/ 2Frames/ 3Frames/ 7Frames
Yes
36dB Variable Gain
Off/ 1~32 Selectable
Off/ x2/ x3/ x4
Off/ On (4 zones)
Brightness, Contrast, Hue, Saturation, Sharpness, Mirror, Flip
IP66
ψ65 Heat Resistant Glass
850nm
30°
18M
Body: 82mm(W) x 72.5mm(H) x 154mm(D) / Bracket: 101mm(L)
600g
DC12V 10% / PoE (IEEE802.3af compliant)±
DC12V, 10W / PoE, 11W
Design and specification are subject to change without notice.
D/N 1080P HD INFRARED IP CAMERA
LR7022E4
4mm
F1.6
Lens
Infrared
LED
43.6 (H), 25.4° °(V), 49.4 (D)°
0.5Lux at F1.8 (Low Light Mode)
/ 0 Lux with IR
-35 C ~ +50 C° ° ° °(-31 F ~ 122 F)

66-IPR722ECSE-1
Video Compression
Resolution
CPU, Memory
Network Protocols
Mobile Phone and PDA
PC Requirement
Security
Maintenance
Network Interface
System Integration
CMX
Video Display
OS
H.264, Motion JPEG
Motion JPEG: up to 15fps @1920x1080, 30fps @720x480, 30fps @352x240
1080P(1920x1080) / 720P(1280x720) / D1(720x480) / CIF(352x240)
Embedded SoC ARM11, 528MHz
256MB DDR2, 256MB flash memory
IP, TCP, UDP, HTTP, SMTP, NTP, DDNS, UPnP, FTP, ARP,
DHCP, PPPoE, DNS, RTSP, RTCP, Telnet, ONVIF
iPad, iPhone and Android support
OS : Windows 2000, Windows XP, Windows Vista, Windows 7
Browser : Windows Internet Explorer 6, 7, 8
CPU : Intel Pentium 4 1.8GHz or above
RAM : 1GB or above, Independent Display Card
Base64 HTTP encryption
Multiple user access levels with password protection
10 user accounts available
Firmware update via HTTP, Firmware available at web site
10Mbps / 100Mbps Base-T, RJ-45
ONVIF & LILIN HTTP API
CMX HD3.6 support
LILIN Universal ActiveX & LILIN Java Applet
Embedded Linux 2.6.32
Design and specification are subject to change without notice.
NETWORK
Maximum Frame Rate
Video Streaming Protocol
Video Bitrate
RTP/HTTP, RTP/TCP, RTP/UDP
VBR/ CBR/ GOP supported
Frame rate and bit rate controllable on-the-fly
128Kbps ~ 5Mbps
Users
Digital Zoom
OSD
Alarm Functions
8 simultaneous users
Yes
Text overlay for date, time, and camera name
Image upload over FTP and E-mail by motion detection
D/N 1080P HD INFRARED IP CAMERA
H.264: up to 15fps @1920x1080, 30fps @1280x720, 30fps @720x480

Instr uction Manual
66-IPR722ECSE
IPR722ES / LR7022E
MERIT LILIN ENT. CO., LTD
http://www.meritlilin.com
D/N 1080P HD Infrared IP Camera
