Car Solutions qpi-lvtx-astm User manual

Car-Solutions.com
[email protected] www.car-solutions.com

•Specification
Car Compatibility : 2014 Aston martin DB9, RAPIDE, VANTAGE
VANQUISH
Components : Interface* 1ea, Sub-board*1ea
Multimedia interface Input/output spec
Input : Analog RGB*2(Navigation, SMI), A/V*3,
CVBS(Rear view Camera)*1,
Output : To LCD*1
Power spec
Input power : 8VDC ~ 18VDC
Consumption : 5WATT
Switch input mode
External video sources skip function : able to control input
videos on and off via DIP switches.
Able to switch videos via the remote, button switch, and
original buttons.
Able to detect the rear view camera (back up camera) via
Lamp or CAN.
2
•Features
Control external videos sources (DVD, DTV) via Multi Media
Touch GUI
Adjust external videos screen position
Check the improved Screen Display (User Friendly Interface)
Switch modes via original OEM button
Supply power to connect rear view camera (Back up
camera)
Assist your parking via Dynamic PAS(Parking Assistance
System), PDC(Parking Distance Control), moving parking line
according movement of steering wheel
Car-Solutions.com
[email protected]
www.car-solutions.com

3
Sub-board * 1ea
(QCPASS0532)
Length-90mm
Height-18mm
Width-140mm
MODE(Button cable connection) | IR(IR cable connection) | POWER(Power cable connection)
| REAR(Rear cable connection) |RGB-IN-HDMI(Mirroiring device connection )
| RGB-IN-NAVI(RGB Navigation Input) |AV IN/OUT(AV cable connection)
| TO NAVI T/S OUT(NAVI touch cable connection) | LVDS-OUT(Sub-board connection)
| TEST(NOT FOR USE) | LED | DIP S/W(DIP switch setting)
Bracket * 1ea
(HPOWER0044)
LVDS * 1ea
(HLVDSC0020)
LCD * 1ea
(HLCDCA0029)
RGB * 1ea
(HRGBCA0013)
AV * 1ea
(HAVCAB0002)
NAVI TOUCH * 1ea
(HTOUCH0004)
REAR* 1ea
(HARETC0002)
BUTTON * 1ea
(HARETC0001)
IR * 1ea
(HIRCAB0002)
RC * 1ea
(REMOTE0001)
TOUCH * 1ea
(HTOUCH0009)
•Product exterior
•Components
Car-Solutions.com
[email protected]
www.car-solutions.com

※ON : DOWN / OFF : UP
4
•DIP SWITCH
•REMOTE CONTROL SETTING
Key FUNCTION
POWER & PIP NO USE
MENU Activating FACTORY MENU
OK Making a selection, changing image display
▲Moving upward
▼Moving downward
◀
Moving leftward
(If you press this button 2 seconds long, you can
access the factory mode.)
▶
Moving rightward
(If you press this button 2 seconds long, you can
reset all the data about user environment.)
※Please make sure to disconnect the power cable of the interface
and reconnect the power cable again to apply the dip switch setting
whenever changing DIP switch. Otherwise, DIP switch setting will not
be applied.
PIN FUNCTION Dip S/W SETTING
1 RGB INPUT MUTE OFF : RGB DISPLAY
ON : Skipping RGB Mode
2 HDMI1 MODE MUTE OFF : HDMI1 DISPALY
ON : Skipping HDMI1 Mode
3 AV MODE MUTE OFF : AV DISPLAY
ON : Skipping AV Mode
4 FRONT CAM MUTE OFF : Front camera function on
ON : Front camera function off
5 NO USE (OFF)
6 MONITOR SETTING OFF : Default
7 REAR MODE OFF : OEM Rear Camera
ON : External Rear Camera
8 NO USE (OFF)
Car-Solutions.com
[email protected]
www.car-solutions.com

5
<H-POSITION> <V-POSITION>
H-POSITION : Move display horizontally
V-POSITION : Move display vertically.
H-SIZE(NAVI) : Control the left-right
monitor size
PARK
UTIL1
UTIL2
INFO
H-POSITION
V-POSITION
H-SIZE(NAVI)
Menu of FACTORY
MENU to Return SEL to Select/Save
PARK
UTIL1
UTIL2
INFO
PAS TYPE
PAS SETUP
REAR TYPE
SAFE ENABLE
READAR ENABLE
Menu of FACTORY
MENU to Return SEL to Select/Save
•Factory setting
PAS TYPE : Select type of parking guide line
- NOT USED : No use parking guide line
- PAS ON : Selecting Dynamic parking guide line
- PAS OFF : Selecting fixed parking guide line
PAS SETUP : Adjusting the position of the parking guide line
REAR TYPE : Choose rear camera recognition.
- CAN : By connecting to “CAN” cable of the car gear, changing to
rear camera mode when shifting into reverse. (Connect “CAN”
cable of the power cable to the “CAN” cable of the car gear.)
- LAMP : By connecting to the rear lamp of the car, switch to rear
camera mode when shifting into rear. (Connect “Rear-C” cable of
the power cable to the rear lamp of the car.)
SAFE ENABLE : If it is enable, HDMI, RGB, and A/V mode doesn’t show up
while driving. (Default : OFF)
RADAR ENABLE : Setting up parking distance alarm sensor. (ON/OFF)
Adjust a current screen position and size.
Adjust rear view camera setting.
Car-Solutions.com
[email protected]
www.car-solutions.com

6
NAVI MODEL : Setting up RGB Navigation.
(Default, Q-ROI)
CAR MODEL : Selecting the model of car.
(Aston martin)
AVOUT SELECT : Selecting background sound
through car AUX. HDMI1, HDMI2,
AV)
HDMI2 SKIP : Skipping HDMI mode when
switching modes.
FACTORY RESET : Factory mode reset.
I-DRV REMOTE : Select ‘User’ mode to use
customized remote control
values on DVD, DTV after
registration.
(Default, User)
I-DRV CONTROL: Select whether to use remote
control or not
IR MEMORY : To register DVD, DTV remote
control, the remote control value
must be registered.
PARK
UTIL1
UTIL2
INFO
NAVI MODEL
CAR MODEL
AVOUT SELECT
HDMI SKIP
FACTORY RESET
Menu of FACTORY
MENU to Return SEL to Select/Save
PARK
UTIL1
UTIL2
INFO
I-DRV REMOTE
I-DRV CONTROL
IR MEMORY
Menu of FACTORY
MENU to Return SEL to Select/Save
PARK
UTIL1
UTIL2
INFO
SYSTEM VERSION
(MAIN-130723)
Menu of FACTORY
MENU to Return SEL to Select/Save
•Factory setting
Navigation & Car model setting up
System version information
Other options setting up
Car-Solutions.com
[email protected]
www.car-solutions.com

※Able to switch modes via NAV button on the center console of
car .
* Long press : Switching modes.
(RGB→HDMI1→A/V→OEM mode)
* Short press : Switching to OEM mode.
7
•How to use OEM buttons
Car-Solutions.com
[email protected]
www.car-solutions.com

8
Touch cable
NAVI BOX
※You can find original cables as the picture left behind of
AC conditioner.
- CAN LOW(Green/Black) → Connect to CAN-H-HS(Green)
- CAN HIGH(Green/Brown) → Connect to CAN-L-
HS(Green/Brown)
※Color of cable would be different depending on
Cars.
LOW
HIGH
AV1
AV2
AV3
REAR C
Audio L
Audio R
AV/OUT Video
ACC
REAR
MMI
GND
CAN-H-HS
CAN-L-HS
F-CAM-DET
SAFE
CAN-H-LS
CAN-L-LS
REAR (9V OUT)
GND
RGB
Cable
Touch Cable
LVDS Cable
Touch panel
•Installation Diagram
•CAN cable connection
Car-Solutions.com
[email protected]
www.car-solutions.com

9
※Take out the connected original cable on the PCB
substrate behind the monitor.
※Connect the original cable from the monitor to “OEM-
IN” on the sub-board and then connect the provided
cable from “OEM-OUT” on sub-board to the monitor
where the original cable connected.
•Connection of Sub-board
Car-Solutions.com
[email protected]
www.car-solutions.com

Q. I cannot change mode
A. Check connection of Ground cable and IR Cable.
Check LED lamp is on, if not check connection of POWER cable.
Q. All I got on the screen is black.
A. Check second LED lamp of the interface is on, if not, check A/V
sources connected are working well. (Second lamp indicates AV
sources connected works well.) Check interface connection has
been done well.
Q. Displayed image color is not proper (too dark or unsuitable color)
A. Press ▶button on the remote control for 2 seconds and check how
it goes, if it does not work, inform to manufacturer.
Q. I cannot watch the rear camera on the screen
A. Set the DIP switch #7 as state “ON”.
Q. I cannot switch set mode
A. Check DIP Switch.
Q. OEM image is not displayed.
A. Check interface’s LCD In/Out cable connection. If the status keeps
on, inform to manufacturer.
Q. Screen only displays white color.
A. Check LCD out cable is connected well, if this status keeps, inform
to manufacturer.
Q. After connect CAN cable, set gear “P”, video doesn’t appear.
A. Go to “FACTORY MODE” and check “UTIL-Rear Select”. Change
“LAMP” settings to “CAN” with remote control.
(※LAMP: when connecting Rear-C wire of LAMP power cable to
Backup lights/ CAN : if controlling rear camera with CAN wire)
10
•Trouble shooting
