Solera®Awning Polycord
Fabric Replacement
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0003784
Table of Contents
Introduction ............................................ 2
Safety ................................................... 2
Resources Required ................................... 2
Removal ................................................. 3
Installation .............................................. 4
Maintenance ............................................ 5
Resources Required: .................................. 5
Fabric Care ............................................ 5
Cleaning Awning ....................................... 5
Notes .................................................... 6
Solera®Awning
Polycord Fabric
Replacement
Installation and
Owner’s Manual
(For Aftermarket Applications)
Solera® Awning Polycord Fabric ReplacementSolera® Awning Polycord Fabric Replacement
Part# Description
Various options available Replacement Fabric
NOTE: Replace fabric varies based on width needed and
color desired.

2
lippert.com 432-LIPPERT (432-547-7378) Rev:06.02.23
Solera®Awning Polycord
Fabric Replacement
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0003784
Introduction
The Solera®Awning Polycord Fabric Replacement features
a new sleek look. The new polycord fabric features one
polycord at the roll tube and no longer has a stitch at the hem.
Additional information about this product can be obtained
from lci1.com/support or by downloading the free
LippertNOW app in Apple App Store®for iPhone®and
iPad®and also on Google Play™for Android™users. App
Store®and iPad®are registered trademarks of Apple Inc.
Google Play™and Android™are trademarks of Google Inc.
Information regarding the assembly and components of
this product can be obtained from https://support.lci1.com/
awnings/.
Safety
Read and fully understand all instructions before installing
or operating this product. Adhere to all safety labels.
This manual provides general instructions. Many variables
can change the circumstances of the instructions, i.e., the
degree of difficulty, operation and ability of the individual
performing the instructions. This manual cannot begin
to plot out instructions for every possibility, but provides
the general instructions, as necessary, for effectively
interfacing with the device, product or system. Failure
to correctly follow the provided instructions may result
in death, serious personal injury, severe product and/or
property damage, including voiding of the Lippert limited
warranty.
Resources Required
• 2 to 3 people, depending on task
• 2 Ladders
• Tape measure
• Cordless or electric drill
• Appropriate drive bits
• Zip ties
• 2 Cotter pins
• Non-permanent marker
MOVING PARTS CAN PINCH, CRUSH OR CUT. KEEP
CLEAR AND USE CAUTION.
THE “WARNING” SYMBOL ABOVE IS A SIGN THAT
A SAFETY RISK IS INVOLVED AND MAY CAUSE
DEATH, SERIOUS PERSONAL INJURY AND/OR
SEVERE PRODUCT OR PROPERTY DAMAGE IF
NOT SAFELY ADHERED TO AND WITHIN THE
PARAMETERS SET FORTH IN THIS MANUAL.
FAILURE TO SUPPORT THE ROLL TUBE, FABRIC
AND DRIVE/IDLER HEAD ASSEMBLIES DURING
REMOVAL MAY RESULT IN SERIOUS INJURY OR
PROPERTY DAMAGE.
IF NOT PROPERLY SECURED, THE SUPPORT ARMS
CAN KICK OUT DUE TO PRESSURE FROM THE GAS
STRUT, WHICH MAY RESULT IN SERIOUS INJURY OR
PROPERTY DAMAGE.
THE “CAUTION” SYMBOL ABOVE IS A SIGN THAT
A SAFETY RISK IS INVOLVED AND MAY CAUSE
PERSONAL INJURY AND/OR PRODUCT OR
PROPERTY DAMAGE IF NOT SAFELY ADHERED TO
AND WITHIN THE PARAMETERS SET FORTH IN THIS
MANUAL.

3
lippert.com 432-LIPPERT (432-547-7378) Rev:06.02.23
Solera®Awning Polycord
Fabric Replacement
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0003784
Removal
1. Remove the drip cap (if equipped) from the end which
the fabric will be removed.
2. Fully extend the awning.
3. Disconnect power to any fabric LED lights in the support
arm assembly or remove the fabric LED light strip from the
polycord of the fabric.
4. Retract the awning until there is approximately 12”
remain visible.
5. Secure both support arm assemblies by running a zip
tie around the outer arm and around the pin on the top
of the mount arm where the mount arm and inner arm
connect, (Fig.1A).
6. Remove the screws holding the polycord in place on the
awning rail.
7. Remove the wax screws holding the end caps onto the
drive and idler head shafts, (Fig.2).
FAILURE TO SUPPORT THE ROLL TUBE, FABRIC
AND DRIVE/IDLER HEAD ASSEMBLIES DURING
REMOVAL MAY RESULT IN SERIOUS INJURY OR
PROPERTY DAMAGE.
Fig.1
8. Place the roll tube and fabric on a clean, level surface
that is free of any debris able to scratch or damage the roll
tube and/or fabric.
9. Remove the end cap from the end of the roll tube from
which the fabric will be removed.
10. With one person holding the end of the fabric that gets
attached to the awning rail on the unit, another can rotate
the roll tube to unroll the fabric until only the polycords are
left on the roll tube.
11. Remove the screws holding the polycord in place on
the roll tube.
12. To remove the fabric, gently pull the roll tube from one
end, while another person holds the fabric in place.
Fig.2
A

4
lippert.com 432-LIPPERT (432-547-7378) Rev:06.02.23
Solera®Awning Polycord
Fabric Replacement
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0003784
Installation
1. Unroll the replacement fabric over the old fabric so
that the cord is parallel with the roll tube and to prevent
scratching the fabric.
NOTE: The replacement fabric only has ONE polycord that
inserts into the roll tube.
2. On a clean, level surface free of any debris that could
scratch or damage the roll tube, gently slide the roll tube
onto the polycord of the fabric, making sure that the non-
printed side is touching the roll tube, (Fig.3).
3. Center the fabric on the roll tube.
4. Roll the fabric onto the roll tube, (Fig.4). and reinstall the
fabric screw into the roll tube. Make sure the fabric stays
snug and at to the roll tube with the printed side facing
away from the tube.
FAILURE TO MAINTAIN CONTROL OF THE ROLL
TUBE, FABRIC AND DRIVE/IDLER HEAD MAY
RESULT IN SERIOUS INJURY OR PROPERTY
DAMAGE.
5. Reinstall the end cap previously removed.
6. With help from another person, install the roll tube and
fabric on the awning rail and support arms, making sure
the awning will unroll with the color of the fabric facing up.
7. With help from another person, slide the head on the
assembly shaft into the end cap. Install the wax screws
at each end to secure the roll tube end caps to the head
assemblies.
NOTE: It is suggested to keep the head of the wax screw
1/8” from being fastened flush so as not to compromise the
structural integrity of the wax screw.
8. Extend and retract the awning several times to make
sure that the fabric is square on the roll tube.
Fabric
Fig.3
Polycord in Roll
Tube Channel Slide
fabric
roll tube
roll
valance
Fig.4

5
lippert.com 432-LIPPERT (432-547-7378) Rev:06.02.23
Solera®Awning Polycord
Fabric Replacement
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0003784
9. Secure the fabric in the awning rail no more than 1”
inside the edge of the fabric on both ends using a #6 x ½”
hex head screw. Install the screw down through the awning
rail into the fabric and the polycord, (Fig.5).
awning rail 1”
Fig.5
10. Install the screw (Fig.6A) that was holding the
polycord (Fig.6B) in place on the roll tube. Between
the edge of the fabric (Fig.6C) and the stitching on the
hem. The screw should NOT go through the fabric.
11. Reinstall the drip cap (if previously equipped).
12. Reconnect any light wiring as needed.
NOTE: The fabric LED light strip will need to be installed
on the polycord of the fabric prior to connecting any wiring
previously removed.
Maintenance
Resources Required:
• 5-gallon bucket
• Clean water
• Soft bristle brush with sufficient reach
• ¼cup of dish soap
Fabric Care
If the awning is retracted while wet, extend it and let it dry
as soon as conditions allow before retracting again. This
will help prevent the formation of mildew and add greatly to
the life of the awning. Mildew does not form on the fabric
itself, but on the accumulated dust, dirt and grime.
Cleaning Awning
Periodically clean vinyl or woven acrylic fabric using a
mixture of ¼cup of dish soap and 5-gallons of warm
water. Liberally apply the mixture on the top of the fabric
and retract the awning for 5 minutes. This will apply the
mixture to the bottom of the fabric as well. Extend the
awning and hose off with fresh water. Repeat if necessary.
Allow to dry before retracting.
OVER-SPRAY OF CLEANING SOLUTION CAN CAUSE
EYE AND SENSITIVE SKIN IRRITATION. FLUSH
AFFECTED AREA WITH CLEAN WATER AND SEEK
MEDICAL ATTENTION, IF NECESSARY. WEAR EYE
PROTECTION AND APPROPRIATE PROTECTIVE
CLOTHING TO AVOID PERSONAL INJURY.
