Screen Assist
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0004313
Table of Contents
Introduction ............................................ 1
Purchase Verication .................................. 2
Handle Style ........................................... 2
Door Size .............................................. 2
Safety ................................................... 2
Resources Required ................................... 3
Parts List ................................................ 3
Mounting Options ...................................... 3
Lever Handle Push Bar Installation ................... 4
Removing Original Lever Handle ...................... 4
Sleeve to Bar Installation (Standard Method) .......... 4
Sleeve to Bar Installation (Alternate Method) .......... 5
Completed Lever Push Bar to Door Installation ........ 6
Lever Handle Push Bar Operation .................... 6
Fixed Push Bar Installation ............................ 7
Sleeve to Bar Installation (Standard Method) .......... 7
Sleeve to Bar Installation (Alternate Method) .......... 8
Completed Fixed Push Bar to Door Installation ........ 9
Fixed Push Bar Operation ............................. 9
Notes ................................................... 10
Screen Assist
Installation and
Owner’s Manual
(For Aftermarket Applications)
Introduction
The Screen Assist is a lever handle push bar that allows
you to conveniently and effortlessly open your screen door
in a simple motion. Screen Assist can alternatively be
utilized as a fixed push bar.
Additional information about this product can be obtained
from lci1.com/support or by using the LippertNOW app.
Replacement kits can be ordered from https://store.lci1.
com/ or by using the LippertNOW app.
The myLCI app is available for free on the Apple App
Store®for iPhone®and iPad®and also on Google Play™for
Android™users.
App Store®, iPhone®, and iPad®are registered trademarks
of Apple Inc.
Google Play™and Android™are trademarks of Google Inc.
Screen Assist Aftermarket KitScreen Assist Aftermarket Kit
PNPN DescriptionDescription QtyQty
2021000090 Screen Assist; Rough Opening
(RO) 26-30 IN - Aftermarket Kit
1

2
lippert.com 432-LIPPERT (432-547-7378) Rev: 10.13.21
Screen Assist
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0004313
XX"
Fig.1
Fig.2
doorjamb
A
measure
here
THE “CAUTION” SYMBOL ABOVE IS A SIGN THAT A
PROCEDURE HAS A SAFETY RISK INVOLVED AND
MAY CAUSE PERSONAL INJURY, PRODUCT AND/OR
PROPERTY DAMAGE IF NOT PERFORMED SAFELY
AND WITHIN THE PARAMETERS SET FORTH IN THIS
MANUAL.
THE “WARNING” SYMBOL ABOVE IS A SIGN THAT
AN INSTALLATION PROCEDURE HAS A SAFETY
RISK INVOLVED AND MAY CAUSE DEATH, SERIOUS
PERSONAL INJURY, SEVERE PRODUCT AND/OR
PROPERTY DAMAGE IF NOT PERFORMED SAFELY
AND WITHIN THE PARAMETERS SET FORTH IN THIS
MANUAL.
FAILURE TO FOLLOW INSTRUCTIONS PROVIDED
IN THIS MANUAL MAY RESULT IN DEATH, SERIOUS
PERSONAL INJURY AND/OR SEVERE PRODUCT AND
PROPERTY DAMAGE, INCLUDING VOIDING OF THE
COMPONENT WARRANTY.
ALWAYS WEAR EYE PROTECTION WHEN
PERFORMING SERVICE, MAINTENANCE OR
INSTALLATION PROCEDURES. OTHER SAFETY
EQUIPMENT TO CONSIDER WOULD BE HEARING
PROTECTION, GLOVES AND POSSIBLY A FULL FACE
SHIELD, DEPENDING ON THE NATURE OF THE TASK.
Safety
Read and fully understand all instructions before installing or
operating this product. Adhere to all safety labels.
This manual provides general instructions. Many variables
can change the circumstances of the instructions, i.e., the
degree of difficulty, operation and ability of the individual
performing the instructions. This manual cannot begin to plot
out instructions for every possibility, but provides the general
instructions, as necessary, for effectively interfacing with the
device, product or system.
Door Size
To verify the proper size of the Screen Assist required, just
above the threshold (Fig.2A), at the front of the entry door
opening (NOT the screen door), measure from doorjamb to
doorjamb (Fig.2). Round up approximately 5/8” to determine the
rough opening (RO) door size. The Screen Assist will only fit
doors with rough openings between 26 and 30 inches.
Purchase Verification
Handle Style
The Screen Assist will only function as a lever handle push bar
if installed on screen doors with the handle style in (Fig.1). The
Screen Assist will work as a fixed push bar on screen doors
with any handle style. See Mounting Options section.

3
lippert.com 432-LIPPERT (432-547-7378) Rev: 10.13.21
Screen Assist
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0004313
A
B
C
G
NOTE: Part numbers are shown for identification purposes
only. Not all parts are available for individual sale. All parts
with a link to the Lippert Store can be purchased.
Screen Assist Aftermarket Kit 2021000090Screen Assist Aftermarket Kit 2021000090
PNPN DescriptionDescription QtyQty
A 2020222201 Mount bracket 2
B 2020222199 Push bar lever handle screw
cover
1
C 2020222200 Push bar lever handle 1
D276611 Screw - #8-18 X 1/2 square head,
black
8
E 2020222203 Sleeve 2
F 2020222202 Sleeve - lever handle side 1
G 20203296552 Push bar 1
NOTE: Kit parts will be left over, depending on Mounting
Options (Fig.3 and Fig.4).
Parts List
Fig.3
Mounting Options
parts list E parts list F
Lever Handle Push Bar Mounting Option Parts List
PNPN DescriptionDescription QtyQty
A 2020222201 Mount bracket 1
B 2020222199 Push bar lever handle screw cover 1
C 2020222200 Push bar lever handle 1
D276611 Screw - #8-18 X 1/2 square head,
black
4
E 2020222203 Sleeve 1
F 2020222202 Sleeve - lever handle side 1
G 20203296552 Push bar 1
Lever Handle Push Bar
Fixed Push Bar
Fig.4
parts list E parts list E
Fixed Push Bar Mounting Option Parts List
PNPN DescriptionDescription QtyQty
A 2020222201 Mount bracket 2
D276611 Screw - #8-18 X 1/2 square head,
black
6
E 2020222203 Sleeve 2
G 20203296552 Push bar 1
NOTE: If choosing this option, proceed to Fixed Push Bar
Installation instructions.
Resources Required
• Cordless or electric drill or
screw gun
• Appropriate drive bits
• Small flat blade screwdriver
• Non-permanent method of
marking
• Measuring tape
E
F
D

4
lippert.com 432-LIPPERT (432-547-7378) Rev: 10.13.21
Screen Assist
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0004313
Fig.7
ball pocket
mount bracket
back view shown
to depict ball
Sleeve to Bar Installation (Standard Method)
1. Insert the ball of the non-lever side sleeve into the
pocket of the mount bracket (Fig.7).
2. Slide the sleeves over the ends of the push bar (Fig. 8)
Fig.5
Fig.6
screw cover
original inside lever handle
push bar inside lever handle
Lever Handle Push Bar
Installation
These steps detail how to install the lever-style push bar to
the inside of the door frame.
Removing Original Lever Handle
Prior to the installation of the lever handle push bar, the
original lever handle must be removed and replaced with
the shorter push bar lever handle that fits into the receiver
sleeve.
1. Using a small at blade screwdriver, remove the
screw cover on the original lever handle on the inside of
the door (Fig.5), then remove the screw.
2. Remove the original inside door lever handle (Fig.5).
3. Install the new push bar lever handle on the inside of the
door, noting the location of the insertion line (Fig.6). Hold
the lever handle on the opposite side to keep it from falling
out while installing the new lever handle.
4. Reinsert the screw and tighten, then install the new
screw cover.
screw
cover
3. From inside the screen door, dry t the assembly to the
door’s width. Insert the lever side sleeve up to the insertion
line (Fig.6) on the inside push bar lever handle (Fig.9) and
align the mount bracket (Fig.7) on the door hinge side so
that the bar rests parallel to the frame of the door.
4. Mark the push bar dimensions with a non-permanent
marker (Fig.9).
insertion
line
Fig.9
Fig.8
mark
center of raised portion of
screen door frame
insertion line
NOTE: Choose one of the following methods to install the
sleeves to the push bar. The standard method begins here
and the alternate method begins on page 5. Both methods
for installing the sleeves to the push bar will utilize the
same method for mounting the completed bar to the door.
parts list F
parts list E

5
lippert.com 432-LIPPERT (432-547-7378) Rev: 10.13.21
Screen Assist
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0004313
5. Move the assembly to a stable work surface and
measure from the ends of the push bar to each mark made
previously in step 4. (Fig. 10A, Fig. 10B)
6. Add these measurements together, then divide that
sum by 2. Then, using a non-permanent marker make
new marks on each end of the push bar equal to this new
number. Example: If measurement (Fig. 10A) = 1 ½” and
measurement (Fig. 10B) = 3”, adding them equals 4 ½”.
Then, 4 ½” divided by 2 equals 2 ¼”. Re-apply marks on
each end of the bar at 2 ¼”.
NOTE: This centers the push bar between the sleeves,
ensuring that there is an equal amount of bar for strength
inside each sleeve.
Fig.11
measure measure
marks
Fig.10
7. Slide the sleeves onto each end of the push bar to the
new marks and, using the supplied screws, fasten the
sleeves to the push bar. (Fig.11). The push bar is now
complete.
NOTE: Ensure that care is taken when measuring and
fastening the push bar to the sleeves. The screw creates
a hole in the bar, and once installed, small adjustments
cannot be made.
Sleeve to Bar Installation (Alternate Method)
NOTE: Additional assistance may be needed for this
method.
1. Measure to nd center point on the push bar. Mark the
center point with a non-permanent marker (Fig 12).
2. Slide sleeves over the ends of the push bar (Fig.12).
Fig.12
center mark
B B
X” X”
Fig.13
center
3. From inside the screen door, dry t the assembly to the
door’s width. Insert the lever side sleeve up to the insertion
line on the inside push bar lever handle (Fig. 13A) and align
the mount bracket on the door hinge side so that the bar
rests parallel to the frame of the door (Fig. 13). The sleeve
mount bracket should be centered vertically on the raised
portion of the screen door frame (Fig. 13).
4. Adjust the push bar in the sleeves and measure to
make sure an equal amount of bar (X”) is showing from
the center mark made in step 1 to the start of the each
sleeve (Fig. 13). This ensures there is an equal amount of
bar inside each sleeve for strength. Mark on the bar where
the sleeves start with a non-permanent marker (Fig.13B).
You may need additional assistance to hold the assembly
in place while the measurements are taken and marks are
made.
Parallel A
center
A B

6
lippert.com 432-LIPPERT (432-547-7378) Rev: 10.13.21
Screen Assist
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0004313
insertion line
Fig.14
Completed Lever Push Bar to Door Installation
1. Insert the lever side sleeve up to the insertion line on the
inside push bar lever handle (Fig.15). The sleeve should rest
at the insertion line on the lever handle.
NOTE: If a sliding panel is present on the door, ensure that
it is out of the way during the Screen Assist installation to
avoid any accidental damage to the sliding panel. If the
sliding panel is all the way to the hinge side of the door,
damage from installing the bracket will occur.
5. Move the assembly to a stable work surface and install
the sleeves to the marked dimensions using the provided
screws (Fig.14). The push bar is now complete.
NOTE: Ensure that care is taken when measuring and
fastening the push bar to the sleeves. The screw creates
a hole in the bar, and once installed, small adjustments
cannot be made.
Fig.15
screw
screw
Fig.16
Fig.17
crossbar
mount
bracket
center of raised portion of
screen door frame
parallel
2. Mount the bracket on the screen door to the center of
the raised portion of the screen door frame (Fig.16).
NOTE: As a guide during installation, the bottom of the
mount bracket will rest near the top of the mid-door
crossbar and the push bar should be parallel to the
crossbar (Fig.13). Adjust as needed.
3. Using two of the supplied screws secure the mount
bracket to the screen door. (Fig.17). The assembly is now
complete
Lever Handle Push Bar
Operation
To operate the Screen Assist, push down on the lever
handle push bar to unlatch the door.

7
lippert.com 432-LIPPERT (432-547-7378) Rev: 10.13.21
Screen Assist
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0004313
Fixed Push Bar Installation
These steps detail how to install the fixed-style push bar to
the inside of the door frame.
NOTE: Be sure to install two Parts List E sleeves (Fig.19).
See the Mounting Options section on page 3 (Fig. 4).
NOTE: Choose one of the following methods to install the
sleeves to the push bar. The standard method begins here
and the alternate method begins on page 8. Both methods
for installing the sleeves to the push bar will utilize the
same method for mounting the completed bar to the door.
Sleeve to Bar Installation (Standard Method)
1. On both sleeves, insert the ball of the sleeve into the
pocket of the mount bracket (Fig.18).
2. Slide the sleeves over the ends of the push bar (Fig. 19)
ball
pocket
mount bracket
back view shown
to depict ball
Fig.18
Fig.19
mark
Fig.20
center of raised portion of
screen door frame
5. Move the assembly to a stable work surface and
measure from the ends of the push bar to each mark made
previously in step 4 (Fig. 21A, Fig. 21B).
6. Add these measurements together, then divide that
sum by 2. Then, using a non-permanent marker, make
new marks on each end of the push bar equal to this new
number. Example: If measurement (Fig. 21A) = 1 ½” and
measurement (Fig. 21B) = 3”, Adding them equals 4 ½”.
Then, 4 ½” divided by 2 equals 2 ¼”. Re-apply marks on
each end of the bar at 2 ¼”.
NOTE: This centers the push bar between the sleeves,
ensuring that there is an equal amount of bar for strength
inside each sleeve.
3. From inside the screen door, dry t the assembly to
the door’s width. Align the mount brackets (Fig.20) on both
sides of the screen door so that the bar rests parallel to the
frame of the door. Each sleeve mount bracket should be
centered vertically on the raised portion of the door frame.
(Fig. 20).
4. Mark the push bar dimensions using a non-permanent
marker (Fig.20).
measure measure
marks
Fig.21
parts list E
A B

8
lippert.com 432-LIPPERT (432-547-7378) Rev: 10.13.21
Screen Assist
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0004313
Fig.22
Sleeve to Bar Installation (Alternate Method)
NOTE: Additional assistance may be needed for this
method
1. Measure to nd center point on the push bar. Mark the
center point with a non-permanent marker (Fig. 23).
2. Slide sleeves over the ends of the push bar (Fig.23).
7. Slide the sleeves onto each end of the push bar to the
new marks and, using the supplied screws, fasten the
sleeves to the push bar. (Fig.22).
NOTE: Ensure that care is taken when measuring and
fastening the push bar to the sleeves. The screw creates
a hole in the bar and, once installed, small adjustments
cannot be made.
4. Adjust the push bar in the sleeves and measure to make
sure an equal amount of bar (X”) is showing from the
center mark made in step 1 to the start of the each sleeve
(Fig. 25). This ensures there is an equal amount of bar
inside each sleeve for strength. Mark on the bar where
the sleeves start with a non-permanent marker (Fig.25A).
You may need additional assistance to hold the assembly
in place while the measurements are taken and marks are
made.
3. From inside the screen door, dry t the assembly to the
door’s width. Align the mount brackets on both sides of the
screen door so that the bar rests parallel to the frame of
the door. Each sleeve mount bracket should be centered
vertically on the raised portion of the door frame. (Fig. 20).
Fig.23
center
mark
Fig.24
center of raised portion of
screen door frame
center mark
A A
X” X”
Fig.25

9
lippert.com 432-LIPPERT (432-547-7378) Rev: 10.13.21
Screen Assist
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0004313
Fixed Push Bar Operation
1. The xed push bar can be used as needed to assist in
opening or closing the screen door in conjunction with the
existing screen door handle.
X”
B
A
cross bar
Fig.26
center of raised
portion of
screen door frame
X”
A
B
cross bar
Fig.27
center of raised
portion of
screen door frame
Completed Fixed Push Bar to Door Installation
1. Determine a preferred height for mounting the xed push
bar Screen Assist.
2. Measure from the top of the crossbar to the top
hole in the mount bracket on each side of the push bar
(Fig.27, Fig.28). Ensure the measurements are identical on
both sides so that the bar is installed level to the door.
3. Mark the location of the top holes in the center of the
raised portion of the screen door frame (Fig.27, Fig.28).
NOTE: If a sliding panel is present on the door, ensure that
it is out of the way during the Screen Assist installation to
avoid any accidental damage to the sliding panel. If the
sliding panel is all the way to the hinge side or non-hinge
side of the door, damage from installing the bracket will
occur.
4. Using a cordless or electric drill or screw gun, install the
top screws into the mount bracket (Fig.27A, Fig.28A).
5. Install the bottom screws (Fig.27B, Fig.28B). The
Assembly is now complete.
5. Move the assembly to a stable work surface and install
the sleeves to the marked dimensions using the provided
screws (Fig.26).
NOTE: Ensure that care is taken when measuring and
fastening the push bar to the sleeves. The screw creates
a hole in the bar, and once installed, small adjustments
cannot be made.
Fig.28

10
lippert.com 432-LIPPERT (432-547-7378) Rev: 10.13.21
Screen Assist
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0004313
Notes

11
lippert.com 432-LIPPERT (432-547-7378) Rev: 10.13.21
Screen Assist
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0004313

12
lippert.com 432-LIPPERT (432-547-7378) Rev: 10.13.21
Screen Assist
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0004313
Manual information may be distributed as a complete
document only, unless Lippert Components provides
explicit consent to distribute individual parts.
All manual information is subject to change without
notice. Revised editions will be available for free
download at lippert.com. Manual information is
considered factual until made obsolete by a revised
version.
Please recycle all obsolete materials and contact
Lippert Components with concerns or questions.
