Introduction
Tire Linc®is a tyre pressure and temperature monitoring
system (TPMS)� The TPMS issues an alert via the
OneControl BT®app when a caravan’s tyre(s) pressure or
temperature falls out of the programmable range�
Key System Components
• Sensors - Stem mount, 1295 kPa (188 psi) maximum
pressure reading, -50 to 205 °C (-58 to 401 °F)
temperature measurement range—Stem Sensor
Working Range: 85 to -20 °C (185 to -4 °F)�
• Repeater - Receives sensor data, communicates with
phone app via Bluetooth Low Energy (BLE)�
• Repeater Dock - Provides power to repeater, which
“docks” to this base�
• OneControl BT App - Displays real-time tyre pressures,
temperatures and visual alerts for faults�
NOTE: Images used in this document are for reference
only when assembling, installing and/or operating this
product� Actual appearance of provided and/or purchased
parts and assemblies may differ�
Tire Linc AU Aftermarket KitsTire Linc AU Aftermarket Kits
PNPN DescriptionDescription
2020130644 Tire Linc®AU 4-stem sensor kit with repeater dock
2020130643 Tire Linc®AU 4-stem sensor kit without repeater
dock
2020130630 Tire Linc®AU 2-stem sensor kit with repeater dock
2020130627 Tire Linc®AU 2-stem sensor kit without repeater
dock
2020130645 Tire Linc® AU stem sensor 1-pack kit
Mobile phone not included

2
lippert.com 432-LIPPERT (432-547-7378) Rev: 09.29.21
Tire Linc®AU
Tyre Pressure & Temperature
Monitoring System 2.0
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0004069
Additional information about this product can be obtained
from lci1�com/support or by using the LippertNOW app�
App Store®for iPhone®and iPad®and also on Google
Play™for Android™users�
App Store®, iPhone®, and iPad®are registered trademarks
of Apple Inc�
Google Play™and Android™are trademarks of Google Inc�
Safety
Read and fully understand all instructions before installing
or operating this product� Adhere to all safety labels� This
manual provides general instructions� Many variables
can change the circumstances of the instructions,
e�g�, the degree of difficulty, operation and ability of
the individual performing the instructions� This manual
cannot begin to plot out instructions for every possibility,
but provides the general instructions, as necessary, for
effectively interfacing with the device, product or system�
Failure to correctly follow the provided instructions may
result in death, serious personal injury, severe product
and/or property damage, including voiding of the LCI
limited warranty�
THE “WARNING” SYMBOL ABOVE IS A SIGN AN
INSTALLATION PROCEDURE HAS A SAFETY RISK AND
MAY CAUSE DEATH OR SERIOUS PERSONAL INJURY,
SEVERE PRODUCT AND/OR PROPERTY DAMAGE IF
NOT PERFORMED SAFELY AND WITHIN PARAMETERS
SET FORTH IN THIS MANUAL.
THE “CAUTION” SYMBOL ABOVE IS A SIGN AN
INSTALLATION PROCEDURE HAS A SAFETY RISK
INVOLVED AND MAY CAUSE PERSONAL INJURY,
PRODUCT AND/OR PROPERTY DAMAGE IF NOT
PERFORMED SAFELY AND WITHIN THE PARAMETERS
SET FORTH IN THIS MANUAL.
Parts List
LetterLetter PNPN DescriptionDescription
A 808485 TPMS Repeater
B 806880 Repeater Dock
C 808506 Stem Sensor
D 2020002102 Stem Sensor Tool (Separates into two
parts)
E 2020003005 Lock Nut Wrench (Optional use)
F 2020001333 Lock Nut and O-Ring Kit (Optional use)
G 2020001329 O-Ring (Part of F)
H 2020001330 Lock Nut (Part of F)
NOTE: Part numbers are shown for identification purposes
only� Not all parts are available for individual sale�
A
B
C D
E
G
H
F

3
lippert.com 432-LIPPERT (432-547-7378) Rev: 09.29.21
Tire Linc®AU
Tyre Pressure & Temperature
Monitoring System 2.0
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0004069
Repeater Dock Installation
Install Tire Linc on a non-prepped caravan as follows:
NOTE: Non-prepped caravans do not have a repeater
dock installed; prepped caravans do� If a repeater dock is
installed, go to Installation and Setup section�
1. Locate a mounting area inside the caravan that allows
connection of the Tire Linc repeater dock (Fig.1A) to the
unit’s 12V power source before the battery disconnect/
constant power source without creating a strain on the
completed connection�
NOTE: Connecting Tire Linc to a power source past the
disconnect will turn off the Tire Linc system if the power
source is turned off during transport�
NOTE: The Tire Linc repeater dock MUST be
mounted vertically�
NOTE: Film covering the repeater posts MUST remain
in-place until the repeater is installed�
2. Repeater dock mounting MUST be located in the
closest compartment to the tow vehicle, e�g�,the front
compartment, that is free of any metal or obstructions that
could interfere with the signal and hinder reception�
3. Vertically orient the repeater dock and secure it to the
wall with two (non-supplied) M4 self-tapping pan head
screws (Fig.1B)�
Fig.1
Resources Required
• OneControl BT®app
• Cordless or electric drill or screw gun
• Appropriate drive bits
• Two M4 self-tapping pan head screws
• Wire strippers
• Appropriate electrical connectors
A
B
C
D
4. Make sure power to the caravan is off, then connect the
repeater dock’s red power wire (Fig.1C) and black ground
wire (Fig.1D) to system power and ground as follows:
A. If necessary, use wire strippers to expose enough bare
wire to make a good connection�
B. Use appropriate electrical connectors to create
good connections�
C. Make sure there is a 15A maximum circuit protection
placed in-line between the power supply and the
repeater dock�

4
lippert.com 432-LIPPERT (432-547-7378) Rev: 09.29.21
Tire Linc®AU
Tyre Pressure & Temperature
Monitoring System 2.0
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0004069
Installation and Setup
1. Locate and remove lm cover from repeater
dock (Fig.2A)�
NOTE: The film cover should only be removed when ready
to install the repeater�
2. Snap the repeater (Fig.2B) into the repeater dock (Fig.2C)�
NOTE: The repeater dock is keyed and the repeater can
only be snapped in one way�
Fig.2
3. The repeater will power on, lighting up the Status LED
(Fig.2D), blinking to indicate the repeater has power�
4. If the Status LED does not light up, check the in-line
fuse to the dock to ensure the dock has power�
5. Use the small tip of a tool or tip of a pen and push and
hold for ve seconds, then release the Pair Mode button
(Fig.2E)� The Status LED will turn on solid for one second,
then blink twice to indicate it’s in pairing mode�
Connect OneControl BT App to Repeater
1. Download the LCI OneControl BT app for either an iOS
or Android smart phone�
2. After the LCI OneControl BT app has been downloaded,
tap the OneControl BT icon (Fig.3A) to launch the app�
Fig.3
Fig.4
3. Read and accept the License Agreement (Fig.4)� Tap I
Accept button to continue�
A
C
A
B
D
E

5
lippert.com 432-LIPPERT (432-547-7378) Rev: 09.29.21
Tire Linc®AU
Tyre Pressure & Temperature
Monitoring System 2.0
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0004069
Fig.5
4. OneControl BT requires location permission to nd and
connect to available networks (Fig.5)� Tap Continue button
to proceed with setup�
Fig.6
5. Allow OneControl BT access to the device’s location
(Fig.6)� Make a selection to move forward with setup�
Tapping the Deny button will stop the process� Fig.7
6. Look for Tire Linc and press the listing� If more than one
Tire Linc option appears in the list, select the one with the
strongest RSSI value. The RSSI value shown in gure 7
(-37dB) is displayed at the end of the listing� For example,
to determine a stronger RSSI value:
A. -60 is greater than -70; select -60 because it is the
stronger number�
B. 20 is greater than 10; select 20 because it is the
stronger number�
RSSI value
7. When the screen indicates the RV has successfully
connected (Fig.8), tap the Continue button to proceed
with setup�
Fig.8

6
lippert.com 432-LIPPERT (432-547-7378) Rev: 09.29.21
Tire Linc®AU
Tyre Pressure & Temperature
Monitoring System 2.0
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0004069
8. Tap the SETUP COACH button (Fig.9A) to continue�
A
9. Select a vehicle class (Fig.10) then tap CONTINUE�
Fig.9
10. Select a vehicle layout (Fig.11) then tap FINISH�
Fig.11
Fig.10

7
lippert.com 432-LIPPERT (432-547-7378) Rev: 09.29.21
Tire Linc®AU
Tyre Pressure & Temperature
Monitoring System 2.0
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0004069
front
rear
Stem Sensor Pairing Sequence
The pairing sequence for stem sensors (Fig.13) is
as follows:
1. SINGLE AXLE: Stem sensors for a single-axle caravan
MUST be paired in the following order: Left front (Fig.14A),
right front (Fig.14C)�
2. DOUBLE AXLE: Stem sensors for a double-axle
caravan MUST be paired in the following order: Left
front (Fig.14A), left rear (Fig.14B), right front (Fig.14C), right
rear (Fig.14D)�
11. Finish setup by tapping the arrow to the right of Learn
Sensors (Fig.12A)�
NOTE: Users must scroll down the screen in order to view
the Learn Sensors option at the bottom of the page�
Fig.12
A
Fig.14
Fig.13
A
B
C
D

8
lippert.com 432-LIPPERT (432-547-7378) Rev: 09.29.21
Tire Linc®AU
Tyre Pressure & Temperature
Monitoring System 2.0
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0004069
Use Smart Phone to Pair Sensors to Repeater
NOTE: If a wrong caravan type is chosen or there is a new
caravan configuration, see Troubleshooting section for
factory reset�
The OneControl BT app on the smart phone will indicate
in specific order which tyre the stem sensor cap should be
installed: Front Left, Rear Left, Front Right, Rear Right, etc�
1. Have stem sensors (Fig.13) available to install on the tyre
stems and remove any existing stem caps from the tyres�
NOTE: If using the lock nuts as a theft deterrent, add the
lock nuts to the tyre stems but make sure there is room to
add the sensors� Lock nuts will be tightened later� The lock
nuts are optional and are not required to be installed�
2. Pair stem sensors to the repeater as follows:
A. Select the Learn Sensors arrow (Fig.15A) in the TYRE
PRESSURE app screen if not having done so already� The
app will display a list of tyres with instructions to screw the
first stem sensor onto the Front Left tyre stem (Fig.16)�
B. Install a stem sensor onto the tyre stem in the proper
sequence (Fig.16) and wait for the smart phone to indicate
the sensor was found (Fig.17A)�
NOTE: It may take up to 90 seconds for the sensor to
awake and be found�
C. If the sensor is not seen within 90 seconds, unscrew the
sensor from the tyre stem, wait approximately 10 seconds
and then reinstall the sensor� Do not proceed to install any
other sensors until the app shows the sensor found�
D. After the sensor has been found, the app will indicate
the next tyre sensor to be paired (Fig.17B)�
3. Repeat steps 2B, 2C and 2D until all sensors are
learned (Fig.18)�
Fig.15 Fig.16
A

9
lippert.com 432-LIPPERT (432-547-7378) Rev: 09.29.21
Tire Linc®AU
Tyre Pressure & Temperature
Monitoring System 2.0
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0004069
4. Tap the FINISHED button (Fig.18A) to exit TYRE
PRESSURE Sensor Conguration mode.
Pressing FINISHED exits configuration mode and
redisplays the TYRE PRESSURE screen� Do NOT tap
the Learn Sensors button again� Doing so resets Tire Linc
into configuration mode, which requires uninstalling the
stem sensors�
NOTE: To exit learn mode, tap the back arrow and the
sensors will not be forgotten�
A
NOTE: When learning has been completed, the low and
high pressure limits of the tyres are estimated at +/- 20%
of the last received sensor data� Make sure sensors are
not removed during the learning process or the pressure
limit values will be incorrectly estimated� Pressure and
temperature limits can be set through the app after
learning has been completed�
NOTE: If installing the optional lock nut as a theft deterrent,
loosen stem sensor slightly and hand tighten lock nut
against the sensor� Using wrench provided in kit, hold
lock nut in position and hand tighten stem sensor against
lock nut�
A
B
Fig.17 Fig.18

10
lippert.com 432-LIPPERT (432-547-7378) Rev: 09.29.21
Tire Linc®AU
Tyre Pressure & Temperature
Monitoring System 2.0
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0004069
Operation
When stem sensors are under pressure, data is
transmitted to the repeater, when tyres are:
• moving/rotating, every one minute;
• not moving/not rotating, every 15 minutes�
1. If using the LCI OneControl BT ap for either an iOS or
Android smart phone do as follows:
A. Tap the OneControl BT icon to launch the app�
B. The app will automatically detect the Tire Linc system�
NOTE: If necessary, follow the online prompts to set up
Tire Linc within the OneControl BT app�
2. The smart phone will connect to the repeater and the
app will display a caravan image with tyre pressures and
temperatures�
3. With the OneControl BT app running, real-time tyre
event notications will be sent to the smart phone (Fig. 19)�
4. Tap the notication to be taken to the TPMS screen
in OneControl BT to visually see which tyre(s) is/are
experiencing an event�
Fig.19

11
lippert.com 432-LIPPERT (432-547-7378) Rev: 09.29.21
Tire Linc®AU
Tyre Pressure & Temperature
Monitoring System 2.0
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0004069
5. Tap the readout button (Fig.20A) of a tyre to launch its
properties window� Within the selected tyre’s properties
window, various tyre and sensor specications can be
observed and altered�
A. Last data received posts the date and time the app
last received tyre monitoring system information�
B. Pressure posts the currently-sensed pressure of
the selected tyre�
C. Temperature posts the currently-sensed
temperature of the selected tyre�
D. Battery Level posts the current battery voltage of
the sensor’s battery�
Fig.20
A
UNDER OR OVER PRESSURIZED TYRES CAN
CAUSE UNFORESEEN, DETRIMENTAL EFFECTS
ON TYRES AND UNIT, INCLUDING UNDESIRABLE
TREAD WEAR. TYRES SHOULD ALWAYS BE
PRESSURIZED TO WITHIN THE MANUFACTURER’S
RECOMMENDATIONS.
E. Minimum/Maximum Pressure Threshold posts
the currently programmed minimum and maximum
pressure limits for the selected tyre�
F. Maximum Temperature Threshold posts the
currently programmed maximum temperature limit for the
selected tyre�
G. Maximum Temperature Change posts the
currently programmed maximum +/- temperature change
limit for the selected tyre�
Tyre Limits Example
Programmable tyre limits have a “next” arrow (>)
that, when tapped, opens that feature’s scrollable window
of available settings� Scroll through the limits window to
find the desired setting, select it, then tap the “back” arrow
(<) (Fig.21A) located above the tyre’s name at the top of the
window’s heading�

12
lippert.com 432-LIPPERT (432-547-7378) Rev: 09.29.21
Tire Linc®AU
Tyre Pressure & Temperature
Monitoring System 2.0
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0004069
Fig.21
Fig.22
A
The following example illustrates the interaction between
the various tyre settings and how the resulting information
is relayed by the monitoring system for display in the app�
NOTE: The Alert Indicator uses LED flashes and audible
(beep) tones to deliver tyre event notifications�
1. Select a tyre by tapping its information button to launch
its settings window  FRONT LEFT TYRE�
A. In this example, the reported current tyre Pressure is
listed as “58 psi” (Fig.21)�
NOTE: Stem Sensor Pressure Reading Tolerance: +/-1�5
psi (+/-10�3 kPa)� For example—because of differences in
accuracy and conversion between a Stem Sensor and a
tyre gauge—actual tyre pressure at 38 psi (262 kPa) may
be reported by the Stem Sensor as 36 psi (248�2 kPa)
while the tyre gauge may report 40 psi (275�8 kPa)�
B. Compare the tyre’s minimum/maximum pressure range
(46 - 68 psi) against the reported tyre pressure (58 psi)�
Make sure tyre pressures are within recommended limits�
C. If the Minimum Pressure Threshold requires
adjusting, tap the next arrow to launch its settings window�
Scroll through the window to a desired limit and select it
(Figs.21 and 23)�
D. If the Maximum Pressure Threshold requires
adjusting, tap the next arrow to launch its settings window�
Scroll through the window to a desired limit and select it
(Figs.21 and 24)�
E. The Maximum Temperature Threshold and the
Maximum Temperature Change can also be adjusted
(Figs.22, 25 and 26)� Scroll through the window to access
the temperature adjustments�
NOTE: Stem Sensor Temperature Reading Tolerance:
+/-3 °C (+/-5�4 °F)� For example, if a Stem Sensor reports
tyre temperature at 29 °C (85 °F), actual tyre temperature
may be 32–26 °C (90�4–79�6 °F)�
NOTE: Stem Sensor Working Range: 85 to -20 °C
(185 to -4 °F)�

13
lippert.com 432-LIPPERT (432-547-7378) Rev: 09.29.21
Tire Linc®AU
Tyre Pressure & Temperature
Monitoring System 2.0
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0004069
Fig.23
Fig.24
Fig.25
Fig.26

14
lippert.com 432-LIPPERT (432-547-7378) Rev: 09.29.21
Tire Linc®AU
Tyre Pressure & Temperature
Monitoring System 2.0
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0004069
Configure All Sensors
As an option to configuring sensors individually, all the
sensors can be configured simultaneously�
1. Press the arrow by Congure All Sensors (Fig.27A)�
2. The next screen will feature settings for all
programmable limits (Fig.28)� Select the arrow to the right
of the setting to establish pressure and temperature
thresholds for all the sensors�
Fig.27 Fig.28
A

15
lippert.com 432-LIPPERT (432-547-7378) Rev: 09.29.21
Tire Linc®AU
Tyre Pressure & Temperature
Monitoring System 2.0
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0004069
Troubleshooting
Remove Stem Sensor to Change Battery
Removal of the stem sensor battery can be completed with
the included stem sensor tool� The stem sensor tool, which
is taken apart to utilize, is comprised of two pieces molded
to match the tops and bottoms of the stem sensors� Slightly
rotate the pieces opposite of each other and then carefully
pry them apart to separate� One piece is used on top
of the stem sensor and one piece of the tool is used on
the bottom�
If the stem sensor batteries fail, replace them as follows:
1. Remove stem sensor from tyre stem�
NOTE: If using the optional lock nuts as a theft deterrent,
use the supplied wrench to hold the lock nut while
unscrewing the sensor from the tyre stem�
Changing Units of Measure
To change the units of measure—to/from Imperial/Metric—
go to the TYRE PRESSURE screen:
1. Tap the Settings icon (gear) (Fig. 9B)�
2. From the SETTINGS screens, tap the Units option�
3. The SETTINGS screen will display the current units of
measure�
4. Tap the arrow right of the Units setting�
5. On the TEMPERATURE SCALE window, tap the
desired unit of measure—°F–Fahrenheit or °C–Celsius�
NOTE: Unit of measure for temperature and pressure
(psi/kPa) will change according to the selection made�
6. Tap the back arrow above the screen title to return to the
SETTINGS screen�
NOTE: Displayed units of measure will change to match
the newly selected units�
7. Tap the back arrow above the screen title to return to the
HOME screen�
2. Using the stem sensor tool with a piece on top and a
piece on the bottom of the stem sensor, unscrew the top
cap of the stem sensor to expose the battery�
3. Replace battery with CR1632 3V lithium coin battery�
NOTE: Replacement batteries are not included�
4. Replace supplied stem sensor O-ring when
replacing battery�
Missing Stem Sensor
If a Stem Sensor becomes loose or is missing from a tyre,
the readout button (Fig. 20A) will be grayed out� Tighten the
loose sensor or replace with new�
Factory Reset
In the event a wrong caravan type is chosen or if there is a
new caravan configuration, the settings can be reset�
1. Press and hold the pair button on the repeater for
approximately 10 seconds�
2. Continue holding the button until there is one long red
blink followed by four red blinks�
3. Release button�
No Power
If system is not working, check the in-line fuse to the
repeater dock to ensure the dock has power�
Learn Sensors Procedure Resets System
Do NOT tap the Learn Sensors button� Doing so resets
Tire Linc into configuration mode, which requires
uninstalling the stem sensors�

16
lippert.com 432-LIPPERT (432-547-7378) Rev: 09.29.21
Tire Linc®AU
Tyre Pressure & Temperature
Monitoring System 2.0
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0004069
Manual information may be distributed as a complete
document only, unless Lippert Components provides
explicit consent to distribute individual parts�
All manual information is subject to change without
notice� Revised editions will be available for free
download at lippert�com� Manual information is
considered factual until made obsolete by a revised
version�
Please recycle all obsolete materials and contact
Lippert Components with concerns or questions�
Notes
