LITESHEET BriteCor AC BHBC User manual

BHBC BriteCor AC
Direct High Bay
Installation Manual

BHBC BriteCor High Bay Installation Manual
Page 2of 4
NOTES
•WARNING –Risk of fire or electric shock.
•WARNING - It is recommended that installation be
performed by a certified electrician.
•All electrical connections must be in compliance with local
codes, ordinances or the national electrical code (NEC).
Contact your municipal building department to learn about
your local codes, permits and/or inspections.
•Do not connect this Luminaire to an electrical system that
does not provide means for equipment grounding. Never
use a fixture in a two-wire system that is not grounded.
•If dimming functionality is included, use only with
Litesheet approved dimmers.
•This unit is not approved for use in ducted ceilings.
•Do not use excessive force when manipulating cables and
wires.
•WARNING –To prevent wiring damage or abrasion, do not
pinch wires between surfaces.
•WARNING –Only connect Luminaire to the voltage
indicated by the Luminaire label. It is intended for direct
connection to this voltage. DO NOT connect to a different
or unknown voltage.
Document #: 11-00026
Rev: E
Date: 4/28/2022

LiteSheet Solutions
Page 3of 4
CONTENTS OF KIT
•BHBC / BHBCG3 High bay luminaire
TOOLS AND ADDITIONAL PARTS REQUIRED
•Hanging Assembly
•¼” Hex or flat head drive.
Preparation
1. Turn off power source.
2. Remove luminaire from packaging.
Installation
1. Remove access plate. Set aside for later.
2. Hang from approved jack chain, aircraft cable
or other approved mounting devices. Use
access holes as shown in the image on Page 2.
a) Do not surface mount and maintain a
minimum clearance of 18” from the ceiling
for proper airflow.
b) For easy aircraft cable insertion, insert
round stop button before inserting the
toggle paddles.
NOTE FOR STEM MOUNTING –Mounting
chain or cable is required for stability.

BHBC BriteCor High Bay Installation Manual
Page 4of 4
Installation (Cont.)
3. Knock out hole on access plate to allow
power into the fixture. (For stem mounting,
use the center knockout. Attach stem rod
through 7/8” knockout hole.)
4. Attach and secure NEC approved strain relief.
5. Attach black wire to black port on luminaire
disconnect.
a) Must use 18 AWG or larger Solid Wire
6. Attach white wire to white port on luminaire
disconnect.
a) Must use 18 AWG or larger Solid Wire
7. Attach green ground wire to green ground
screw on the access plate.
8. Secure access plate to fixture.
For warranty information and
technical support, contact us at:
434-446-1460
