LIVARNO LUX 102618 Technical specifications

IAN 102618
LED GLASS SHELF LIGHTING
LED-GLASBODENBELEUCHTUNG
Montage-, Bedienungs- und Sicherheitshinweise
LED-GLASHYLDEBELYSNING
Monterings-, betjenings- og sikkerhedshenvisninger
LED-BELYSNING FÖR
GLASHYLLPLAN
Monterings-, bruks- och säkerhetsanvisningar
LED GLASS SHELF LIGHTING
Assembly, operating and safety instructions
LED-VALO LASIHYLLYIHIN
Asennus-, käyttö- ja turvallisuusohjeet
ÉCLAIRAGE LED POUR
FOND EN VERRE
Instructions de montage, d‘utilisation et
consignes de sécurité
LED-GLASPLAATVERLICHTING
Montage-, bedienings- en veiligheidsinstructies

GB/IE Assembly, operating and safety instructions Page 3
FI Asennus-, käyttö- ja turvallisuusohjeet Sivu 16
SE Monterings-, bruks- och säkerhetsanvisningar Sidan 30
DK Monterings-, betjenings- og sikkerhedshenvisninger Side 43
FR/BE Instructions de montage, d‘utilisation et
consignes de sécurité Page 56
NL/BE Montage-, bedienings- en veiligheidsinstructies Pagina 70
DE/AT/CH Montage-, Bedienungs- und Sicherheitshinweise Seite 84

3GB/IE
Intended use......................................................Page 4
Parts description ............................................Page 4
Technical data...................................................Page 5
Scope of delivery...........................................Page 6
Safety notes.......................................................Page 6
Safety notice concerning batteries..........................Page 8
Safety advice for installation...................................Page 9
Before initial use
Mounting ..................................................................Page 10
Preparing the product for use
Switching the lamp on/off......................................Page 11
Controlling the light effects with the
remote control ..........................................................Page 11
Changing the battery.................................Page 13
Cleaning and Care........................................Page 13
Disposal.................................................................Page 13
Warranty..............................................................Page 15

4 GB/IE
LED Glass shelf lighting
Intended use
This product is suitable for providing decorative illumination
in indoor use. It is indended for clipping onto glass shelfs with
a thickness approx. 5–8mm. This product is intended for use
in private, domestic environments only and not for commercial
purposes.
Not suitable for ordinary lighting in household
room illumination.
Parts description
1LED driver
2Plug-in mains adapter with connection lead
3Double-sided adhesive tape
4Connector box
5Metal clip with LEDs
6Remote control
7Screw

5GB/IE
8Battery (type: CR 2025, 3 V )
9Battery drawer
Technical data
LED Glass shelf lighting
Operating voltage: 12V , 4x max. 0.5 W
Nominal capacity: max. 0.5W per clip (Note: The
bulbs cannot be replaced.)
Protection category:
TÜV/GS tested
Mains adapter
Primary rated voltage: 220–240V∼, 50 Hz
Secondary rated voltage: 12V , 0.5A
Protection category:
Model No. SBA-RCRGB120518
Remote control
Battery: 3V , type CR 2025
Max. range: ca. 6–8m

6 GB/IE
Scope of delivery
4 Metal clips with LEDs
1 LED driver with connector box
1 Plug-in mains adapter
1 Remote control
1 Battery (already installed)
2 Screws
2 Pieces of double-sided adhesive tape
1 Set of operating instructions
Safety notes
Before using the product, please familiarise yourself with all of
the safety information and instructions for use. When passing
this product on to others, please also include all the documents.
RISK OF FATAL INJURY!
During installation keep children away from the
area in which you are working. A large number
of screws and other small parts are included with delivery.
These may prove life-threatening if swallowed or inhaled.
This appliance can be used by children aged from 8 years
and above and persons with reduced physical, sensory or

7GB/IE
mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction concerning
use of the appliance in a safe way and understand the
hazards involved. Children shall not play with the appli-
ance. Cleaning and user maintenance shall not be made
by children without supervision.
WARNING: The extremely high speed of the light
change during the colour change effect can under cer-
tain circumstances result in visual impairment of children or
predisposed persons (e.g. by mental illness).
Avoid the danger of death
from electric shock:
Before use, ensure that the available mains voltage is the
same as the required operating voltage for the device
(220–240V∼, 50Hz).
Always check the product for damage before connecting
it to the power supply.
Never use the product if you find it damaged in any way.
This product does not contain any parts that can be ser-
viced by the user. The LEDs cannot be replaced.
Protect the product from sharp edges, mechanical stress
and hot surfaces.

8 GB/IE
Safety notice concerning
batteries
DANGER TO LIFE!
Batteries are not intended for children. If accidentally
swallowed seek immediate medical attention.
CAUTION!
EXPLOSION HAZARD!
Never recharge non-rechargeable batteries and do not
short-circuit and/ or open any batteries.
Never throw batteries into fire or water.
Do not exert mechanical loads to batteries.
If you do not observe these instructions, the battery could
be discharged beyond the cut-off voltage. This will then
pose a risk of leaking. If a battery has leaked, please
remove it instantly from the appliance to avoid damage.
Avoid contact with the skin, eyes and mucous membranes.
In the event of contact with battery acid, thoroughly flush
the affected area with clean water and seek immediate
medical attention.
Avoid extreme conditions and temperatures which may
impact batteries, e.g. on radiators.

9GB/IE
Remove the battery from the device if it is not going to be
used for a prolonged period.
Use only the recommended battery type!
When inserting the battery ensure the correct polarity!
This is shown in the battery compartment.
If necessary, clean the batteries and device contacts
before inserting batteries.
Promptly remove drained batteries from the product.
Safety advice for installation
Do not use any sharp and/or pointed objects, such as
wire, nails or clamps, to fasten the product in place.
The plug must be plugged into an easily accessible
socket, to ensure the plug can be unplugged easily in an
emergency.
The luminaire is not suitable for mounting on tubular
material.

10 GB/IE
Before initial use
Mounting
First install all the separate components of the light as
shown in Figure A.
Note: You can fit the LED driver 1of the light for glass
edge lighting using either the screws 7or using the
double-sided adhesive tape 3.
If you choose installation using double-sided adhesive
tape, please remove the protective foil from the back first
and stick it to the intended area, pressing firmly.
Make sure that the surface is clean, dry, smooth and free
of grease.
Insert the short edge of the metal clip with LED 5under
the glass and twist it to slip it onto the glass (see Fig. B).
Carefully move the metal clip with LED all the way onto
the glass.
Note: Always make sure that the LED touches the edge
of the glass, this might otherwise affect the lighting
effects.
The battery of the remote control 6is already inserted.
Remove the insulating stripes from the battery compart-
ment before first use.

11GB/IE
Preparing the product for use
Switching the lamp on/ off
Press the ON button of the remote control 6, to switch
the light on.
Press the OFF button of the remote control to switch the
light off.
Note: The OFF switch of the remote control is only suita-
ble for short term switching off of the light.
Pull the plug in mains adapter 2from the mains socket
to switch off the light permanently.
Controlling the light effects with the
remote control
Note: The infrared sensor is on the opposite side to the
battery compartment. The receiver is on the LED driver 1.
The range is approx. 6–8m
Note: For all light functions except STROBE and FADE the
intensity can be adjusted.
Ensure that there are no obstacles between the sender
and the receiver.

12 GB/IE
The following functions are available:
Button : Increase light intensity in 8 steps
Button : Reduce light intensity in 8 steps
Button : set red light
Button : set green light
Button : set blue light
Button : set white light
: select pre-mixed colours
Button FLASH: 7 colours flash
Button STROBE: stronger and weaker getting white light
Button FADE: flowing colour change
Button SMOOTH: RGB colours flash

13GB/IE
Changing the battery
If the range of the remote control 6is reduced, you must
change the battery (see Fig. C).
For this, pull the battery drawer 9from the remote control.
Remove the battery 8.
Insert the new battery.
Note: The correct polarity is depicted on the back of
the remote control.
Push the battery drawer back into the remote control.
Cleaning and Care
CAUTION! DANGER OF ELECTRIC SHOCK!
First unplug the plug from the socket.
Only use a dry, lint-free cloth for cleaning.
Disposal
The packaging is made from environmentally
friendly materials, which may be disposed through
your local recycling facilities.

14 GB/IE
Contact your local authorities for information on how to
dispose of the product at the end of product life.
Never dispose of the product/the article in your
regular household waste. Dispose of the device/
article at an authorised disposal centre or at your
local council disposal facility. Observe the appli-
cable regulations. In case of doubt, please contact
your waste disposal centre.
Defective or used batteries must be recycled in accordance
with Directive 2006/ 66 /EC. Return batteries and/ or the
device to a local recycling facility.
Pb
Improper disposal of batteries can harm
the environment!
Never dispose of batteries in your household waste. They may
contain toxic heavy metals and are subject to hazardous waste
regulations. The chemical symbols of the heavy metals are:
Cd = cadmium, Hg = mercury, Pb = lead. Therefore dispose
of used batteries through your municipal collection site.

15GB/IE
Warranty
The device has been manufactured to strict quality guidelines
and meticulously examined before delivery. In the event of
product defects you have legal rights against the retailer of
this product. Your legal rights are not limited in any way by
our warranty detailed below.
The warranty for this device is 3 years from the date of purchase.
Should this device show any fault in materials or manufacture
within 3 years from the
date of purchase, we will repair or replace
it – at our
choice – free of charge to you.
The warranty period begins on the date of pur chase. Please
keep the original sales receipt in a safe location.
This document is
required as your proof of purchase. This warranty becomes
void if the device has been damaged or improperly used or
maintained.
The warranty applies to faults in material or manufacture. This
warranty does not cover product parts subject to normal wear,
thus possibly considered con
sumables (e.g. batteries) or for dam-
age to fragile parts, e.g. switches, rechargeable batteries or
glass parts.

16 FI
Määräystenmukainen käyttö............. Sivu 17
Osien kuvaus..................................................... Sivu 17
Tekniset tiedot................................................... Sivu 18
Toimituksen sisältö........................................ Sivu 18
Turvallisuusohjeet.......................................... Sivu 19
Paristojen turvallisuusohjeet...................................... Sivu 21
Asennusta koskevat turvallisuusohjeet ..................... Sivu 22
Toimenpiteet ennen
käyttöönottoa
Asennus ..................................................................... Sivu 23
Käyttöönotto
Valaisimen päälle- ja pois päältä kytkentä.............. Sivu 24
Valotehosteiden ohjaaminen kaukosäätimellä........ Sivu 24
Pariston vaihto................................................. Sivu 26
Puhdistus ja hoito........................................... Sivu 26
Hävittäminen..................................................... Sivu 27
Takuu........................................................................ Sivu 28

17FI
LED-valo lasihyllyihin
Määräystenmukainen käyttö
Tuote on tarkoitettu tunnelmalliseksi koristevalaisimeksi sisäti-
loihin. Se voidaan kiinnittää n. 5–8mm paksuihin lasilevyihin.
Tuote on tarkoitettu vain kotikäyttöön, ei kaupalliseen käyttöön.
Tämä tuote ei sovellu kodin normaaliin huone-
valaistukseen.
Osien kuvaus
1LED-ohjain
2Pistokeverkkolaite ja liitäntäjohto
3Kaksipuolinen teippi
4Liitäntärasia
5Metallikiinnitin ja ledit
6Kaukosäädin
7Ruuvi
8Paristo (tyyppi CR 2025, 3V )
9Paristolokero

18 FI
Tekniset tiedot
LED-lasilevynvalaisin
Käyttöjännite: 12V , 4x kork. 0,5W
Nimellisteho: kork. 0,5W per kiinnitin
(Huomio: lamppuja ei voi vaihtaa
uusiin.)
Suojausluokka:
TÜV/GS testattu
Verkkolaite
Ensisijainen nimellisjännite: 220–240V∼, 50 Hz
Toissijainen nimellisjännite: 12 V , 0,5A
Suojausluokka:
Mallinro SBA-RCRGB120518
Kaukosäädin
Paristo: 3V , tyyppi CR 2025
Maksimikantama: n. 6–8m
Toimituksen sisältö
4 metallikiinnitintä, jossa ledit
1 LED-ohjain ja liitäntärasia

19FI
1 pistokeverkkolaite
1 kaukosäädin
1 paristo (valmiiksi asennettu)
2 ruuvia
2 kpl kaksipuolista teippiä
1 käyttöohje
Turvallisuusohjeet
Tutustu ennen tuotteen käyttöä huolellisesti kaikkiin käyttö- ja
turvallisuusohjeisiin. Anna kaikki ohjeet tuotteen mukana mah-
dolliselle uudelle omistajalle.
HENGENVAARA! Pidä
huolta, että lapset eivät oleskele työskentely-
alueella asennuksen aikana. Toimitukseen kuu-
luu koko joukko ruuveja ja muita pienosia. Nämä voivat
nieltynä tai hengitettynä olla hengenvaarallisia.
Laitetta voivat käyttää 8 vuotta täyttäneet lapset sekä
henkilöt, jotka ovat fyysisiltä tai psyykkisiltä kyvyiltään tai
aisteiltaan rajoittuneita tai joilla ei ole kokemusta tai tie-
toa laitteen käytöstä, jos he käyttävät laitetta valvonnan
alaisina tai heitä on opastettu laitteen turvallisessa käy-
tössä ja he ovat tietoisia laitteeseen liittyvistä vaaroista.

20 FI
Lapset eivät saa leikkiä laitteella. Lapset eivät saa puhdis-
taa tai huoltaa laitetta ilman valvontaa.
HUOMIO: valon nopea vaihtuminen saattaa aiheuttaa
lapsille tai henkisesti kuormitetuille henkilöille (esim.
psyykkisesti sairaille) muun muassa häiriöitä näkökyvyssä.
Vältä sähköiskusta aiheutuvaa
hengenvaaraa:
Varmista ennen käyttöä, että käytettävissä oleva verkko-
jännite vastaa laitteen vaatimaa käyttöjännitettä (220–
240V∼, 50Hz).
Tarkista aina ennen verkkoon liittämistä, ettei tuotteessa
ole vaurioita.
Älä milloinkaan käytä tuotetta, jos havaitset siinä jotain
vikoja.
Tuote ei sisällä osia, jotka käyttäjä voisi itse huoltaa.
Lamppuja ei voi vaihtaa uusiin.
Suojaa tuote teräviltä reunoilta, mekaaniselta rasitukselta
ja kuumilta pinnoilta.
