Ltech WiFi-101-RGBW User manual

Operating Instruction
WiFi-101-RGBW
WiFi-101-CT
Model:
Living room
lights
Bedroom
lights
Corridor
lights
Dining room
lights
System Diagram
Wireless router
Internet
WiFi
WiFi
L-Home
cloud service
3G/ 4G
APP
…
Amazon
Echo
TmallGenie

Model WiFi-101-RGBW
Product Parameters
WiFi LED Controller
12 ~ 24Vdc
RGBW LED lights
3A x 4CH Max. 12A
(0~36...72W)x4CH
WiFi 2.4GHz , IEEE 802.11b/g/n
2.4GHz
-30 55
L125 x W33 x H20(mm)
L127 x W35 x H24(mm)
70g
°C ~ + °C
Product Name
Out Control
Current Load
Output Power
Network Type
RF Frequency
Working Temp.
Dimension
Packing
Gross Weight
Input Voltage
WiFi LED controller can be connected with
lamps directly, support remote control via
intelligent device, smart speaker, mobile
phone etc.
warranty
5 years
WiFi-101-CT
CT LED lights
Max. 6A
0~72W...144W
33mm
120mm
20mm
125mm
Product Structure
DC power supply socket
(φ5.5mm x φ2.5mm)
12~24Vdc
power input
LED lamp
connection socket
The running light
Power indicator
Setting key
Long press 6s to
default setting

Product Installation
WiFi-101-RGBW
WiFi-101-CT
LED strip
Power adapter
220/110Vac
24V+
WW
NW
Load power below
240W, use this round
adapter socket for
connection.
Operating Guidance
iOS / Android
Scan QR code to download the APP via
mobile phone.
After installation, the strip flashes within
30s when powered on and then the
controller is ready to the configuration
status accordingly.
1
2

4
3Open the APP, click icon in the top
right corner.
Enter the interface "Add Device", choose
"Color light" or “CT light” and follow the
prompts to connect, once successfully
that will immediately open intelligent
life and realize long-distance control via
mobile phone.

5
Please click “ Smart speaker” in the
“setting” interface, choose TmallGenie or
Amazon Echo and connect according to
the prompts.
Smart speaker & WiFi LED controller
work together:
Attention
www.ltech-led.com Update time: 2019.07.23_A0
1.
serviced by the qualified person.
2.This product is non-waterproof. Please
avoid the sun and rain. When installed
outdoors, please ensure it is mounted in a
water proof enclosure.
3.Good heat dissipation will prolong the
life time of the controller. Please ensure
good ventilation.
4.Please check if the output voltage of the
LED power supply used comply with the
working voltage of the product.
5. Please make sure the diameter of the
wire must be sufficient to load the
connected LED lights with firm wire
connection.
6. Ensure all wire conn ect ion s an d
polarities are correct before connecting
with power to avoid any damages to the
LED lights.
7.If errors caused, please do not attempt
to fix this product by yourself, please
contact the supplier.
The product shall be installed and
No further notice if any changes in the manual.
Product function depends on the goods.
Please feel free to contact your supplier if any question.
