LUCCI Air AIRFUSION A Owner's manual

V1.4 Published on 07. 2017
LUCCI
AIRFUSION TYPE A
DC CEILING FAN
INSTALLATION
OPERATION
MAINTENANCE
WARRANTY INFORMATION
CAUTION
READ INSTRUCTIONS CAREFULLY FOR SAFE
INSTALLATION AND FAN OPERATION.

Airfusion Type A Installation Instructions
1 | P a g e
THANK YOU FOR PURCHASING
Thankyou for purchasing the latest in energy saving ceiling fans. This fan runs on DC (direct current) power which
gives it the benefit of being super energy efficient whilst still maintaining high volume air-movement and silent
operation.
Energy saving - The DC motor is the latest technology in fan design. Its highly efficient motor saves up to 65% more
energy than ceiling fans with traditional AC motors.
Silent operation –This DC fan motor is programmed with a stabilized current which efficiently reduces motor noise.
Low operating temperature –The DC power is managed effectively which brings down the motor operating
temperature to less than 50degs. This results in a much cooler motor than a standard AC fan and increases the
longevity of the motor.
12 speed remote control. Regular AC ceiling fans usually come with only 3 speeds, this DC fan comes complete with
a 12 speed remote, which gives greater choice of comfort levels.
SAFETY PRECAUTIONS
1. In Europe: This appliance can be used by children aged from 8 years and above and persons with reduced
physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision
or instruction concerning the use of the appliance in a safe way and understand the hazards involved. Cleaning
and maintenance shall not be undertaken by children without supervision.
2. In Australia: The appliance is not intended for use by persons (including children) with reduced physical, sensory
or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or
instruction concerning the use of the appliance by a person responsible for their safety.
3. Children should be supervised to ensure that they do not play with the appliance.
4. An all-pole disconnection switch must be incorporated into the fixed wiring, in accordance with local wiring rules.
IN AUSTRALIA
WARNING:
FOR SAFE USE OF THIS FAN AN ALL-POLE DISCONNECTION
MUST BE INCORPORATED INTO THE FIXED WIRING IN
ACCORDANCE WITH THE WIRING RULES.
As outline in clause 7.12.2 of AS/NZS 60335-1 for meeting the
minimum electrical safety of this standard.
Please note warranty will be void if installation is without a means for
an all-pole disconnection incorporated in the fixed wiring in accordance
with the wiring rules.

Airfusion Type A Installation Instructions
2 | P a g e
Example: If a fan is connected to a circuit that can be isolated via an
all-pole safety switch at the switchboard, then this is considered to be
an all-pole disconnection to the ceiling fan electrical circuit, meeting the
requirements of clause 7.12.2 of AS/NZS 60335.1.
A single-pole switch on the active of the receiver input of remote
control must also be included in the wiring, and located the same
room as the ceiling fan.
5. Do not dispose of electrical appliances as unsorted municipal waste, use separate collection facilities.
Contact your local government for information regarding the collection systems available. If electrical appliances
are disposed of in landfills or dumps, hazardous substances can leak into the groundwater and get into the food
chain, damaging your health and well-being.
6. The structure to which the fan is to be mounted must be capable of supporting a weight of 40kg.
7. The fan should be mounted so that the blades are at least 2.3m above the floor in Europe or 2.1m above the floor
in Australia.
8. This fan is designed for indoor use only. Mounting the fan in a location where it is subject to water or moisture is
a hazard and will void the warranty.
9. Only a licensed electrician should execute the installation.

Airfusion Type A Installation Instructions
3 | P a g e
BEFORE INSTALLATION
Unpack your fan and check contents. You should have the following:
1
Canopy x 1
2
Down rod x 1
3
Coupling cover x 1
4
Motor assembly x 1
5
Blades x 3
6
Bottom cover x 1
7
Plastic anchors x 2
8
Blades screws x10
9
Wood screws x 2
10
Balance kit x 1 set
11
Remote x 1 set (2 x 1.5VDC AAA Battery included)
Fig. 1

Airfusion Type A Installation Instructions
4 | P a g e
INSTALLING THE FAN
TOOLS REQUIRED:
- Phillips / flat head screwdriver
- Pair of pliers
- Adjustable spanner
- Step ladder
- Wire cutter
- Wiring, supply cable as required by local provincial and national wiring codes and regulations.
INSTALLING THE MOUNTING BRACKET
The ceiling fan must be installed in a location so that the blades are 300mm spacing from the tip of the blade to the
nearest objects or walls.
Secure the hanging bracket to the ceiling joist or structure that is capable of carrying a load of at least 40kg, with two
long screws provided. Ensure at least 30mm of the screw is threaded into the support.
NOTE: The bracket screws provided are for use with wooden structures only. For structures other than wood,
the appropriate screw type MUST be used.
ANGLED CEILING INSTALLATION
This fan hanging system supports a maximum 18 degree angled
ceiling installation.
Fig. 2
Fig. 3

Airfusion Type A Installation Instructions
5 | P a g e
HANGING THE FAN MOTOR ASSEMBLY
Lift the fan assembly onto the mounting bracket. Fig. 4
Ensure the notch of the ball joint is positioned on the stopper of the mounting bracket to prevent the fan from
rotating when in operation. Fig. 5
PREPARE AND COMPLETE THE ELECTRICAL WIRING --- WIRING DIAGRAM (FIG. 6)
WARNING: FOR YOUR SAFETY ALL ELECTRICAL CONNECTIONS MUST BE UNDERTAKEN BY A LICENSED
ELECTRICIAN.
NOTE: AN ADDITIONAL ALL POLE DISCONNECTION SWITCH MUST BE INCLUDED IN THE FIXED WIRING.
PLEASE MAKE SURE THE MAIN SWITCH HAS BEEN TURNED OFF BEFORE CONNECTING.
NOTE: IF THERE ARE TWO OR MORE DC CEILING FANS INSTALLED IN THE ONE LOCATION, AN ISOLATION
SWITCH IS REQUIRED FOR EACH CEILING FAN. THIS IS REQUIRED WHEN PROGRAMMING THE REMOTE
AND RECEIVER TO PAIR TOGETHER.
Fig. 6
Fig. 4
Fig. 5

Airfusion Type A Installation Instructions
6 | P a g e
INSTALL CANOPY
Loosen the 2 screws from the bottom of the mounting bracket. Fig. 7
Slide the canopy up to the mounting bracket and place the key hole on the canopy over the screw on the
mounting bracket, turn the canopy until it locks in place at the narrow section of the key holes and secure it
by tightening the two set screws. Avoid damaging the electrical wiring prepared previously.
BLADE INSTALLATION
Insert the blade screws through the blade then secure the blade to the motor by tightening the 3 screws.
Fig.8
Repeat this process to install the other blades to the motor.
Finally install the bottom cover to the shaft by rotating it clockwise. Fig. 9
USING YOUR CEILING FAN
Pairing Transmitter and Receiver
NOTE: Ensure that you have installed a single pole disconnection switch in the fixed wiring for each fan.
NOTE: Ensure power to the receiver is ON prior to pairing the transmitter with the receiver.
Turn OFF the mains supply to the receivers of the ceiling fan.
Install the 2 x1.5V DC battery in the compartment. Please make sure the polarity of the battery is correct.
Fig.10
Fig. 7
Fig. 8
Fig. 9

Airfusion Type A Installation Instructions
7 | P a g e
Turn on the power to fan.
Press and hold the “ ” button of transmitter for 3-5 seconds within 60 seconds of switching the power
ON to the receiver of ceiling fan.
If the fan has light kit attached, the light will flash on and off to indicate the pairing process is activated.
Turn ON and change the speed of the ceiling fan by the transmitter to check the operation and
successful pairing.
Note: The fan supports control by up to 2 transmitter. To reset the fan to only can be controlled by
one transmitter, do the pairing process twice, but press and hold the “ ” button of transmitter
more than 10 seconds.
Pairing Transmitter and Receiver –when 2 or more DC ceiling fans are installed in one location
When two or more fans are located near each other, you may want to have the receiver/transmitter for each fan set to
a different remote, so that the operation of one fan does not affect the operation of the other fan/s.
Transmitter/Receiver pairing for ceiling fan 1:
Turn OFF the mains supply to the receivers of both ceiling fans 1 and 2.
Install the 2 x 1.5VDC batteries in the compartment. Please make sure the polarity of the battery is correct.
Turn on the power to receiver 1. Keep the power OFF to receiver 2. (Each ceiling fan must have its own
isolation switch, so that only the ceiling fan that needs to be paired with the transmitter will be ON).
Press and hold the “ ” button on transmitter 1 for 3-5 seconds within 60 seconds of switching the power to
the receiver of ceiling fan 1.
Turn ON and change the speed of the ceiling fan 1 by the transmitter to check the operation and successful
pairing.
Setting DC Ceiling fan 2:
Turn off the mains supply to the receivers of both ceiling fans 1 and 2.
Install the 2x1.5VDC batteries in the compartment. Please make sure the polarity of the battery is correct.
Turn on the power to receiver 2. Keep the power OFF to receiver 1. (Each ceiling fan must have its own
isolation switch, so that only the ceiling fan that needs to be paired with the transmitter will be ON).
Press and hold the “ ” button on transmitter 2 for 3-5 seconds within 60 seconds of switching the power to
the receiver of ceiling fan 2.
TurnONand change the speed of ceiling fan 2 by the transmitter to check the operation and successfulpairing.

Airfusion Type A Installation Instructions
8 | P a g e
Remote Control Buttons
: FAN ON/OFF BUTTON (A):
Press the button to turn the fan on/off.
Press and hold the button for 3 seconds within 60 seconds of switching the power to the receiver for pairing the
transmitter and receiver.
+: SPEED INCREASE BUTTON (B): Press the button to increase the fan speed. The LED indicator (D) will indicate
the fan speed (1-12 speed) accordingly.
-: SPEED DECREASE BUTTON (C): Press the button to decrease the fan speed. The LED indicator (D) will indicate
the fan speed (1-12 speed) accordingly.
: LED INDICATOR (D):
Indicates the fan current fan speed level (1-12 speed).
Indicates the current timer setting time (1 hour, 2 hours, 4 hours, 8
hours).
: REVERSE FUNCTION BUTTON (E): Press the button to activate the
reverse running function. The fan must be operating to activate the reverse
function.
NOTE: When the fan can NOT detect the rotary redirection it will stop,
just press the “ ” button two times to activate the fan again.
: FAN TIMER BUTTON (F): Press the button to start programming the
timer to switch the fan off automatically, or to cancel the timer. Press the
button to set timer at 1h →2h →4h →8h →Timer OFF. The LED indicator
(D) will indicate the fan timer (1H, 2H, 4H, and 8H) accordingly.
Fig. 10
Fig. 12

Airfusion Type A Installation Instructions
9 | P a g e
: LIGHT CONTROL BUTTON (G):Press the button to turn on/off the light.
: LIGHT DELAY BUTTON (H): Press the button to activate the light delay function, which will turn off the light 3
minutes later.
REPAIRING THE FAN RECEIVER & REMOTE
Should the remote and receiver lose control after installation or during use, the pairing of the remote and the receiver
must be repaired. Below are the operating symptoms and method to repair the pairing of the DC ceiling fan remote
and receiver.
Issues:
Loss of control - Fan is only running at high speed after installation
Loss of control - No reverse function after installation
Loss of control - Remote cannot communicate with the receiver
Solution:
Switch off the main power to ceiling fan.
Press and hold the “ ” button on transmitter for 3 seconds within 60 seconds of switching the power to the
receiver of the ceiling fan.
Turn ON and change the speed of the ceiling fan by the transmitter to check the operation and successful
paring.
AFTER INSTALLATION
WOBBLE:
Note: Ceiling fans tend to move during operation due to the fact that they are mounted on a rubber grommet. If the
fan was mounted rigidly to the ceiling it would cause excessive vibration. Movement of a few centimeters is quite
acceptable and does not suggest any problem.
TO REDUCE THE FAN WOBBLE: Please check that all screws which fix the mounting bracket and down rod are
secure.
BALANCING KIT: A balancing kit is provided to balance the ceiling fan on initial installation. Please refer to the
instruction on how to use the balancing kit. The balancing kit can be used to assist re-balancing should the ceiling fan
become un-balanced again. Store your balancing kit away after installation for future use if required.
NOISE:
When it is quiet (especially at night) you may hear occasional small noises. Slight power fluctuations and frequency
signals superimposed in the electricity for off-peak hot water control, may cause a change in fan motor noise.
This is normal. Please allow a 24-hour “settling-in” period, most noises associated with a new fan disappear during
this time.

Airfusion Type A Installation Instructions
10 | P a g e
The manufacturer’s warranty covers actual faults that may develop and NOT minor complaints such as hearing the
motor run –all electric motors are audible to some extent.
CARE & CLEANING
Periodic cleaning of your ceiling fan is the only maintenance required. Use a soft brush or lint free cloth to avoid
scratching the paint finish. Please turn off electricity power when you do so.
Do not use water when cleaning your ceiling fan. It could damage the motor or the blades and create the possibility
of an electrical shock.
The motor has a permanently lubricated ball bearing. There is no need to oil.
NOTE: Always turn off the power at the mains switch before attempting to clean your fan.
TECHNICAL INFORMATION
AIRFUSION
SERIES TYPE A
DC FAN models
Rated Voltage
Rated power
(motor)
Battery for remote
60”blade fan only
220-240VAC
35W
2 x 1.5Vdc AAA

Airfusion Type A Installation Instructions
11 | P a g e
LUCCI CEILING FAN WARRANTY DETAIL
LUCCI WARRANTY HOTLINE- 1800 602 243
THIS WARRANTY IS VALID IN AUSTRALIA ONLY
In the event of service being required, please call the Lucci Fan Warranty Hotline on 1800 602 243 between 9am &
5pm (EST) Monday to Friday. Please make sure you have all the ceiling fan details filled out at the end of the manual
before making the call.
Every Lucci ceiling fan is thoroughly inspected and tested before being released for sale. In addition to any warranty
rights or conditions under statutory regulations, Lucci warrants all of its ceiling fans against defective workmanship
and faulty materials for twenty four (24) months from the date of purchase. Lucci undertakes, at its option, to repair or
replace, free of charge, each product or part thereof on condition that;
1. The fan or relevant part has not been subjected to misuse, neglect, or been involved in an accident.
2. The repairs are not required as a result of normal wear and tear.
3. The product was installed by a licensed electrical contractor.
4. A copy of the original receipt of purchase is presented.
5. 12 month warranty applies when used in any non-domestic applications.
6. This warranty does not cover stains, scratch and scuff marks, or dents if the product is purchased through a
factory outlet or to refurbished items.
Our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You are entitled to a
replacement or refund for a major failure and compensation for any other reasonably foreseeable loss or damage. You
are also entitled to have the goods repaired or replaced if the goods fail to be of acceptable quality and the failure
does not amount to a major failure.
Lucci Design cannot be held responsible for any repair other than those carried out by it or one of its
Authorised Service Agents. Please keep this warranty information in a safe place. This information must be
produced in the event of service being required.
Distributed by:
Beacon Lighting
140 Fulton Drive
Derrimut, Victoria, 3030
Australia
Ph [phone]
Fax [phone]
Email: [e-mail]

Airfusion Type A Installation Instructions
12 | P a g e
CEILING FAN WARRANTY INFORMATION
LUCCI WARRANTY HOTLINE- 1800 602 243
Complete and retain this form for your personal records and warranty purposes.
NAME…………………………………………………………………………………
ADDRESS……………………………………………………………………………
……………………………………………………POSTCODE……………………
MODEL NUMBER……………………………………………………………………
(PO# + DATECODE Sticker here)
PO NUMBER or DATECODE ………………………………………………………
DATE OF PURCHASE………………………………………………………………
INSTALLING LICENSED ELECTRICAN……………………………………………
…………………………………………………………………………………………
LICENCE No…………………………………………………………………………
ATTACH PROOF OF PURCHASE HERE
THIS COMPLETED DETAILPAGE SHOULD BE PRODUCED AND FAXED TO THE
WHOLESALER OR THEIR AUTHORISED AGENTS BEFORE OBTAINING
WARRANTY SERVICE
