Airfusion HAVANA Installation Instructions
2 | P a g e
THANK YOU FOR PURCHASING
Thank you for purchasing this quality Lucci product. To ensure correct function and safety, please read and
follow all instructions carefully before assembly, installation and use of this ceiling fan. Please keep
instructions for future reference.
SAFETY PRECAUTIONS
1. In Europe: This appliance can be used by children aged from 8 years and above and persons with reduced
physical, sensory or mental capabilities or lack of experience and knowledge if they have been given
supervision or instruction concerning the use of the appliance in a safe way and understand the hazards
involved. Cleaning and maintenance shall not be undertaken by children without supervision.
2. In Australia: The appliance is not intended for use by persons (including children) with reduced physical,
sensory or mental capabilities, or lack of experience and knowledge, unless they have been given
supervision or instruction concerning the use of the appliance by a person responsible for their safety.
3. Children should be supervised to ensure that they do not play with the appliance.
4. An all-pole disconnection switch must be incorporated into the fixed wiring, in accordance with local wiring
rules.
IN AUSTRALIA
WARNING:
FOR SAFE USE OF THIS FAN AN ALL-POLE DISCONNECTION
MUST BE INCORPORATED INTO THE FIXED WIRING IN
ACCORDANCE WITH THE WIRING RULES.
As outline in clause 7.12.2 of AS/NZS 60335-1 for meeting the
minimum electrical safety of this standard.
Please note warranty will be void if installation is without a means for
an all-pole disconnection incorporated in the fixed wiring in accordance
with the wiring rules.

Airfusion HAVANA Installation Instructions
3 | P a g e
Example: If a fan is connected to a circuit that can be isolated via an
all-pole safety switch at the switchboard, then this is considered to be
an all-pole disconnection to the ceiling fan electrical circuit, meeting the
requirements of clause 7.12.2 of AS/NZS 60335.1.
A single-pole switch on the active of the receiver input of remote
control must also be included in the wiring, and located the same
room as the ceiling fan.
5. Do not dispose of electrical appliances as unsorted municipal waste, use separate collection facilities.
Contact your local government for information regarding the collection systems available.
6. If electrical appliances are disposed of in landfills or dumps, hazardous substances can leak into the
ground water and get into the food chain, damaging your health and well-being.
7. The structure to which the fan is to be mounted must be capable of supporting a weight of 16kg.
8. The fan should be mounted so that the blades are at least 2.3 m above the floor in Europe or 2.1 m above
the floor in Australia. (Refer to the ‘Clearance requirement’ section for more information.)
9. This fan is suitable for indoor and alfresco areas where the fan is fully undercover with a minimum of 2
walls. This fan is not waterproof. When installed in an alfresco area, the ceiling fan must be positioned in
a location protected from water, wind, dust and salt. Exposure to these elements will void the warranty.
Mounting the fan in a situation where it is subject to water or moisture is dangerous and may increase the
risk of damage, injury or electrical shock and will void the warranty.
10. Must be assembled and installed by a licensed electrician.
11. WARNING: If unusual wobbling or oscillating movement is observed, immediately stop using the ceiling
fan and contact the manufacturer, its service agent or suitably qualified persons.
12. The replacement of parts of the safety suspension system device shall be performed by the manufacturer,
its service agent or suitably qualified persons.
13. The fixing means for attachment to the ceiling such as hooks or other devices shall be fixed with a
sufficient strength to withstand 4 times the weight of the ceiling fan; that the mounting of the suspension
system shall be performed by the manufacturer, its service agent or suitably qualified persons.

Airfusion HAVANA Installation Instructions
4 | P a g e
PARTS LIST
•Unpack your ceiling fan carefully. Remove all parts and hardware.
•Lay out all the components on a smooth surface and make sure there are no components missing before
assembling. If parts are missing, return the complete product to the place of purchase for inspection or
replacement.
•Check whether the ceiling fan has been damaged during transport. Do not operate/install any product
which appears damaged in any way. Return the complete product to the place of purchase for inspection,
repair or replacement.
•Examine all parts, you should have the following:
1 Mounting bracket x 1
2 Fan motor assembly x 1
3 Fan blade bracket x 1
4 Fan bladesx 3
5 Fan blades fixing cap x 3
6 Fan blades screw x 9 (and 1 spare)
7 Screw for mounting bracket x 2
8 Remote receiver x 1 set
9 Remote transmitter x 1 set
Fig. 1

Airfusion HAVANA Installation Instructions
5 | P a g e
CLEARANCE REQUIREMENT
•The fan must be installed so that the lowest point of the fan blade must be 2.1m from the floor (In Australia);
2.3m from the floor (In Europe).
NOTE: The lowest point of the fan blade is when the fan head is adjusted to 45°.
•The ceiling fan must be installed in a location so that the blades are a minimum1M spacing from the tip of
the blade to the nearest objects or walls.
NOTE: Please be aware of that the fan head can be oscillating 60°. Please take this into
consideration when selecting the installation location.
Fig. 2

Airfusion HAVANA Installation Instructions
6 | P a g e
INSTALLATION OF THE MOUNTING BRACKET
•Install the hanging bracket to the ceiling joist or structure that is capable of carrying a load of at least 16kg,
with the two long screws provided. Ensure at least 30mm of the screw is threaded into the support. (Fig. 3)
NOTE: The bracket screws provided are for use with wooden structures only. For structures other
than wood, the appropriate screw type MUST be used. Ensure the screws used are suitable for the
mounting surface and the surrounding environment.
ANGLED CEILING INSTALLATION
This fan hanging system supportsa maximum
13 degree angled ceiling installation. (Fig.4)
Fig. 4
Fig. 3
16
KG

Airfusion HAVANA Installation Instructions
7 | P a g e
INSTALLATION OF THE FAN BLADES
•Align the 3 mounting holes on the blade (3) to the 3 mounting holes of the blade bracket (2);
•Insert the fixing cap (4) into the mouting holes from the bottom of the blade (3) and secure by tightening
the 3 screws (1) from the top of the blade bracket (2);
•Once completed, repeat the same process on the remaining blades.
•Install the assembled fan-blades (7) to the motor part (5);
•Tighten the 2 set screws (6) on the side of the motor shaft;
Fig. 5
Fig. 6

Airfusion HAVANA Installation Instructions
8 | P a g e
HANGING THE FAN
Lift the fan assembly onto the mounting bracket. Ensure thekey slot (A) of the hanger ball is positioned on
the key pin (B) of the mounting bracket (C) to prevent the fan from rotating when in operation.(Fig.7A)
NOTE: Please be aware of that the fan head can be oscillating 60°. There are key slots (Fig.7B) provided
on the hanger ball which allow you to adjust the direction of the fan according to your requirement.
Fig. 7A
Fig. 7B

Airfusion HAVANA Installation Instructions
9 | P a g e
ADJUSTMENT OF THE FAN HEAD
•Loosen the two set screws on both sides of the motor; (Fig.8)
•Rotate the fan head and aim the arm screw at the desired angle (There are only three angles available:
0°, 45°, 90°.They are labelled on the motor part) (Fig.9)
•Retighten the set screws after adjusting to the desired angle. Ensure the set screws are tighten and
postioned well into the slot of the desired angle. (Fig.10)
Fig. 8 Fig. 9
Fig. 10

Airfusion HAVANA Installation Instructions
10 | P a g e
ELECTRICAL WIRING DIAGRAM
WARNING:FOR YOUR SAFETY ALL ELECTRICAL CONNECTIONS MUST BE UNDERTAKEN BY A
LICENSED ELECTRICIAN.
NOTE:AN ADDITIONAL ALL POLE DISCONNECTION SWITCH MUST BE INCLUDED IN THE FIXED
WIRING.
Ensure the motor earth wire is connected to the single earthing terminal block “1” in the diagram
below. (Fig. 11)
Fig. 11
