Petrol 2 Man Post Hole Borer
Operator’s Manual
EB400PRO
FOR YOUR SAFETY
READ AND UNDERSTAND THE ENTIRE MANUAL
BEFORE OPERATING THIS MACHINE
FOR YOUR SAFETY
READ AND UNDERSTAND THE ENTIRE MANUAL
BEFORE OPERATING THIS MACHINE
FOR YOUR SAFETY
Ensure you read and understand how to operate
the machine safely. Check your machines oil
levels before every use.

Distribution Limited
Lumag Servicing and Maintenance Schedules
Engine Service & Maintenance Schedule
Machine Service & Maintenance Schedule
Item Checks/Work Each Use 20hrs
(1st Month)
50hrs
(2nd Month)
100hrs
(6th Month)
300hrs
(Yearly)
Engine Oil Check Level X
Change X (1) X
Air Filter Check X
Clean X (3)
Replace X (4)
Sediment Cup Clean X
Spark Plug Check/Clean X
Replace X
Idle Speed Check/Adjust X (2)
Valve Clearance Check/Adjust X (2)
Fuel Tank Strainer Check/Clean X (2)
Combuster Chamber Inspect/Clean X (2)
Fuel Lines Check X (2)
Item Checks/Work Each Use Weekly 20hrs
(1st Month)
50hrs
(2nd Month)
100hrs
(6th Month)
300hrs
(Yearly)
Vibraon Oil Check Level X
Oil Change X (1) (2) X (2)
Fasteners Tension Check X
Clean Machine Check X
Inspect Clutch Check/Adjust X (2)
Drive Belt Check/Adjust X
Replace X (2)
All Other Moving
Parts & Cables
Lubricate X X (2)
Engine Oil 550ml Lumag Engine 1
Gearbox Oil 50-90ml Lumag Trans 1
1 – First service only, 2 = Should be carried out by your Lumag Dealer, 3 = May need to be done more
often in dusty areas & 4 = Replace paper element only
To maximise the life of your Lumag machine it needs to be serviced and maintained at every
indicated month or operating hour interval, whichever comes first, in accordance with the
below Schedules. Please note that failure to service your machine on schedule or use genuine
Lumag parts and consumables will result in your warranty being void.

Distribution Limited
Service & Maintenance Record
Product Details: Model: __________________________________
Serial number: ____________________________ Purchase Date: ____________________________
Date: Description of checks/work carried out: Parts Used?
Y/N
Parts Invoice Number:
Dealers Name:
Engineers Name:
Engineers Signature:
Please note that failure to service your machine on schedule or use genuine Lumag parts and consumables will result in your warranty being void

Distribution Limited
Service & Maintenance Record
Product Details: Model: __________________________________
Serial number: ____________________________ Purchase Date: ____________________________
Date: Description of checks/work carried out: Parts Used?
Y/N
Parts Invoice Number:
Dealers Name:
Engineers Name:
Engineers Signature:
Please note that failure to service your machine on schedule or use genuine Lumag parts and consumables will result in your warranty being void

OVERVIEW
1. FOREWORD
2. INFORMATION MANUAL
3. INTENDED USE
4. TECHNICAL DESCRIPTION
5. RUN TIME LIMITATION
6. ENVIRONMENT
7. SAFETY INSTRUCTIONS
7.1 General safety
7.2 Personal protective equipment
7.4 Safe Handling of Fuels / Refueling
7.4. Service security
7.5 behavior in case of emergency
7.6 Residual hazards and protective measures
8. SYMBOLS
9. DELIVERY
10. CONTROLS AND FUNCTIONS
11. TRANSPORT
12. STORAGE
13. ASSEMBLY
13.1 Mounting bracket handle, throttle and connecting shaft
13.2 Assembly drill (accessory)
14. GETTING STARTED
14.1 Special security for Earth drilling
14.2 Labor Practices and Technology
14.3 Fuels / Refueling
14.4 start the motor
14.5 Stop engine
14.6 business
14.7 Working with stem extension (accessory)
15. MAINTENANCE
15.1 maintenance Schedule
15.2 air filter
15.3 spark plug
15.4 spark protection
15.5 Draining supplies
15.6 cleaning
16. TROUBLE
17. TECHNICAL SPECIFICATIONS
18. EQUIPMENT
19. WARRANTY / WARRANTY / SERVICE
20. EC DECLARATION OF CONFORMITY
21. PARTS OF THE TOOL
OVERVIEW

D
3
1. FOREWORD
WATCH OUT!
Read and follow the safety information and instructions before use.
Familiarize yourself with this manual with the machine, its proper use and the safety
instructions. Keep this safe place so that you are readily available information.
Pass the machine to another person, please hand over the complete manual from with.
limitation of liability
We have tried to give as much information to prevent accidents during the operation, but can not
for lack of completeness listed risk points
sources are held accountable.
The manufacturer is not liable for damages due to:
– Failure to follow the operating instructions
– Improper use of the machine
– Improper installation, commissioning, operation and maintenance of the machine
– Operation of the machine mounted with defective safety equipment or incorrectly or not
functional safety and protective equipment
– Failure to observe the instructions in the operating instructions regarding transport, storage,
Function, operation, maintenance and care of the
machine
– Unauthorized modifications to the machine
– Unauthorized modification of the machine
– Inadequate monitoring of machine parts that are subject to wear
– Improper repairs
– Disaster caused by foreign objects and force majeure
designation machine
The term machine replaces the commercial designation of the object to which these operating
instructions - see cover sheet - applies.
copyright
All documents are protected under copyright law. A transmission and reproduction of
documents, even in extracts and releases the contents are not permitted unless expressly
agreed.
FOREWORD

4
reservations
Information on specifications, dimensions and illustrations of the machine as well as changes of
safety standards are subject to further development and are therefore not in any case for the
supply binding.
Printing and typographical errors.
2. INFORMATION MANUAL
This manual describes functions, operation, maintenance and care of your new machine. Please
read it carefully and follow the instructions carefully to ensure your machine a long life and give
you a safe operation. Observe the safety information and instructions as well as for the local
accident prevention regulations and general safety regulations.
Read Before carrying out any work with the machine, the operating manual, especially the
section on safety and the respective safety instructions. You must fully understand the read and
observe. These are basic instructions and suggestions to prevent accidents. Errors in operation,
inspection and maintenance can cause injury or even death.
3. INTENDED USE
This comfortable one-man drill is exclusively intended for drilling holes in the ground up to 250
mm diameter. The machine finds its wide range of applications, such as in the garden
maintenance. B. for excavating planting holes, for making holes for fence posts or pergolas on
light soils and well accessible documents.
There are drills of 150 mm, 200 mm and 250 mm diameter for this model.
The machine may be used only in the vertical position (drill down) and must be held during
operation with both hands.
INFORMATION ON THE OPERATING
INSTRUCTIONS INTENDED USE

D
5
For use on rocky, hard and strong the rooted soil, the machine has limited abilities.
■The machine must not be used in public facilities, parks, sports grounds or on streets and in
agriculture and forestry.
■The machine must where electrical lines, gas lines, water pipe or telephone lines are laid
underground not in rain, on ice, on very hard, stony ground or in areas used. WATCH OUT!
Risk of injury.
■The machine must not be used in continuous commercial operation.
■The safety devices must not be removed or bypassed.
Another or further use, the mixing of flammable or explosive materials (fire and explosion
hazard) and the use in the food industry, is not regarded as intended. The manufacturer is not
liable for any resulting damage. The risk is borne solely by the user.
Observance of the operating and maintenance instructions and carrying out the maintenance,
and compliance with the maintenance intervals, are intended for use.
WATCH OUT!
Persons who are not familiar with the operating instructions, children, youth and persons
with alcohol, drugs and medication influence may not operate the machine.
4. TECHNICAL DESCRIPTION
The machine is driven by a 4-stroke gasoline engine OHV.
The hand-operated earth boring device consists of a frame on which a gasoline engine, a fuel
tank, a gearbox and two handles are mounted. The drill bit is connected to the PTO.
The vibration damper at the bar handles provide a firm and comfortable grip. The tip of the drill
allows making precision drilling on light and medium-hard floors.
For the machine only suitable drill must, as stated in the manual, be used.
The machine has a reversible rotation and stops automatically when you release the throttle.
TECHNICAL DESCRIPTION

6
5. RUN TIME LIMITATION
In residential and small housing estates or on the grounds of hospitals and
Nursing homes must on Sundays and public holidays all day and on weekdays from 20.00 to
7:00 Drilling rigs are not operated.
Please also refer to the regional regulations for noise control.
6. ENVIRONMENT
Please waste a for recycling, and not disposed of as waste. All tools, hoses and
packaging should be sorted, and to bring to the recycling center on site to ensure
proper disposal.
The site must be protected from contamination with expiring supplies. Used or remaining
supplies are to be supplied in accordance with the local regulations for environmental recycling.
Check with your local waste disposal authority options for environmentally friendly and proper
disposal.
7. SAFETY INSTRUCTIONS
Observe the following precautions to protect themselves and others from possible injury.
The notices referring to your personal safety are highlighted by a warning triangle, notices
referring only to property damage have no warning triangle.
DANGER
Failure to follow these instructions highest danger to life or the risk of life-threatening
injuries.
Failure to follow these instructions can be fatal or serious injury.
RUN TIME LIMITATION
ENVIRONMENT

D
7
NOTE
Failure to observe this instruction is a risk of damage to the engine or other property.
In addition, the manual contains other important passages that by the word
ATTENTION Marked are.
7.1 General safety
To ensure correct operation the user has to read this manual to familiarize yourself with the
handling of the machine. Insufficiently informed will endanger themselves and others due to
improper use.
First time users should be instructed by the seller to familiarize yourself with the characteristics of
the engine-driven machine.
borrow the machine only to users who have experience with an auger. The instruction manual
should be handed over to it.
Children and adolescents under 18 years, the operation of the machine is prohibited.
Aged 16 and over are allowed to use the machine as part of training and under the
supervision of a trained person.
Working with the machine requires great care.
– Pay attention to the environmental conditions in the workplace.
– care in handling and surrounding area of the machine for adequate light.
– eighth in bad weather, on uneven ground or on slopes proper footing.
Only work in good physical condition. Also fatigue leads to carelessness. Particularly close
attention is required at the end of working hours. All work calmly and carefully perform. The
operator is liable to third parties.
Never work under the influence of alcohol, drugs or medication.
Inserting timely work breaks.
Individuals with poor circulation problems exposed too often excessive vibration may experience
injury to blood vessels or the nervous system. The following symptoms may occur from
vibrations to fingers, hands or wrists: Numbness, itching, tingling, pain, stabbing sensation,
alteration of skin color or skin. If these symptoms occur, consult a doctor.
However, suitable gloves and taking regular breaks can use duration
SAFETY INSTRUCTIONS

8
SAFETY INSTRUCTIONS
extend. Note, however, that the personal predisposition to poor circulation and / or large gripping
forces reduce the period of use while working.
Other persons, especially children away from work area.
The machine does not operate in damp or wet environment or exposing it to rain
The machine in highly flammable vegetation and where fire or explosion hazard do not use. In
dry fire extinguisher (fire hazard) provide.
7.2 Personal protective equipment
To prevent injuries to head, eye, hand, foot and ear damage while working to
avoid must be worn personal protective equipment (PPE).
Clothing should be appropriate, ie snugly, but not be a hindrance.
(Etc. scarf, tie) Do not wear loose clothing or body jewelry. Long hair may not be worn open
(hairnet wear).
To prevent eye injuries, always wear safety glasses.
To avoid hearing damage, wear appropriate personal hearing protection such as ear protection,
capsules, etc..
WATCH OUT! Noise can be harmful. If the allowable noise level of 80 dB (A)
is exceeded, a hearing protection must be worn.
working gloves of thick leather are part of the prescribed equipment and must always be worn
when working with the auger.
In workplaces where an object may fall, is absolutely a hard hat
to wear.
When working with the machine safety boots or shoes with good tread and
to wear steel toe. Safety shoes ensure a secure footing. In case of dust-producing
work is to wear a respirator.
7.3 Safe Handling of Fuels / Refueling
DANGER
Internal combustion engines during operation and fueling a special

9
D
Hazard. Always follow the warnings and parallel to the additional safety instructions
given in this manual. Failure to do so could result in serious injury or death.
not refuel the engine indoors, garages or enclosed spaces, start or run. The exhaust gas of the
engine contains poisonous carbon monoxide. Staying in a carbon monoxide-containing
environment may lead to unconsciousness and death.
turn off the engine before refueling and allow to cool. Smoking and
open fires are not permitted.
Fuel may contain substances similar to solvents. Avoid skin and eye contact with
mineral products. Wear gloves when refueling.
No fuel or oil spill. When fuel or oil spills, cleaning machine immediately. Do not allow fuel mix to
contact clothing. If fuel is spilled on clothing, change clothing immediately.
Make sure that no fuel or oil oozes into the soil
(Environmental Protection!). use an appropriate base.
Loosen filler cap carefully so that the existing pressure in the tank is released gently.
Check fuel lines, fuel tank cap and tank for leaks or cracks. The
Machine must not be put into operation with such damage. close tank
cap after refueling good again.
For starting the engine change the location (at least 3 meters from the place of refueling).
Fuel cannot be stored indefinitely. Only so much shopping, as will be consumed in a few
months. Do not use old fuel!
transporting fuel and oil only approved and marked containers and store.
Fuel and oil transport on near burning cook or combustible materials, and sparks or open flames
and store.
Never use a machine with a damaged ignition cables and plugs. Risk of sparking!
Keep fuel and oil children accessible.
SAFETY INSTRUCTIONS

10
SAFETY INSTRUCTIONS
7.4 Service security
Improper maintenance or failure to comply or failure to correct a problem can be a
source of danger during operation. Only operate regularly and properly maintained
machine. Just so you can assume that you operate your machine safe, economical and
trouble-free. And for a long time.
off before all maintenance and repair work machine, disconnect the spark plug and unscrew the
spark plug.
The safe state of the machine must be checked before the start of the work, especially the
function of the throttle control, start / stop switch and the integrity of the fuel system.
clean the machine regularly. follow maintenance instructions and instructions for the tool change and
keep the handles dry and free of resin, oil and grease.
Check drill bits in good condition. Replace dull or damaged drill.
Check fuel cap regularly for leaks.
The label on the machine warn of dangers. Keep the machine clean and if necessary, replace
damaged stickers.
No gasoline or other flammable solvents to clean machine parts
use. Fumes from fuels and solvents can explode.
Near the motor housing piled out of paper, cardboard or similar material. By the hot housing a fire
can occur.
The disposal laws and regulations for operating materials and supplies
contaminated parts must be observed. To protect the environment, discard the
supplies as hazardous, even if it is only small amounts.
The machine shall operate noise and exhaust levels. Correct idle setting to look for. Operating
the machine at a higher speed than in the "Technical data" recommended can cause engine
damage. High engine speed increases risk of accidents!
These are the relevant accident prevention regulations and comply with all other generally
recognized safety and occupational health regulations.
Check the machine for possible damage:
– In front Use of the machine safety devices must be carefully examined for proper and
intended function. The operation of the machine is permitted only with complete and
correctly attached safety equipment. No way on the machine to make structural changes!
You will put your safety!
– Moving parts must not be damaged, must be operating properly and may

11
D
do not jam. All parts must be fitted correctly and fulfill all conditions to ensure proper
operation.
Always check before switching on that all tools have been removed.
Maintenance and repair work must be carried out as far as they are described in this manual. All
other work must be carried out by a specialist workshop or LUMAG service workshop.
Use only original spare parts and accessories. Through the use of other spare parts and other
accessories can be expected with an increased risk of accidents. any liability for any resulting
damages.
7.5 behavior in case of emergency
In a possible accident, please forward the corresponding necessary first aid
Measures and request as soon as possible qualified medical attention.
When calling for help, give the following information:
- where it happened
- what happened
- how many injured
- Kind of injuries
- Your name!
7.6 Residual hazards and protective measures
The machine is built according to state of the art and recognized safety regulations. Yet when
working individual residual risks may occur.
Consideration and care, will reduce the risk of personal injury and property damage.
Mechanical residual hazards
Feeding, detecting winding
Loose clothing or jewelry, cords or wires can be caught in moving parts.
→Pending wear clothes, wear safety shoes with non-slip sole and steel toe,
wear a hairnet for long hair. Residual risk - Hidden
invisible foreign bodies
shock
For stony, hard and strong the rooted soil may cause the handles to strong rebounds.
→Avoid stony to work hard and strong root mass floors with the machine.
keep operating handles well, wear protective clothing.
SAFETY INSTRUCTIONS

12
SAFETY INSTRUCTIONS
Neglecting ergonomic principles
Careless use of personal protective equipment (PPE)
Negligent use or omission of personal protective equipment can result in serious injury.
→Wear prescribed protective equipment.
Human behavior, misconduct
→Always be fully focused when working.
residual risk - Can never be ruled out.
Electrical residual hazards
Electric contact
When touching the spark plug may cause an electric shock when the engine is running.
→Do not touch the spark plug or the spark plug with the engine running.
Thermal residual hazards
Burns, frostbite
Touching the exhaust / housing can cause burns.
Let cool →motor unit.
Exposure to noise
hearing loss
Longer unprotected working with the machine can cause hearing damage.
→wear hearing protection principle.
Exposure to materials and other substances
Contact, inhalation
The exhaust gases from the engine can be harmful to health.
→Use power tool only outdoors and take regular breaks.
In large dust can cause permanent damage to the lungs.
→In case of dust-producing work is to wear a respirator.
Fire, explosion
Gasoline and oil are flammable and explosive.
→During the work and refueling is prohibited smoking and open flames.
Hazard due to vibration
Whole Body Vibration
Longer working with the machine can perform vibrations to physical impairments.
→Insert regular breaks.

13
D
other dangers
Escaping objects or liquids
When boring people and animals can be injured by being thrown out of stones, wood pieces
and the like..
→Make sure that no persons or animals are in the danger area and
wear appropriate protective clothing and eye and ear protection.
Slipping, tripping or falling of persons
On unstable surfaces can be damaged by tripping.
→Watch out for obstacles in the working area. Always pay attention to proper footing and
wear non-slip footwear.
residual risks can minimized become, if the "Safety instructions" and the
"Intended Use" and the operating instructions are observed overall.
8. VERWEMDETE SYMBOLS
Danger of carbon monoxide poisoning! not allow the engine to start in closed
rooms or run, even if the doors and windows are open.
Gasoline and oil are highly flammable and explosive. Before refueling, stop the
engine and let it cool. Keep the engine from heat, sparks and flames. Do not
smoke in the vicinity of the machine!
Warning! Take special care and attention. The machine can cause serious
injuries!
In front Commissioning read the operating instructions and safety information.
Otherwise, the risk of injury to operator and others increased.
Eye and ear protection. Wear a helmet to protect against flying
Parts.
Safety boots with good sole and steel toe wear.
SYMBOLS

14
Wearing safety gloves.
Warning of hot surfaces. Burns! Do not touch hot engine parts. They remain
hot for a short time even after switching off the machine.
Warning of rotating parts.
Warning! Risk by flying objects with the engine running.
Keep uninvolved persons and domestic animals away from rotating machine
parts.
off before cleaning, maintenance and repair engine and remove the spark plug cap.
Protect machine against moisture.
Do not touch rotating parts.
It is forbidden to remove protective and safety devices or alter.
keep the engine running at a safe distance of min. 15 meters.
SYMBOLS

15
D
9. DELIVERY
Check the contents of the box / shipping box after unpacking
■completeness
■any transport damages
Share with complaints immediately to the dealer or manufacturer. Later complaints will not be
accepted.
1 Drive unit (drill attachment optional)
2 Bow handle (2 pieces)
3 connecting shaft
4 torsion spring
5 The original operating instructions
6 Accessory bag for petrol engine
7 Accessory bag for drive unit
Watch out! Fill before commissioning MOTOR OIL!
DELIVERY

16
10. CONTROLS AND FUNCTIONS
drive unit
The drive unit consists of gasoline engine, clutch, fuel system, ignition system, reversing and
maintenance-free special gear.
recoil
the engine is started by pulling of the cable.
Fuel pump (primer)
To start relief after prolonged shutdown of the machine. The pump operate until the fuel flows
visible through the transparent return line. Primer pump 2 - press 3 more times.
centrifugal clutch
A centrifugal clutch is a clutch that is produced at the frictional connection by moving weights
with increasing speed to the outside, whereby contact with the inner wall of the clutch housing
(clutch drum) is prepared which serves as the output.
drive shaft
The drive shaft transmits the force to the drill bit.
transmission
The maintenance-free, sealed gear housing allows translation of 16: 1, which provides the best
combination of strength and speed of rotation.
CONTROLS AND FUNCTIONS
