Lumascape LS471LED User manual

Warranty voided if not installed as per installation instructions
INSTALLATION INSTRUCTIONS
Lumascape Lighting Industries Pty Ltd
38-44 Enterprise Street, Cleveland, QLD 4163, Australia
PO Box 1875, Cleveland D.C., QLD 4163, Australia
T 07 3286 2299
F 07 3286 6599
E [email protected]
W www.lumascape.com.au
IN0087 - 03 December 2013
LS471LED: Centria Up / Down IP66 / IP 67
A.C.N. 0105 72 773
MODEL: LS471LED
INPUT VOLTAGE: 110-240 V AC, 50 Hz
SPOTLIGHT & FLOODLIGHT
Warranty voided if not installed as per installation instructions
1.
4.
NOTE: Use only 1 x circular
cable to keep IP rating
DANGER
ISOLATE LUMINAIRE FROM POWER
Failure to isolate power
supply before installation or
maintenance may result in
fire, serious injury, electric
shock, death and may
damage the luminaire.
COMPONENTS
Luminaire can become very hot. Use
discretion in placement.
Ensure that installation complies with local
authority standards.
All connections must be kept dry; failure
to do so may result in product reliability
issues.
WARNING
x2
gland
x4
screw
x1
x1
Allen key
installation
sleeve
3. Connect cabling to supply.
120 mm
6 mm
4 mm² max per terminal
cable strip length
2. Screw base onto surface, eg. wall.
Insert cabling into gland.Twist glands onto base.
Screw onto base, DO NOT use power tools.
Ensure correct torque is applied.
Power supply must be isolated prior to
connection or disconnection of cables.
Failure to do so will result in damage
to the luminaire components.

Copyright ©2013 Lumascape Lighting Industries Pty. Ltd. ABN 21 010 572 773
www.lumascape.com.au
WARNING - To reduce the risk of FIRE or INJURY:
1. Luminaires and transformers to be installed by licensed electrical contractors.
2. Luminaires to be used for intended purpose only.
3. Do not operate the luminaires with a missing or damaged parts.
4. Use only genuine Lumascape parts to replace damaged or missing components.
5. Refer to instructions for installation and operating requirements.
6. Ensure installation complies with local regulations
Voltage insulation test (megger) will permanently damage product and will void warranty.
SAVE THESE INSTRUCTIONS.
SAFETY INSTRUCTIONS
IN0087 - 03 December 2013
