Lumascape LS431LED User manual

Warranty void if not installed as per installation instructions
INSTALLATION INSTRUCTIONS
Lumascape Lighting Industries Pty Ltd
38-44 Enterprise Street, Cleveland, QLD 4163, Australia
PO Box 1875, Cleveland D.C., QLD 4163, Australia
T 07 3286 2299
F 07 3286 6599
E [email protected]
W www.lumascape.com.au
IN0094 - 28 May 2014
Copyright ©2014 Lumascape Lighting Industries Pty. Ltd. ABN 21 010 572 773
www.lumascape.com.au
LS431LED: Surface Mount Remote Gear IP66 / IP67
A.C.N. 0105 72 773
MODEL: LS431LED
INPUT VOLTAGE: Remote Driver
SPOTLIGHT & FLOODLIGHT
2.
IP67
B
C
A
A
LS6097 remote constant current LED driver
(or Lumascape approved equivalent) cable strip length
120 mm
6 mm
4 mm² max per terminal
IP67
B
C
A
A
LS6097 remote constant current LED driver
(or Lumascape approved equivalent) cable strip length
120 mm
6 mm
4 mm² max per terminal

Depending on your requirements punch out one or two holes and
install gland(s) as shown in illustration below.
1.
IP67
A
1 or 2

Drill mounting holes for luminaire. Feed the cable through the gland and
tighten as shown in illustration. Repeat this process if a secod gland is
installed. Ensure a correct sized, round cable (Ø 5-10 mm) is used or seal
will not be IP67. Screw down luminaire base. Ensure gasket seal is inserted
between surface and luminaire base.
Wire up luminaire to supply cable. Please note that the single colour LED
luminaire will be supplied with a terminal block. For the RGB verions wire
nuts (not supplied) must be used to make the connection between the
luminaire to the supply cable.
Refer to wiring diagram 1.0 for
conductor colour and designation.
DANGER
ISOLATE LUMINAIRE FROM POWER
Failure to isolate power
supply before installation or
maintenance may result in
fire, serious injury, electric
shock, death and may
damage the luminaire.
1x LS431LED

x4
screw
gland
x2
x2
x1
Allen key
gasket seal









Refer to Wiring
Diagram(s) 1.0
COMMON
RED
GREEN
BLUE
DC

 
Red Red +
Orange Red
-
Green Green +
White Green
-
Blue Blue +
Black Blue
-

 
Yellow +
Blue
-

fit gasket seal

IN0094 - 28 May 2014
Copyright ©2014 Lumascape Lighting Industries Pty. Ltd. ABN 21 010 572 773
www.lumascape.com.au
WARNING - To reduce the risk of FIRE or INJURY:
1. Luminaires and transformers to be installed by licensed electrical contractors.
2. Luminaires to be used for intended purpose only.
3. Do not operate the luminaires with a missing or damaged parts.
4. Use only genuine Lumascape parts to replace damaged or missing components.
5. Refer to instructions for installation and operating requirements.
6. Ensure installation complies with local regulations
Voltage insulation test (megger) will permanently damage product and will void warranty.
SAVE THESE INSTRUCTIONS.
SAFETY INSTRUCTIONS
Questions?
Call [phone]
Email [email protected]
www.lumascape.com.au
Correct installation Incorrect installation. Void warranty


Do not allow soil, ll or any material to build up around the luminaire.
Warranty will be void.
3. 4.
2 Nm
4 Nm
2 Nm

Screw top of luminaire to base ensuring the gasket seal is firmly in
place between the two components.

Loosen the adjustment screws to change the aim of the luminaire. Once
you have the desired tilt and rotation re-tighten the adjustment screws
to lock the luminaire in place.
