Lumascape Centria C4 User manual

INSTALLATION INSTRUCTIONS
SURFACE MOUNT
ADJUSTABLE SPOTLIGHT
LUMASCAPE ASIA PACIFIC Brisbane Technology Park, 18 Brandl Street, Eight Mile Plains, QLD 4113, Australia
Phone [phone] | Fax [phone] | Email: [email protected] | www.lumacape.com
LUMASCAPE NORTH AMERICA 1300 Industrial Road, Unit #19, San Carlos, CA 94070, USA
Phone [phone] | Fax [phone] | Email: [email protected] | www.lumacape.com
Products and specifications are subject to change without notice.
USA I Australia I Asia I Middle East I Europe
1 / 4
IN0182US N181130
Centria C4 LS1010
READ ALL SAFETY INSTRUCTIONS FIRST
› Follow instructions carefully, failure to do so will void
warranty.
› Ensure installation complies with local law and
applicable standards.
› Input voltage is 120-277 V AC, 50/60 Hz
› Only use Lumascape power supply, control equipment
and leader cables.
› Ensure mains input power is surge protected.
› Never make connections whilst the power is connected.
› Do not make modifications or alter the product.
› Keep luminaire and connections clean and free of debris
and moisture.
› It is the installers responsibility that the installation is
adequately sealed to avoid moisture ingress.
LS1010
WARNING
Install in accordance with
National Electric Code, ANSI/NFPA 70 or
the Canadian Electrical Code,
Part I (CEC), CSA C22.1

INSTALLATION INSTRUCTIONS
SURFACE MOUNT
ADJUSTABLE SPOTLIGHT
LUMASCAPE ASIA PACIFIC Brisbane Technology Park, 18 Brandl Street, Eight Mile Plains, QLD 4113, Australia
Phone [phone] | Fax [phone] | Email: [email protected] | www.lumacape.com
LUMASCAPE NORTH AMERICA 1300 Industrial Road, Unit #19, San Carlos, CA 94070, USA
Phone [phone] | Fax [phone] | Email: [email protected] | www.lumacape.com
Products and specifications are subject to change without notice.
USA I Australia I Asia I Middle East I Europe
2 / 4
IN0182US N181130
Centria C4 LS1010
Open Luminaire
Loosen the four screws and remove
the lid and open the luminaire.
Drill the hole for the gland.
Use a 16mm drill bit to drill the
gland hole.
In the base drill out gland holes as
required.
Install Gland
To Light
Engine
Ø16mm
Drill Bit
To Light
Engine
Feed supply cable through
gland and tighten. Outer
diameter of cable should
be Ø5-10mm
O-Ring
To Light
Engine
Outer Cable
Ø5-10mm

INSTALLATION INSTRUCTIONS
SURFACE MOUNT
ADJUSTABLE SPOTLIGHT
LUMASCAPE ASIA PACIFIC Brisbane Technology Park, 18 Brandl Street, Eight Mile Plains, QLD 4113, Australia
Phone [phone] | Fax [phone] | Email: [email protected] | www.lumacape.com
LUMASCAPE NORTH AMERICA 1300 Industrial Road, Unit #19, San Carlos, CA 94070, USA
Phone [phone] | Fax [phone] | Email: [email protected] | www.lumacape.com
Products and specifications are subject to change without notice.
USA I Australia I Asia I Middle East I Europe
3 / 4
IN0182US N181130
Centria C4 LS1010
Connect the supply cable to the
terminal block. Refer to table
below for conductor colour and
designation.
Re-attach lid to base, making sure the seal is correctly placed between the two components.
Bolt luminaire to mounting surface making sure the
gasket seal is inserted between the mounting surface
and the wall.
Connect Supply Cable Mount Base to Wall
Close Luminaire
Seal
Gasket
Seal
To Light Engine
Conductor
colours
shown are for
a standard
Lumascape
leader cable.
Colour Designation
White Neutral
Green Earth
Black Active
Red Data
To Light Engine
To Light Engine

INSTALLATION INSTRUCTIONS
SURFACE MOUNT
ADJUSTABLE SPOTLIGHT
LUMASCAPE ASIA PACIFIC Brisbane Technology Park, 18 Brandl Street, Eight Mile Plains, QLD 4113, Australia
Phone [phone] | Fax [phone] | Email: [email protected] | www.lumacape.com
LUMASCAPE NORTH AMERICA 1300 Industrial Road, Unit #19, San Carlos, CA 94070, USA
Phone [phone] | Fax [phone] | Email: [email protected] | www.lumacape.com
Products and specifications are subject to change without notice.
USA I Australia I Asia I Middle East I Europe
4 / 4
IN0182US N181130
Centria C4 LS1010
Aim Luminaire
Using an Allen key adjust the luminaire’s tilt and rotation.
Loosen the screws to adjust and tighten to lock luminaire into place.
Luminaire Tilt
Luminaire Rotation
