Lumascape LS411LED Guide

IMPORTANT INSTRUCTIONS
For Installation LS411LED
LUMASCAPE USA INC
1300 Industrial Rd, Unit #19
San Carlos, CA 94070, USA
T 1-(650)-595-LUMA(5862)
F 1-(650)-595-5820
W www.lumascape.com
E [email protected]
Free Call 1-866-695-LUMA(5862)
spotlight | floodlight
.CNI
T 1-(650)-595-LUMA(5862) 1-(650)-595-5820
LUMASCAPE USA INC
Free Call 1-866-695-LUMA(5862)
www.lumascape.com
C1986US - 2012_Rev-004
4
MODEL
2
0.5 Nm
5 Nm
(44 in-lb)
(0.056 in-lb)
Lumascape USA Inc. 2009©
IMPORTANT SAFETY INSTRUCTIONS
instructions pertaining to a risk of fire, or injury to persons
WARNING
SAVE THESE INSTRUCTIONS.
- To reduce the risk of FIRE or INJURY:
2. Do not touch hot lens, guard, or enclosure.
3. Do not operate the lighting fixture with a missing or damaged shield.
4.
1. Fixtures can become very hot. Use discretion in placement.
Loctite Silver Grade Anti Seize on threads. Reapply if needed.
3
LS411LED
120/277V, 50/60Hz, or
12-15V AC/12-24V DC, or
12-15V AC/12-24V DC with PWM Dimming input.
Check fixture label for product configuration before
connecting to branch circuit.
LS6054
1
Fixing Holes
3.5” (88.9mm)
4" round/octagonal
junction box,
(by others).
OROR
See individual mounting
accessory instructions
(ordered separately)
LS6023LS6025
Suitable for wet locations.
Suitable for mounting within 4' (1.2m) of the ground.

C1282US - 11 November 2011
INSTALLATION INSTRUCTIONS
1. Disassemble pole clamp.
Use 4 screws provided to fix the luminaire to the front half
of the pole clamp.
4. Position the clamp and tighten both bolts evenly
using 6mm allen key.
2. Feed factory-attached cord through hole
in post.
3. Position the luminiare over the hole in the post, and
re-attach back half of clamp.
LS461/LS411: LS6023 Accessory
A.C.N. 0105 72 773
MODEL: LS6023 Accessory
SPOTLIGHT AND FLOODLIGHT
Warranty voided if not installed as per installation instructions
WARNING
It is strongly
recommended to use
Lumascape power
supply or transformer
Opening luminaire
will void warranty
LUMASCAPE USA INC
1300 Industrial Rd, Unit #19
San Carlos, CA 94070, USA
T 1-(650)-595-LUMA(5862)
F 1-(650)-595-5820
E [email protected]
W www.lumascape.com
Free Call :1-866-695-LUMA(5862)
Minimum Pipe
Size
78mm (3.0in)
38mm
(1.5in)
Double clamp
Maximum Pipe
Size
Single clamp

C1282US - 11 November 2011
Copyright ©2011 LUMASCAPE USA INC.
www.lumascape.com
WARNING - To reduce the risk of FIRE or INJURY:
1. Luminaires and transformers to be installed by qualied installers only to the NEC.
2. Luminaires to be used for intended purpose only. e.g. Wall Mount ttings must be wall mounted.
3. Luminaires can become very hot. Use discretion in placement.
4. Do not touch hot lens, guard, or enclosure.
5. CAUTION - HOT SURFACE. Keep away from curtains and other combustible material.
6. Turn Off/Unplug and allow to cool before replacing lamp.
7. Keep lamp away from materials that may burn.
8. Never touch lamp with bare ngers. Oil from skin may damage lamp. Hold lamp with soft
cloth when installing or replacing.
9. Do not operate the luminaires with a missing or damaged parts.
10. Replace any cracked protective shield.
11. Use only lamp type, voltage and wattage as specifed by Lumascape on the product label.
12. Use only genuine Lumascape parts to replace damaged or missing components.
13. Refer to instructions for installation and operating requirements.
14. Ensure installation complies with local regulations.
SAVE THESE INSTRUCTIONS.
General
LUMASCAPE USA INC
1300 Industrial Rd, Unit #19
San Carlos, CA 94070, USA
T 1-(650)-595-LUMA(5862)
F 1-(650)-595-5820
E [email protected]
W www.lumascape.com
Free Call :1-866-695-LUMA(5862)
Questions?
Free Call 1-866-695-LUMA(5862)
Email [email protected]
www.lumascape.com

A
67$57
+(5(
For Installation LS6025 Signage Pole to Suit LS411 & LS461 Luminaires
Drill/cast holes and run cables and locate junction boxes (by others) as per lighting plan.
Use discretion in placement as fixture can become very hot and may burn.
Select/purchase appropriate stainless steel fasteners for mounting substrate. (Not supplied.)

Feed supply cable through pole until exiting mounting stud at the end.
Bolt signage pole to the junction box, using the black foam seal and 4 screws (provided).
Open turnbuckle to approximately half of it’s adjustment range. Extend the rope assembly up the wall and fasten saddle in place.
Fit rope assembly to saddle and lightly adjust tension if required.
Conduit
Supply Cable
Saddle
Turnbuckle
2x #8 screws (by others - select for mounting surface)
Warning: The Luminaire should only be used complete with its protective shield (cover)
&1,
,03257$17 ,16758&7,216 Lumascape USAInc.
1300 Industrial Rd., Unit #19
San Carlos, CA94070, USA
T 1-(650)-595-LUMA(5862)
F 1-(650)-595-5820
E [email protected]
W www.lumascape.com
Free Call US & Canada1-866-695-LUMA(5862)
C1682US 07_2011
Lumascape USA Inc. 2006©
www.lumascape.com
LUMASCAPE
HEAD OFFICE
T 07 3286 2299 F 07 3286 6599
LUMASCAPE
SYDNEY - NSW
T 02 9519 6860 F 02 9519 8834
LUMASCAPE
MELBOURNE - VIC
T 03 9686 1900 F 03 9686 1700
ECC LIGHTING
LUMASCAPE AGENT - NZ
T 09 379 9680 F 09 308 9328
H.I. LIGHTING
LUMASCAPE AGENT - WA
T 08 9321 5422 F 08 9321 5881
NQ LIGHTING
LUMASCAPE AGENT - NTH QLD
T 07 4031 4490 F 07 4031 5933
T 1-(650)-595-LUMA(5862) 1-(650)-595-5820
LUMASCAPE USA INC
Free Call 1-866-695-LUMA(5862)
LIGHTING PARTNERS AUSTRALIA
LUMASCAPE AGENT - SA
T 08 8232 0074 F 08 8232 0076
Turnbuckle
Mounting Stud
24.21” (614.87 mm)
minimum - 25" recommended
41.6” (1056.76 mm)
Use 4" round weatherproof
box and gasket to seal
the box (by others)
Secure signage post to
weatherproof box using
4 screws (typically
supplied with box)
Secure junction box to wall with
appropriate fasteners for the material
Fix Saddle to wall using 2 x #8 screws.
Select screw type to suit mounting surface

B

Remove base from fixture and feed
through supply cable.


Finalise installation and adjust as per the instructions supplied with the fixture
Screw fixture base onto mounting
stud. Terminate supply cable as per instructions supplied with fixture.
IMPORTANT: Seal cable entry point and 4 small holes in base with silicone.
Base from
Fixture
Cable Entry
4x Through
Holes
Warning: The Luminaire should only be used complete with its protective shield (cover)
&1,
,03257$17 ,16758&7,216 Lumascape USAInc.
1300 Industrial Rd., Unit #19
San Carlos, CA94070, USA
T 1-(650)-595-LUMA(5862)
F 1-(650)-595-5820
E [email protected]
W www.lumascape.com
Free Call US & Canada1-866-695-LUMA(5862)
Lumascape USA Inc. 2006©
www.lumascape.com
LUMASCAPE
HEAD OFFICE
T 07 3286 2299 F 07 3286 6599
LUMASCAPE
SYDNEY - NSW
T 02 9519 6860 F 02 9519 8834
LUMASCAPE
MELBOURNE - VIC
T 03 9686 1900 F 03 9686 1700
ECC LIGHTING
LUMASCAPE AGENT - NZ
T 09 379 9680 F 09 308 9328
H.I. LIGHTING
LUMASCAPE AGENT - WA
T 08 9321 5422 F 08 9321 5881
NQ LIGHTING
LUMASCAPE AGENT - NTH QLD
T 07 4031 4490 F 07 4031 5933
T 1-(650)-595-LUMA(5862) 1-(650)-595-5820
LUMASCAPE USA INC
Free Call 1-866-695-LUMA(5862)
LIGHTING PARTNERS AUSTRALIA
LUMASCAPE AGENT - SA
T 08 8232 0074 F 08 8232 0076
C1682US 07_2011
For Installation LS6025 Signage Pole to Suit LS411 & LS461 Luminaires
