INSTRUCTION MANUAL
FILTER/LAG TRANSMITTER
(eld-programmable) MODEL 10JFT
BEFORE USE ....
Thank you for choosing M-System. Before use, please check
contents of the package you received as outlined below.
If you have any problems or questions with the product,
please contact M-System’s Sales Office or representatives.
■PACKAGE INCLUDES:
Signal conditioner ...............................................................(1)
Mounting screw (M3.5 × 10)...............................................(2)
■MODEL NO.
Confirm Model No. marking on the product to be exactly
what you ordered.
■INSTRUCTION MANUAL
This manual describes necessary points of caution when
you use this product, including installation and connection,
hardware setting, and basic maintenance procedures.
When you need to change software settings, please refer to
the Operation Manual for Model PU-2x (EM-9255), Section
A.
POINTS OF CAUTION
■POWER INPUT RATING & OPERATIONAL RANGE
• Locate the power input rating marked on the product and
confirm its operational range as indicated below:
24V DC rating: 24V ±10%,
approx. 60mA with voltage output 1
approx. 90mA with current output 1
■GENERAL PRECAUTIONS
• Before you remove the unit or mount it, turn off the power
supply and input signal for safety.
■ENVIRONMENT
• Indoor use.
• When heavy dust or metal particles are present in the
air, install the unit inside proper housing with sufficient
ventilation.
• Do not install the unit where it is subjected to continuous
vibration. Do not subject the unit to physical impact.
• Environmental temperature must be within -5 to +55°C
(23 to 131°F) with relative humidity within 30 to 90% RH
in order to ensure adequate life span and operation.
■WIRING
• Do not install cables close to noise sources (relay drive
cable, high frequency line, etc.).
• Do not bind these cables together with those in which
noises are present. Do not install them in the same duct.
• Be sure to put the terminal cover on while the power is
supplied.
■AND ....
• The unit is designed to function as soon as power is sup-
plied, however, a warm up for 10 minutes is required for
satisfying complete performance described in the data
sheet.
COMPONENT IDENTIFICATION
Body
Specifications
Connection Diagram
(side)
Terminal Cover
*Provided only when the second output is selected.
Zero Adj.
Output 2*Span Adj.
Modular Jack
INSTALLATION
Use Standard Rack (model: 10BXx).

10JFT
5-2-55, Minamitsumori, Nishinari-ku, Osaka 557-0063 JAPAN
Phone: [phone] Fax: [phone] E-mail: [e-mail]
EM-0879 Rev.1 P. 2 / 7
TERMINAL CONNECTIONS
Connect the unit as in the diagram below or refer to the connection diagram on the side of the unit.
■EXTERNAL DIMENSIONS unit: mm (inch)
130 (5.12)
3 (.12)
51 (2.01)
82 (3.23)
2–4.3 (.17) dia.
MTG HOLE
TERMINAL COVER
7–M3.5 SCREW
8 (.31)
91 (3.58)
99 (3.90 )
25 (.98)
12
3
56
78
■CONNECTION DIAGRAM
+
–
+
–
INPUT
1
OUTPUT 1
2
7
8
+
–
OUTPUT 2
5
6
CONNECTOR
OUTPUT 2*
POWER
PU-2x
MODULAR JACK
*For 1 output channel type, OUTPUT 1 is also connected to the
card-edge connector inside.
Note: The section enclosed by broken line is only for 2nd output channel.

10JFT
5-2-55, Minamitsumori, Nishinari-ku, Osaka 557-0063 JAPAN
Phone: [phone] Fax: [phone] E-mail: [e-mail]
EM-0879 Rev.1 P. 3 / 7
WIRING INSTRUCTIONS
■SCREW TERMINAL
Torque: 0.8 N·m
CHECKING
1) Terminal wiring: Check that all cables are correctly con-
nected according to the connection diagram.
2) Power input voltage: Check voltage supplied to the rack
(model: 10BXx). For the DC power source, be sure that
the ripple level is within 10% p-p.
3) Input: Check that the input signal is within 0 – 100% of
the full-scale.
4) Output: Check that the load resistance meets the de-
scribed specifications.
ADJUSTMENT PROCEDURE
This unit is calibrated at the factory to meet the ordered
specifications, therefore you usually do not need any cali-
bration, unless you need to match the signal to a receiving
instrument or conduct regular calibration.
Zero and span are adjusted with using the Programming
Unit (model: PU-2x). Also, fine adjustments for the Output
2 can be done with the potentiometers on top of the unit
which are accessible using Extender Card (model: 10EC)
maintaining electrical connection to the rear connector.
Refer to the Operation Manual for Model PU-2x for expla-
nations how to use the programmer.
■WARNING ON USE OF THE PROGRAMMING UNIT
• Be sure to disconnect the Programming Unit before you
turn on/off power supply to the unit.
• The output signal is held when the Programming Unit is
connected. You need to disconnect when confirming cur-
rent output values.
■HOW TO CALIBRATE THE OUTPUT 1
Use a signal source and measuring instruments of sufficient
accuracy level. Turn the power supply on and warm up for
more than 10 minutes.
• Fine Output Calibration
Using the Programming Unit (ITEM 19, 20)
ITEM 19 is for Zero, and ITEM 20 is for Span.
1) Turn the unit into Program mode (ITEM 01).
2) Apply simulated 0% input. Increase/decrease values
(default: 0%) at ITEM 19 until the output signal is cali-
brated to actual 0%.
3) Apply simulated 100% input. Increase/decrease value
(default: 100%) at ITEM 20 until the output signal is cali-
brated to actual 100%.
4) Apply simulated 0% input again and check 0% output.
5) When 0% value is changed, repeat the above procedure
2) – 4).
The 0% value may be shifted when the output span is
greater than the input span (gain > 1).
■HOW TO CALIBRATE THE OUTPUT 2
Use Extender Card (model: 10EC) to access the Output 2
Adjustments on top of the unit.
1) ZERO: Apply 0% input and adjust output to 0%.
2) SPAN: Apply 100% input and adjust output to 100%.
3) Check ZERO adjustment again with 0% input.
4) When ZERO value is changed, repeat the above proce-
dure 1) – 3).
MAINTENANCE
Regular calibration procedure is explained below:
■CALIBRATION
Warm up the unit for at least 10 minutes. Apply 0%, 25%,
50%, 75% and 100% input signal. Check that the output
signal for the respective input signal remains within accu-
racy described in the data sheet. When the output is out of
tolerance, recalibrate the unit according to the “ADJUST-
MENT PROCEDURE” explained earlier.
LIGHTNING SURGE PROTECTION
M-System offers a series of lightning surge protector for
protection against induced lightning surges. Please contact
M-System to choose appropriate models.

10JFT
5-2-55, Minamitsumori, Nishinari-ku, Osaka 557-0063 JAPAN
Phone: [phone] Fax: [phone] E-mail: [e-mail]
EM-0879 Rev.1 P. 4 / 7
PROGRAMMABLE ITEMS
The following items can be monitored and programmed.
Setting ITEM 23 enables to select various filters.
ITEM 01 through 20 are common to each filter.
For detailed explanations, please refer to the Operation Manual for Model PU-2x (EM-9255), Section A.
[GROUP 01]
ITEM MDFY. DATA INPUT DISPLAY CONTENTS
01 S MAINTENANCE SWITCH (lock command)
0 MTSW: MON.MODE MONITOR mode: data monitoring only
1 MTSW: PRG.MODE PROGRAM mode: “P” marked data modifiable
02 P Alphabets & No. TG: XXXXXXXXXX Tag name entry (10 characters max.)
03
05
06
P
D
D
Number (%)
No input
No input
OUTPER XXX.XX
INPPER XXX.XX
INPVAL XXX.XX
Output status monitor (%) & simulation output
Input status monitor (%)
Input status monitor in actual value, same unit as selected in
ITEM 10.
10 TYPE OF TRANSMITTER INPUT
D 11 mV-1: 5 – 100mV
D 12 mV-2: 0.05 – 1V
P 13 mV-3: 0.5 – 10V
P 14 mV-6: 1 – 5V
D 15 mV-A: 4 – 20mA
D 16 mV-H: 10 – 50mA
11 P COARSE INPUT RANGE SELECTION
mV-1
(± mV)
mV-2
(± V)
mV-3
(± V)
mV-6/A/H
0 INPRNG: XXXX 5 0.05 0.5
No
Adjustment
Needed
1 INPRNG: XXXX 10 0.10 1.0
2 INPRNG: XXXX 20 0.20 2.0
3 INPRNG: XXXX 50 0.50 5.0
4 INPRNG: XXXX 100 1.00 10.0
14
15
P
P
Actual value
Actual value
SCLLOW XXXXXX
SCLHIG XXXXXX
Input range scaling 0% value
Input range scaling 100% value
Use the same engineering unit as the coarse range selected in
ITEM 11.
19 P Percentage FINZER Fine zero adjustment
Initial status shows actual bias (%). When data is entered, out-
put (%) is shown.
20 P Percentage FINSPN Fine span adjustment
Initial status shows actual gain (%). When data is entered, out-
put (%) is shown.
Modication Code
D: No modification (writing) possible. Used only for monitoring (reading).
S: Modifiable at any time.
P: Modifiable only when the MAINTENANCE SWITCH is in the “PRG” mode.

10JFT
5-2-55, Minamitsumori, Nishinari-ku, Osaka 557-0063 JAPAN
Phone: [phone] Fax: [phone] E-mail: [e-mail]
EM-0879 Rev.1 P. 5 / 7
■MOVING AVERAGE OUTPUT
[GROUP 01]
ITEM MDFY. DATA INPUT DISPLAY CONTENTS
23 P FUNCTION TYPE
0 0: NO FILTER Without the function
11: RUNNING AVE With the moving average output
24
25
P
P
0.1 – 100.0
1 – 8
H XXX.X
N X
Sampling cycle “H” (seconds)
“N” number of samples to be calculated
[FUNCTION]
This unit samples input signals every H seconds and outputs pro-
portionally to an average of N numbers of sampled data. When a
new input is sampled after another H seconds, it gives up the oldest
sample and calculates a new average including the latest sample
and outputs proportionally.
H: Sampling cycle (0.1 to 100.0 seconds adjustable)
N: Number of samples to be calculated (1 to 8 adjustable)
■DEAD TIME COMPUTING
[GROUP 01]
ITEM MDFY. DATA INPUT DISPLAY CONTENTS
23 P FUNCTION TYPE
0 0: NO FILTER Without the function
22: DEAD TIME With the dead time computing
24
25
26
P
P
P
0.1 – 100.0
1 – 8
0.0 – 100.0
H XXX.X
N X
T XXX.X
Sampling cycle “H” (seconds)
“N” number of samples to be calculated
Time constant “T” (seconds)
[FUNCTION]
This unit does not respond to an input signal for a preset dead-time
duration. In addition, with adjusting a time constant T, it generates a
first order lag output after the dead-time.
Xo (s) = e –Ls Xi (s)
1 + Ts
Xi
Xo
Ls
:
:
:
Input
Output
Dead-time (H × N) s
H
N
T
:
:
:
Sampling cycle (0.1 to 100.0 seconds adjustable)
Number of samples to be calculated
(1 to 8 adjustable)
Time constant (0.0 to 100.0 seconds adjustable)
HH
INPUT
t
OUTPUT
t
N numbers
N numbers
average
INPUT
• Step Input with Dead-Time
t
OUTPUT
t
0
0
H x N
INPUT
• Step Input with Dead-Time Plus Time Constant
t
OUTPUT
t
0
0
T
H x N

10JFT
5-2-55, Minamitsumori, Nishinari-ku, Osaka 557-0063 JAPAN
Phone: [phone] Fax: [phone] E-mail: [e-mail]
EM-0879 Rev.1 P. 6 / 7
■DELAY BUFFER
[GROUP 01]
ITEM MDFY. DATA INPUT DISPLAY CONTENTS
23 P FUNCTION TYPE
0 0: NO FILTER Without the function
3 3: LAG MODULE With the delay buffer
26 P 0.0 – 100.0 T XXX.X Time constant “T” (seconds)
[FUNCTION]
This unit generates a first order lag output.
Xo (s) = 1Xi (s)
1 + Ts
Xi
Xo
T
:
:
:
Input
Output
Time constant (0.0 to 100.0 seconds adjustable)
■LEAD TIME COMPUTING
[GROUP 01]
ITEM MDFY. DATA INPUT DISPLAY CONTENTS
23 P FUNCTION TYPE
0 0: NO FILTER Without the function
4 4: LEAD MODULE With the lead time computing
26 P 0.0 – 100.0 T XXX.X Time constant “T” (seconds)
[FUNCTION]
This unit operates a lead-time equation.
Xo (s) = (1 + Ts) Xi (s)
Xi
Xo
Ls
:
:
:
Input
Output
Lead-time constant (0.0 to 100.0 seconds adjustable)
INPUT
• Step Input with Time Constant
t
OUTPUT
t
0
0
T
INPUT
• Step Input with Time Constant (Lead)
t
OUTPUT
t
0
0
T

10JFT
5-2-55, Minamitsumori, Nishinari-ku, Osaka 557-0063 JAPAN
Phone: [phone] Fax: [phone] E-mail: [e-mail]
EM-0879 Rev.1 P. 7 / 7
■RAMP BUFFER
[GROUP 01]
ITEM MDFY. DATA INPUT DISPLAY CONTENTS
23 P FUNCTION TYPE
0 0: NO FILTER Without the function
5 5: RAMP BUFFER With the ramp buffer
27
28
P
P
0.00 – 200.00
0.00 – 200.00
CP XXX.XX
CN XXX.XX
Maximum rate of positive output change (%/s)
Maximum rate of negative output change (%/s)
[FUNCTION]
This unit output does not change faster than a preset maximum rate,
positive CP and negative CN, no matter how fast its input changes.
CP
CN
:
:
Maximum rate of positive output change
(0.00 to 200.00%/second adjustable)
Maximum rate of negative output change
(0.00 to 200.00%/second adjustable)
■MEAN AVERAGE OUTPUT
[GROUP 01]
ITEM MDFY. DATA INPUT DISPLAY CONTENTS
23 P FUNCTION TYPE
0 0: NO FILTER Without the function
6 6: MAJORITY With the mean average output
24
25
29
30
P
P
P
P
0.1 – 100.0
2 – 8
0 – 7
0 – 7
H XXX.X
N X
L X
U X
Sampling cycle “H” (seconds)
“N” number of samples to be calculated
“L” number of smallest samples to be cut off
“U” number of largest samples to be cut off
[FUNCTION]
This unit samples input signals every H seconds and, excluding U num-
bers of largest samples and L numbers of smallest samples, outputs
proportionally to an average of the rest [N – (U + L)] of sampled data.
When the number of samples to be calculated equals 0 or less, it outputs
an error.
H
N
U
L
:
:
:
:
Sampling cycle (0.1 to 100.0 seconds adjustable)
Number of samples to be calculated
(2 to 8 adjustable)
Number of largest samples to be cut off
(0 to 7 adjustable)
Number of smallest samples to be cut off
(0 to 7 adjustable)
INPUT
• Step Input with Rate-of-Change Limit
t
OUTPUT
t
0
0
CP CN
IN 1 IN 2
INPUT
• Example (N=5, U=1, L=1)
t
OUTPUT
t
OUT 1 OUT 2
IN 1 IN 2
