M-ti Cx flex single-power User manual

CX FLEX™ SINGLE-POWER PRODUCT MANUAL

Product Manual for

CX FLEX™ Single-Power

DO NOT REMOVE FROM STORE

Contents

1. Materials in Box 2

2. Installation 2

3. Key Whitelist 3

4. Merchandising 3

5. Managing Alarms 4

6. Cable Removal 4

7. Remerchandising 4

8. Adding New User Keys 5

9. Deleting Whitelist 5

10. LED Status Indicators 6

11. Dimensions 8

12. FCC and ISED Statement 9

For additional support, please reach out to our

Contact Center at 800-426-6844

CONTENTS

CX FLEX™

Single-Power

Barrel

Female End

Barrel

Male End

Optional Power Supply

(400-00054)

CX FLEX™ SINGLE-POWER PRODUCT MANUAL

INSTALLATION

MATERIALS IN BOX

Feed power cable through hole in xture (if needed),

and press down on the base plate for 10 seconds for full

VHB contact. Allow 24 hours for full VHB adhesion.

Alternately, use the Power Supply provided with

the product you are intending to secure, with the

appropriate adapter.

Clean the desired surface with an alcohol pad allow it to

completely dry. Peel the red lm from the VHB adhesive.

Use the individual power supply and plug it into

the nearest outlet. Use an outlet installed near the

equipment that is easily accessible.

Use only certiﬁed AC main power supply adapters compliant

with Limited Power Source (LPS); use of other power supply

may cause malfunctions and electrical hazard.

132

USB-C Sensor: Insert the other end of the cable into

the device.

Plug the USB-C end of the sensor into the CX Flex until it

clicks.

Flexi-Disc Sensor: Peel the red lm from the VHB

adhesive and press rmly onto the product for 1

minute if the product surface is curved, or 30 seconds

if it is at.

System will auto-arm after 1 minute, or arm

immediately by holding a whitelisted User Card over

the RFID Icon.

click

CX FLEX™ SINGLE-POWER PRODUCT MANUAL

MERCHANDISING

KEY WHITELIST

Place Authorization Card over the

RFID icon to register to system.

LED will be solid blue.

System must be disarmed

to perform this operation.

Place the User Key over the RFID

icon you want to add.

If successful unit beeps 2 times

If unsuccessful unit beeps 4

times (retry)

Repeat process for all User Keys

until they are successfully added.

To close the whitelist mode, place

the Authorization Card over the

RFID icon. Whitelist mode will end

automatically after 3 minutes of no

use. LED will be ashing white.

132

CX FLEX™ SINGLE-POWER PRODUCT MANUAL

To silence an alarm, hold the user card over the RFID icon. To disarm after silencing an alarm, hold the user card over the

RFID icon for 5 seconds.

MANAGING ALARMS

2Remove the cable.

Insert a corner of the RFID card into the slot and press

down until the cable ddetaches.

REMERCHANDISING

CABLE REMOVAL

Re-arm by holding user card over

RFID icon or system will auto-arm

after 1 minute.

Insert new cable until it clicks.From an armed state, place the

user key over the RFID icon to

disarm the system. LED will be

ashing white. Then remove the

cable.

click

From an armed state, place the user key over the RFID

icon to disarm the system. LED will be ashing white.

CX FLEX™ SINGLE-POWER PRODUCT MANUAL

1 2 3

DELETING WHITELIST (This will delete all User Keys from the system.)

ADDING NEW USER KEYS

Hold down the Authorization Card

for 5 seconds, LED will be solid

yellow.

Place Authorization Card over the RFID icon. Follow Key

Whitelist process starting on page 3.

From an Armed state, place the

User Key over the RFID icon to

disarm the system. LED will be

ashing white.

Place the Authorization Card over

the RFID icon AGAIN while LED is

yellow.

If successful unit beeps 2 times

and the LED will turn solid green

If unsuccessful unit beeps 4

times (retry)

CX FLEX™ SINGLE-POWER PRODUCT MANUAL

LED STATUS INDICATORS

Visual Reference System Status Condition Solution

LED is solid white. Armed System is armed.

LED is ashing white. Disarmed System is disarmed and is ready to merchandise or re-arm.

LED is ashing red and white. Alarm System is alarming and requires immediate attention.

LED is ashing green. Factory Reset System has no whitelist or Authorization Card. Follow key

whitelist process.

LED is solid green. Ready to Whitelist System has an Authorization Card, but does not have any

User Keys added. Follow key whitelist process.

CX FLEX™ SINGLE-POWER PRODUCT MANUAL

LED STATUS INDICATORS

Visual Reference System Status Condition Solution

LED is solid blue. Overcurrent when armed System has gone into overcurrent protection. Unplug any

product which may be drawing too much power.

LED is ashing blue. Overcurrent when disarmed

System has gone into overcurrent protection and user has

disarmed the system. Unplug any product which may be

drawing too much power. The system will self-heal.

LED is solid yellow. Delete Whitelist Mode (If using

Authorization Card) System is deleting whitelist. Wait until complete.

WARNINGS

1. For indoor use only, shall not be exposed to dripping or splashing.

2. Do not expose to excessive heat sources, sunshine, ﬁre or the like.

3. The socket-outlet shall be installed near the equipment and shall be easily accessible.

4. No user replaceable parts inside, refer servicing to manufacturer speciﬁed agency or qualiﬁed service

personnel.

5. Only use accessories/battery speciﬁed by the manufacturer.

Disposal:

All electrical and electronic products including batteries should be disposed of separately

from the municipal waste stream via designated collection facilities appointed by the

government or the local authorities.

CX FLEX™ SINGLE-POWER PRODUCT MANUAL

DIMENSIONS

2.36”

1.09”

1.87”

18”

CX FLEX™ SINGLE-POWER PRODUCT MANUAL

FCC AND ISED STATEMENT

This device complies with Innovation, Science and Economic Development Canada licence-exempt RSS standard(s). Operation is subject to the following

two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause

undesired operation of the device.

CAN ICES-3(B)/NMB-3(B)

Le présent appareil est conforme aux CNR Innovation, Sciences et Développement économique Canada applicables aux appareils radio exempts de licence.

L’exploitation est autorisée aux deux conditions suivantes:

(1) il ne doit pas produire de brouillage et (2) l’ utilisateur du dispositif doit étre prêt à accepter tout brouillage radioélectrique reçu, même si ce brouillage

est susceptible de compromettre le fomctionnement du dispositif.

CAN ICES-3(B)/NMB-3(B)

The device meets the exemption from the routine evaluation limits in section 2.5 of RSS 102 and compliance with RSS-102 RF exposure, users can obtain

Canadian information on RF exposure and compliance.

Le dispositif rencontre l’exemption des limites courantes d’évaluation dans la section 2.5 de RSS 102 et la conformité à l’exposition de RSS-102 rf,

utilisateurs peut obtenir l’information canadienne sur l’exposition et la conformité de rf.

This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. This equipment should be installed and operated

with a minimum distance of 20 millimeters between the radiator and your body.

Cet émetteur ne doit pas être Co-placé ou ne fonctionnant en même temps qu’aucune autre antenne ou émetteur. Cet équipement devrait être installé et

actionné avec une distance minimum de 20 millimètres entre le radiateur et votre corps.

This device complies with Part 15 of the FCC Rules.

Caution: If any changes or modications not expressly approved by the party responsible for compliance could void the user’s authority to operate the

equipment.

Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference

received, including interference that may cause undesired operation.

The grantee is not responsible for any changes or modications not expressly approved by the party responsible for compliance. Such modications could

void the user’s authority to operate the equipment.

The RF Exposure Compliance distance is 20 millimeters.

NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These

limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can

radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.

However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or

television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more

of the following measures:

—Reorient or relocate the receiving antenna.

—Increase the separation between the equipment and receiver.
