Magellan MG-6060 User manual

780 Industriel Blvd., Saint-Eustache (Quebec) J7R 5V3 CANADA
www.paradox.ca
unit shown is
actual size
User Guide
780 Industriel Blvd., Saint-Eustache (Quebec) J7R 5V3 CANADA
www.paradox.ca
unit shown is
actual size
User Guide
user guide cover 5/25/04 08:55 Page 1
Technical Manuals Online! - http://www.tech-man.comTechnical Manuals Online! - http://www.tech-man.com

Printed in Canada 05/2004 Magellan is a trademark or registered trademark of Paradox Security Systems Ltd. or its affiliates in Canada, the United States and/or other countries. All rights reserved. Specifications may change without prior notice. © 2004 Paradox Security Systems Ltd.
Printed in Canada 05/2004 Magellan is a trademark or registered trademark of Paradox Security Systems Ltd. or its affiliates in Canada, the United States and/or other countries. All rights reserved. Specifications may change without prior notice. © 2004 Paradox Security Systems Ltd.
Ultra-Small Door
Contact
(MG-DCT2)
Range: 18m (60ft)*
Door Contact
(MG-DCTXP)
Range: 30m (100ft)*
Long-Range Door
Contact
(MG-DCT1)
Range: 35m (115ft)*
Magellan Remote Control
with backlight
(MG-REM1)
Range: 30m (100ft)*
* typical range in a residential environment
†manufactured and available exclusively through
EVERday Technology Co. Ltd.
Smoke Detector
(SD738)
Range: 30m (100ft)*
Made by EVERday (Taiwan)†
Analog Single-Optic PIR
(18kg/40lb Pet Immunity)
(MG-PMD1P)
Range: 35m (115ft)*
Digital Dual-Optic
High-Performance PIR
(40kg/90lb True Pet Immunity)
(MG-PMD75)
Range: 35m (115ft)*
Digital Dual-Optic
High-Performance Outdoor PIR
(40kg/90lb True Pet Immunity)
(MG-PMD85)
Range: 35m (115ft)*
All-In-One Wireless System
(MG-6060)
Ultra-Small Door
Contact
(MG-DCT2)
Range: 18m (60ft)*
Door Contact
(MG-DCTXP)
Range: 30m (100ft)*
Long-Range Door
Contact
(MG-DCT1)
Range: 35m (115ft)*
Magellan Remote Control
with backlight
(MG-REM1)
Range: 30m (100ft)*
* typical range in a residential environment
†manufactured and available exclusively through
EVERday Technology Co. Ltd.
Smoke Detector
(SD738)
Range: 30m (100ft)*
Made by EVERday (Taiwan)†
Analog Single-Optic PIR
(18kg/40lb Pet Immunity)
(MG-PMD1P)
Range: 35m (115ft)*
Digital Dual-Optic
High-Performance PIR
(40kg/90lb True Pet Immunity)
(MG-PMD75)
Range: 35m (115ft)*
Digital Dual-Optic
High-Performance Outdoor PIR
(40kg/90lb True Pet Immunity)
(MG-PMD85)
Range: 35m (115ft)*
All-In-One Wireless System
(MG-6060)
user guide cover 5/25/04 08:56 Page 2
Technical Manuals Online! - http://www.tech-man.comTechnical Manuals Online! - http://www.tech-man.com

Magellan 1
Table of Contents
Overview.................................................... 3
Introduction ......................................................... 4
Basic Operation .................................................. 7
Arming / Disarming ................................ 11
Arming............................................................... 12
Disarming.......................................................... 16
Fire Alarms........................................................ 18
Panic Alarms..................................................... 22
Consumer Features................................ 23
Message Center................................................ 24
FM Radio Feature ............................................. 25
Alarm Clock....................................................... 26
Speakerphone................................................... 27
Chime Zones..................................................... 28
Keypad Settings................................................ 29
Time and Date .................................................. 29
Programmable Outputs (PGMs) ....................... 30
Trouble Display.................................................. 30
Making a Service Call........................................ 31
Demo Mode ....................................................... 31
X10 Automation ................................................. 31
Access System Features by Phone....... 33
Access System Features by Phone................... 34
Advanced Features ................................. 37
Programming User Codes ................................. 38
Adding a Remote Control to an Existing User ... 39
Setting the Language ........................................ 40
Voice Reporting ................................................. 40
Utility Reporting ................................................. 41
Pager Reporting ................................................ 43
Bell Cut-Off Timer.............................................. 43
System Test....................................................... 43
Zone Labels....................................................... 44
Technical Manuals Online! - http://www.tech-man.comTechnical Manuals Online! - http://www.tech-man.com

2User’s Guide
Technical Manuals Online! - http://www.tech-man.comTechnical Manuals Online! - http://www.tech-man.com

Overview 3
Chapter 1: Overview
What’s in this chapter:
• Introduction
• Basic Operation
This chapter will give you a basic overview of your Magellan system. This chapter will cover Magellan’s light
indicators, keypads and remote controls. This chapter also includes sections explaining how to use this
guide and what the icons used mean.
Technical Manuals Online! - http://www.tech-man.comTechnical Manuals Online! - http://www.tech-man.com

4User Guide
Introduction
Magellan is the first security system to combine security with popular consumer features and a stylish design. Magellan looks different
than anything else in the security industry. Install it anywhere in your home or small business, Magellan blends beautifully with any décor.
Listen to the radio, leave a message or use your system as a telephone, alarm clock or monitoring device.
Magellan consists of wireless detection devices installed at specific entry and exit points, as well as other vulnerable areas, such as
windows. These devices protect the premises and communicate with Magellan’s main console. If you have armed the system and a
device detects a breach, a siren will be activated and your central station will immediately be notified by phone. Choose from wireless
motion detectors that are immune to pets, door contacts, and remote controls that automate your most frequently used security functions.
With Magellan you have security and so much more:
• Built-in FM radio (page 25)
• Hands-free telephone (page 27)
• Family message center (page 24)
• Access system features by phone (page 34)
• Alarm clock (page 26)
• Chiming (page 28)
• Voice, Utility and Pager reporting (page 40 to page 43)
• One-touch arming (page 14) and emergency keys (page 22)
• Full, force, stay, instant and automatic arming (page 12)
• X10 home automation (page 31)
• 16 wireless zones, 16 remote controls and 16 users
Technical Manuals Online! - http://www.tech-man.comTechnical Manuals Online! - http://www.tech-man.com

Overview 5
How to Use this Guide
This manual employs an icon-based instruction format to display the steps required to use Magellan’s features. The icon-based
instructions are designed to be used in conjunction with the on-screen instructions being displayed on Magellan. In other words, as
you are following the instructions shown in this guide, you should also be reading what is being displayed on the LCD screen. All the
icons displayed in this guide are explained in Conventions on page 6.
Example
When setting the Magellan console’s time and date (page 29), the following will be displayed:
This instruction set is explaining the following:
A- Press the [MENU]action key (the right action key located under the right side of the LCD screen.
B- Press the [3] key on the main keypad.
C- Select the time format that Magellan will follow; press the [12HRS]action key (the left action key under the LCD
screen) to select the 12-hour format or the [24HRS]action key (the center action key under the LCD screen) to
select the 24-hour format.
D- Program the desired time (following the time format selected before) and then the date.
D
CBA
Menu
Enter the
time and
date
12Hrs 24Hrs
Select the
console’s time
format
or
Technical Manuals Online! - http://www.tech-man.comTechnical Manuals Online! - http://www.tech-man.com

6User Guide
Conventions
Icon Definition Icon Definition
Reference to another manual or guide. Enter the System Master code on the main keypad.
Warning or important information. Enter your user code on the main keypad.
Reminder or suggestion. Enter a time value (such as when programming
Magellan’s date and time) on the main keypad.
[DATA]
or
[KEY]
Type required data or press the designated key from
either the main or center keypad.
Enter numerical data for the specified feature on the
main keypad.
Record voice label when prompted or speak into the
Magellan console when using Magellan’s
Speakerphone feature (see page 27).
Press a button on a remote control.
Press the specified action key. See Figure 1 on page
7.
Wait the specified amount of time before performing
another action.
Press specified key from the main keypad. See
Figure 1 on page 7.
Call Magellan through a standard touch-tone
telephone.
Press the specified function key. See Figure 1 on
page 7.
Technical Manuals Online! - http://www.tech-man.comTechnical Manuals Online! - http://www.tech-man.com

Overview 7
Basic Operation
The following sections will introduce you to the basic functionality of the Magellan console.
Figure 1: Basic Overview
Action KeysVolume Keys
LCD Clock Display Center Keypad
(see page 9)
Main Keypad
(see page 9)
Light Indicators:
Orange MESSAGE light
Flashing: A voice message has been recorded.
See Message Center on page 24.
Green READY light
ON: All zones closed. System can be armed.
Flashing: System in Exit Delay mode.
Red ARMED light
ON: System is armed.
Flashing: System is in alarm.
Orange INFORMATION light
ON: There is a trouble in the system, an alarm
has just occurred or a zone has been
bypassed.
Flashing: There is a power failure and the
Magellan console is receiving no power.
Function Keys
Message Key
Press once: play a recorded voice message
Press & hold: Record message
See page 24.
Radio Tuner / Alarm Clock Key
Press once: Turn ON/OFF radio (page 25)
Press & hold: Enable/disable alarm clock
(page 26)
Stay Arming Key
Press once: Enter user code to Stay arm
Press & hold: One-touch Stay arm
See page 13.
Regular Arm Key
Press & hold: One-touch Regular arm
See page 12.
LCD Screen
(see page 8)
Technical Manuals Online! - http://www.tech-man.comTechnical Manuals Online! - http://www.tech-man.com

8User Guide
LCD Screen
Remote Controls
Alarm clock feature enabled (see page 26).
Instructions and/or messages appear in this line
The function or action associated with the
action key directly underneath the text appear in
this line. Press the appropriate action key to
access the function.
Information symbol. This means:
• There is a trouble in the system (see page 30).
• There is an alarm in memory (see page 17).
• Zones or a zone is currently bypassed (see
page 14).
Remote Control Default Settings
Your installer can add other functions and/or change the default settings of your remote controls. To use the functions programmed in your
remote control, press and hold the desired key(s) for at least two seconds. Your remote control has already been programmed with the
following features:
= Force Arm (page 13)
= Disarm (page 16)
= Turn FM radio ON/OFF (page 25)
= Scroll through programmed radio station’s in memory (page 25)
MG-REM1
