Magellan Paradox 2WPGM User manual

The 2WPGM is a two-way wireless PGM, which
also provides one zone input. After assigning
the PGM module to a system, the PGM can be
programmed to activate and deactivate, as
detailed in the system’s programming guide.
Location and Mounting
The 2WPGM must be installed within 35 m
(115 ft.) of the control panel. Before you mount
the 2WPGM, perform the signal strength tests
to ensure optimal performance of the unit.
Do not cut, bend, or alter the antenna.
Avoid mounting the PGM module near or
on metal, as this may affect transmission.
Powering the Unit
The unit requires either AC or DC power input.
For wire connections, see Figure 1.
AC: 6 Vac (500 mA) to 16.5 Vac (200 mA)
DC: 5 Vdc (500 mA) to 24 Vdc (200 mA)
The external power supply used with this
module must be of an Approved/Certified type,
acceptable to the authorities where the module
is installed and used.
Enrollment and Testing
Jumper 2 (JP2) is used for enrolling (Learn
mode) and for testing signal strength.
Learn Mode: Remove and re-install JP2.
Signal Strength: Perform a transmission by
temporarily removing and re-installing JP2, or by
opening the zone that is connected to the PGM.
To interpret the RSSI LED, see the LED
Indicators table.
To test the signal strength of the 2WPGM at the
control panel, see the control panel’s
programming guide.
Normal Operation: JP2 must be CLOSED for
normal operation.
Zone Setting
ZONE Jumper determines the input setting of
the zone.
ZONE CLOSED = Normally Closed (N.C.) zone
(default)
ZONE OPEN = Normally Open (N.O.)
zone
Do not use EOL resistors with universal/zone
inputs.
Figure 1
Instructions
Two-way Wireless PGM
2WPGM (433/868MHz)
V1.1
Printed in Canada 10/2015 www.paradox.com 2WPGM-EI05
ZONE
JP2
AC/DC
Power
PGM
Output
Door
Contact
Antenna
Relay
LED Indicator
LED Indicator

Technical Specifications LED Indicators
Warranty
The Limited Warranty Statement can be found on the website
www.paradox.com/terms.
Patents
Your use of the Paradox product signifies your acceptance of
these terms and conditions.
One or more of the following US patents may apply: 7046142,
6215399, 6111256, 6104319, 5920259, 5886632, 5721542,
5287111, 5119069, 5077549 and RE39406 and other pending
patents may apply. Canadian and international patents may also
apply.
© 2015 Paradox Security Systems (Bahamas) Ltd. All rights
reserved. Specifications may change without prior notice.
Specification Description
Power Input AC: 6 Vac (500 mA) to 16.5
Vac (200 mA)
DC: 5 Vdc (500 mA) to 24 Vdc
(200 mA)
RF Frequency 433 MHz, 868 MHz
Current
Consumption
Relay ON: 45-160 mA
Relay OFF: 6-20 mA
PGM 1 N.O./N.C. 5A, 28V relay
Relay’s Maximum
Voltage
60 Vdc/28 Vac
Operating
Temperature
0°C to 50°C (32°F to 122°F)
Range 35 m (115 ft.) with MG6250
70 m (230 ft.) with MG5000 /
MG5050 / RTX3
Compatibility • MG6250, MG5000 and
MG5050
• SP5500, SP6000, SP7000
and SP65
(RTX3 is required)
• EVO192 and EVOHD
(RTX3 is required)
Dimensions 12.5 cm x 4.6 cm x 2.5 cm
(4.9 in. x 1.8 in. x 1.0 in.)
Certification For updated information, visit
www.paradox.com
LED Description
RX Receiving information
TX Sending information
RSSI Indicates signal strength
Flash twice Strong signal
Flash once Weak signal
No flash No signal
Relay Indicates that the relay is ON
