Magnescale LH71 Series Manual

1/3
LH71 Initial setup (Example)
Ver.1 (2021.1) CS&S
Press key once.
The display will be . (Measurement unit resolution)
Press key to check the current measurement unit resolution.
If the resolution is not 5μm, press key to change it.
After checking the resolution, press key to save the settings.
Switch from basic settings to normal count mode.
Press key once and the display will change to .
Press key once and the display will change to .
Press key once to automatically switch to advanced settings mode.
The display will be . Press key once.
Confirm that the display is display.
(Press key to change the polarity)
When the selection is complete, press key to save the settings.
When the display is , press the key on the right side
once.
The display will be . (Destination selection mode)
( If you want to change the destination, press key. )
When you have made your selection, press to save your settings.
Setting conditions
Connect the AC adapter and
Turn on the primary power supply
(Not key) Confirm that the resolution of input 1
is 5 μm (SJ700A scale).
* 10 μm “10U” for Digiruler PL20C
When you press key, the display becomes the normal display.
This completes the initial settings
Input 1
For LH71-1, LH71-2
LH71 Initial setup (Example)
AC adapter is energized.
Turn on key,
the LED light changes
from “blinking” to “off” and then
Press and hold key
for 3 seconds.
The following display appears
Ver.1 (2021.1) CS&S
Setting items Setting value (selection)
Basic
settings
TYPE 1 axis model is not displayed
ADD(Addition display) 1 axis model is not displayed
Destination STD
Measuring unit
resolution
5μｍ
Detailed
settings
Display resolution*
and polarity
5μｍ
Display switching
Input 1:
Axis label Display：X
Scaling 1 time（1.000000)
Compensation value No setting（OFF）
Flicker control Strong （2）
Sleep No setting（OFF）
Measuring unit
SJ700A (1 axis)
Output resolution: 5μm
When the power is turned
on for the first time after
shipment from the factory
When you want to change
the basic settings
START
Set to basic setting mode
The detailed settings are the factory default settings.
Display unit: LH71-1 (1 axis input)
SJ700A
X axis
Finished
* The initial value is the measurement unit resolution set in the basic settings.
default
default
default
default
default
default
AC primary power source
①
④
③
②
default
About 2 sec
Power ON

2/3
LH71 Initial setup (Example)
Ver.1 (2021.1) CS&S
Input 1
Input 2
X axis
Y axis
Measuring unit
SJ700A (2 axes)
Output resolution: 5μm
Confirm that the resolution of input 1
and input 2 is 5 μm (SJ700A scale).
* 10 μm “10U” for Digiruler PL20C
Display unit: LH71-2 (2 axes input)
SJ700A
SJ700A
Press key once.
The display will be . (Measurement unit resolution)
Press key to check the current measurement unit resolution.
If the resolution is not 5μm, press key to change it.
After checking the resolution, press key to save the settings.
Switch from basic settings to normal count mode.
Press key once and the display will change to .
Press key once and the display will change to .
Press key once to automatically switch to advanced settings mode.
The display will be . Press key once.
Confirm that the display is display.
(Press key to change the polarity)
When the selection is complete, press key to save the settings.
When the display is , press the key on the right side
once.
The display will be . (Destination selection mode)
( If you want to change the destination, press key. )
When you have made your selection, press to save your settings.
COUNTRY
SET UP After about
2 seconds
Connect the AC adapter and
Turn on the primary power supply
(Not key)
When you press key, the display becomes the normal display.
This completes the initial settings
For LH71-1, LH71-2
AC adapter is energized.
Turn on key,
the LED light changes
from “blinking” to “off” and then
Press and hold key
for 3 seconds.
The following display appears
When the power is turned
on for the first time after
shipment from the factory
When you want to change
the basic settings
START
Set to basic setting mode
Finished
AC primary power source
①
④
③
②
Setting conditions
Setting items Setting value (selection)
Basic
settings
TYPE 2 axes model is not displayed
ADD(Addition display) 2 axes model is not displayed
Destination STD
Measuring unit
resolution
5μｍ
Detailed
settings
Display resolution*
and polarity
5μｍ
Display switching
Input 1:Upper display
Input 2:Middle display
Axis label Upper：X, Middle：Y
Scaling 1 time（1.000000)
Compensation value No setting（OFF）
Flicker control Strong （2）
Sleep No setting（OFF）
The detailed settings are the factory default settings.
* The initial value is the measurement unit resolution set in the basic settings.
default
default
default
default
default
default
default

3/3
LH71 Initial setup (Example)
Ver.1 (2021.1) CS&S
When the display is , press the key once.
The display will be . (Destination selection mode)
Press key on the right side once.
The display will be .
( If you want to change the destination, press key. )
When you have made your selection, press to save your settings.
TYPE
Measuring unit
SJ700A (3 axes)
Output resolution: 5μm
SET UP After about
2 seconds
For LH71A-3
①
Display unit: LH71-3 (3 axes input)
Z axis
X axis
Y axis
SJ700A
SJ700A
SJ700A
Press key once.
The display will be . (Measurement unit resolution)
Press key to check the current measurement unit resolution.
If the resolution is not 5μm, press key to change it.
After checking the resolution, press key to save the settings.
Switch from basic settings to normal count mode.
Press key once and the display will change to .
Press key once and the display will change to .
Press key once to automatically switch to advanced settings mode.
The display will be . Press key once.
Confirm that the display is display.
(Press key to change the polarity)
When the selection is complete, press key to save the settings.
Connect the AC adapter and
Turn on the primary power supply
(Not key)
When you press key, the display becomes the normal display.
This completes the initial settings
AC adapter is energized.
Turn on key,
the LED light changes
from “blinking” to “off” and then
Press and hold key
for 3 seconds.
The following display appears
When the power is turned
on for the first time after
shipment from the factory
When you want to change
the basic settings
START
Set to basic setting mode
Finished
AC primary power source
④
③
②
Setting conditions
Setting items Setting value (selection)
Basic
settings
TYPE GENERAL (General machine )
ADD(Addition display) Not displayed when GENERAL is selected
Destination STD
Measuring unit
resolution
5μｍ
Detailed
settings
Display resolution*
and polarity
5μｍ
Display switching
Input 1: Upper display
Input 2: Middle display
Input 3: Lower display
Axis label Upper : X, Middle : Y, Lower : Z
Scaling 1 time（1.000000)
Compensation value No setting（OFF）
Flicker control Strong （2）
Sleep No setting（OFF）
The detailed settings are the factory default settings.
* The initial value is the measurement unit resolution set in the basic settings.
default
default
default
default
default
default
default
Input 1
Input 2
Input 3
Confirm that the resolution of
input 1,2, and 3 is 5 μm (SJ700A scale).
* 10 μm “10U” for Digiruler PL20C
