Mainstays GSDB21002-1 User manual

TM
MAINSTAYS
Industrial Long Dresser
Stock # GSDB21002-1
25-30minutes
approx assembly time
Two adults
Assembly required
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION.
PLEASE READ AND KEEP FOR FUTURE REFERENCE.
For assistance with assembly or installation, parts and customer
service , call 1-888-568-3818 Monday-Friday 8:30am-5:30pm
PST (U.S)
Email: [e-mail]
Working hour: Mon.-Fri., 8:30am - 5:30pm Pacific Standard
Time.
Stock # GSDB21002-1
Lot Number : _________
Date Purchased ______/____/_____
Manufactured By : Young Chain Company Limited
Binh Duong Province, Vietnam
TEL : [phone]
EMAIL : [e-mail]
We are available to assist you Monday-Friday
From 8:30am-5:30pm PST (US)
MAXIMUM LOAD 55 LB (25 KG)
SHELF MAXIMUM
LOAD
20 LB (9.09 KG)
BASE MAXIMUM
LOAD 30 LB
(13.64 KG)
DRAWERS MAXIMUM
LOAD 10 LB (4.54 KG)
Review your purchases, thank you!
Share your feedback to help other shoppers
Link for this product is as below:
www.walmart.com/ip/608033996

TM
MAINSTAYS
Industrial Long Dresser
Stock # GSDB21002-1
Manufactured By : Young Chain Company Limited
Binh Duong Province, Vietnam
TEL : [phone]
EMAIL : [e-mail]
We are available to assist you Monday-Friday
From 8:30am-5:30pm PST (US)
Important Safety Information
Please read all instructions carefully before assembling this furniture.
For your safety, assembly by two or more adults is strongly recommended.
Use only vendor-supplied hardware to assemble this item. Using unauthorized hardware
could jeopardize the structural integrity of the item.
Hardware may loosen overtime. Periodically check that all connections are tight.
NOTICE: To prevent injury and property damage from unexpected tipping of furniture, we highly
recommend installation of the anti-tip kit included with this product.
General Information, Tips & Tricks
Remove all parts and hardware from the box. Place all items on a carpeted or scratch-free work
surface, as this will avoid damaging parts during assembly.
The shipping box provides an ideal work surface.
To avoid accidentally discarding small parts or hardware, do not dispose of any packaging or
contents of the shipping carton until assembly is complete.
Use the parts and hardware lists below to identify and separate each of the pieces included.
The use of power tools for assembly is not recommended. Power tools can damage the hardware
and/or split the wood
Note: Do not fully tighten all bolts until all parts are in place. Failure to follow these instructions may
cause the bolts to misalign during assembly.
Safety and care
It is advisable to dust frequently with a clean, soft, dry, lint-free cloth. Clean the surface by
rubbing in the direction of the grain.
Do not place furniture in direct sunlight and keep furniture at least 60 cm / 2 ft from heat
sources to avoid fading.
DO NOT USE POWER DRILL / DRIVERS FOR INSERTING
SCREWS / BOLTS AS THIS COULD DAMAGE THE UNIT.
ONLY USE HAND SCREWDRIVERS.
Help and support
For assistance with assembly or installation, parts and customer service ,
call 1-888-568-3818 Monday-Friday 8:30am-5:30pm PST (U.S)
Email: [e-mail]
Working hour: Mon.-Fri., 8:30am - 5:30pm Pacific Standard Time.

PARTS
ATOP
×1
BBASE
×1
C D
E F G H
IJK L
M N O P
QR
LEFT SIDE
PANEL ×1
RIGHT SIDE
PANEL ×1
PARTITION
×1
LEFT BACK
PANEL ×1
RIGHT BACK
PANEL ×1
MIDDLE BAR
×1
DRAWER FRONT
PANEL ×4
SIDE METAL
FRAME ×2
CROSS BAR
×2
DRAWER LEFT
PANEL ×4
DRAWER RIGHT
PANEL ×4
DRAWER BACK
PANEL ×4
DRAWER BOTTOM
PANEL ×4
SUPPORT BAR
×4
DOOR
×1
SHELF
×2
VERIFY THAT ALL PARTS ARE LISTED BEFORE BEGINNING Page 3

CAM LOCK
×56+1
CAM BOLT
×56+1
DOWEL
×24+1
BUCKLE
×8
LONG FLAT
HEAD SCREW
×24+1
ROUND HEAD
SCREW ×16+1
STICKER PVC
×20+1
HANDLE
×5
ALLEN WRENCH
×1
SMALL BOLT
×10
SHORT BOLT
×8+1
SPRING WASHER
×22+1
LONG BOLT
×14+1
FLAT WASHER
×22+1
DOOR HINGE
×2
SHORT FLAT
HEAD SCREW
×12+1
DOOR BLOCK
×1
SHELF PIN
×8+1
SMALL ROUND
HEAD SCREW
×2+1
BRACKET
×2
2 3 41
6 7 85
10 11 129
14 15 1613
18 1917
ANTI-TIP CABLE
×1
LONG SCREW
×1
SHORT SCREW
×1
PLASTIC ANCHOR
×1
VERIFY THAT ALL PARTS ARE LISTED BEFORE BEGINNING Page 4
HARDWARE LIST
Anti-tip Hardware
TOOLS NEEDED
FOR ASSEMBLY
(NOT PROVIDED)
20

1. Screw the cam bolt into the predrilled panel. The cam bolt should be tightened
so no threads are visible.
2. The larger ring of the cam should touch the panel.
3. Insert the cam lock into the predrilled hole in the panel. Arrow faces the
outside of the panel.
4. Connect the previously tightened cam bolt with the panel connected into the
cam lock.
5. Using a flat head screw driver, turn the cam lock halfway clockwise to secure
the cam bolt.
6. FAILURE TO PROPERLY SECURE THE CAM LOCK AND CAM BOLT COULD RESULT
IN PRODUCT INSTABALITY AND FAILURE.
Page 5
CAM FASTEN SYSTEM EXAMPLE
Please call for replacement parts or assistance: 1-888-568-3818
Young Chain Company Limited
RING SHOULD
TOUCH THE BOARD
1 2 3
45 6

11. Align the SIDE METAL FRAME ( Q ) with the CROSS BAR ( R ) and then insert the SIDE
METAL FRAME ( Q ) into the CROSS BAR ( R ).
2. And then use the ALLEN WRENCH ( 10 ) to secure the FLAT WASHER ( 13 ), SPRING
WASHER ( 12 ) and SHORT BOLT ( 11 ) to attach the SIDE METAL FRAME ( Q ) with the
CROSS BAR ( R ). Tighten the SHORT BOLT ( 11 ).
Page 6
Please call for replacement parts or assistance: 1-888-568-3818
Young Chain Company Limited
ALLEN WRENCH
×1
SHORT BOLT
×8
SPRING WASHER
×8
FLAT WASHER
×8
10 11 12 13
ASSEMBLY

21. Align the pre-assembled metal feet to the corresponding hole of the BASE ( B ).
2. And then use the ALLEN WRENCH ( 10 ) to secure the FLAT WASHER ( 13 ) ,
SPRING WASHER ( 12 ) and LONG BOLT ( 14 ) to attach the SIDE METAL FRAME
( Q ) and CROSS BAR ( R ) to the BASE ( B ). Tighten the LONG BOLT ( 14 ).
** Note: Use the adjustable levelers to level the Industrial long dresser if needed.
Page 7
ASSEMBLY
Please call for replacement parts or assistance: 1-888-568-3818
Young Chain Company Limited
ALLEN WRENCH
×1
SPRING WASHER
×14
FLAT WASHER
×14
10 12 13
LONG BOLT
×14
14

31. Turn over the BASE ( B ) like the figure shown below.
2. Insert the CAM BOLT ( 1 ) into the corresponding hole of the BASE ( B ). And use a
hand screwdriver to tighten the CAM BOLT ( 1 ) clockwise.
ASSEMBLY
Page 8
Please call for replacement parts or assistance: 1-888-568-3818
Young Chain Company Limited
DO NOT USE POWER DRILL / DRIVERS
FOR INSERTING SCREWS / BOLTS
AS THIS COULD DAMAGE THE UNIT.
ONLY USE HAND SCREWDRIVERS.
CAM BOLT
×11
1

41. Place the TOP ( A ) face down on a smooth soft surface. The side with the holes
should be facing up.
2. Insert the CAM BOLT ( 1 ) into the corresponding hole of the TOP ( A ). And use a
hand screwdriver to tighten the CAM BOLT ( 1 ) clockwise.
ASSEMBLY
Page 9
Please call for replacement parts or assistance: 1-888-568-3818
Young Chain Company Limited
CAM BOLT
×11
1

51. Place the LEFT SIDE PANEL ( C ) face down on a smooth soft surface. The side with
the holes and glides should be facing up.
2. Insert the CAM BOLT ( 1 ) into the corresponding hole of the LEFT SIDE PANEL ( C ).
And use a hand screwdriver to tighten the CAM BOLT ( 1 ) clockwise.
ASSEMBLY
Page 10
Please call for replacement parts or assistance: 1-888-568-3818
Young Chain Company Limited
CAM BOLT
×5
1

61. Place the PARTITION ( E ) face down on a smooth soft surface. The side with the
glides should be facing up.
2. Insert the CAM BOLT ( 1 ) into the corresponding hole of the PARTITION ( E ). And
use a hand screwdriver to tighten the CAM BOLT ( 1 ) clockwise.
ASSEMBLY
Page 11
Please call for replacement parts or assistance: 1-888-568-3818
Young Chain Company Limited
1
CAM BOLT
×5
1

71. Turn over the PARTITION ( E ) like the figure shown below. The other side without
the glides should be facing up.
2. Insert the CAM BOLT ( 1 ) into the corresponding hole of the PARTITION ( E ). And
use a hand screwdriver to tighten the CAM BOLT ( 1 ) clockwise.
3. Align the DOOR BLOCK ( 18 ) with the pre-drilled pilot holes in the PARTITION (E)
and attach with SMALL ROUND HEAD SCREW ( 19 ) using screwdriver (Not provided)
as shown below.
ASSEMBLY
Page 12
Please call for replacement parts or assistance: 1-888-568-3818
Young Chain Company Limited
CAM BOLT
×2
1DOOR BLOCK
×1
SMALL ROUND
HEAD SCREW
×2
18 19

1. Place the RIGHT SIDE PANEL ( D ) face down on a smooth soft surface. The side with
holes should be facing up.
2. Insert the CAM BOLT ( 1 ) into the corresponding hole of the RIGHT SIDE PANEL ( D ).
And use a hand screwdriver to tighten the CAM BOLT ( 1 ) clockwise.
ASSEMBLY
Page 13
Please call for replacement parts or assistance: 1-888-568-3818
Young Chain Company Limited
8
CAM BOLT
×2
1

Insert the DOWEL ( 3 ) all the way into the corresponding hole of the LEFT SIDE
PANEL ( C ).
ASSEMBLY
Page 14
Please call for replacement parts or assistance: 1-888-568-3818
Young Chain Company Limited
DOWEL
×4
3
9

Insert the DOWEL ( 3 ) all the way into the corresponding hole of the PARTITION ( E ).
ASSEMBLY
Page 15
Please call for replacement parts or assistance: 1-888-568-3818
Young Chain Company Limited
DOWEL
×4
3
10

Insert the DOWEL ( 3 ) all the way into the corresponding hole of the RIGHT SIDE
PANEL ( D ).
ASSEMBLY
Page 16
Please call for replacement parts or assistance: 1-888-568-3818
Young Chain Company Limited
DOWEL
×4
3
11

Insert the DOWEL ( 3 ) all the way into the corresponding hole of the LEFT BACK
PANEL ( F ).
ASSEMBLY
Page 17
Please call for replacement parts or assistance: 1-888-568-3818
Young Chain Company Limited
DOWEL
×4
3
12

Insert the DOWEL ( 3 ) all the way into the corresponding hole of the RIGHT BACK
PANEL ( G ).
ASSEMBLY
Page 18
Please call for replacement parts or assistance: 1-888-568-3818
Young Chain Company Limited
DOWEL
×4
3
13

1. Align the corresponding hole of the RIGHT BACK PANEL ( G ) and RIGHT SIDE PANEL
( D ) as figure shown below.
2. Insert the CAM LOCK ( 2 ) into the corresponding hole ( the direction of the notch is
aligned with the cam bolt as the figure shown below).
3. Use a hand screwdriver to turn the CAM LOCK ( 2 ) clockwise to secure the cam bolt.
ASSEMBLY
Page 19
Please call for replacement parts or assistance: 1-888-568-3818
Young Chain Company Limited
CAM LOCK
×2
2
Make sure edge of both panel
align and even
14
The direction of the
notch of the cam
lock is aligned with
the cam bolt.

1. Align the corresponding hole of the RIGHT BACK PANEL ( G ) and PARTITION ( E ) as
figure shown below.
2. Insert the CAM LOCK ( 2 ) into the corresponding hole ( the direction of the notch is
aligned with the cam bolt as the figure shown below).
3. Use a hand screwdriver to turn the CAM LOCK ( 2 ) clockwise to secure the cam bolt.
Page 20
Please call for replacement parts or assistance: 1-888-568-3818
Young Chain Company Limited
15
2
2
CAM LOCK
×2
2
ASSEMBLY
Make sure edge of both panel
align and even
The direction of the
notch of the cam
lock is aligned with
the cam bolt.
