Makita Rbc260 Operating and installation instructions

Makita Werkzeug Ges.m.b.H.

Airportstr. 4, 2401 Fischamend

Tel: 02232 / 777 00

Fax: 02232 / 777 00 - 40

Mail: [email protected]

Web: www.makita.at

Makita Service Information / Model: RBC260

Seite 1/12

Makita Werkzeug Ges.m.b.H.

Airportstr. 4, 2401 Fischamend

Tel: 02232 / 777 00

Fax: 02232 / 777 00 - 40

Mail: [email protected]

Web: www.makita.at

Makita Service Information / Model: RBC260

Seite 2/12

Makita Werkzeug Ges.m.b.H.

Airportstr. 4, 2401 Fischamend

Tel: 02232 / 777 00

Fax: 02232 / 777 00 - 40

Mail: [email protected]

Web: www.makita.at

Makita Service Information / Model: RBC260

Seite 3/12

Makita Werkzeug Ges.m.b.H.

Airportstr. 4, 2401 Fischamend

Tel: 02232 / 777 00

Fax: 02232 / 777 00 - 40

Mail: [email protected]

Web: www.makita.at

Makita Service Information / Model: RBC260

POS Bestell-Nr. Artikelbeschreibung Stk. Stk.Preis

16254500000 GRIP 1 N/A

26214501600 HANDLE*** 000129 2 N/A

30119059840 SOCKET HEAD BOLT M5X25 4 N/A

3.2 0119059890 SOCKET HEAD BOLT M5X25 4 N/A

3.3 266805-0 H.S.H.BOLT M5X25 WITH W 4 N/A

46254007000 HOLDER HANDLE ASS'Y 1 N/A

4 *** INC.3,5 N/A

4.2 6254007001 HANDLE HOLDER ASS'Y 1 N/A

4.2 *** INC. 3,5 N/A

50119059890 SOCKET HEAD BOLT M5X25 4 N/A

5.2 266805-0 H.S.H.BOLT M5X25 WITH W 4 N/A

66255026001 CONTROL LEVER ASS'Y 1 N/A

76259509801 SERIAL LABEL 1 N/A

86211003000 BUSH COMPL. 5 N/A

96257500100 CUSHION 1 N/A

9.2 168676-0 CUSHION 1 N/A

10 6254004000 HANGER ASS'Y 1 N/A

10 *** INC.11,15 N/A

10.2 6254019000 HANGER ASS'Y 1 N/A

10.2 *** INC. 11 N/A

10.2 *** INC. 11,15 N/A

10.3 126379-2 HANGER ASSEMBLY 1 N/A

10.3 *** INC. 11 N/A

11 0043105140 PAN HEAD SCREW M5X14 1 N/A

12 6219500400 WASHER 1 N/A

12.2 6219500400 WASHER 2 N/A

13 0032214000 WAVE WASHER*** Y02187 2 N/A

14 6211502902 DAMPER BOLT 1 N/A

14.2 6211005000 DAMPER COMPL. BOLT 2 N/A

15 0022705000 NUT M5*** 000109 1 N/A

16 6251036000 SHAFT PIPE COMPLETE*** 000129 1 N/A

17 6207003000 BAND ASS'Y 1 N/A

17.2 6207003002 band ass´y 1 N/A

17.3 6207003003 TRAGEGURT KPL. RBC250/220/225 1 N/A

18 6258028000 PROTECTOR ASS'Y FOR HARD CUT. 1 N/A

18 *** INC.23,24 N/A

18.2 6258028001 PROTECTOR ASS'Y FOR HARD CUT 1 N/A

18.2 *** INC. 23-1,24 N/A

18.3 6258028002 PROTECTOR ASS'Y 1 N/A

18.3 *** INC. 23-1,24 N/A

Seite 4/12

Makita Werkzeug Ges.m.b.H.

Airportstr. 4, 2401 Fischamend

Tel: 02232 / 777 00

Fax: 02232 / 777 00 - 40

Mail: [email protected]

Web: www.makita.at

Makita Service Information / Model: RBC260

POS Bestell-Nr. Artikelbeschreibung Stk. Stk.Preis

18.4 6258060002 PROTECTOR ASS'Y 1 N/A

18.4 *** INC. 23-1,24 N/A

19 6251505000 SHAFT 1 N/A

19.2 6251505001 SHAFT 1 N/A

20 0031424000 INNER SNAP RING 1 N/A

20.2 257987-9 RETAINING RING (INT)R-24 1 N/A

21 0031508000 OUTER SNAP RING 1 N/A

22 6212500300 BALL BEARING #609ZZ 1 N/A

22.2 210049-4 ložisko 1 N/A

23 6418500301 PROTECTOR CLAMP 1 N/A

23.2 6418500302 PROTECTER CLAMP 1 N/A

24 0011706300 Bolt M6x30 2 N/A

25 6213009000 GEAR CASE ASS'Y 1 N/A

25 *** INC. 20,21,26,31-38 N/A

25 *** INC.20-21,26,28,29,31-38 N/A

25.2 6213009002 GEAR CASE ASS'Y 1 N/A

25.2 *** INC. 20,21,26,31-38 N/A

26 6413500600 OIL BOLT 1 N/A

26.2 266671-5 HEX.SOCKET HEAD BOLT M10X9 1 N/A

27 0119059780 SOCKET HEAD BOLT M5X12 2 N/A

27.2 922213-2 H.S.H.BOLT M5X12 WITH WR 2 N/A

28 0119059900 SOCKET HEAD BOLT M5X12 1 N/A

29 0119059890 SOCKET HEAD BOLT M5X25 1 N/A

29.2 266805-0 H.S.H.BOLT M5X25 WITH W 1 N/A

30 6218500200 chránič 1 N/A

30.2 450653-9 GUARD 1 N/A

31 6213004000 GEAR SET 1 N/A

31.2 6213004001 soukolí komplet 1 N/A

32 0600109980 BALL BEARING 6000 1 N/A

32.2 0600109940 BALL BEARING 6000ZZ 1 N/A

32.3 0600109980 BALL BEARING 6000 1 N/A

32.4 210086-8 BALL BEARING 6000 1 N/A

33 0031426000 INNER SNAP RING 1 N/A

33.2 257988-7 RETAINING RING (INT) R-26 1 N/A

34 6213500500 OIL SEAL 1 N/A

34.2 213681-3 OIL SEAL 16 1 N/A

35 6218500000 RECEIVE WASHER 1 N/A

35.2 332042-9 RECEIVE WASHER 1 N/A

36 6218003000 CLAMP COMPL. WASHER 1 N/A

36.2 6218003001 těsnění RBC/EM 1 N/A

Seite 5/12

Makita Werkzeug Ges.m.b.H.

Airportstr. 4, 2401 Fischamend

Tel: 02232 / 777 00

Fax: 02232 / 777 00 - 40

Mail: [email protected]

Web: www.makita.at

Makita Service Information / Model: RBC260

POS Bestell-Nr. Artikelbeschreibung Stk. Stk.Preis

36.3 168481-5 CLAMP WASHER COMPLETE 1 N/A

36.4 168797-8 CLAMP WASHER COMPLETE 1 N/A

37 0203089990 SPRING WASHER*** 000119 1 N/A

38 6258500501 NUT 1 N/A

38.2 6258505000 matice pojistná=new6258505001 1 N/A

38.3 6258505001 matka RBC/EM=old6258505000 1 N/A

38.4 264018-7 HEX.NUT M8 1 N/A

39 5103502800 SPACER GASKET 1 N/A

39.2 5103502801 SPACER GASKET 1 N/A

39.3 442177-9 GASKET AIR CLEANER 1 N/A

40 0119059730 SOCKET HEAD BOLT M5X20 2 N/A

40.2 0119059630 SOCKET HEAD BOLT M5X20 2 N/A

40.3 266903-0 INBUSSCHRAUBE M5x22 RBC3101 2 N/A

41 0021705000 NUT M5 2 N/A

41.2 264086-0 HEX.NUT M5 2 N/A

42 5243500301 INSULATOR GASKET 1 N/A

43 0119059730 SOCKET HEAD BOLT M5X20 4 N/A

43.2 266814-9 HEX SOCKET HEAD BOLT M5X20 4 N/A

44 5241500403 CYLINDER 1 N/A

45 0119059730 SOCKET HEAD BOLT M5X20 1 N/A

45.2 266814-9 HEX SOCKET HEAD BOLT M5X20 1 N/A

46 0230059990 SPACER 1 N/A

46.2 346438-8 SPACER 1 N/A

47 5243004001 INSULATOR COMPL. 1 N/A

47 *** INC.41 N/A

48 5245501502 CYLINDER COVER 1 N/A

48.2 5245501503 CYLINDER COVER 1 N/A

49 5415001160 NUT 1 N/A

49.2 264083-6 NUT 1 N/A

49.3 264050-1 SQUARE NUT M5-8 1 N/A

50 6219512401 TRADE MARK LABEL*** 000104 1 N/A

51 0650149710 SPARK PLUG 1 N/A

51.2 168588-7 SPARK PLUG 1 N/A

52 0654009940 PLUG CAP SPRING 1 N/A

52.2 0654009931 botka = old 0654009940 1 N/A

52.3 324891-8 PLUG CAP SPRING 1 N/A

53 5317500200 SPARK PLUG CAP 1 N/A

54 5243500101 MUFFLER GASKET 1 N/A

55 5243001002 EXHAUST MUFFLER 1 N/A

56 5243500203 MUFFLER COVER 1 N/A

Seite 6/12

Makita Werkzeug Ges.m.b.H.

Airportstr. 4, 2401 Fischamend

Tel: 02232 / 777 00

Fax: 02232 / 777 00 - 40

Mail: [email protected]

Web: www.makita.at

Makita Service Information / Model: RBC260

POS Bestell-Nr. Artikelbeschreibung Stk. Stk.Preis

57 0119059690 SOCKET HEAD BOLT M5X55 2 N/A

57.2 0119059670 SOCKET HEAD BOLT M5X55 2 N/A

58 0230059940 SPACER 1 N/A

59 0230059930 SPACER 1 N/A

60 0119059730 SOCKET HEAD BOLT M5X20 1 N/A

60.2 266814-9 HEX SOCKET HEAD BOLT M5X20 1 N/A

61 0119059730 SOCKET HEAD BOLT M5X20 1 N/A

61.2 266814-9 HEX SOCKET HEAD BOLT M5X20 1 N/A

62 6251024000 DAMPER ASS'Y 1 N/A

62.2 6251024001 DAMPER ASS'Y 1 N/A

63 0031432000 INNER SNAP RING 1 N/A

63.2 0031432000 INNER SNAP RING 1 N/A

63.3 962151-6 segrovka vnitřní R-32 1 N/A

64 0600129950 BALL BEARING #6201DD/#6201 2RU 1 N/A

64.2 0600129950 BALL BEARING #6201DD/#6201 2RU 1 N/A

64.3 210121-2 KUGELLAGER 6201DD/6201 2RU 1 N/A

65 0241029990 GROMMET 1 N/A

66 6252010000 CLUTCH COMPL. DRUM 1 N/A

67 0119059730 SOCKET HEAD BOLT M5X20 1 N/A

67.2 266814-9 HEX SOCKET HEAD BOLT M5X20 1 N/A

68 6252008000 CLUTCH 1 N/A

68 *** INC.69,109-111 N/A

68.2 6252500800 CLUTCH SHOE 2 N/A

68.3 6252500801 CLUTCH SHOE 2 N/A

69 6252500600 SPRING 1 N/A

70 0241055000 GROMMET 1 N/A

71 5247004020 IGNITION COIL 1 N/A

72 0119059730 SOCKET HEAD BOLT M5X20 1 N/A

72.2 266814-9 HEX SOCKET HEAD BOLT M5X20 1 N/A

73 0119059730 SOCKET HEAD BOLT M5X20 2 N/A

73.2 266814-9 HEX SOCKET HEAD BOLT M5X20 2 N/A

74 0565089980 CLIP 1 N/A

74.2 0565089970 pojistka 1 N/A

74.3 233976-8 CLIP 1 N/A

75 5242500100 PISTON PIN 1 N/A

76 0053203101 WOODRUFF KEY 1 N/A

76.2 0323039990 klínek BHX2500/EBH341R/EPH1000X 1 N/A

76.3 254040-2 WOODRUFF KEY 3 1 N/A

77 5242500701 pístní čep 2 N/A

77.2 257979-8 PISTON RING 2 N/A

Seite 7/12

Makita Werkzeug Ges.m.b.H.

Airportstr. 4, 2401 Fischamend

Tel: 02232 / 777 00

Fax: 02232 / 777 00 - 40

Mail: [email protected]

Web: www.makita.at

Makita Service Information / Model: RBC260

POS Bestell-Nr. Artikelbeschreibung Stk. Stk.Preis

78 5242500601 PISTON 1 N/A

79 0565089980 CLIP 1 N/A

79.2 0565089970 pojistka 1 N/A

79.3 233976-8 CLIP 1 N/A

80 5241500500 CYLINDER GASKET 1 N/A

81 5241003000 CRANK CASE ASS'Y 1 N/A

81 *** INC. 106 N/A

81 *** INC. 73,83,85,86,104-106 N/A

81 *** INC. 73,83-1,85,86,104-1,105 N/A

81 *** INC.83,85,104-106 N/A

82 0610089990 NEEDLE ROLLER BEARING 1 N/A

83 0600129920 BALL BEARING #6001 C3 1 N/A

83.2 0600129850 BALL BEARING 6001C3 UR 1 N/A

83.3 210113-1 BALL BEARING 6001 1 N/A

84 5215500000 PROTECTOR 1 N/A

85 0440129911 OIL SEAL 1 N/A

85.2 0440129991 OIL SEAL 1 N/A

86 0119059730 SOCKET HEAD BOLT M5X20 2 N/A

86.2 266814-9 HEX SOCKET HEAD BOLT M5X20 2 N/A

87 5215003040 E RING 1 N/A

88 5245007000 PULLEY STARTER 1 N/A

88 *** INC.87,89,90 N/A

89 5245007020 RETURN SPRING 1 N/A

90 5245007010 RATCHET 1 N/A

91 5105015110 SCREW 1 N/A

92 5415003010 REEL 1 N/A

93 5415003020 SPIRAL SPRING 1 N/A

94 5245006000 REWIND STARTER 1 N/A

94 *** INC.88,91-98,100 N/A

95 0119059730 SOCKET HEAD BOLT M5X20 4 N/A

95.2 266814-9 HEX SOCKET HEAD BOLT M5X20 4 N/A

96 5305002110 STARTER KNOB 1 N/A

96.2 140884-5 STARTER KNOB COMPLETE 1 N/A

97 5415001140 STARTER ROPE 1 N/A

97.2 444030-5 STARTER ROPE 1 N/A

98 5415001120 ROPE GUIDE 1 N/A

99 6259509601 MODEL LABEL*** 000100 1 N/A

100 5415003030 WASHER 1 N/A

101 0119069841 SOCKET HEAD BOLT M6X15 1 N/A

102 5246500301 DAMPER 2 N/A

Seite 8/12

Makita Werkzeug Ges.m.b.H.

Airportstr. 4, 2401 Fischamend

Tel: 02232 / 777 00

Fax: 02232 / 777 00 - 40

Mail: [email protected]

Web: www.makita.at

Makita Service Information / Model: RBC260

POS Bestell-Nr. Artikelbeschreibung Stk. Stk.Preis

103 5242001002 CRANK SHAFT COMPL. 1 N/A

104 0600129920 BALL BEARING #6001 C3 1 N/A

104.2 0600129850 BALL BEARING 6001C3 UR 1 N/A

104.3 210113-1 BALL BEARING 6001 1 N/A

105 5241500600 CRANK CASE GASKET 1 N/A

106 0440129911 OIL SEAL 1 N/A

106.2 0440129991 OIL SEAL 1 N/A

107 5247004000 MAGNETO FLYWHEEL 1 N/A

107 *** INC.71 N/A

107.2 5247002011 MAGNETO FLYWHEEL 1 N/A

108 0119069841 SOCKET HEAD BOLT M6X15 1 N/A

109 6202500600 WASHER 2 N/A

109.2 267429-5 FLAT WASHER 6 2 N/A

110 0200089910 WASHER M8 2 N/A

110.2 0200089911 WASHER M8 2 N/A

110.3 267817-6 WASHER 8 2 N/A

111 6252500400 CLUTCH BOLT 2 N/A

111.2 266457-7 SHOULDER HEX. BOLT M6X25 2 N/A

112 5245500702 BAFFLE PLATE 1 N/A

112.2 5245500703 BAFFLE PLATE 1 N/A

113 6251505300 CLUTCH CASE 1 N/A

113.2 6251505301 CLUTCH CASE 1 N/A

114 0031512000 OUTER SNAP RING 1 N/A

114.2 0031512000 OUTER SNAP RING 1 N/A

114.3 961052-5 segrovka vnější S-12 1 N/A

115 0119059730 SOCKET HEAD BOLT M5X20 2 N/A

115.2 266814-9 HEX SOCKET HEAD BOLT M5X20 2 N/A

116 0119059730 SOCKET HEAD BOLT M5X20 2 N/A

116.2 266814-9 HEX SOCKET HEAD BOLT M5X20 2 N/A

117 6255502002 STAND 1 N/A

118 6255502100 STAND DAMPER 2 N/A

119 5316501701 TUBE 1 N/A

119.2 0851169970 TUBE 1 N/A

119.3 0851169971 TUBE 1 N/A

120 0561080010 svorka 1 N/A

120.2 0230089970 SPACER*** 000081 1 N/A

121 5236503900 filtr RST/RBC/RBL/EM4250/BHX 1 N/A

121.2 163447-0 palivový filtr DCS230T 1 N/A

122 5316011000 FUEL TANK CAP ASS'Y*** 000129 1 N/A

122.2 5316014000 FUEL TANK CAP COMPLETE 1 N/A

Seite 9/12

Makita Werkzeug Ges.m.b.H.

Airportstr. 4, 2401 Fischamend

Tel: 02232 / 777 00

Fax: 02232 / 777 00 - 40

Mail: [email protected]

Web: www.makita.at

Makita Service Information / Model: RBC260

POS Bestell-Nr. Artikelbeschreibung Stk. Stk.Preis

122.3 5256058000 víčko palivové nádrže= old 5316014000 1 N/A

122.4 452920-8 FUEL TANK CAP 1 N/A

123 5246500301 DAMPER 1 N/A

124 5246500301 DAMPER 1 N/A

125 5246500500 FUEL TANK 1 N/A

126 5246500202 FUEL TANK PLATE 1 N/A

127 0119059730 SOCKET HEAD BOLT M5X20 2 N/A

127.2 266814-9 HEX SOCKET HEAD BOLT M5X20 2 N/A

128 5216008010 CABLE ADJUST SCREW M6X8 1 N/A

128.2 266795-7 ADJUST SCREW 1 N/A

129 5316005450 CABLE ADJUST NUT 1 N/A

129.2 264065-8 CABLE ADJUST NUT M6 1 N/A

130 5246001240 THROTTLE COLLAR SCREW 2 N/A

130.2 266704-6 PAN HEAD SCREW M3X10 2 N/A

131 5206008110 PLUG 1 N/A

131.2 424439-7 PLUG CUP 1 N/A

132 5236018040 SWIVEL 1 N/A

132.2 325922-6 SWIVEL 1 N/A

133 5236018010 THROTTLE VALVE ASS'Y 1 N/A

134 5316005120 RING 1 N/A

134.2 257964-1 STOP RING E-3 1 N/A

135 5246008000 CARBURETOR 1 N/A

135 *** INC.128-134,136-148,150 N/A

136 5236018030 CABLE BRACKET 1 N/A

137 5246001010 O RING 1 N/A

137.2 213538-8 O RING 2 1 N/A

138 5236046030 JET 1 N/A

139 5246001030 PUMP GASKET 1 N/A

139.2 442172-9 PUMP GASKET 1 N/A

140 5246001040 membrána 1 N/A

140.2 168575-6 membrána čerpadla 1 N/A

141 5236046130 PUMP BODY ASS'Y 1 N/A

141.2 140989-1 PUMP BODY ASSEMBLY 1 N/A

142 5236046040 METERING DIAPHRAGM GASKET 1 N/A

142.2 442154-1 těsnění membrány 1 N/A

143 5316005250 membrána 1 N/A

143.2 168767-7 METALING DIAPHRAGM 1 N/A

144 5236046060 AIR PURGE BODY ASS'Y 1 N/A

144.2 140988-3 AIR PURGE BODY ASSEMBLY 1 N/A

145 5246001150 páčka čerpadla BHX2500A 1 N/A

Seite 10/12

Other Makita Power Tools Accessories manuals

Makita

Makita EN422MP User manual

Makita

Makita 4301BV Operating and installation instructions

Makita

Makita WST05 User manual

Makita

Makita UB400MP User guide

Makita

Makita UB400MP User guide

Makita

Makita P-54190 User manual

Makita

Makita EM407MP User guide

Makita

Makita 194485-1 User manual

Makita

Makita HR4013C User manual

Popular Power Tools Accessories manuals by other brands

Bosch

Bosch OSC004 manual

Rockler

Rockler 57510 instructions

Bosch

Bosch RA1054 Operating/safety instructions

Kitagawa

Kitagawa SC N Series instruction manual

Wolfcraft

Wolfcraft FKS 145 Translation of the original operating instructions

ADAMAS

ADAMAS B32 Instructions for use

STEINEL PROFESSIONAL

STEINEL PROFESSIONAL 4007841009595 quick start guide

Grizzly

Grizzly T10808 instructions

RG AVAK

RG AVAK MaxDrill Series instruction manual

Stihl

Stihl 4850 490 0500 quick start guide

Husqvarna

Husqvarna BV 30 Operator's manual

Malco

Malco TurboShear HD TSHDRB Replacement instructions

TREND

TREND trend COMBI 650 user manual

Sealey

Sealey Power Products AK456DX instructions

Dust Right

Dust Right Downdraft Table Assembly instructions

Toro

Toro 138-5050 installation instructions

Ryobi

Ryobi AC04142 manual

jbc

jbc CL6220 instruction manual

Makita RBC260 Operating and installation instructions

Popular Power Tools Accessories manuals by other brands
