Parts Breakdown 3612

Page 1 of 3 2/8/2008

Parts Breakdown 3612

Fig # Part ID Part Name Quantity

1 266021-4 TAPPING SCREW PT5X20, HM1100C 2

2 415450-0 REAR COVER, 3612 1

5 159668-0 MOTOR HOUSING COMPLETE, 3612 1

6 851516-6 NAME PLATE, 3612 1

7 636056-3 FIELD 1

8 415069-5 BAFFLE PLATE, 3612 1

9 211092-6 B. BEARING 629DDW, BO4530 1

10 681633-6 INSULATION WASHER, LS1211 1

11 516566-5 ARMATURE ASS'Y 115V, 3612 1

12 241878-4 FAN 83,3612 1

13 285657-0 BEARING RETAINER 50, 3612BR 1

14 211326-7 B. BEARING 2012DDW, 3612BRA 1

15 415070-0 KNOB (L), 3612 1

16 150443-7 MOTOR BRACKET CPL.,3612-T1 1

17 231142-1 COMP. SPRING, 3612B, 3612BR 1

18 323559-3 HALF NUT, 3612BRA 1

19 911263-2 P.H. SCREW M5X40, 2711 4

20 763629-0 COLLET NUT, 3612BR 1

21 763622-4 1/2 COLLET CONE, 3612BR 1

22 911368-8 P.H. SCREW M6X45, 3612 2

23 415071-8 KNOB (R), 3612 1

24 231618-8 TORSION SPRING 15, 3612 1

25 266015-9 SET BOLT M10, 3612 1

26 344097-2 LOCK LEVER, 3612 1

27 265269-5 HEX BOLT M5X12, 3612BR 1

28 286235-9 CAP 11, 3612 1

29 962062-5 RETAINING RING R-12, 3612 1

30 256606-4 PIN 6, 3612BR, 9300 1

31 231037-8 COMP. SPRING 7, GA7001L 1

32 251861-3 SCREW M10X77, 3612BR 1

33 251295-0 F.H. SCREW M4X14, 3612BRA 4

34 911944-8 P.H.SCREW M5X80, LS1211 2

35 643700-5 BRUSH HOLDER CAP 7-18 , HM1500B 2

36 191953-5 CARBON BRUSH SET CB-203, LS1211 1

37 682505-8 CORD GUARD, 2711 1

38 687052-4 STRAIN RELIEF, HM1500B 1

39 265995-6 TAPPING SCREW 4X18, 4323K 2

40 664463-0 CORD (2X14X8 SJ), 2414B 1

41 316499-2 HOUSING W/O BEARING, 3612 1

42 265995-6 TAPPING SCREW 4X18, 4323K 2

43 152566-7 KNOB 50 COMPLETE 1

44 410129-8 NYLON NUT M10, 3612BR 1

46 651416-8 SWITCH , 3612 1

47 415072-6 SWITCH COVER, 3612 1

48 265995-6 TAPPING SCREW 4X18, 4323K 2

49 314062-5 POLE, 3612BR 1

50 231329-5 COMP. SPRING 11, 3612BR 2

51 151158-9 BASE, 3612BR 1

52 924206-5 THUMB SCREW M5X10, 5077B 1

53 410128-0 CHIP DEFLECTOR, 3612BR 1

54 912112-6 C.S.H. SCREW M4X10, 3700B 4

56 413024-1 BASE PLATE, 3612C 1

57 134205-1 STOPPER,3612BR 1

58 931202-6 HEX NUT M5, HR2410 1

59 265335-8 HEX BOLT M5X28, 3620 1

60 231231-2 COMP. SPRING 12, 3612BR 1

61 251423-7 SCREW M6, 3612BR 1

62 931202-6 HEX NUT M5, HR2410 1

63 265336-6 HEX BOLT M5X40, 3612C 1

64 931202-6 HEX NUT M5, HR2410 1

Page 2 of 3 2/8/2008

Parts Breakdown 3612

65 265333-2 HEX BOLT M5X16, 3620 1

66 231240-1 COMP. SPRING 7, 2414B 2

67 924216-2 THUMB SCREW M5X15, 9030 2

1,002 781213-9 WRENCH, 3612BR, 3620 1

1,003 781030-7 WRENCH, 3612 1

1,007 763803-0 1/4 COLLET SLEEVE, 3612BR 1

Page 3 of 3 2/8/2008
