Makita 4326 User manual

*4326, 4327, 4328, 4329
65mm*
Capacity in Wood
450W
Powerful Low
Vibration
Satisfy Professional's Needs
Extremely Smooth Operation
by Powerful Motor
Bayonet shank Jig Saw Blade Makita shank Jig Saw Blade
Jig Saw
4326M, 4327M4326, 4327, 4328, 4329

Jig Saw 4326/M, 4327/M, 4328, 4329
Continuous rating Input
Capacity
In wood at 90 degrees
In steel at 90 degrees
Length of stroke
Strokes per minute (spm)
Dimensions
(L x W x H)
Net weight
Power supply cord
450W
: 65mm (2-9/16")
: 6mm (1/4")
18mm (11/16")
500 - 3,100
223 x 77 x 197mm
(8-3/4" x 3" x 7-3/4")
1.9kg (4.2lbs)
2.0m (6.6ft)
450W
: 65mm (2-9/16") (4326, 4327, 4328)
: 40mm (1-9/16") (4326M, 4327M)
: 6mm (1/4")
18mm (11/16")
3,100 (4326/M)
500 - 3,100 (4327/M, 4328)
217 x 77 x 197mm
(8-1/2" x 3" x 7-3/4")
1.8kg (4.0lbs)
2.0m (6.6ft)
Items of standard equipment and specifications may differ by country or area.
Standard Equipment Jig Saw Blade, Hex Wrench
Double Insulation
Dust Collecting
Variable Speed
4327/M, 4328, 4329
Orbital Cutting
4328, 4329
Bayonet Shank Jig Saw Blade
4326, 4327, 4328, 4329
Makita Shank Jig Saw Blade
4326M, 4327M
Accessories
Hose Complete 28-3
Part No. 192279-8
Anti-Splintering Device
(For cleaner cuts) 5per pkg.
Guide Rule Set
Part No. 192732-4
Cover Plate
For Model 4329
Part No. 417852-6
43294326/M, 4327/M, 4328
64
4329
4326
Comparison of Features
For more Comfortable Cutting...
Jig Saw Blade
type
Orbital cutting
Base plate
Variable speed
control by dial
For Model 4326 4326M 4327 4327M 4328 4329
Bayonet
-
Steel
-
Makita
-
Steel
-
Bayonet
-
Steel
Makita
-
Steel
Bayonet
Steel
Bayonet
Aluminum
Rigid and Rust- Resistant
Aluminum Base (4329 only)
slides smoothly over the surface of a workpiece.
Sliding Dust Cover
Connectable to Vacuum Cleaner
Using Hose (Optional Accessory)
3 Orbital Settings
+Straight Cutting
Hex Wrench
Storage
Bevel cutting
Thick Blade (1.7mm thickness) is available
Variable speed control by dial
Low Vibration
Counterweight balancing
system reduces vibration.
Reducing vibration makes
operator feel more
comfortable when cutting
various workpieces.
Provides more control and
comfort while minimizing
hand fatigue and pain.
(4328, 4329)
Optimum cutting action can
be selected by simply turning
the change lever.
in Addition to the Current 1.1mm Thickness Blade. 1.7mm thick blade performs
well in straight cutting and curve cutting to thick workpiece.
Bosch's equivalent can be installed. (4326, 4327, 4328, 4329)
Base can be tilted up to 45 degrees to the left or right.
ensures optimum cutting speed per job.
(4327, 4327M, 4328, 4329)
Improves dust-collection
efficiency and prevents
scattering of chips.
Ergonomically
designed
rubberized grip
Photo : 4329
450
W
Powerful
For Model
4326/M, 4327/M, 4328
Part No. 192733-2
For Model 4329
Part No. 192557-6
PRINTED IN JAPAN Z23329-2 2007-08
Makita Corporation
3-11-8 Sumiyoshi-cho, Anjo, Aichi, 446-8502 Japan
