Makita 4304t User manual

Jig

Saw

Model

4304T

4305T

.

MODEL

4304T

MODEL

4305T

Variable Speed

INSTRUCTION

~

MANUAL

Length Max. cuttingcapacities Strokes Overall Net

of

stroke Wood Mild

Steel

Aluminum per minute length weight

249

mm

26" 135" 10mm 19-3/4"1 2.4 kg

(1") (5-5116") (318")

(:g/yg')

500

~

3,000

287

mm

(5.3

Ibs)

(11-5/16',)

43041

4305T

DOUBLE

INSULATION

SPECIFICATIONS

Manufacturer reserves the right to change specifications without notice.

Note: Specifications may differ from country to country.

WARNING: For your personal safety, READ and UNDERSTAND before using.

SAVE

THESE

INSTRUCTIONS

FOR

FUTURE REFERENCE.

IMPORTANT

SAFETY INSTRUCTIONS

(For

All

Tools)

WARNING:

WHEN USINGELECTRICTOOLS, BASICSAFETY

PRECAUTIONSSHOULD ALWAYS BE FOLLOWEDTO REDUCE

THE RISK OF FIRE, ELECTRIC SHOCK, AND PERSONAL

INJURY, INCLUDING THE FOLLOWING:

READ ALL INSTRUCTIONS.

1.

KEEP WORK AREA CLEAN. Cluttered areas and benches invite injuries.

2.

CONSIDER WORK AREA ENVIRONMENT. Don't use power tools

in

damp

or wet locations. Keep work area well

lit.

Don't expose power tools to rain.

Don't use tool

in

presence of flammable liquids or gases.

3.

KEEP CHILDREN AWAY. All visitors should be kept away from work area.

Don't let visitors contact tool or extension cord.

4.

STORE IDLETOOLS. When not

in

use, toolsshould bestored

in

dry, andhigh

or locked-up place

-

out of reach of children.

5.

DON'T FORCE TOOL.

It

will

dothejob better andsafer atthe ratefor which

it

was intended.

6.

USE RIGHT TOOL. Don't force small tool or attachment todo the job of a

heavy-dutytool. Don't usetoolfor purposenotintended; for example, don't

use circular saw for cutting tree limbs or logs.

7.

DRESS PROPERLY. Don't wear looseclothing orjewelry. They can becaught

in

moving parts. Rubber gloves and non-skid footwear are recommended

when working outdoors. Wear protectivehair covering to contain long hair.

8.

USE SAFETY GLASSES. Also use face or dust mask if cutting operation is

dusty.

9.

DON'T ABUSE CORD. Never carry tool by cordor yank

it

todisconnect from

receptacle. Keep cord from heat, oil, and sharp edges.

IO.

SECURE WORK. Use clamps

or

a vise to hold work. It's safer than using

your hand and

it

frees both hands to operate tool.

11.

DON'T OVERREACH. Keep proper footing and balance at all times.

12.

MAINTAIN TOOLS WITH CARE. Keep tools sharp and clean for better and

safer performance. Follow instructionsfor lubricatingand changing acces-

sories. Inspecttoolcords periodicallyand ifdamaged, have repairedbyautho-

rized service facility. Inspect extension cords periodically and replace if

damaged. Keep handles dry, clean, and free from oil and grease.

13.

DISCONNECTTOOLS. When not

in

use, beforeservicing, and when chang-

ing accessories, such as blades, bits, cutters.

2

14. REMOVE ADJUSTING KEYS AND WRENCHES. Form habit of checking to

see that keys andadjusting wrenches are removed from toolbefore

turning

it

on.

15. AVOID UNINTENTIONALSTARTING. Don't carry toolwith finger onswitch.

Be sure switch is OFF when plugging

in.

16.

EXTENSION CORDS. Make sure your extension cord is in good condition.

When using an extension cord, be sure to use one heavy enough to carry

the current your product will draw. An undersized cord will cause a drop

inlinevoltage resulting in

loss

of power and overheating. Table

1

shows the

correct size touse depending oncord lengthand nameplate ampere rating.

If in doubt, use the next heavier gage. The smaller the gage number, the

heavier the cord.

TABLE

1

MINIMUM

GAGE

FOR

CORD

SETS

18

16

14

I

Total Length

of

Cord in Feet

16 16 14

16 14 12

12

Not

Recommended

I

0

-

25

I

26

-

50

I

51

-

100

I

101

-

150

Ampere Rating

More

Not

More

Than Than

0-

6

-

10

-

12

-

16

17. OUTDOOR USE EXTENSIONCORDS. When toolisused outdoors, use only

extension cords intended for use outdoors and

so

marked.

18. STAY ALERT. Watch what you are doing, use common sense. Don't operate

tool when you are tired.

19. CHECK DAMAGEDPARTS. Before further use of the tool, a guard or other

part that is damaged should be carefully checked to determine that

it

will

operate properly and perform itsintended function. Check for alignment of

moving parts, bindingof moving parts, breakageof parts, mounting, and any

other conditions that may affect its operation. A guard or other part that

is damaged should be properly repaired or replaced

by

an authorized serv-

ice center unless otherwise indicated elsewhere inthis instruction manual.

Have defective switches replaced

by

authorized service center. Don't use

tool

if

switch does not turn

it

on and off.

20.

GUARD AGAINST ELECTRIC SHOCK. Preventbody contact withgrounded

surfaces. For example; pipes, radiators, ranges, refrigerator enclosures.

21.

REPLACEMENT PARTS. When servicing, useonly identicalreplacementparts.

22.

POLARIZEDPLUGS. To reduce the risk of electric shock, this equipment has

a polarized plug (one blade is wider than the other). This plug will

fit

in a

polarized outlet only one way. If the plug does not fit fully in the outlet,

reverse the plug. If

it

stilldoes notfit, contact a qualifiedelectrician toinstall

the proper outlet. Do not change the plug in any way.

3

VOLTAGE WARNING: Before connecting the tooltoa powersource (receptacle,

outlet, etc.) be sure the voltage supplied is the same as that specified on the

nameplate of the tool. A power source with voltage greater thanthat specified

for the tool can result

in

SERIOUS INJURY tothe user

-

as well as damage to

the tool.

If

in

doubt, DO NOT PLUG IN THE TOOL. Using a power source

with

voltage less than the nameplate rating is harmful to the motor.

ADDITIONAL SAFETY RULES

1.

Avoid cutting nails. Inspectfor and removeall nails from the workpiece before

2.

Don't cut hollow pipe.

3.

Do not cut oversize workpiece.

4.

Check for the proper clearance beneath the workpiece before cutting

so

that

5.

Always wear eye protection conforming with current national standard.

6.

Hold the tool firmly.

7.

Make sure cord is out of your way and not

in

the line of cut.

8.

Make sure the blade is not contacting the workpiece before the switch is

9.

Keep hands away from moving parts.

operation.

the blade will not strike the floor, workbench, etc.

Severe eye injury could result.

turned on.

.

IO.

When cuttingthrough walls, floors or wherever "live" electrical wires may

be encountered, DO NOT TOUCH ANY METAL PARTS

OF

THE TOOL!

Holdthe tool only by the insulatedgraspingsurfacestopreventelectric shock

if you cut through a "live" wire.

11.

Do not leave the tool running. Operate the tool only when hand-held.

12.

Always switchoff and wait for the blade tocometoa completestop before

13.

Do not touchthe blade or the workpiece immediately after operation; they

removing the blade from the workpiece.

may be extremely hot and could

burn

your skin.

SAVE THESE INSTRUCTIONS.

4

,

Installing

or

removingthe saw blade

CAUTION

:

.Always be sure that the tool

is

switched off and unplugged before installingor removing

the blade.

.Always clean off the blade and blade holder before installingthe blade.Chips or foreign

matter on them may cause insufficient securingof the blade, possibly resulting in blade

breakage or serious injury.

0

Do

not switch on the tool with the clamp protruding from the blade holder. The clamp,

blade holder or roller may be damaged.

For 4304T

1.

Pull the blade installinglever in the

@

direction until

it

stops while lifting

it

slightly.

2.

Rotate the blade installing lever in the

@

direction and the clamp on the blade holder

will open. Open the clamp

a

little

more than the thickness of the blade to be installed.

3.

With the blade teeth facing forward, insert the blade into the blade holder

as

far

as

it

will go. Make sure that the back edge of the blade fits properly into the groove

of

the

ro

I

ler

.

direction to tighten the clamp.

4.

With the blade held against the blade holder, rotate the blade installing lever inthe

@

Blade holder

Roller

5.

With the blade installing lever held

ii

this position, move

it

in the

@

direc-

tion. Then rotate the blade installing

lever in the

@

direction to return

it

to

its

original position.

"I

5

For

4305T

1.

Press the button to raisethe blade installing knob.

2.

Rotatethe blade installingknob inthe

0

direction and the clamponthe blade holder

will open. Open the clamp

a

little

more than the thicknessof the blade to be installed.

3.

With the blade teeth facing forward, insert the blade into the blade holder

as

far

as

it

will go. Make sure that the back edge of the blade

fits

properly into the groove of the

roller.

4.

With the blade heldagainst the blade holder, rotate the blade installingknob inthe

@

direction totighten the clamp.

Position Cutting action

Blade installing knob

Button

Applications

Blade holder

Roller

Straight

line

cutting

action

0

5.

With the blade installing knob kept inthis position, push

it

back down to

its

original

NOTE

:

Occasionally lubricatethe roller.

position.

For cutting mild steel, stainless steel and plastics.

For clean cuts in wood and plywood.

Selecting

the

cutting action

This tool can be operated with an orbital

or

a

straight line cutting action. To change

the cutting action, just turn the lever tothe

desired cutting action position. Refer to

the table below to help determine the

appropriatecuttingaction.

Medium

orbit cutting

action

I1

I

For cutting wood and plywood.

For fast cutting in aluminum and mild steel.

1

I

Small orbit cutting action

I

For cutting mild steel, aluminum and hard wood

I

111

I

Large orbit cutting action

I

For fast cutting

in

wood and plywood.

6

Switch

action

For4304T

CAUTION

:

Before plugging in the tool, always check to

see

that the switch trigger actuatesproperly

and returnsto the

"OFF"

position when released.

operation, pull the trigger and move the

lock lever backward.

To

stop the

tool

from

the locked position, pull the trigger fully,

then release

it.

I

Lock

lever

To

start the tool, simply pull the trigger.

Release

the trigger to stop. Forcontinuous

Switch trigger

For 4305T

CAUTION:

Beforeplugging inthe tool, always check to

see

that the switch actuatesproperly.

To start the tool, slide the switch lever

forward. Slide the switch lever backward

tostop.

Speed adjustingdial

The tool speed can be adjusted and maintained between

500

and 3,000 strokes per

minute by turning the adjustingdial. The dial

is

marked

1

(lowestspeed) to

6

(fullspeed).

For

4304T

Speed adjusting dial

I

Speed

adjusting

dial

For

4305T

Refer to the table

at

right to Select the Pro-

However, the appropriatespeed may differ

Mild

Steel

per speed for the workpiece to be cut.

with the type

or

thickness of the work-

piece. In general, higher speeds will allow

Stainless

Steel

you to cut workpieces faster but the

Aluminum

service lifeof the bladewill be reduced.

Plastics

CAUTION

:

Adjust the speed adjusting dial only within the range of numbers

1

through

6.

Do

not

force the dial beyondthis range or damage tothe tool may result.

Cutting operation

CAUTION

:

0

Always hold the tool with the base flush with the workpiece. Failuretodo

so

may cause

.Advance the tool very slowly when cutting curves or scrolling. Forcingthe tool may

a

slanted cutting surface and blade breakage.

cause

a

slanted cutting surface and blade breakage.

Turn the tool on without the blade making

any contact.

Rest

the base flat on the

workpiece and gently move the tool for-

ward along the previously marked cutting

line.

Cutting line

Bevel

cutting

CAUTION

:

Always unplugthe tool before makingany adjustments.

With the base tilted, you can make bevel cuts

at

any angle between

0'

and

45'

(left or

right). Loosen the base securing lever and move the base

so

that the dent mark in the

motor housing

is

aligned with the slot in the base. Tilt the base until the desired bevel

angle

is

obtained. The edge of the motor housing indicatesthe bevel angle by graduations.

Then tighten the base securing lever tosecure the base.

NOTE

:

Always remove the plastic cover (chip shield) from the tool when you make bevel cuts

usingan optional guide rule (ripfence) or circular guide.

.

Base

securing

lever

8

Flushcutting

Loosen

the

base securing

lever

and slide the

base

all

the way back. Then tighten the

base securing lever tosecure the base.

cutouts

Cutouts can be made with either

of

two methods A or

B.

A)Boring

a

starting hole:

For internal cutouts without

a

lead-in

cut from and edge, pre-drill starting hole

more than 12mm (15/32") indiameter.

Insert the blade into this hole and hold

the tool firmly against the workpiece

to start your cut.

B)

Plungcutting:

You need not bore

a

starting hole

or

make

a

lead-in cut if you carefully

do

as

follows:

1.

Tilt the tool up on the front edge of

the base, with the blade point posi-

tioned just above the workpiece sur-

face.

2. Apply firm pressure to the tool

so

that the front edge

of

the base will

not move when you switch on the

tool and gently lower the back end

of the tool slowly.

\

,-,/---

3. As the blade slices into the workpiece, slowly lower the base

of

the tooldown onto

4.

Completethe cut inthe normal manner.

the workpiece surface.

9

Finishing edges

To

trim

edges

or

make slight dimensional

adjustments, runthe blade lightly alongthe

cut edges.

//

Metal

cutting

Always use

a

suitablecoolant (cuttingoil) when cuttingmetal. Failure to do

so

will cause

significant blade wear. The underside of the workpiece can be greased insteadof using

a

coolant.

Plasticbase plate

Use the plastic base plate when cuttingde-

corative veneers, plastics,

etc.

l

t

protects

sensitive or delicate surfaces from damage.

To

replace the base plate, remove the four

screws.

Anti-splintering device

To

reduce the potential for workpiece

surface splintering, the anti-splintering

device can be used. Fit

it

into the base

from below

so

that

it

surrounds the

sides

of the blade.

Screw

ic

base plate

I

ase

Anti-splintering

device

ef

10

Guide rule (ripfence; optional accessory)

When

cutting widths of under

150

mm

(5-29/32")

repeatedly, use of the guide

rule will assure fast, clean, straight cuts.

To

install

it,

loosen the bolt on the front

of

the base. Slip

in

the guide rule and secure

the bolt.

Circular guic, (optional accessory

Use

of

the circular guide insures clean,

smooth cutting

of

circles under

200

mm

(7-7/8")

in radius. Insert the pin through

the center hole and secure

it

with the

threaded knob. Move the base of the tool

fully forward. Then install the circular

guide on the base in the same manner

as

the guide rule (ripfence).

Vacuum head (optional accessory)

The vacuum head

is

recommended to per-

form clean cutting operations. Install the

plastic cover on the tool by fitting

it

into

the notches inthe tool.

To attach the vacuum head on the tool,

insert the hook of the vacuum head into

the hole in the base. The vacuum headcan

be installed on either left or right side

of

the base. Then connect

a

Makita vacuum

cleaner to the vacuum head.

Hex wrench

Bolt

Guide rule

Y

0

Threaded

knob

&Circular

guide

Vacuum head

17-

I

Base

11

MAINTENANCE

CAUTION:

Always be sure that the tool

is

switched off and unplugged before attemptingtoperform

inspectionor maintenance.

Cleaningthe

clamp

on

the

blade holder

If chips or foreign matter

get

into the clamp on the blade holder, clean out

the

clamp

after removing

it

from the blade holder. To removethe clamp, rotate the blade installing

lever (for 4304T) or knob (for4305T) inthe blade loosening direction

as

far

as

it

will go.

Then remove the clamp from the blade holder while rotating the clamp counterclock-

wise. To install the clamp, first make sure that the blade installing lever (for 4304T) or

knob (for 4305T) has been rotated in the blade loosening direction

as

far

as

possible.

Insert the clamp into the blade holder while rotating

it

clockwise one quarter toone full

turn. Grasp the clamp with your fingers

so

that

it

will not turn, then rotate the blade

installing lever or knob inthe bladetighteningdirection

so

that the clampwill go intothe

blade holder.

8

Blade holder

Clamp

To maintain product SAFETY and RELIABILITY, repairs, any other maintenance or

adjustment should be performed

by

Makita Authorized or Factory Service Centers,

always using Makita replacementparts.

12

ACCESSORIES

CAUTION:

These accessories or attachments are recommended for use with your Makita tool specified in this

manual. The use

of

any other accessories or attachments might present

a

risk

of

injury to persons.

The accessories or attachments should be used only in the proper and intended manner.

An exception: Universalshank jig saw blades with a thickness

of

1 mm

-

1.25 mm (1/32"

-

3/64")

-

No.

58

No.

59

No.

6-10

and a length

of

58

mm

792429

1

8

80

mm (3-1/8")

792430-6

8

EO

mm 13-1/8"1

792529-7 9

80

mm

13-l/E"l

82 mm (2-9/32"

-

3-7/32").

No.

8-14

Plastic base plate

Part

No.

415537-8

792466-5

18

50"

12")

*Hex wrench

3

Part

No.

783201-2

r

Circular guide assembly

Part No. 123030.5

Vacuum head

Part No. 192418-0

Jig saw blade

(Packed 5 each)

Effective cutting

blade length

'lade

type

I

Part

No'

I

pz?i:h

I

NO.

51

I

792428-3

I

24

I

65mm i2-1/2")

No.

6-11

I

792463-1

1

9

1

75 mm 13")

No.

6-12

I

792464~9

1

6

1

80" 13-1/6"1

No.

6-13

I

792465-7

I

8

I

80

mm (3-118")

NO.

6-16

1

792468-1

I

6

I

80

mm 13-1/8"1

NO.

6-17

I

792469-9

I

6

I

70

mm

12-314")

Anti-splintering device

Part

No.

415524-7

Plastic cover

Part No. 415525-5

Guide rule

Part

No.

164113-2

Hose

19

-

2.5

Part

No.

192108.5

(Note)

Refer to the next page for "Application" of each blade.

13

Jig

saw

blade

Wood and plywood Plastics Aluminum

1.5

-

3

mm

thick 1

-

6

mm

thick

-

11/16''

-

118") 13/64"

-

1/4"l

H

Blade type Mild steel

1

-

3

mm

thick

(3164''

-

1/8"l

Application

4

-

60

mm thick

15/32"

-

2

318") 15/32"

-

2-318")

-

4

-

60

mm

thick

9

Feature

-

4

-

30 mm thick

15/32"

-

l-l/8"1 15/32"

-

l-l/8"l

-

4

-

30

mm

thick

S

~

No.

51

-

Also ideal for cutting

stainless steel.

3

-

30mm thick 3

-

50

mm

thick

1118"

-

1-118"I

IlW'

-

2")

-

S

-

For fast cutting.

4

-

60

mm

thick

15/32"

-

2-318")

2

-

30mm thick

15/64,

-

1-118"l

No.

58

4

-

60

mm thick

15132"

-

2-318")

-

S

2

-

30 mm thick

15/64'

-

l-l/E"I

- -

H

5

-

60

mm

thick

5

-

60

mm thick

S

113164'

-

2-318") 113/64'

-

2-318")

-

~~

For fast finish work

-

No

59

3

-

30

mm

thick

1118"

-

1~1/8")

-

3

-

30

mm

thick

1118"

-

1~1/8")

-

H

3

-

55 mm thick 3

-

10mm thick

1118''

-

2-118"l

-

1118"

-

318")

H

1.5

-

3

mm

thick 1

-

6

mm

thick

-

11/16"

-

118") (3164'

-

1/4"l

U

1

-

3 mm thick

13/64"

-

1/8"l

-

3

-

6

mm

thick 3

-

10

mm

thick 3

-

6

mm

thick

(118"

-

1/4'1 1118''

-

318")

1118''

-

1/4"l

H

1

-

3 mm thick

0.5

-

3 mm thick 0.5

-

2

mm

thick

(3164''

-

118"I (1164''

-

118") (1164''

-

5/64,')

H

3

-

55

mm thick 3

-

55 mm thick 3

-

30 mm thick

1118''

-

2-118") 1118''

-

2-118") 1118"

-

1-1/8"1

3

-

10

mm

thick

1118''

-

318")

H

3

-

55

mm

thlck

11/8"

-

2-118")

H

3

-

55 mm thick 3

-

30

mm

thick 3

-

10

mm

thick

1118''

-

2 118") 1118"

-

1 118") 11/8"

-

3/8"l

H

5

-

60

mm

thick

113/64"

-

2 318")

5-llOmmthick

113164'

-

4-5/16',)

-

- -

5-11Ommthick

-

113164'

-

4-5/16"1

-

I-

For fast finish work,

especially in plywood.

For fast finish work

No.

6-10

No.

8-

11

No.

8-12

I-

For fast finish work

No.

8-13 For roughing-in work.

Ideal for cutting

thin materials.

No.

8-14

I

3

-

30

mm

thick 3

-

30 mm thick

1118"

-

1-1/8"1 11/8"

-

1-118"l

IH

Ideal for cutting

thin materials.

No.

B-

15

No.

8-16 For fast cutting.

Ideal for scroll cutting.

5

-

60

mm

thick

I13/64'

-

2-3/8"1

5

-

60

mm thick

I13/64"

-

2-318")

Is

No.

8-17

No.

6-18

~

2

-

30mm thick

15/64'

-

1-118") 2

-

30

mm

thick

15/64"

-

1 1/8"1

4

I-

Ideal for scroll cutting

No.

8-19 Cuts on down stroke.

Splinter-free

on

finish side

For finish work,

especially in plastics.

No.

8-21

Also ideal for cutting

stainless steel.

No.

8-22

Also ideal for cutting

stainless steel.

No.

8-23

No.

8-24 Also ideal for cutting

stainless steel.

No.

8-25 Ideal for cutting

thick materials.

Ideal for scroll cutting

No.

8-26

1.511/16,,

-

3

-

mm

thick

l

I

1

-

6

mm thick

I

1

-

3

mm

thick

-1H

13/64"

-

114") 13/64"

-

118") Ideal for scroll cutting.

No.

8-27

No.

BR-

13 Splinter-free cuts in wood,

requiring

no

sanding.

Idealfor cutting

thick materials.

No.

8-16L

NOTE:

"H"

stands for hard materials

"S" stands

for

soft

materials

14

JIG

SAW

Model

4304T

Note: The switch, noise suppressor and other part configurations

may differ from country to country.

15

ITEM

NO.

NO. USE0 DESCRIPTION

$2D

DESCRIPTION

MACHINE

-

1

2

3

4

5

6

7

8

9

10

11

12

14

15

16

17

18

19

20

21

22

23

24

25

26

27

28

29

30

31

32

33

34

35

36

37

38

39

40

41

42

43

44

45

46

47

1

2

1

2

1

2

1

-

Pan

Head

Screw

M4x8 [With Washer1

Handle

Set

[With Item 441

Lever 51

Inner

Level

Compression Spring 4

Caution Label

Lock

On

Lever

Switch

Controller

PI"

3

Switch

Lever

Tapping

Screw

4x18

Strain

Relief

Cord

Guard

Tapping

Screw

Flange PT 4x20

Cord

Gear

Shaft

Flat Washer

8

Needle

Bearing

810

Helical

Gear

51

Needle Bearing 810

Flat Washer 26

Push Plate

Balance

Plate

Balance

Plate

Flat Washer 26

Crank Complete

Needle

Bearing

607

Thrust

Plate

Slider

Holder

Gear

Housing

Cover Complete

CO"WCt0,

Joint

Driver

Rod

Tapping Screw CT 4x16

Tapping

Screw

Flange PT 4x20

Retainer Complele

Tapping

Screw

PT 4x35

P," 4

Tapping Screw Flange PT 4x35

Handle

Set

IWith

Item

21

Rod

Blade

Fix

Slide

Plate

Spacer

MACHINE

~

48

49

50

51

52

53

54

55

56

57

58

59

60

61

62

63

64

65

66

67

68

69

70

71

72

73

74

75

76

77

78

79

80

81

82

83

84

85

86

87

88

89

90

91

92

-

2

1

2

1

2

1

3

1

4

1

2

1

2

1

2

1

-

Compression

Spring

4

Stop Ring

E-3

Countersunk

Head

Screw

M4x10

Hex

Socket Head Bolt M4x16

Retaining

Ring

5-8

Packing

Tapping

Screw

Flange PT 4x20

Flat Washer

6

Gem

Housing

Pan

Head

Screw

M4x10 [With Washer)

Flat Washer

6

Flat Washer 5

Lever

65

Hex Bolt M5x24

Nut

M6

Ball

Bearing

608LLB

Fan

54

ARMATURE ASSEMBLY

IWith

Item

63.

64

66

&

671

Insulation Washer

Ball

Bearing

607LL8

Rubber Ring

19

Base

Clamp Plate

Hex

Nut MI

Pan

Head

Screw

M4x8 IWith Washer1

Countersunk

Head

Screw

M5x8

Base

Plate

Carbon Brush

Brush

Holder

Choke Coil

Name Plate

Tapping

Screw

Flange PT 4x30

Rear

Cover

Makita Label

Motor

Housing

Field

All

cap

Baffle

Plate

Tapping

Screw

Flange PT 4x60

Lever 17

Compression Spring 4

Steel

Ball

4

Stop Ring E-5

Rubber

Pm 4

Cap

Note The switch

and

other part ~pe~ifi~ation~may

differ

from

country

to

country

16

JIG

SAW

Model

4305T

Note: The switch, noise suppressor and other part configurations

may differ from country to country.

17

'iiM

,,!&

DESCRIPTION

MACHINE

45

46

47

48

49

50

51

52

53

54

55

56

57

58

59

60

61

62

63

64

65

66

67

68

69

70

71

72

73

74

76

77

78

79

80

82

83

84

85

86

87

88

~

1

4

1

2

1

2

1

2

1

2

1

Head Cover Set IWith Item 261

Gear

Shaft

Flat Washer 8

Needle

Bearing

810

Helical

Gear

51

Needle

Bearing

810

Flat Wsher 26

Push Plate

Balance

Plate

Balance

Plate

Flat

Washer 26

Crank Complete

Needle

Bearing

601

Thrust Plate

Slider

Holder

Gear

Housing

Cover Complete

Joint

Driver

Rod

Tapptng

Screw

CT 4x16

Retainer

Complete

PO" 5

Lift Button

Knob

Box

Wrench

Head Cover Set [With

Item

11

Tapping Screw Flange PT 4x35

Tapping

Screw

PT 4x55

P," 4

Rod

Blade

Fix

Slide

Plate

Compression Spring 4

Stop Ring E-3

Countersunk Head

Screw

M4x10

Hex

Socket Head Bolt M4x16

Retaining

Ring

5-8

Packing

Tapping

Screw

Flange PT 4x20

Flat Washer 6

Gear

Housing

Pan Head

Screw

M4x10

(With

Washer1

Flat Washer

6

Flat Washer 5

MACHINE

~

10

It

12

13

14

15

16

17

18

19

20

21

22

23

24

25

26

27

28

29

30

31

32

33

34

35

36

37

38

39

40

41

42

43

44

11

21

31

41

51

61

71

81

91

1

2

1

2

1

2

1

2

1

2

1

3

1

Lever 65

Hex

Bolt

M5~24

Nut M6

Rubber Pin 4

Ball

Bearing 608LLB

Fan 54

ARMATURE ASSEMBLY

lWtth Item 49. 50. 52

&

531

InsulattonWasher

Ball

Bearing

607LLB

Rubber

Ring

19

Base

Clamp Plate

Hex Nut M5

Pan Head

Screw

M4xB IWith Washer)

Countersunk Head

Screw

M5x8

Base Plate

Switch Rod

Switch

SUppOrt

Terminal Block 2P

Controller

Rear

Covet

Name Plate

Tapping

Screw

Flange PT 4x60

Makita Label

Cord

Guard

Choke Coil

Tapping

Screw

4x18

Strain

Relief

Brush Holder

Carbon Brush

Motor Housing

Switch

Lever

Field

Air Cap

Bsffle

Plate

Tapping

Screw

Flange PT 4x60

Lever

17

Compression Spring 4

Steel Ball

4

Stop

Ring

E

-

5

Caution

Label (Not Illustratedl

Note: The Switch and other

part

specifications

may dbffer from country

to

countrv.

19

MAKCTA

LIMCTED

ONE

YEAR

WARRANTY

Warranty

Policy

Every Makita tool is thoroughly inspected and tested before leavingthe factory. It is warranted to

be free of defects from workmanship and materials for the period of ONE YEAR from the date of

original purchase. Should any trouble develop duringthis one-yearperiod, retum the COMPLETE

tool, freight prepaid, to one of Makita’s Factory or Authorized ServiceCenters.

If

inspectionshows

the trouble is caused by defective workmanship or material, Makita

will

repair (or at

our

option,

replace) without charge.

This Warranty doesnot apply where:

repairs have been madeor attempted by others:

a

repairs are required because

of

normal wear and tear:

a

The

tool

has been abused, misused or improperly maintained

;

alterationshave been made

to

the tool.

IN NO EVENT SHALL MAKlTA BE LIABLE FOR ANY INDIRECT, INCIDENTALOR CON-

SEQUENTIAL DAMAGES FROM THE SALEOR USE OFTHE PRODUCT.THIS DISCLAIMER

APPLIES BOTH DURING AND AFTER THE TERM OF THIS WARRANTY.

MAKlTA DISCLAIMS LIABILITY FOR ANY IMPLIED WARRANTIES, INCLUDING IMPLIED

WARRANTIES OF “MERCHANTABILITY” AND “FITNESS FOR A SPECIFIC PURPOSE,”

AITER THEONE-YEAR TERM OFTHIS WARRANTY.

This

Warranty gives you specific legal rights, and you may

also

have other rights which vary from

state to state. Some states do not allow the exclusion or limitation of incidental or consequential

damages,

so

the above limitation

or

exclusion may not apply to you. Some states do not allow

Limitation onhow

long

an implied warranty lasts,

so

the above limitation may not apply to you.

MAKlTA MANUFACTURINGEUROPE LTD

ROAD

7,

HORTONWOODINDUSTRIAL ESTATE

TELFORD, SHROPSHIRETF1 4GP

004032-065

Makita 4304T User manual

Popular Power Tools manuals by other brands
