Manrose EXTRACT-A-LITE Service manual

INSTALLATION INSTRUCTIONS
MANROSE CLASSIC 150mm
EXTRACT-A-LITE FAN RANGE
Installation Instructions
Important: The Halogen Extract-a-lite must not work independently of the fan.
1. Cut a 165mm diameter hole in ceiling, (always ensure the hole is cut between
ceiling rafters and away from any wiring or plumbing). Fix the Extract-a-lite chassis
using the 4 screws provided. Use the fixing clips to secure the fan in panel walls
& ceilings.
2. For the LED models: Connect a suitable driver to the Extract-a-Lite and to a
suitable power supply, ideally to the switched live of the extractor fan installed.
Recommended driver: FAN5342. Replacement lamp: LHT0221.
For the Halogen models: Connect a suitable transformer to the Extract-a-Lite and
to a suitable power supply, ideally to the switched live of the extractor fan installed.
Recommended transformer: FAN2101. Recommended lamp: FAN0431.
3. Place the white ceiling cover onto the Extract-a-lite chassis by positioning over the 3
lugs, and twisting clockwise.
4. Never connect mains direct to the lamp.
5. The transformer/driver must be suitable for 230V AC input.
CAUTION: Disconnect the power supply, and be sure that the lamp has
fully cooled before removing or replacing.
Fixing clip
Ceiling board
Screw
Fan
chassis
When screw is tightened fixing
clip fingers secure the fan
INSTALLATION
Thank you for selecting our Manrose 150mm Extract-a-Lite Fan Kit.
Please read all instructions before commencing installation.
Please ensure the corrrect LED lamp and driver OR Halogen lamp and transformer are used for
replacements. The LED model MUST be replaced with an LED lamp and the Halogen model
MUST be replaced with a Halogen lamp. They are not interchangeable.
Light Specifications:
LED models: FAN5369 and FAN5370
Driver Input: 220-240 VAC
Driver Output: 12VDC
Lamp MR16: 12V / 3W high power LED, 250beam angle
Halogen models: FAN0803 and FAN0804
Transformer Input: 220-240 VAC
Transformer Output: 12VAC
Lamp MR16: 12V / 50W Halogen, 600beam angle
DIMENSIONS
200mm
148mm
74mm
CLASSIC SERIES
IMPORTANT
• Isolate the mains supply before making any electrical connections. This system should be
installed by a qualified electrician.
• When fitting through an external wall, an external grille must be fitted at all times.
• Fan should only be installed by fixed wiring, a flexible cord should not be used.
• The appliance is not intended for use by young children or infirm persons without supervision.
• Young children should be supervised to ensure that they do not play with the appliance.
• Precautions must be taken to avoid the back-flow of gases into the room from the open flue of
gas or other open-fire appliances when mounted in outside windows or walls.
Fan Specifications:
Electrical: 220-240V ~50Hz
Airflow: 89l/s (320m³/hr)
Wattage: 38W
Max Temp: 70°C
IP Rating: IP44
Flexible
ducting
External
Grille
Internal
Extract-a-Lite
The Shower Fan
screwed to the joist
PUB0165 iss06 10/13
We reserve the right to change specification without prior warning
Manrose is proudly distributed by Simx Limited
PO Box 14 347, Panmure, Auckland, NZ. Technical Support [phone]
e: [email protected] | www.simx.co.nz | www.manrose.com.au

BROWN
BLUE
LIVE
EARTH
NEUTRAL
GREEN/YELLOW
RED
BLACK
TIMER
FAN0372
LIVE
NEUTRAL
EARTH
LIGHT SWITCH
FLUSH BOX
(WALL MOUNTED)
BLUE
BROWN
GREEN/YELLOW
YELLOW
ORANGE
BROWN
BLUE
LIVE
EARTH
NEUTRAL
GREEN/YELLOW
RED
BLACK
TIMER
FAN0372
LIVE
NEUTRAL
EARTH
LIGHT SWITCH
FLUSH BOX
(WALL MOUNTED)
BLUE
BROWN
GREEN/YELLOW
YELLOW
ORANGE
FITTING THE INDUCT FAN
1. Select a suitable place for the fan to be screwed to a joist and secure using two screws through the fixing
bracket.
2. Using the external grille select a suitable position in the soffit/wall and cut a 165mm hole. Attach one end
of the flexible duct to the grille, using the duct tape supplied. Feed the ducting through the hole until the
grille is secure and flush with the soffit/wall. Secure the grille to the soffit/wall using four screws and fixing
clips supplied.
NB: It is best not to cut the flexible ducting until the grille with the flexible ducting attached has been
screwed to the outside wall so as to avoid the possibility of cutting the duct too short.
3. Pull the flexible ducting gently to the discharge spigot of the fan and cut the duct to length and connect to
the fan using the duct tape supplied.
There is an arrow on the unit showing the airflow direction. Try to keep the ducting as straight as
possible and keep the distance between the Extract-a-Lite and the external soffit or wall as short
as possible to achieve optimum fan performance of the fan.
4. Connect the other piece of duct to the Extract-a-lite and onto the fan using the duct tape supplied.
Cut off and discard any excess ducting. NB: Make sure wherever possible to keep the ducting running in
a straight line as this will improve the performance of the fan.
5. Wiring of Standard Model EL150. Diagram 2.
The fan can be connected to the light switch so that the fan will start when the light is switched on.
The fan should not be accessible to a person using either the shower or the bath.
NB: All wiring must be fixed securely and the cable to the fan should be a minimum of 1mm2in section.
All wiring must comply with current Regulations.
6. Wiring of Timer Model EL150 as Diagram 3.
The fan can be connected to the light switch so that the fan will start when the light is switched on.
The fan should not be accessible to a person using either the shower or the bath.
NB: All wiring must be fixed securely and the cable to the fan should be a minimum of 1mm2in
section. All wiring must comply with current Regulations.
The timer mechanism fitted is a fixed seven minute timer which is installed in the flush box. This means
that the fan will run on for approx 7 seven minutes after it has been switched off. (see diagram 5 for
wiring instructions, and also instructions included with FAN0372).
Diagram 1
Diagram 2
Diagram 3
(EL150S) Standard Model This diagram is for a lighting circuit only
230/12VAC
SELV transformer
OR LED Driver
Existing
Light
230VAC
Existing Switch
12VAC
Extract-a-Lite
12VAC light
FAN
Recommended mounting position
