Matsing MS-MBA-3-F4A3 User manual

TABLE OF CONTENTS:
BEAMS & CONNECTORS:
Plan View Resultant Beam Layout
Connector Ports Table
Connector Detail
Connector Layout
PATTERN DIAGRAM
Horizontal Pattern
Vertical Pattern
MANUAL TILT ADJUSTMENT
BRACKET INSTALLATION
Bolts & Nuts Requirements
Tools Requirement
Adjustable Spanner
M12 Spanner
Bracket Spacing & Installation Sample
Revision History:
[email protected] www.matsing.com 1 / 5
Pavel
MBA-3-F4A3-IM-001
0
INSTRUCTION MANUAL MS-MBA-3-F4A3
1.00
1.10
MS-MBA-3-F4A3
Instruction Manual
Date
Prepared by
Approved by
Document nos
Rev
24 Jun 2021
Ray Ling
4.30
3.00
4.00
4.10
4.21
4.20
4.22
1.20
1.30
1.40
2.00
2.10
2.20
Revision
nos.
Date
Description
Revised by
email:
website:
Page

BEAMS & CONNECTORS:
Plan View Resultant Beam Layout Connector Layout
Connector Ports Table
Connector Detail
2 / 5
1.00
1.10
1.20
1.30
1.40
Page
Port 12
(-45˚)
Port 9
(+45˚)
Port 10
(+45˚)
Port 2
(-45˚)
Port 1
(+45˚)
Port 4
BEAM 1
Port 3
(-45˚)
(-45˚)
BEAM 2
Port 7
(+45˚)
Port 8
(-45˚)
Port 5
(+45˚)
Port 6
(-45˚)
BEAM 3
Port 11
(+45˚)
0
BEAM 2
BEAM 2
Plan View Resultant Beam Directions
Frequency: 3300 MHz
AISG IN
FB Beams: 1,2,3
FB Ports: 1 to 12
REAR VIEW CONNECTOR LAYOUT
MS-MBA-3-F4A3
BEAM 1BEAM 2BEAM 3
Port 3 (+45)
Port 1 (+45)
Port 2 (-45)
Port 4 (-45)
Port 6 (-45)
Port 5 (+45)
Port 12 (-45)
Port 10 (-45)
Port 9 (+45)
Port 11 (+45)
Port 7 (+45)
Port 8 (-45)

PATTERN DIAGRAM
Horizontal Pattern
Vertical Pattern
3 / 5
Page
2.10
2.20
2.00
BEAM 2
3300 - 4200 MHz
Frequency:
MS-MBA-3-F4A3


3300 - 4200 MHz
Frequency:
MS-MBA-3-F4A3

MANUAL TILT ADJUSTMENT
BRACKET INSTALLATION
Bolts & Nuts Requirements
All MBA's Antenna
Bolts & Nuts
Bracket
4 / 5
3.00
1
The MBA antenna come in RET mode as default, but if needed can also be manually
adjusted. To do so, please unscrew the waterproof cap behind the element whose
tilt is to be adjusted.
Page
2
M12 x
200mm
4
4.00
4.10
Bracket
2
By Default the knob is on engaged mode, pull out the handle for manual tilt
adjustment, turn the handle to change the tilt.
3
When done, push the handle back in, screw the waterproof cap back to the position.
M12
10
4.11
4.12
Bolts
Nuts
Qty
Size
Qty
Size
Qty
1. Engaged with
internal RET motor
position
2. Unscrew/
Screw the cap for tilt
adjustment process
3. Pull knob out to
disengaged RET for
tilt adjustment
Tilt
Adjustment
Knob
Angle
Indicator
RET
Controller

Tools Requirement
Adjustable Spanner
M12 Spanner
Bracket Spacing & Installation Sample
5 / 5
Page
4.20
4.21
4.22
4.30
