Matt Blatt HANSEN MBHANQBAWA User manual

HANSEN QUEEN BED
MBHANQBAWA

1 Foot Rail
1 Bed Head 2 Side Rail(x2)
3 Middle Rail
4 Center Leg
6 Leg(x4)
A Bolt(x16) B Washer(x16)
5 Slat(x4)
C Bolt Large
F Spanner
E Spanner Big
D Hexa Nut
G Allen Key

Step 1: Align the side rails with the Bed Head & Foot rails as② ①
shown in the diagram below. Unscrew the hex head bolts and
remove them from the brackets.

Step 2: Fit the end rails and side rails together so that the bolt holes
overlap. Make sure the labels on each side match as shown in the
diagram below. Fit the hex head bolt removed in Step 1 into the
hole and tighten it with the spanner E. Repeat this for the other
bolt and then repeat the process for the remaining brackets.

Step 3: Align a leg with the bottom of the frame formed in Step 2. ⑥
Make sure the label on the leg matches the label on the side as
shown in the diagram below.
Fit a washer B to a bolt A and then insert the bolt into a hole. Tighten
the bolt with the Allen key G. Repeat this for the remaining holes and
then repeat the process for the remaining legs.

Step 4: Fit the middle legs to the middle rail and make sure the ④ ③
holes overlap. Insert the long bolt C into the hole and make sure
it protrudes from the other side. Attach the hex nut D to the bolt
and tighten it with the spanner F.

Step 5: Place the structure formed in Step 4 upon the
slots of the end rails. Once placed securely, middle legs
should be 2-3mm o the ground.

Step 6: Place the slat sets ⑤ on the bed frame. Make sure the Flat End
sits close to the bed ends while Protruding End sits in the centre.

Step 7: Place the bed in its desired location and enjoy your
new Bed !

NOTES
