Matt Blatt RHS User manual

KINGSLEY CHAISE SOFA
RHS
MBKINGSRHMA & MBKINGSRHGA

SAFETY & WARNINGS
Read these instructions carefully and keep for future reference.
Refer to “components”, and ensure you have all items.
Before assembling, place all items on a soft, clean and flat surface such as a carpet to
prevent scratches.

COMPONENTS
1 Seat
2Chaise
3Small pillow
4Large pillows (x2)
5Legs (x6)
6Support leg
FITTINGS
AM8x38mm
Bolts (x14)
BØ13mm Spring
washer (x14)
CØ25mm Flat
washer (x14)
D5mm Allen key (x2)

ASSEMBLY
Step 1: Remove the x2 Legs, Support leg and Fittings from the underside of the seat (1).
Step 2: Remove the x4 Legs and Fittings out from the underside of the Chaise (2).

Step 3: Using the Allen key (D), attach the Legs (5) and Support leg (6) to the underside
of the Seat (1) with the Bolts (A), Spring washers (B) and Flat washers (C).
Step 4: Using the Allen key (D), attach the Legs (5) to the underside of the Chaise (2)
with the Bolts (A), Spring washers (B) and Flat washers (C).

Step 5: Lift the Seat end and connect it to the Chaise.
Step 6: Place the Small pillow (3) and the x2 Large pillows (4) in position
Complete!

NEED MORE INFORMATION?
We hope that this user guide has given you
the assistance needed for a simple set-up.
For the most up-to-date guide for your product,
as well as any additional assistance you may require,
head online to help.mattblatt.com.au
