Medline ATKnee User manual

ATKNEE
ATKnee, All-Terrain Knee Walker
ATKnee, déambulateur tout-terrain avec
repose-genou
ATKnee, andador de rodilla todoterreno
Weight Capacity
Capacité de poids de
Capacidad de peso de
350 lbs (158 kg)
CAUTION: This Product Contains Natural Rubber Latex
Which May CauseAllergic Reactions.
ATTENTION : Ce produit contient du latex de caoutchouc
naturel, susceptible de causer des réactions allergiques.
PRECAUCIÓN: Este producto contiene látex de caucho
natural que puede producir reacciones alérgicas.
Step-by-Step
Assembly Guide
Guide d’assemblage
étape par étape
Guía de montaje
paso a paso

2MEDLINE |ATKNEE | PIC-00918 (Rev: V2 031822)
A
C
D
E
N
M
What’s Included:
O
B
G
H
JK
L
I
F

1-800-MEDLINE (633-5463) |medline.com 3
AHand Brakes
BHand Grips
CBrake Cable
DHandle Height
Adjust Knob
EBasket
FSteering Column
GLocking Tiller
Assembly Pin
HSwivel Lock Screw
IKneepad
JRear Wheels
KFront Wheels
LSeat Cam Lock
MSeat Height
Adjust Pin
NAllen Key
OMemory Foam
Seat Cover
PStep-By-Step As-
sembly Guide
QSafety Guidelines
PQ
This guide applies to the following kneewalker:
Item Number Description Frame
Color
Weight
Capacity
ATKNEE All-Terrain Knee Walker Black 350 lbs
(158 kg)
ATKNEE
ATKnee, All-Terrain Knee Walker
ATKnee, déambulateur tout-terrain avec
repose-genou
ATKnee, andador de rodilla todoterreno
Weight Capacity
Capacité de poids de
Capacidad de peso de
350 lbs (158 kg)
CAUTION: This Product Contains Natural Rubber Latex
Which May Cause Allergic Reactions.
MISE EN GARDE : Ce produit contient du latex de
caoutchouc naturel qui peut causer une réaction allergique.
PRECAUCIÓN: Este producto contiene látex de caucho
natural que puede producir reacciones alérgicas.
Step-by-Step
Assembly Guide
Guide d’assemblage
étape par étape
Guía de montaje
paso a paso
ATKNEE
Safety
Guidelines
Consignes
de sécurité
Pautas de
seguridad
ATKnee, All-Terrain Knee Walker
ATKnee, déambulateur tout-terrain avec
repose-genou
ATKnee, andador de rodilla todoterreno
Weight Capacity
Capacité de poids de
Capacidad de peso de
350 lbs (158 kg)
CAUTION: This Product Contains Natural Rubber Latex
Which May Cause Allergic Reactions.
MISE EN GARDE : Ce produit contient du latex de
caoutchouc naturel qui peut causer une réaction allergique.
PRECAUCIÓN: Este producto contiene látex de caucho
natural que puede producir reacciones alérgicas.
ATTENTION: This item does not come with a tire pump. A tire
pump is needed to inflate tires. Check tire pressure routinely to
ensure tires are inflated. Do not inflate over 28 PSI.

4MEDLINE |ATKNEE | PIC-00918 (Rev: V2 031822)
First: Open and Secure Handle Bar
2
3
1Remove contents from carton and lay parts next to frame.
Raise tiller to the upright position. Push locking tiller assembly pin in until
you hear a click. Make sure steering column is secure.
Turn front wheels to face forward so that tiller is on front of knee walker

1-800-MEDLINE (633-5463) |medline.com 5
Rotate clockwise to tighten. Lift pin to upright position and push
down tiller to secure.
4
Insert swivel lock screw into hole. Tighten using Allen key.
Insert handlebar into steering column with hand brake on front
of knee walker.
5
6

6MEDLINE |ATKNEE | PIC-00918 (Rev: V2 031822)
Lower the Kneepad to desired height.
Adjust to desired height and insert Handle Height Adjust Knob. Turn
clockwise until tightened.
7
8
Next: Set Desired Kneepad Height

1-800-MEDLINE (633-5463) |medline.com 7
Now: Using the Hand Brakes
Insert the Seat Height Adjust Pin into the hole. Lock pin in place by
sliding the loop over the protruding end of the pin.
Rotate the seat cam lock clockwise to tighten the lock pad into
place. Fold close to frame.
9
10
11 Adjust brake cable to reduce loose slack and prevent from catching
on objects.

8MEDLINE |ATKNEE | PIC-00918 (Rev: V2 031822)
To apply the brakes, simply pull the hand brake lever with your
fingertips toward the hand grip.
Attach basket to designated hook on steering column.
To lock the brakes, push brake handle down until you hear a click.
12
14
13
Attaching Accessories

1-800-MEDLINE (633-5463) |medline.com 9
Slip memory foam seat cover over kneepad. Ensure string is on back
of kneepad. Tighten string and tuck excess string under kneepad.
Adjusting The Knee Pad Height
Uninstall the locking seat height adjustment pin. Adjust kneepad to
desired height.
Reinstall the locking seat height adjust pin and secure it in place. Next
tighten the Seat Cam Lock to lock pad in place.
16
17
15

10 MEDLINE |ATKNEE | PIC-00918 (Rev: V2 031822)
19
18 To adjust the handle height, loosen the handle height adjustment knob
below the handle by turning it counterclockwise until it can be removed.
Adjust the handlebar to the desired height and reinstall the handle height
adjust pin by turning it clockwise until it is tightened.
Release the Seat Cam Lock and seat height adjust pin.
Finally: Adjust Handle Height
To Fold the Kneewalker
