Medline MDS86800XWC User manual

STEP-BY-STEP
ASSEMBLY GUIDE
GUÍA DE MONTAJE
PASO A PASO
GUIDE D’ASSEMBLAGE
ÉTAPE PAR ÉTAPE
Heavy Duty Rollator
Andador de alta resistencia
Déambulateur à roulettes ultrarobuste

2MEDLINE |Heavy Duty Rollator | PIC–00311 (Rev: 12-13-17)
A
C
C
H
I
J
D
FE
What’s Included:
B
G

1-800-MEDLINE (633-5463) |medline.com 3
A6 Three
Point Knobs
BExtra
Padded Backrest
C2 Handle Brake
Assemblies with
Rear Wheels
DCup Holder
ECup Holder
Frame Clip
FCup Holder Knob
GRollator Frame
H2 Front Wheels
IFront Bag
JUnder Bag
KStep-By-Step
Assembly Guide
LSafety Guidelines
STEP-BY-STEP
ASSEMBLY GUIDE
GUÍA DE MONTAJE
PASO A PASO
GUIDE D’ASSEMBLAGE
ÉTAPE PAR ÉTAPE
Heavy Duty Rollator
Andador de alta resistencia
Déambulateur à roulettes ultrarobuste
1-800-MEDLINE (633-5463) | medline.com 1
Medline Rollator
SAFETY
GUIDELINES
To ensure your safety in using the Medline rollator, the following
safety information and all instructions must be followed.
» DO NOT use this product without first reading and understanding
the instructions contained in this booklet. If you are unable to
understand the warnings, cautions, or instructions, contact a
healthcare professional, dealer, or technical personnel before use-
otherwise serious bodily injury and damage may occur.
» Consult with your doctor, physical, or occupational therapist or other
qualified professional to assure the proper height adjustment.
» Rollators are for individual use only and are NOT to be used as a
wheelchair.
» DO NOT attempt to move the rollator while you or anyone is sitting
on the seat.
» DO NOT self-propel the rollator while seated. Brakes must always be
locked while the seat is in use.
» Serious injury to you and/or damage to the rollator frame or wheels
may result from improper use.
» DO NOT use the seat to transport people or objects. DO NOT use the
seat to carry or move anything.
» DO NOT sit on the rollator while it is being loaded into a vehicle or
while it is being transported in a vehicle.
» DO NOT exceed the maximum weight capacity (including bag
contents). As stated in the assembly guide and on the device itself or
serious injury could result.
KL
This guide applies to the following Rollator:
Item Number Description Frame
Color Weight Capacity
MDS86800XWC Bariatric Rolling Walker.
8" Wheels. Black 400 lbs.
(181 kg.)

4MEDLINE |Heavy Duty Rollator | PIC–00311 (Rev: 12-13-17)
First: Open the Rollator
IMPORTANT NOTE:
Proceed with caution
when opening the rollator
as there are areas around
the moving parts that
could potentially pinch
fingers.
1
Remove the rollator components from shipping carton. Then,
unfold the rollator by pushing down on the folding bracket until
the frame is in full extension and place on its side.

1-800-MEDLINE (633-5463) |medline.com 5
Next: Install Wheels
Take wheels, squeeze push button on both sides and slide wheel
fully into slot. (Note: For rear wheels, make sure the shoe brake
is on the outside.)
1
2
3

6MEDLINE |Heavy Duty Rollator | PIC–00311 (Rev: 12-13-17)
4
Screw on three point knob. (Note: Make sure push buttons are
fully engaged.)
Repeat steps 1-4 for all wheels.
5
IN

1-800-MEDLINE (633-5463) |medline.com 7
Now: Install Handle Brake Assembly
Stand the rollator up so all 4 wheels are on the floor, insert
brake handle assembly into the frame and set to desired height.
Brake cables should be on the outside of the handle bars
and frame.
1
2

8MEDLINE |Heavy Duty Rollator | PIC–00311 (Rev: 12-13-17)
Repeat steps 1-3 on the other brake handle assembly.
4
3
Screw on three point knobs. Make sure the screw head recesses
into the frame.
IN

1-800-MEDLINE (633-5463) |medline.com 9
Insert the backrest so that the curved portion faces the front of
the unit. Make sure that the button snaps firmly into the hole so
the back is secure.
Secure the hook and loop onto the seat frame and make sure
the under bag is centered.
1
3
Loop the cloth hooks onto the seat frame and make sure the
bag is centered.
2
Finally: Install Backrest & Bags

10 MEDLINE |Heavy Duty Rollator | PIC–00311 (Rev: 12-13-17)
4
5
Secure the side release buckle onto the backrest and lower
front frame.

1-800-MEDLINE (633-5463) |medline.com 11
Lastly: Attach Cup holder
Attach cup holder frame clip to backrest.
Take cup holder and insert screw through the cup holder
frame clip.
1
2

12 MEDLINE |Heavy Duty Rollator | PIC–00311 (Rev: 12-13-17)
Screw on cup holder knob.
3
IN

1-800-MEDLINE (633-5463) |medline.com 13

14 MEDLINE |Andador de alta resistencia | PIC–00311 (Rev.: 12-13-17)
A
C
C
H
I
J
D
FE
Lo que se incluye:
B
G

1-800-MEDLINE (633-5463) |medline.com 15
A6 perillas de
tres puntas
BRespaldo
extraacolchado
C2 conjuntos
de mango de
freno con ruedas
traseras
DPortavaso
EPresilla del
armazón del
portavaso
FPerilla del
portavaso
GArmazón
del andador
H2 ruedas
delanteras
IBolsa delantera
JBolsa de abajo
KGuía de montaje
paso a paso
LConsignes de
sécurité
STEP-BY-STEP
ASSEMBLY GUIDE
GUÍA DE MONTAJE
PASO A PASO
GUIDE D’ASSEMBLAGE
ÉTAPE PAR ÉTAPE
Heavy Duty Rollator
Andador de alta resistencia
Déambulateur à roulettes ultrarobuste
1-800-MEDLINE (633-5463) | medline.com 1
Medline Rollator
SAFETY
GUIDELINES
To ensure your safety in using the Medline rollator, the following
safety information and all instructions must be followed.
» DO NOT use this product without first reading and understanding
the instructions contained in this booklet. If you are unable to
understand the warnings, cautions, or instructions, contact a
healthcare professional, dealer, or technical personnel before use-
otherwise serious bodily injury and damage may occur.
» Consult with your doctor, physical, or occupational therapist or other
qualified professional to assure the proper height adjustment.
» Rollators are for individual use only and are NOT to be used as a
wheelchair.
» DO NOT attempt to move the rollator while you or anyone is sitting
on the seat.
» DO NOT self-propel the rollator while seated. Brakes must always be
locked while the seat is in use.
» Serious injury to you and/or damage to the rollator frame or wheels
may result from improper use.
» DO NOT use the seat to transport people or objects. DO NOT use the
seat to carry or move anything.
» DO NOT sit on the rollator while it is being loaded into a vehicle or
while it is being transported in a vehicle.
» DO NOT exceed the maximum weight capacity (including bag
contents). As stated in the assembly guide and on the device itself or
serious injury could result.
KL
Esta guía rige para el siguiente andador:
Número del artículo Descripción Color del
armazón Capacidad de carga
MDS86800XWC
Andador rodante
para
pacientes bariátricos.
Ruedas de 8 pulg.
Black 400 lbs.
(181 kg.)

16 MEDLINE |Andador de alta resistencia | PIC–00311 (Rev.: 12-13-17)
Primero: Abra el andador
NOTA IMPORTANTE:
Proceda con precaución
cuando abra el andador, ya
que hay áreas alrededor
de las piezas móviles con
las que potencialmente se
podría apretar los dedos.
1
Retire los componentes del andador de la caja de envío. Luego,
despliegue el andador empujando hacia abajo sobre el soporte
plegable hasta que el armazón esté totalmente extendido y
colocado de costado.

1-800-MEDLINE (633-5463) |medline.com 17
A continuación: Instale las ruedas
Tome las ruedas, apriete el pulsador a ambos lados y deslice
la rueda hasta el fondo de la ranura. (Nota: para las ruedas
traseras, asegúrese de que la zapata de freno quede afuera).
1
2
3

18 MEDLINE |Andador de alta resistencia | PIC–00311 (Rev.: 12-13-17)
4
Enrosque la perilla de tres puntas. (Nota: cerciórese de que los
pulsadores encajen completamente).
Repita los pasos 1 al 4 para todas las ruedas.
5
ADENTRO

1-800-MEDLINE (633-5463) |medline.com 19
Ahora: Instale el conjunto de mango
de freno
Ponga el andador en posición vertical de modo que las 4 ruedas
estén apoyadas en el suelo, inserte el conjunto de mango de
freno en el armazón y fíjelo a la altura deseada. Los cables del
freno deben estar en el exterior de los manillares y el armazón.
1
2

20 MEDLINE |Andador de alta resistencia | PIC–00311 (Rev.: 12-13-17)
Repita los pasos 1 al 3 con el otro conjunto de mango de freno.
4
3
Enrosque las perillas de tres puntas. Cerciórese de que la cabeza
del tornillo quede dentro del armazón.
ADENTRO
