Medline MDS86850ESAR User manual

STEP-BY-STEP
ASSEMBLY GUIDE.
GUIDE D’ASSEMBLAGE
ÉTAPE PAR ÉTAPE.
GUÍA DE MONTAJE
PASO A PASO.
Basic Steel Knockdown Rollator With 6" Wheels
Déambulateur démontable de base en acier à roulettes de 6 po
Andador básico de acero con ruedas de 6" que requiere montaje
MDS86850ESAR, MDS86850ESAB

2MEDLINE |MDS86850ESAR, MDS86850ESAB | PIC-00311 (Rev: 10-10-18)
A
C
D
F F
E
What’s Included:
B
G
HH

1-800-MEDLINE (633-5463) |medline.com 3
A2 Four Point
Knobs
B4 Triangular Knobs
C2 Screws &
Curved Washers
DBag
ERollator Frame
F2 Handle Bars with
Brake assembly
GBackrest
H2 Front Wheels
IStep-by-Step
Assembly Guide
JGeneral Warnings
STEP-BY-STEP
ASSEMBLY GUIDE.
GUIDE D’ASSEMBLAGE
ÉTAPE PAR ÉTAPE.
GUÍA DE MONTAJE
PASO A PASO.
Basic Steel Knockdown Rollator With 6" Wheels
Déambulateur démontable de base en acier à roulettes de 6 po
Andador básico de acero con ruedas de 6” que requiere montaje
MDS86850ESAR, MDS86850ESAB 1-800-MEDLINE (633-5463) | medline.com 1
Medline Rollator
SAFETY
GUIDELINES
To ensure your safety in using the Medline rollator, the following
safety information and all instructions must be followed.
» DO NOT use this product without first reading and understanding
the instructions contained in this booklet. If you are unable to
understand the warnings, cautions, or instructions, contact a
healthcare professional, dealer, or technical personnel before use-
otherwise serious bodily injury and damage may occur.
» Consult with your doctor, physical, or occupational therapist or other
qualified professional to assure the proper height adjustment.
» Rollators are for individual use only and are NOT to be used as a
wheelchair.
» DO NOT attempt to move the rollator while you or anyone is sitting
on the seat.
» DO NOT self-propel the rollator while seated. Brakes must always be
locked while the seat is in use.
» Serious injury to you and/or damage to the rollator frame or wheels
may result from improper use.
» DO NOT use the seat to transport people or objects. DO NOT use the
seat to carry or move anything.
» DO NOT sit on the rollator while it is being loaded into a vehicle or
while it is being transported in a vehicle.
» DO NOT exceed the maximum weight capacity (including bag
contents). As stated in the assembly guide and on the device itself or
serious injury could result.
IJ
This guide applies to the following rollator:
Item Number Description Frame
Color Weight Capacity
MDS86850ESAR
Steel rollator with 6"
wheels, knockdown.
Handles are in 1"
increments from
31" – 35". Includes
nylon bag under seat
Burgundy 350 lbs.
(159 kg)
MDS86850ESAB
Steel rollator with 6”
wheels, knockdown.
Handles are in 1”
increments from
31” – 35”. Includes
nylon bag under seat
Blue 350 lbs.
(159 kg)

4MEDLINE |MDS86850ESAR, MDS86850ESAB | PIC-00311 (Rev: 10-10-18)
Place the rollator on its side.
First: Open the Rollator
IMPORTANT NOTE:
Proceed with caution
when opening the rollator
as there are areas around
the moving parts that
could potentially pinch
fingers.
2
1
Remove the rollator components from shipping carton. Then, in
an upright position, unfold the rollator by pushing down on the
folding bracket until the frame is in full extension.

1-800-MEDLINE (633-5463) |medline.com 5
Now: Install the Wheels
Front Wheels
Use the triangular knob to screw the front legs in place.
Repeat steps 1-3 for the other front leg extension without brakes.
1
3
2
Remove the four black
plastic plugs from the
outer tubes and discard.
Attach front legs without
brakes to the front of the
rollator. The front legs are
marked ‘Front Left’ & ‘Front
Right’.

6MEDLINE |MDS86850ESAR, MDS86850ESAB | PIC-00311 (Rev: 10-10-18)
2
1
With the rollator still on its side, attach rear wheels with
brakes. Make sure that the rear wheels and brake shoe are on
the outside of the rollator and brake handle (See above). Use
the triangular knobs to thread the rear legs in place.
Rear Wheels & Brakes

1-800-MEDLINE (633-5463) |medline.com 7
On the same side insert the brake handle assembly into the
frame and set to desired height. Brake cables should be on the
outside of the handle bars and frame.
3
4
Insert the screw into the 6 sided hole in the frame. Make sure
the screw head recesses into the frame.

8MEDLINE |MDS86850ESAR, MDS86850ESAB | PIC-00311 (Rev: 10-10-18)
Slide the curved washer onto the other end of the screw with
the curved side facing the frame.
Turn the rollator onto the other side so that the wheels that
were just installed are now on the floor. Then, repeat steps 1-4.
on the other side.
3
4
5
Screw on the four point knob.

1-800-MEDLINE (633-5463) |medline.com 9
Finally Install Backrestngage both wheel
locks before entering or exiting the transport chair, when leaning
forward, or while in an elevator or wheelchair lift.
Stand the rollator up so all 4 wheels are on the floor.
Insert the backrest so that the curved portion faces the front of
the unit. Make sure that the button snaps firmly into the hole so
the back is secure.
1
2
Loop the cloth hooks onto the seat frame and make sure the
bag is centered.
3

10 MEDLINE |MDS86850ESAR, MDS86850ESAB | PIC-00311 (Rev: 10-10-18)
A
C
D
F F
E
Contenu :
B
G
HH

1-800-MEDLINE (633-5463) |medline.com 11
A2 molettes de
serrage
B4 boutons
triangulaires
C2 vis et rondelles
courbées
DSac
ECadre de
déambulateur
F2 poignées et
freins
GDossier
H2 roulettes
avant
IGuide d’assem-
blage étape par
étape
JAvertissements
généraux
STEP-BY-STEP
ASSEMBLY GUIDE.
GUIDE D’ASSEMBLAGE
ÉTAPE PAR ÉTAPE.
GUÍA DE MONTAJE
PASO A PASO.
Basic Steel Knockdown Rollator With 6" Wheels
Déambulateur démontable de base en acier à roulettes de 6 po
Andador básico de acero con ruedas de 6” que requiere montaje
MDS86850ESAR, MDS86850ESAB 1-800-MEDLINE (633-5463) | medline.com 1
Medline Rollator
SAFETY
GUIDELINES
To ensure your safety in using the Medline rollator, the following
safety information and all instructions must be followed.
» DO NOT use this product without first reading and understanding
the instructions contained in this booklet. If you are unable to
understand the warnings, cautions, or instructions, contact a
healthcare professional, dealer, or technical personnel before use-
otherwise serious bodily injury and damage may occur.
» Consult with your doctor, physical, or occupational therapist or other
qualified professional to assure the proper height adjustment.
» Rollators are for individual use only and are NOT to be used as a
wheelchair.
» DO NOT attempt to move the rollator while you or anyone is sitting
on the seat.
» DO NOT self-propel the rollator while seated. Brakes must always be
locked while the seat is in use.
» Serious injury to you and/or damage to the rollator frame or wheels
may result from improper use.
» DO NOT use the seat to transport people or objects. DO NOT use the
seat to carry or move anything.
» DO NOT sit on the rollator while it is being loaded into a vehicle or
while it is being transported in a vehicle.
» DO NOT exceed the maximum weight capacity (including bag
contents). As stated in the assembly guide and on the device itself or
serious injury could result.
IJ
Ce guide concerne le modèle de déambulateur
suivant :
Numéro d’article Description Couleur du
cadre Capacité de charge
MDS86850ESAR
Déambulateur en
acier à roulettes de
6 po, démontable.
Poignées réglables
par incréments de
1 po, de 31 à 35 po.
Comprend un sac en
nylon sous le siège
Bourgogne 350 lbs.
(159 kg)
MDS86850ESAB
Déambulateur en
acier à roulettes de
6 po, démontable.
Poignées réglables
par incréments de
1 po, de 31 à 35 po.
Comprend un sac en
nylon sous le siège
Bleu 350 lbs.
(159 kg)

12 MEDLINE |MDS86850ESAR, MDS86850ESAB | PIC-00311 (Rev: 10-10-18)
Placez le déambulateur sur son
flanc.
Première étape : Ouverture du
déambulateur à roulettes
REMARQUE IMPORTANTE :
Ouvrez le déambulateur
avec précaution pour éviter
de vous pincer les doigts
près des pièces mobiles.
2
1
Retirez les composants du déambulateur du carton d’expédition.
Le déambulateur étant à la verticale, dépliez-le en poussant
sur le mécanisme de pliage jusqu’à ce que le cadre soit
complètement déployé.

1-800-MEDLINE (633-5463) |medline.com 13
Deuxième étape : Installation des
roulettes
Roulettes avant
Fixez les pattes avant en vissant le bouton triangulaire.
Répétez les étapes 1 à 3 pour l’autre patte avant sans freins.
1
3
2
Retirez les quatre embouts
noirs en plastique des
tubes extérieurs et jetez-
les.
Fixez les pattes avant
sans freins à l’avant du
déambulateur. Les pattes
avant sont identifiées par les
termes « Avant gauche » et
« Avant droite ».

14 MEDLINE |MDS86850ESAR, MDS86850ESAB | PIC-00311 (Rev: 10-10-18)
2
1
Le déambulateur toujours sur le côté, fixez les roulettes arrière
munies de freins. Assurez-vous que les roulettes arrière et les
sabots de freins sont à l’extérieur du déambulateur et du levier
de frein (voir ci-dessus). Fixez les pattes arrière en vissant le
bouton triangulaire.
Roulettes arrière et freins

1-800-MEDLINE (633-5463) |medline.com 15
Du même côté, insérez le levier de frein dans le cadre et réglez-
le à la hauteur désirée. Les câbles du frein doivent être à
l’extérieur des poignées et du cadre.
3
4
Insérez la vis dans le trou hexagonal sur le cadre. Assurez-vous
que la tête de vis rentre dans le cadre.

16 MEDLINE |MDS86850ESAR, MDS86850ESAB | PIC-00311 (Rev: 10-10-18)
Glissez la rondelle courbée à l’autre extrémité de la vis de façon à
ce que le côté incurvé soit orienté vers le cadre.
Retournez le déambulateur de façon à ce que les roulettes qui
viennent d’être installées reposent sur le sol. Répétez ensuite les
étapes 1 à 4.
3
4
5
Vissez la molette de serrage.

1-800-MEDLINE (633-5463) |medline.com 17
Installez le dossier both wheel
locks before entering or exiting the transport chair, when leaning
forward, or while in an elevator or wheelchair lift.
Placez le déambulateur en position debout sur ses quatre
roulettes.
Insérez le dossier de façon à ce que la partie incurvée soit ori-
entée vers le devant du déambulateur. Vérifiez que le bouton
s’enclenche bien dans le trou de façon à sécuriser le dossier.
1
2
Enfilez les attaches en tissu sur le châssis du siège et assurez-vous
que le sac est centré.
3

18 MEDLINE |MDS86850ESAR, MDS86850ESAB | PIC-00311 (Rev: 10-10-18)
A
C
D
F F
E
Lo que se incluye:
B
G
HH

1-800-MEDLINE (633-5463) |medline.com 19
A2 perillas de
cuatro puntas
B4 perillas
triangulares
C2 tornillos y
arandelas curvas
DBolsa
EArmazón del
andador
FConjunto de 2 ma-
nillares con freno
GRespaldo
H2 ruedas
delanteras
IGuía de montaje
paso a paso
JAdvertencias
generales
STEP-BY-STEP
ASSEMBLY GUIDE.
GUIDE D’ASSEMBLAGE
ÉTAPE PAR ÉTAPE.
GUÍA DE MONTAJE
PASO A PASO.
Basic Steel Knockdown Rollator With 6" Wheels
Déambulateur démontable de base en acier à roulettes de 6 po
Andador básico de acero con ruedas de 6” que requiere montaje
MDS86850ESAR, MDS86850ESAB 1-800-MEDLINE (633-5463) | medline.com 1
Medline Rollator
SAFETY
GUIDELINES
To ensure your safety in using the Medline rollator, the following
safety information and all instructions must be followed.
» DO NOT use this product without first reading and understanding
the instructions contained in this booklet. If you are unable to
understand the warnings, cautions, or instructions, contact a
healthcare professional, dealer, or technical personnel before use-
otherwise serious bodily injury and damage may occur.
» Consult with your doctor, physical, or occupational therapist or other
qualified professional to assure the proper height adjustment.
» Rollators are for individual use only and are NOT to be used as a
wheelchair.
» DO NOT attempt to move the rollator while you or anyone is sitting
on the seat.
» DO NOT self-propel the rollator while seated. Brakes must always be
locked while the seat is in use.
» Serious injury to you and/or damage to the rollator frame or wheels
may result from improper use.
» DO NOT use the seat to transport people or objects. DO NOT use the
seat to carry or move anything.
» DO NOT sit on the rollator while it is being loaded into a vehicle or
while it is being transported in a vehicle.
» DO NOT exceed the maximum weight capacity (including bag
contents). As stated in the assembly guide and on the device itself or
serious injury could result.
IJ
Esta guía rige para el siguiente andador:
Número del
artículo Descripción Color del armazón Capacidad de carga
MDS86850ESAR
Andador de acero
con ruedas de 6",
requiere montaje.Los
mangos vienen en
incrementos de 1", de
31" a 35". Incluye una
bolsa de nilón debajo
del asiento
Borgoña 350 lbs.
(159 kg)
MDS86850ESAB
Andador de acero
con ruedas de 6”,
requiere montaje.Los
mangos vienen en
incrementos de 1”, de
31” a 35”. Incluye una
bolsa de nilón debajo
del asiento
Azul 350 lbs.
(159 kg)

20 MEDLINE |MDS86850ESAR, MDS86850ESAB | PIC-00311 (Rev: 10-10-18)
Coloque el andador sobre su
lado.
Primero: Abra el andador
NOTA IMPORTANTE:
Proceda con precaución
cuando abra el andador ya
que hay áreas alrededor
de las piezas móviles con
las que potencialmente se
podría apretar los dedos.
2
1
Retire los componentes del andador de la caja de envío. Luego,
en posición vertical, despliegue el andador empujando hacia
abajo sobre el soporte plegable hasta que el armazón esté
totalmente extendido.
