Members Mark GC-11633-3PC 990018896 Owner's manual

1 | P a g e
Assembly Instructions & User’s Manual
For
Member’s Mark 3pc French Cafe set
Item Number: 990018896
Model Number: GC-11633-3PC
Customer Assistance (spare/replacement parts): 1-888-691-2824
or Email: [email protected]
THIS ASSEMBLY MANUAL CONTAINS IMPORTANT SAFETY INFORMATION.
PLEASE READ AND KEEP FOR FUTURE REFERENCE.

2 | P a g e
Table of Contents
Quality Statement ....................................................................................................................................3
Important Safety Information................................................................................................................3
Before Assembly .....................................................................................................................................3
Care & Use.................................................................................................................................................3
Package Contents ...................................................................................................................................4
Product Information ................................................................................................................................5
Components..............................................................................................................................................5
Hardware....................................................................................................................................................5
Tools ...........................................................................................................................................................5
Step 1 .........................................................................................................................................................6
Step 2............................................................................................................................................7
Step 3............................................................................................................................................8
Step 4 .........................................................................................................................................................9
Warranty Information..............................................................................................................................9

3 | P a g e
Quality Statement
Important Safety Information
Please read all instructions carefully before assembling this product.
Where applicable, and for your safety, assembly by an adult is strongly
recommended.
Use only vendor-supplied hardware to assemble this item. Using unauthorized
hardware could jeopardize the structural integrity of the item.
Hardware may loosen overtime. Periodically check that all connections are tight.
Before Assembly
Remove all parts and hardware from the box. Place all items on a carpeted or
scratch-free work surface, as this will avoid damaging parts during assembly.
The shipping box can provide an ideal work surface if none is available.
Use the components and hardware lists below to identify, inventory and separate
each of the hardware and components included.
To avoid accidentally discarding small components or hardware, do not dispose
of any packaging or contents of the shipping carton until assembly is complete.
DO NOT USE power tools unless it is explicitly identified in this manual as
required for use during assembly. Power tools can damage the fasteners,
hardware and/or components.
Do not fully tighten all fasteners / screws until all parts are in place. Failure to
follow these instructions may cause the fasteners / screws to misalign during
assembly.
Care & Use
Use a soft, clean cloth that will not scratch the surface when cleaning.

4 | P a g e
Package Contents
Component
Description
Quantity
Component
Description
Quantity
A
X Support frame
1
G
M12 Washer
2
B
Table leg
1
H
Allen/Hex Head Bolt
M6x30mm
4
C
Table base
1
I
M6 Washer
4
D
Table top
1
J
Allen Head Bolt
M6x20mm
2
E
Hex Head Bolt
M12x30mm
2
K
M6 Allen Wrench
1
F
M12 Spring Washer
2
L
M12 Hex Wrench
1
Need Assistance? Visit us at: samsclub.com/membersmarkhelp

5 | P a g e
Product Information
Product Dimensions：
Chair: 19.3"x24.4"x34.8" (49cm x 62cm x 88.4cm)
Table: φ28” x 29.3” (φ71cm x 74.5cm)
Product Weight Capacity
Chair: Supports up to 150 lbs. (68 kg)
Table: Supports up to 50 lbs. (23 kg)
Components
(A)
X Support frame
Qty: 1pc
(B)
Table leg
Qty: 1pc
(C)
Table base
Qty: 1pc
(D)
Table top
Qty: 1pc
Hardware
(E)
Hex Head Bolt
M12x30mm
Qty: 2pcs
(F)
M12 Spring Washer
Qty: 2pcs
(G)
M12 Washer
Qty: 2pcs
(H)
Allen/Hex Head Bolt
M6x30mm
Qty: 4pcs
(I)
M6 Washer
Qty: 4pcs
(J)
Allen Head Bolt
M6x20mm
Qty: 2pcs
Tools
(K)
M6 Allen Wrench
Qty: 1pc
(L)
M12 Hex Wrench
Qty: 1pc
Need Assistance? Visit us at: samsclub.com/membersmarkhelp

6 | P a g e
Step 1
(B)
Table leg
Qty: 1pc
(C)
Table base
Qty: 1pc
(E)
Hex Head Bolt
M12x30mm
Qty: 1pc
(F)
M12 Spring Washer
Qty: 1pc
(G)
M12 Washer
Qty: 1pc
(J)
Allen Head Bolt
M6x20mm
Qty: 1pc
(K)
M6 Allen Wrench
Qty: 1pc
(L)
M12 Hex Wrench
Qty: 1pc
Carefully place the table leg (B) upside down on a non-abrasive surface.
Assemble the table leg (B) to the table base (C) with M12 bolts (E), M12 Spring Washer
(F) and M12 Washer (G) by using M12 Hex wrench (L).
Meanwhile assemble them with M6x20mm Allen Head Bolt (J) by using M6 Allen
Wrench (K) .
Do not tighten the bolts until assembling is completed.
Need Assistance? Visit us at: samsclub.com/membersmarkhelp

7 | P a g e
Step 2
(A)
X Support frame
Qty: 1pc
(E)
Hex Head Bolt
M12x30mm
Qty: 1pc
(F)
M12 Spring Washer
Qty: 1pc
(G)
M12 Washer
Qty: 1pc
(J)
Allen Head Bolt
M6x20mm
Qty: 1pc
(K)
M6 Allen Wrench
Qty: 1pc
(L)
M12 Hex Wrench
Qty: 1pc
Assemble the X Support frame (A) and leg (B) M12 bolts (E), M12 Spring Washer (F)
and M12 Washer (G) by using M12 Hex wrench (L).
Meanwhile assemble them with M6x20mm Allen Head Bolt (J) by using M6 Allen
Wrench (K) .
Tighten all bolts with M6 Allen Wrench (K) and M12 Hex wrench (L).
Need Assistance? Visit us at: samsclub.com/membersmarkhelp

8 | P a g e
Step 3
(D)
Table top
Qty: 1pc
(H)
Allen/Hex Head Bolt
M6x30mm
Qty: 4pcs
(I)
M6 Washer
Qty: 4pcs
(J)
M6 Allen Wrench
Qty: 1pc
Carefully place the table top (D) upside down on a non-abrasive surface.
Assemble the table top (D) to the X support frame (A) with M6x30mm bolts (H) and M
Washer (I) by using M6 Allen wrench (J).
Tighten all bolts with M6 Allen wrench (J).
Need Assistance? Visit us at: samsclub.com/membersmarkhelp

9 | P a g e
Step 4
Carefully turn the table over.
The table is ready for your enjoyment.
Warranty Information
This product component has a 5 year guarantee against defects in material and/or workmanship. If you
have any questions regarding the warranty or spare / replacement parts, please call our toll-free number
1-888-691-2824 or email us at [email protected]
NOTE: Please consider recycling all applicable packaging material.
Distributed by Sam’s West Inc.
2101 SE Simple Savings Dr.
Bentonville, Arkansas 72716-0745
Made in China
