Mercia Garden Products 01DTOVRA0604SDFW-V1 User manual







 

 
















  



2mm Drill bit
x2 





























































 


































¡













¡





 
Before assembly
please make sure you have a
suitable base ready to erect your
building
MADE IN GREAT BRITAIN
2
134
567
20
8
9
11
12
13
14
15
16
17 18 19
50mm Screw x 20
20mm Screw x 10
30mm Screw x 109
10
24
21 22 23
40mm Screw x 20
Door Panel QTY 1
AI-01R11OVSD1180X1799-V1
Window Panel QTY 1
AI-01R11OV1CW583X1799-V1
Plain Gable QTY 2
AI-01R11OVAGP1130X2053-V1
Plain Panel 1 QTY 1
AI-R11OVPP583X1799-V1
Plain Panel 2 QTY 1
AI-R11OVPP1180X1799-V1
Roof QTY 2
PI-03-0222
Floor QTY 1
AI-R11OSBF1175X1753-V1
Door QTY 1
AI-R11FBMBZBD660X1660-V1
Door Block 150x28x28mm QTY 1
F2828-150mm
Ridge Bar 1707x28x28mm QTY 1
F2828-1707mm
Eaves Framing 1794x28x28mm QTY 2
F2828-1794mm
Door Beading Strips 1600x12x28mm QTY 2
S1228-1600mm
Window Cover Trims 518x12x40mm QTY 2
S1240-518mm
Window Cover Trims 583x12x40mm QTY 1
S1240-583mm
Cover Trims 1790x12x40mm QTY 6
S1240-1790mm
Fascias 690x12x60mm QTY 4
S1260-690mm
Felt QTY 1
PI-01-0013
Styrene QTY 1
PI-05-0114
Corner Brace QTY 2
PI-07-0012
T-Hinge QTY 3
PI-07-0021
Turn Button QTY 2
PI-07-0034
Hasp and Staple QTY 1
PI-07-0207
Window Cill QTY 1
PI-08-0012
Finial QTY 2
Shed diamond Finial
Nail Bag
There may be extra screws present in the nail bag
Overall Dimensions:
Width = 1842mm
Depth = 1313mm
Height = 2148mm
Base Dimensions:
Width = 1753mm
Depth = 1175mm
Contents:


 
Pre Assembly
Before assembling remove the transportation
blocks from the bottom of each panel.
Take care removing the blocks as to not damage
the panels. Tap with a at headed screwdriver
and hammer.
Dispose of the blocks once removed.
Step 1
Parts Needed- No.7 QTY 1
Place the oor (No.7) on a rm and level base,
ensure the base has suitable drainage free
from areas where standing water can collect.
See the front page for base requirements.
7
1
20
20
20
8
Pre drill
hole
30mm
screw
20
Opens from the Left Opens from the Right
IMPORTANT: Pre-drill before xing screws.
Step 2
Parts needed - No. 1 QTY 1
No. 8 QTY 1
No. 20 QTY 3
Place the door (No.8) within the Door Panel
(No. 1). Fix the T Hinges (No. 20) onto the
door and Door Panel as shown (taking into
account on which side of the Door Panel
opening you want the Door to open).
Ensure that the screws go through the
cladding and into the framing behind.
21x30mm Screws
**PLEASE NOTE** Before tting the
hinges, ensure the door is in the correct
position depending on which side you want
the door to open. See external illustrations
below which show the doors internal
framing.


 
Pre drill
hole
50mm
screw
Step 3
Parts Needed- No.3 QTY 1
- No.4 QTY 1
**Please note: the front and back panels
are interchangeable and can be
positioned on either side of the building.
Decide which works best before
assembly**
Place the Plain Gable (No.3) and the Plain
Panel 1 (No.4) onto the oor, ensuring to
position the panels so there is equal spacing
between the oor and cladding. secure at
the corners using 3x50mm screws.
Do not secure the building to the oor until
the roof is tted.
3x50mm Screws
3
4
a
a
a
a
IMPORTANT: Pre-drill before xing screws.
a
Pre drill
hole
50mm
screw
Step 4
Parts Needed- No.2 QTY 1
- No.5 QTY 1
**Please note: the front and back panels are
interchangeable and can be positioned on
either side of the building.**
Place the Window Panel (No.2) onto the oor,
secure to the corner of the Plain Gable using
3x50mm screws.
Place the Plain Panel 2 (No.5) and x to the
Plain panel 1 using 3x50mm screws in an
alternating pattern.
Do not secure the building to the oor until
the roof is tted.
Position the panels so there is equal spacing
between the oor and cladding
6x50mm Screws
2
5
a
a
a
a
a
a
IMPORTANT: Pre-drill before xing screws.
a
a
3
1
Step 5
Parts Needed- No.1 QTY 1
- No.3 QTY 1
**Please note: the front and back panels
are interchangeable and can be positioned
on either side of the building. **
Place the Door Panel (No.1) onto the oor and
x to the Window panel using 3x50mm screws
in an alternating pattern.
Place the Plain Gable (No.3) onto the oor,
secure at the corners using 3x50mm screws
per corner.
Do not secure the building to the oor until
the roof is tted.
Position the panels so there is equal spacing
between the oor and cladding
9x50mm Screws
Pre drill
hole
50mm
screw
a
a
a
a
a
a
a
a
IMPORTANT: Pre-drill before xing screws.


 
IMPORTANT: Pre-drill before xing screws.
Step 6
Parts Needed- No.10 QTY 1
- No.19 QTY 2
Fix the Corner Braces (No.19) to each end of
the Ridge bar (No.10) using 2x20mm
screws per Corner brace. Fix the ridge bar to
each Gable, ensuring it is ush with the
gable framing as shown in the illustration.
Secure using 2x20mm screws per Corner
brace.
8x20mm Screws
19
19
19
10
10
Pre drill
hole
20mm
screw
Step 7
Parts Needed- No.6 QTY 2
- No.11 QTY 2
Fix the Eaves framing (No.11) to the roof
sheets (No.6) using 4x30mm screws per
eaves frame.
The framing should nish ush with the
edge of the roof sheet
8x30mm Screws
30mm
screw
Pre drill
hole
IMPORTANT: Pre-drill before xing screws.
11
11
6
6
30mm
screw
Pre drill
hole
66
Step 8
Parts needed - No. 6 QTY 2
Place the Roof Panels (No.6) on top of the
building, ensuring equal spacing either side of
the building
**Make sure that you have got the roof
panels the correct way round with the Eaves
Framing to the front and back of the
building.**
From the top, x directly through the roof panels
(No.6) and into the ridge bar (No.10) below
using 5x30mm screws per roof panel.
It is essential that the ridge bar (No.10) and roof
panel (No.6) framing pull together when xed
with 30mm screws. You may require another
person pushing the ridge bar (No.10) up from
below to achieve this.
Fix the remaining edges of the roof panels using
12x30mm screws. Ensure there is no more than
300mm between each screw.
20x30mm Screws
IMPORTANT: Pre-drill before xing screws.


 
bbbbbbbbb
b
b
b
40mm
screw
Pre drill
hole
Step 9
Fix the building to the oor using
20x40mm screws, ensuring to go
through the panel framing and into
the oor
20x40mm Screws
IMPORTANT: Pre-drill before xing screws.
Pre drill
hole
20mm
screw
a
b
c
Styrene
Window Cill
Cladding
Side View
a
b
c
SILICONE
SEALANT
30mm
screw
Step 10
Parts Needed- No.13 QTY 2
- No.14 QTY 1
- No.18 QTY 1
- No.23 QTY 1
18
23
13
14
13
IMPORTANT: Pre-drill before xing screws.
Place the plastic cill (No.18) into the window
panel as shown in the illustration.
Fit the styrene sheet (No.23) on top of the
window cill.
*For added weather protection t your windows
using silicone sealant around the outside edges.
**When positioning the styrene sheets ensure
there is an equal distance on all sides.
Attach the window strips (No.13 and No.14) to
either side of the windows and the top. Secure
into place using 3x30mm screws per strip.
2x20mm screws
9x30mm Screws


 
Felt
tacks
12
Step 11
Parts Needed- No.17 QTY 1
Cut the felt (No.17) into 2 sheets of
1900mm (L) x 1000mm (W) and lay onto
roof as shown in diagram.
Ensure there is a 50mm overhang around
each side.
Secure in place using felt tacks at 100mm
intervals.
85 x Felt tacks
17
IMPORTANT: Pre-drill before xing screws.
100mm
HANDLE
WITH CARE
1 2
3
4
Step 12
Parts Needed- No.15 QTY 6
Fix the cover trims (No.15) to the corners and
the joins of the building, secure using
3x30mm for each cover trim
18x30mm Screws
30mm
screw
Pre drill
hole
15
15 15
15
15
15
15
IMPORTANT: Pre-drill before xing screws.
Step 13
Parts Needed- No.16 QTY 4
- No.24 QTY 2
Fix the Fascias (No.16) to each side of the
building, secure using 3x30mm Screws
per fascia.
Fix the Diamond Finials (No.24) to the
top of each gable, secure using 2x30mm
per Finial, ensuring to go through the
Fascias and into the plain gable
16x30mm Screws
30mm
screw
Pre drill
hole
16
24
16 24
16
16
IMPORTANT: Pre-drill before xing screws.

¢
 
Step 14
Parts Needed- No.9 QTY 1
- No.12 QTY 2
Fix the Door Beading strips (No.12) to the
door panel framing, secure using 4x30mm
Screws per strip.
Fix the door block (No.9) onto the door
framing using 2x50mm Screws
8x30mm Screws
2x50mm Screws
30mm
screw
Pre drill
hole
50mm
screw
12
12
12
9
9
IMPORTANT: Pre-drill before xing screws.
Pre drill
hole
50mm
screw
Step 15
Parts Needed- No.21 QTY 2
- No.22 QTY 1
Fix the Turn Buttons (No.21) to the door
panel, ensuring that the turn buttons
catch the door, secure using 2x30mm
screws
Fix the Hasp and Staple (No.22) onto
the door and door panel, secure using
7x30mm screws, ensuring the screws
go through the framing.
9x30mm Screws 22
22
21
21
21
IMPORTANT: Pre-drill before xing screws.
It is ESSENTIAL that you apply wood
treatment immediately after the building
has been assembled.
AFTER TREATMENT:
score around protective
cover on glazing and
carefuly peel
covering back



¡




¡


¡

¡


¡



¢





¡
¡¡

¢


£

 
¡







