Universal Space Dizzy Lizzy User manual

Operation Manual
www.universal-space.com
IMPORTANT

Dizzy Lizzy STD Manual
03/14/2018
1
CONTENT
IMPORTANT SAFETY INSTRUCTIONS........................................................................ 3
1. SPECIFICATIONS ..................................................................................................... 5
2. PACKAGE CONTENTS.............................................................................................. 7
3. PART NAME.............................................................................................................. 8
4. SET UP & INSTALLATION........................................................................................ 9
5. HOW TO PLAY ........................................................................................................12
6. IO SETTING.............................................................................................................13
7. TROUBLE SHOOTINGS .......................................................................................... 17
8. MAINTENANCE & INSPECTION ...........................................................................20
9. OVERALL CONSTRUCTION ...................................................................................20

Dizzy Lizzy STD Manual
03/14/2018
2
WE ARE HERE TO ASSIST
For parts and service
Have Questions? Contact us!
UNIS SERVICE CENTER
Tel: [phone]
Fax: [phone]
Email: [e-mail]

Dizzy Lizzy STD Manual
03/14/2018
3
Thank you for purchasing Dizzy Lizzy. We hope you enjoy the product.
This manual contains valuable information about how to operate and maintain your game
machine properly and safely. It is intended for the owner and/or personnel in charge of
product operation. Carefully read and understand the instructions.
If you need any help during installation and setup please utilize this manual and
troubleshooting guide. If the product fails to function properly, non-technical personnel
should under no circumstance attempt to service the machine. Contact your distributor or
manufacturer for help.
Before use, please read IMPORTANT SAFETY INSTRUCTIONS.
IMPORTANT SAFETY INSTRUCTIONS
To ensure the safe usage of this product, carefully read and
understand these instructions before operating your game.
Save these instructions for future reference.
Use this product only as described in this manual. Other uses not recommended may
cause fire, electric shock or personal injury. Unplug the game from the outlet when not in
use, when moving from one location to another, and before cleaning/servicing.
Explanations which require special attention are indicated by signs of warning. Depending
on the potential hazardous degree, the terms: NOTE, NOTICE, and WARNING are used.
NOTE: A NOTE indicates useful hints or information about product usage.
NOTICE: A NOTICE indicates potential damage to product and how to avoid the problem.
WARNING: A WARNING indicates a potential for product damage or serious personal Injury.
It is important to understand the meaning of the following HAZARD SIGNS before
continuing:
High Voltage and Shock Hazard:
High voltage can cause electric shock.
Turn off/unplug power before servicing.
High Temperature Hazard:
This part may cause scalding.
Do not touch. Surface may be hot.
No Touching Hazard:
This part may be hot or can cause electric shock.
Do not touch.

Dizzy Lizzy STD Manual
03/14/2018
4
Use the following safety guidelines to help ensure your own personal safety and to help
protect your equipment and surrounding environment from potential damage.
This product is an indoor game machine. Do not install
outdoors.
Avoid installing in the following places to prevent fire, electric shock, injury
and/or machine malfunctioning:
Places subject to rain/moisture, or places subject to high humidity.
Places subject to direct sunlight, or places subject to extremely hot or cold
temperatures to ensure that it is used within the specified operating range.
Places where inflammable gas may be present or in the vicinity of highly
inflammable/volatile chemicals or items that can easily catch fire
On unstable or sloped surfaces. The machine may topple or cause unforeseen
accidents.
Vicinity of fire exits, fire extinguishers etc that may block/prevent safety measures
IMPORTANT NOTE:
ALL REPAIRS MUST BE DONE TO ORIGINAL MANUFACTURER SPECIFICATIONS.
FAILURE TO DO SO VOID ALL WARRANTIES AND OPERATOR ASSUMES ALL
RISKS.
Note: The contents of this manual may be updated without notice.

Dizzy Lizzy STD Manual
03/14/2018
5
1. SPECIFICATIONS
Rated power supply: AC110V 50/60Hz; AC220V 50/60Hz
Min. Power consumption: 70W
Max. Power consumption: 135W
Dimension: W29×D 38×H 86 in
Weight：Approximately 322 lb
Part No.: D137
Model No: A-406
NOTICE: After turning off the game, please wait at least 1 minute
before restarting again.
Note: Game parameters are subject to change without notice.

Dizzy Lizzy STD Manual
03/14/2018
6
The dimension of the game during transportation.
W29×D38×H75.2 in
Note: Game specifications are subject to change without notice.

Dizzy Lizzy STD Manual
03/14/2018
7
2. PACKAGE CONTENTS
Open the package and make sure all the items are included:
1. Following accessories
No. Part No. Code No. Name QTY Picture
1 D140-301-000 20101048005
Hexagon flat round head
screws 2
2 D140-302-000 20113000053
C large washer 2
3 D140-303-000 25300171002
Key 2
4 D140-304-000 25300172002
Key 2
5 D140-305-000 410000170 Ping pong(yellow) 7
6 D140-306-000 410000171 Ping pong(red) 7
7 D140-307-000 410000172 Ping pong(blue) 7
8 D140-308-000 21901000013
Fuse(Φ5×20mm T10A ) 1
9 D140-309-000 23301000001
Power cord 1
10 D140-310-000 Manual 1
NOTE: Part models are subject to change without notice.

Dizzy Lizzy STD Manual
03/14/2018
8
3. PART NAME
Coin Ass
y
.
Mar
q
uee Ass
y
.
Ticket dispenser Assy.
Display
J
oystick

Dizzy Lizzy STD Manual
03/14/2018
9
4. SET UP & INSTALLATION
This product is an indoor game machine. Do not install outdoors.
Refer to IMPORTANT SAFETY INSTRUCTIONS (Pg. 3) for places to avoid
Place the unit on a dry level surface
Ventilation openings in the back of the unit must not be obstructed by objects or by
wall.
4.1 Transporting the Game
If you need to move the game, adjust the levelers back to an “up” position.
NOTICE
Be careful not to damage the machine during transport.
Always unplug the game before moving.
Keep the machine in upright position during transport.
For longer distance transport, package the game properly to prevent damages.
4.2 Level Adjustment
Install this machine on a flat surface. Adjust levers to lift casters off the ground to level the
game. If the game is installed on an unsuitable floor, it could cause game malfunction.
To secure the game, adjust the Leveler down until it touches the floor, lifting the casters off
the ground by 0.2 in. Repeat the same for all levelers.
Leveler Caster
Move F
i
Caster
Leveler
About 0.2 in
Move Fix
NOTICE
Make sure the machine is level.
We do not recommend using power tools as they may cause damage.
NOTICE

Dizzy Lizzy STD Manual
03/14/2018
10
4.3 Play Zone
This machine requires space for playing and for maintenance as shown below.
Leave space around the game upon installation:
Service area: 20 in
Service area
Play area
Your unit must be leveled to operate properly.
NOTICE

Dizzy Lizzy STD Manual
03/14/2018
11
4.4 Marquee installation
Before processing with assembly assure you have the following tool.
No. Part No. Code No. Name Picture Qty
1 D140-301-000 20101048005 Hexagon flat round head
screws
2
2 D140-302-000 20113000053 C large washer
No. Name Picture
Use for
1 Allen hexagon wrenches Marquee installation
Use Hexagon flat round head screws and C large washers to
lock the marquee.

Dizzy Lizzy STD Manual
03/14/2018
12
5. HOW TO PLAY

Dizzy Lizzy STD Manual
03/14/2018
13
6. IO SETTING
6.1 Adjustment button instruction
6.2 IO setting
SW 1
Open the coin door and there is a
meter panel. Press test button to get
into the setting menu.
Settin
g
s
Test Reset
Item Content
SW1
1 2
1 ON ON
Coin 2 off on
per game 3 on off
4
off off
Item Content
SW1
3 4 5
10 balls
on
on on
Balls 15 balls
off
on on
per game
20 balls
ON
OFF ON
30 balls
off
off on
40 balls
on
on off
50 balls
off
on off
Item Content
SW1
6
Ticket 1：1 ON
payout ratio* 2：1 off
Item
Content
SW1
7
Demo
Yes ON
music
No off
Item Content
SW1
8
Save Yes ON
Memory No off
Ticket
payout ratio*
1：1 Ticket payout as one to one
2：1 Ticket payout will be divided by 2

Dizzy Lizzy STD Manual
03/14/2018
14
SW 2
SW 3
Item Content SW2
1 2 3
A group ON ON ON
Bonus B group off on on
Score C group on
off on
D group
off off on
E group on
on off
Item Content
SW2
4 5 6
200
on
on
on
Bonus
300 off
on
on
Payout 400 on
off
on
Ticket
500 off
off
on
600 ON
ON
OFF
800 off
on
off
1000 on
off
off
1500 off
off
off
Item Content
SW2
7
Ticket
payout Yes ON
No off
Item
Content SW2
8
Out of Continue ON
ticket
Call attendant
off
Item Content SW3
1 2 3
4
A
on on on
on
Score
B off on on
on
groups C on off on
on
D OFF OFF ON
ON
CEC off off off
off
Item Content
SW3
5
Shoot ball Continuously on
Mode* Once OFF
Bonus score:
Balls per game
A group B group C group D group E group
10 balls 1000 900
15 balls 1500 1400
20 balls 2000 1900 1800
30 balls 3000 2900 2800 2700
40 balls 4000 3900 3800 3700 3600
50 balls 5000 4900 4800 4700 4600
Shoot ball
mode**:
Continuously: Player pulls the joystick and hold still,
the tongue will move in and out continuously.
Once: Player pulls the joystick once, the tongue moves once.
Players need to pull the joystick repeatedly.

Dizzy Lizzy STD Manual
03/14/2018
15
10 balls score group:
Score 0-400 500-600 700
800 - ＜bonus score ≧bonus score
A 1 ticket(s) 5 ticket(s) 15 ticket(s)
20 ticket(s) bonus ticket(s)
B 3 ticket(s) 10 ticket(s)
20 ticket(s)
30 ticket(s) bonus ticket(s)
C 5 ticket(s) 15 ticket(s)
30 ticket(s)
50 ticket(s) bonus ticket(s)
D 10 ticket(s) 20 ticket(s)
50 ticket(s)
100 ticket(s) bonus ticket(s)
CEC 1 ticket(s) 3 ticket(s) 5 ticket(s) 7 ticket(s) bonus ticket(s)
15 balls score group:
Score 0-700 800-900 1000-1100
1200 - ＜bonus score ≧bonus score
A 1 ticket(s) 5 ticket(s) 15 ticket(s)
20 ticket(s) bonus ticket(s)
B 3 ticket(s) 10 ticket(s)
20 ticket(s)
30 ticket(s) bonus ticket(s)
C 5 ticket(s) 15 ticket(s)
30 ticket(s)
50 ticket(s) bonus ticket(s)
D 10 ticket(s) 20 ticket(s)
50 ticket(s)
100 ticket(s) bonus ticket(s)
CEC 1 ticket(s) 3 ticket(s) 5 ticket(s) 7 ticket(s) bonus ticket(s)
20 balls score group:
Score 0-900 1000-1300
1400-1500
1600 - ＜bonus score ≧bonus score
A 1 ticket(s) 5 ticket(s) 15 ticket(s)
20 ticket(s) bonus ticket(s)
B 3 ticket(s) 10 ticket(s)
20 ticket(s)
30 ticket(s) bonus ticket(s)
C 5 ticket(s) 15 ticket(s)
30 ticket(s)
50 ticket(s) bonus ticket(s)
D 10 ticket(s) 20 ticket(s)
50 ticket(s)
100 ticket(s) bonus ticket(s)
CEC 1 ticket(s) 3 ticket(s) 5 ticket(s) 7 ticket(s) bonus ticket(s)
30 balls score group:
Score 0-1400 1500-2000
2100-2300
2400 - ＜bonus score ≧bonus score
A 1 ticket(s) 5 ticket(s) 15 ticket(s)
20 ticket(s) bonus ticket(s)
B 3 ticket(s) 10 ticket(s)
20 ticket(s)
30 ticket(s) bonus ticket(s)
C 5 ticket(s) 15 ticket(s)
30 ticket(s)
50 ticket(s) bonus ticket(s)
D 10 ticket(s) 20 ticket(s)
50 ticket(s)
100 ticket(s) bonus ticket(s)
CEC 1 ticket(s) 3 ticket(s) 5 ticket(s) 7 ticket(s) bonus ticket(s)
40 balls score group:
Score 0-1900 2000-2700
2800-3100
3200-＜bonus score ≧bonus score
A 1 ticket(s) 5 ticket(s) 15 ticket(s)
20 ticket(s) bonus ticket(s)
B 3 ticket(s) 10 ticket(s)
20 ticket(s)
30 ticket(s) bonus ticket(s)
C 5 ticket(s) 15 ticket(s)
30 ticket(s)
50 ticket(s) bonus ticket(s)
D 10 ticket(s) 20 ticket(s)
50 ticket(s)
100 ticket(s) bonus ticket(s)
CEC 1 ticket(s) 3 ticket(s) 5 ticket(s) 7 ticket(s) bonus ticket(s)

Dizzy Lizzy STD Manual
03/14/2018
16
Item Content
SW4
1
Game Free on
mode Coins OFF
Item Content
SW3
6 7 8
Random
ON
ON ON
Side Red
off
on on
light& Blue
on
off on
Speaker Green off
off on
light Yellow
on
on off
Purple off
on off
Blue on
off off
White off
off off
50 balls score group:
Score 0-2400 2500-3400
3500-3900
4000 - ＜bonus score ≧bonus score
A 1 ticket(s) 5 ticket(s) 15 ticket(s)
20 ticket(s) bonus ticket(s)
B 3 ticket(s) 10 ticket(s)
20 ticket(s)
30 ticket(s) bonus ticket(s)
C 5 ticket(s) 15 ticket(s)
30 ticket(s)
50 ticket(s) bonus ticket(s)
D 10 ticket(s) 20 ticket(s)
50 ticket(s)
100 ticket(s) bonus ticket(s)
CEC 1 ticket(s) 3 ticket(s) 5 ticket(s) 7 ticket(s) bonus ticket(s)

Dizzy Lizzy STD Manual
03/14/2018
17
7. TROUBLE SHOOTINGS
7.1 Common Problem
Please confirm whether every connector connected tightly.
Symptom Possible Cause Recommended action
Game will not
start
Frame assembly connector is
loose. Plug the connector tightly.
Frame assembly fault Contact with UNIS Service.
Power cutting Circuit protector make power SW
in cutting state
Turn on power SW again. If appeared
again and again, machine has
anomaly. Please contact with UNIS
Service.
Game will not
coin up
Coin mech. fault or sample coin
not installed. Change coin mech. or sample coin.
Coin mech. signal cable loose. Check coin mech. signal cable loose.
IO control board no signal. Change IO board.
No ticket
dispensing
Out of ticket. Add ticket and press reset button
Ticket jamming. Remove the jammed tickets and press
reset button.
Wrong connection. Check the connections.
No sound
Volume set too low. Raise the volume.
Connector loose. Plug in connector tightly.
PCB fault. Change PCB.
Speaker fault. Change speaker.
POT installation error. Install POT correctly.
POT fault. Change POT.
Audio cable problem. Reconnect the audio cable or change
it.
PC crash. Restart or system recovery.
Driver problem Restart the audio driver.

Dizzy Lizzy STD Manual
03/14/2018
18
7.2 Error code
If you see following error code showing on the display, please try the recommended action.
Error
Code Error Recommended action
Er01 Settings button Check the connection of the buttons. Replace the
buttons.
Er02 Test button
Er03 Reset button
Er04 Ball deliver sensor error
Check the connection of the sensor. Replace the
sensor.
Er05 Ball out counting sensor
error
Check the connection of the sensor. Replace the
sensor.
Ball deliver sensor Ball out counting
sensor
Score sensor

Dizzy Lizzy STD Manual
03/14/2018
19
Error
Code Error Recommended action
Er06 Joystick button
error
Check the connection of the button. Replace the button.
Er09 Score sensor
error
Check the connection of the sensor. Replace the sensor.
HELP Out of ticket
Please check the connection. Add ticket or remove the
jammed tickets, then press reset button.
E83 Coin mech.
error
Change coin mech. or sample coin.
Check the connection. Replace the Coin mech.
E84 Coin mech.
error
Change coin mech. or sample coin.
Check the connection. Replace the Coin mech.
