INSTALLATION INSTRUCTIONS FOR PART 95-2009 or 99-2009
APPLICATIONS
METRA. The World’s best kits.™metraonline.com1-800-221-0932 © COPYRIGHT 2004-2011 METRA ELECTRONICS CORPORATION
REV. 9/19/2013 INST-2009
CAUTION: Metra recommends disconnecting the
negative battery terminal before beginning any
installation. All accessories, switches, and especially
air bag indicator lights must be plugged in before
reconnecting the battery or cycling the ignition.
NOTE: Refer to the instructions included with the
aftermarket radio.
95-2009:
• DoubleDINradioprovision
• StackedISODINradioprovision
99-2009:
• DINradioprovision
 withpocket
• ISODINradioprovision
 withpocket
KIT FEATURES
WIRING & ANTENNA CONNECTIONS(soldseparately)
WiringHarness:
•Visitwww.metraonline.comforspecific
 interfaceapplications
AntennaAdapter:
•40-GM10-GMantennaadapter1988-up
•40-CR10-Chryslerantennaadapter2002-up
•Utilityknife•Phillipsscrewdriver•Socketset
TOOLS REQUIRED
GM/Suzuki multi-kit 1999-2011
95-2009 or 99-2009
See application list inside
95-2009: •A1)DoubleDINtrimplate•B1)DoubleDINbrackets•C1)Spacers•D1)(4)Carriagebolts
•E1)(4)Kepnuts•F1)(3)Screwsand(3)speedclips
99-2009: •A2)Radiohousing•B2)Radiohousingbrackets•C2)Trimplate•D2)ISObrackets
•E2)DINspacer•F2)(4)Carriagebolts•G2)(4)Kepnuts•H2)(3)Screws&(3)Speedclips
•I2)(2)#83/8”Phillipsscrews
KIT COMPONENTS
B1A1
E1D1 F1
B2 C2 D2
H2 I2
C1 A2
F2E2 G2

INST-2009
Applications
Buick
Century.......................... 1997-2005
LeSabre......................... 1995-2005
ParkAvenue.................. 1995-2005
Rainier........................... 2004-2007
Regal............................. 1995-2004
Rendezvous................... 2002-2007
Riviera........................... 1996-1999
Roadmaster................... 1995-1996
Skylark.......................... 1996-1998
Cadillac
EscaladeESV/EXT.......... 2003-2006
Brougham...................... 1990-1996
Eldorado........................ 1992-1995
Fleetwood...................... 1990-1996
Seville............................ 1992-1995
Chevrolet
Avalanche...................... 2003-2006
Blazer(with DDIN)............ 2002-2005
Cavalier......................... 2000-2005
Chevrolet (continued)
Colorado........................ 2004-2012
ExpressVan (full)............ 2001-2007
Impala........................... 2000-2005
Kodiak........................... 2003-2009
Malibu........................... 2001-2003
MalibuClassic............... 2004
Metro/Geo...................... 1995-2001
MonteCarlo................... 2000-2005
SSR............................... 2003-2006
S-10Pickup(with DDIN).. 2002-2004
Silverado....................... 2003-2006
SilveradoClassic........... 2007
Suburban....................... 2003-2006
Tahoe............................ 2003-2006
Tracker.......................... 1992-2004
Trailblazer...................... 2002-2009
Venture.......................... 2000-2005
GMC
Canyon.......................... 2004-2012
GMC (continued)
Envoy............................ 2002-2009
Savana.......................... 2001-2007
Sierra............................ 2003-2006
SierraClassic................. 2007
Sonoma(with DDIN)......... 2002-2004
TopKick......................... 2005-2009
Yukon/Denali/XL............ 2003-2006
Honda
Passport........................ 1998-2002
Hummer
H2................................. 2003-2007
Isuzu
Ascender....................... 2003-2009
Amigo............................ 1998-2000
i290/i370....................... 2007-2008
i280/i350....................... 2006
Rodeo............................ 1998-2004
RodeoSport................... 2001-2003
Oldsmobile
Achieva.......................... 1996-1998
Alero.............................. 1999-2004
Aurora........................... 1995-2003
Bravada......................... 1998-2001
Bravada......................... 2002-2004
Cutlass.......................... 1997-1999
CutlassSupreme........... 1995-1997
Eighty-Eight................... 1994-1999
Intrigue.......................... 1998-2003
LSS................................ 1996-1999
Ninety-Eight................... 1994-1996
Regency........................ 1997-1998
Silhouette...................... 2000-2004
Pontiac
Aztec............................. 2001-2005
Bonneville...................... 2000-2005
GrandAm...................... 2001-2005
Montana........................ 2000-2005
Sunfire........................... 2000-2005
Suzuki
Aerio.............................. 2002
Esteem.......................... 1995-2003
Sidekick......................... 1992-1998
Swift.............................. 1995-2001
Vitara............................. 1999-2005
GrandVitara................... 1999-2002
XL-7.............................. 2001-2002
Toyota
Matrix............................ 2003-2004

INST-2009
Dash Disassembly
- BuickCentury1997-2005/
 Regal1995-2004......................................4
- BuickLeSabre/ParkAvenue1995-1999....4
- BuickLeSabre/ParkAvenue2000-2005....4
- BuickRendezvous2002-2007..................5
- BuickRiviera1996-1999..........................5
- BuickRoadmaster1995-1996................10
- BuickSkylark1996-1998.........................6
- CadillacEldorado/Seville1992-1995.........7
- CadillacEscaladeESV/EXT/Chevrolet
 Avalanche/Suburban/Tahoe2003-2006....6
- CadillacFleetwood/
 Brougham1990-1996.......................... 6-7
- ChevroletBlazer2002-2005.....................8
- ChevroletCavalier2000-2005..................8
- ChevroletColorado2004-2012/
 GMCCanyon2004-2012...........................9
- ChevroletExpressVan/
 GMCSavana2001-2002...........................9
- ChevroletExpressVan/
 GMCSavana2003-2007.........................10
- ChevroletImpala2000-2005...................10
- ChevroletMalibu2001-2003/
 MalibuClassic2004................................11
- ChevroletMetro/
 SuzukiSwift1995-2001.........................11
- ChevroletMonteCarlo2000-2005..........11
- ChevroletS-10(with DDIN)/
 GMCSonoma(with DDIN) 2002-2004.........8
- ChevroletSilverado/GMCSierra
 2003-2006,ChevroletSilverado
 Classic/GMCSierraClassic2007,
 ChevroletKodiak2003-2009.....................6
- ChevroletSSR2003-2006.......................12
- ChevroletTracker1992-2004/Suzuki
 Sidekick1992-1998/Vitara1999-2005...12
- ChevroletTrailblazer2002-2009.............13
- ChevroletVenture/OldsmobileSilhouette/
 PontiacMontana(except SV6)2000..........13
- ChevroletVenture/PontiacMontana
(except SV6)2001-2005............................13
- GMCEnvoy2002-2009/
 IsuzuAscender2003-2009.....................14
- GMCTopKick,Yukon/Denali/XL
 2003-2006...............................................6
- HondaPassport1998-2002....................18
- HummerH22003-2007.................... 14-15
- Isuzui290/i3702007-2008......................9
- Isuzui280/i3502006................................9
- IsuzuAmigo1998-2000/Rodeo
 1998-2004/RodeoSport2001-2003.......18
- OldsmobileAchieva1996-1998..............15
- OldsmobileAlero1999-2004..................16
- OldsmobileAurora1995-2003................16
- OldsmobileBravada1998-2004/
 BuickRainier2004-2007........................14
- OldsmobileBravada1998-2001................8
- OldsmobileCutlass1997-1999/
 CutlassSupreme1995-1997..................16
- OldsmobileEightyEight1994-1999........17
- OldsmobileNinetyEight1994-1996........17
- OldsmobileIntrigue1998-2003...............17
- OldsmobileLSS1996-1999/
 Regency1997-1998...............................18
- OldsmobileSilhouette2001-2004...........13
- PontiacAztec2001-2005........................19
- PontiacBonneville2000-2005................19
- PontiacGrandAm2001-2005.................20
- PontiacSunfire2000-2005.....................20
- SuzukiAerio2002...................................21
- SuzukiEsteem1995-2003......................21
- SuzukiGrandVitara1999-2002/
 XL-72001-2002.....................................12
- ToyotaMatrix2003-2004/
 PontiacVibe2003-2008..........................21
Tab Instruction
95-2009:
- Cadillac/Chevy/GMC/Isuzu/Metro/
 Pontiac/Suzuki/Toyota....................... 22-23
95-2009:
- Cadillac/Chevy/GMC/Isuzu/Metro/
 Pontiac/Suzuki/Toyota....................... 26-27
Kit Assembly
95-2009:
- CadillacFleetwood/Brougham
 1990-1996(assembly with brackets)...........24
- CadillacEldorado/Seville1992-1995.......24
- DoubleDINradio/StackedISO
 mountunitprovision...............................25
99-2009:
- CadillacFleetwood/Brougham
 1990-1996(assembly with brackets)...........28
- CadillacEldorado/Seville1992-1995.......28
- ISOmountradioprovisionwithpocket....29
- DDINradioprovisionwithpocket........ 30-31
Table of Contents

4
Dash Disassembly
1. Removetheplastic
trimpiecetothe
leftoftheglovebox
andthe(1)exposed
Phillipsscrew.
2. Unsnapthetop
edgeoftheknee
bolsterpanel.
3. Remove(1)Phillips
screwfromthepanel.
4. Removethe
ashtrayclusterand(2)
Phillipsscrewsfrom
eachside.
5. Uncliptheentire
dashtrimbezeland
remove.(FigureA)
6. Opendoorsand
unsnapendcapsfrom
eachsideofdash.
7. Unsnapandremove
radio/instrument
clusterpanel.
8. Remove(3)screwsin
ordertoremoveradio.
Continue to tab
instructions
Buick Century 1997-2005
Regal 1995-2004
1. Opendriver’sdoorandunsnapandremove
dashendcap.
2. Unsnapandremovetrimalongcenterofdash
(onepieceonrightandoneonleftofwheel).
3. Unsnapandremoveradio/instrumentbezel.
(FigureA)
4. Remove(2)screwsin ordertoremoveradio.
Continue to tab instructions
Buick LeSabre/Park
Avenue 2000-2005
(Figure A)
1. Unsnaptheclimatecontroltrimpanel(fromdoor
todoor)andremove(4)Phillipsscrewsexposed.
2. PopouttheA/Cventsandremove
(1)Phillipsscrewexposedineachventcavity.
3. Uncliptheradiotrimbezelandremove.
4. Removethescrewssecuringthefactoryhead
unitanddisconnectthewiring.
Continue to tab instructions
Buick LeSabre/Park
Avenue 1995-1999
(Figure A)
2 2
1 1 1 1 1
4
44
22

5
Dash Disassembly
1. Opencenterconsoleandremove(2)
screwsatfrontofconsoleopening.
(FigureA)
2. Removelinersfromcupholdersand
storagepocketnexttocupholders,
thenremovescrews.Unsnapand
removepanel.(FigureB)
3. Remove(2)screwsfrombottomof
radio/climatecontrolbezel,unclip
andremove.(FigureC)
4. Remove(3)9/32”hexheadscrews
toremoveradio.(FigureD)
Continue to tab instructions
Buick Rendezvous 2002-2007
1. Unsnapleftsidepanelexposing(1)
Phillipsscrewbeneathpaneland
remove.(FigureA)
2. Unsnaprightsidepaneltoexpose
(1)Phillipsscrewbeneathpanel
andremove.(FigureA)
3. Unsnapundersideofoverhanging
dashtounsnap(6)plasticrivets
andremovepanel.(FigureA)
4. Remove(5)hexheadscrews
exposedunderoverhang.
(FigureB)
5. Unsnapbottomedgeof
trimbezelthen,whileholding
overhangup,unsnapandremove
trimbezelbyremovingany
necessaryharnesses.
6. Remove(3)Phillipsscrewto
removeclimatecontrol.
7. Remove(2)Phillipsscrewsto
removerearsupportand(3)9/32”
hexheadscrewstoremoveradio.
Continue to tab instructions
(Figure B)
Buick Riviera 1996-1999
(Figure A)
(Figure B) (Figure D)
(Figure A) (Figure C)
Step 4
Step 3
Step 1
Step 2

6
Dash Disassembly
1. Remove(6)
9/32”screwsinside
glovebox.
2. Undergloveboxand
driverskneebolster
remove(2)plastic
panelsbyturningthe
(2)1/4-turnfasteners
perside.
3. Removethe(4)9/32”
screwsrevealed
(2perside).
4. Unsnappanelfrom
driver’ssideto
passenger’sside.
5. Remove(3)
9/32”screwsto
removeradio.
Continue to tab
instructions
Buick Skylark 1996-1998
1. CarefullyunsnaptrimpanelaboveA/Ccontrols.
(FigureA)
2. Remove(2)7mmscrewsatthetopoftheradio/air
conditioningbezel,thenunclippanelandremove.
(FigureB&C)
3. Remove(4)7mmscrewsthatholdtheradioin,
slideradioout,unplugtheradioharnessesand
removeradio.(FigureD)
Continue to Radio Bracket Disassembly (pg. 7)
Cadillac Fleetwood/
Brougham 1990-1996
(Figure A)
1. Unsnapandremovedashbezel.(FigureA)
2. Remove(3)9/32”screwsandremoveradio.
Continue to tab instructions
Cadillac Escalade ESV/EXT/
Chevrolet Avalanche/Suburban/
Tahoe 2003-2006,
Chevrolet Kodiak 2003-2009,
Chevrolet Silverado/GMC
Sierra 2003-2006, Chevrolet
Silverado Classic/GMC Sierra
Classic 2007, GMC Top Kick
2005-2009, GMC Yukon/
Denali/XL 2003-2006
(Figure A)
Step 1Step 1
Step 1
Step 2
Step 2
Step 5

7
Dash Disassembly
(Figure C) (Figure A)
Cadillac Fleetwood/
Brougham 1990-1996
1. Usingapanelremovaltoolpryoutontheradio
trimringandremove.
Caution: Use extreme care when removing.
2. Gentlypryupontheashtray/gearshiftertrimbezel
andremove.(FigureA)
Note: Some models are equipped with bezels
made of real wood.
3. Remove(2)nutssecuringthebottomofthefactory
headunitanddisconnectthewiring.
Continue to tab instructions
Cadillac Eldorado/Seville
1992-1995
1. Remove(4)10mmnuts,(2)ontopoftheradioand
(2)onthebottomoftheradio,thatholdthefactory
mountingbracketson.
2. Savebracketsandnutsforkitassembly.
Continue to tab instructions
Cadillac Fleetwood/
Brougham 1990-1996
Radio Bracket
Disassembly
(Figure B)
(Figure D)
Bottom Factory Bracket
Top Factory Bracket
Remove 10mm nuts
Remove 10mm nuts
1

8
Dash Disassembly
1. Remove(2)9/32”hexheadscrews
fromthekneebolsterpanel.
2. Pulldownonthepaneland
removethe9/32”hexheadscrews
exposedonthebottomofthedash
trimbezel.
3. Remove(1)Phillipsscrewabovethe
instrumentcluster.
4. Unclipthedashtrimbezel
andremove.(FigureA)
5. Remove(2)9/32”hexheadscrews
securingthefactoryheadunitand
disconnectthewiring.
Continue to tab instructions
Chevrolet Blazer (withDDIN)
2002-2005, Chevrolet S-10 (withDDIN)/GMC
Sonoma (withDDIN) 2002-2004, Oldsmobile
Bravada 1998-2001 1. Opendriversdoorandremovefuse
panelonendofdash.
2. Openpassengerdoorandremove
panelonendofdash.
3. Remove(1)Phillipsscrewfromeach
sideexposed.
4. Remove(3)screwsfromtopofglove
boxliner.
5. Remove(2)screwsfromthetop-left
cornerofthegloveboxcavity.
6. Remove(1)Phillipsscrewfromthe
defrosterduct.
7. Removetheductworkand(1)
Phillipsscrewexposed.
8. Removethedashpadand(3)
Phillipsscrewsexposedatthetopof
theradiotrimbezel.
Continue to tab instructions
Chevrolet Cavalier
2000-2005
(Figure A)
1, 3
8
8
8 86, 7
444
52, 3

9
Dash Disassembly
1. Unsnapandremovetheentirepanelsurroundingtheradioand
A/Ccontrols.(FigureA)
2. Remove(3)9/32”screwssecuringtheradiotoremove.(FigureB)
Continue to tab instructions
Chevrolet Colorado 2004-2012,
GMC Canyon 2004-2012,
Isuzu i290/i370 2007-2008,
Isuzu i280/i350 2006 1. Unsnapandremovesmalltrimpanel
belowsteeringcolumn.(FigureA)
2. Unsnapradio/climate/instrumentpanel.
(FigureB)
3. Moveshiftlevertofirstgearposition.
4. Rotatepanelcounterclockwisetolift
oversteeringcolumnandremove.
5. Remove(3)9/32”hexheadscrewsto
removeradio.(FigureC)
Continue to tab instructions
Chevrolet Express Van/GMC
Savana 2001-2002
(Figure A) (Figure C)(Figure B) (Figure A)
(Figure B)

10
Dash Disassembly
1. Remove(2)10mm
boltsfrombelow
kneebolsterunder
steeringcolumnand
removepanel.
2. Remove(2)10mm
boltsfrompanel
belowpassenger
dashairbagand
removepanel.
3. Remove(2)10mm
nutsfrominside
centerpocketbetween
poweroutlets.
4. Unsnapandremove
radioandinstrument
clusterpanel.
Note: it may not
be necessary to
completely remove
radio and instrument
cluster panel to
access radio.
5. Remove(3)9/32”
boltstoremoveradio.
Continue to tab
instructions
Chevrolet Express Van/
GMC Savana 2003-2007
1. Unclipeachsideof
thedashtrimbezel
(fuseaccess)and
remove(1)Phillips
screwexposedon
eachside.
2. Remove(2)Phillips
screwsunderthe
instrumentcluster.
3. Unclipthetrimpanel
abovethepedals.
Itisnotnecessaryto
removethepanelit
canbelefthanging.
4. Remove(2)
Phillipsscrewsfrom
thekneepanel.
5. Uncliptheknee
panelandremove
(1)Phillipsscrew
exposedonthe
rightsideofthe
steeringcolumn.
6. Unclipandremove
theentiredash
trimbezel.(FigureA)
Continue to tab
instructions
Chevrolet Impala
2000-2005
1. Unclipdashpanelsidesandremove.
2. Unclippanelbelowsteeringcolumnandremove.
3. Remove(2)7mmscrewsaboveinstrumentcluster.
4. Setparkingbrake,turnkeytoonposition,and
moveshiftertothelowestgear.Tiltsteeringwheel
downthenunsnapentireinstrumentcluster/radio
panelandremove.Returnshiftertopark.
5. Remove(3)7mmscrewstoremoveradio.
Continue to tab instructions
Buick Roadmaster
1995-1996
(Figure A)
Step 3, 4
Step 1
Step 5Step 2

11
Dash Disassembly
1. Unsnapandremoveradiobezel.(FigureA)
2. Remove(3)boltsandremoveradio.(FigureA)
Continue to tab instructions
Chevrolet Malibu
2001-2003/Malibu
Classic 2004
(Figure A)
1. Unclipthetrimpanel
abovethepedals.It
isNOTnecessaryto
removethepanelit
maybelefthanging.
2. Remove(2)9/32”
screwsfromthe
kneepanelandunclip
thepanel.
3. Unsnapthedriver’s
sidefusepanelcover
andremove(1)
9/32”screw.
4. Opentheglovebox
andremove(1)9/32”
screwfromtheupper
leftcorner.
5. Remove(3)9/32”
screwssecuringthe
factoryradioand
disconnectthewiring.
Continue to tab
instructions
Chevrolet Monte Carlo
2000-2005
1. Removetheashtrayand(2)Phillipsscrews
exposed.(FigureA)
2. Remove(2)Phillipsscrewsabovetheradio
opening.(FigureA)
3. Uncliptheradiotrimbezelanddisconnectthe
cigarettelighterwiring.
4. Remove(2)screwssecuringeachside
ofthefactoryheadunitand(1)screwfrom
therearsupport.
5. Slidetheunitoutanddisconnectthewiring.
Continue to tab instructions
Chevrolet Metro/Suzuki
Swift 1995-2001
(Figure A)
1
22
2

12
Dash Disassembly
1. Unclipandremovethe
(3)climatecontrolknobs.
(FigureA)
2. Unclipandremovethelong
trimpanelbelowtheradioand
passengerairbag.(FigureB)
3. Unclipandremovethesmall
trimpaneltotheleftofthe
steeringwheel.(FigureC)
4. Removethe(5)9/32”screws
securingtheradio/instrument
panelthenunclipandremove
thepanel.(FigureD)
5. Removethescrewssecuring
thefactoryheadunitand
disconnectthewiring.
Continue to tab instructions
Chevrolet SSR 2003-2006
1. Removethecigarette
lighterandclimate
controlknobs.
2. Removethe
ashtrayandthe(1)
exposedscrew.
3. Pulloutontheclimate
controlclusterand
removethe(2)
exposedscrews.
4. Uncliptheradiotrim
bezel.(FigureA)
5. Remove(4)screws
fromthefactory
headunit,slide
theunitoutand
disconnectthewiring.
Continue to tab
instructions
Chevrolet Tracker 1992-
2004, Suzuki Sidekick
1992-1998, Vitara 1999-
2005/Grand Vitara 1999-
2002/XL-7 2001-2002
(Figure A)(Figure A) (Figure D)
(Figure C)
123
(Figure B)
123

13
Dash Disassembly
1. Remove(2)Phillipsscrewsinside
instrumentcluster.
2. Remove(1)Phillipsscrewunder
climatecontrolstotheleftofthe
poweroutlet.
3. Remove(2)7mmhexheadsfrom
understeeringcolumnandlower
thepanel.
4. Remove(3)Phillipsscrews
aroundsteeringwheel.
5. Unsnapandremovebezel
(usecautionwhenpullingover
hazardswitch).
6. Remove(3)7mmhexhead
screwstoremoveradio.
Continue to tab instructions
Chevrolet Trailblazer
2002-2009
1. Removetheashtrayand(1)Phillips
screwexposedintheashtraycavity.
2. Remove(1)Phillipsscrewfromthe
cigarettelightercompartment.
3. Remove(2)Phillipsscrewssecuring
thefactoryheadunitanddisconnect
thewiring.
Continue to tab instructions
ChevroletVenture/
Pontiac Montana
(exceptSV6) 2001-
2005/Oldsmobile
Silhouette
2001-2004
1. Removetheashtrayand(1)Phillips
screwexposedintheashtraycavity.
2. Remove(1)Phillipsscrewfromthe
cigarettelightercompartment.
3. Remove(2)Phillipsscrewssecuring
thefactoryheadunitanddisconnect
thewiring.
Continue to tab instructions
Chevrolet Venture/
Oldsmobile
Silhouette/
Pontiac Montana
(exceptSV6) 2000
Step 1
Step 2
Step 3
Step 1
Step 2
Step 3
(1)
(3) (3)
(2)

14
Dash Disassembly
1. Remove(4)Phillipsscrews,(2)fromleftand(2)fromrightofcarpeted
panel.(FigureA)
2. Slidecarpetedpaneldownandbackwardstoreveal(2)Phillipsscrews
andremove.(FigureB)
3. Unsnapradiobezelandunplug
cigarettelighterandaccessories.
(FigureC)
4. Remove(3)screwsandremoveradio.
(FigureC)
Continue to tab instructions
GMC Envoy 2002-2009, Isuzu Ascender
2003-2009, Oldsmobile Bravada
1998-2004, Buick Rainier 2004-2007
(Figure C)
1. Opencenterconsoleandremove(4)
9/32”screwsfromconsoleboxand
removebox.(FigureA)
2. Remove(4)Phillipsscrewsfrom
hingeonconsoledoorinside
consoleandremovedoor.(FigureB)
3. Loosen(1)T-15Torxonforward
facingsideofshiftleverandpullup
toremove.(FigureC)
4. Unclipcupholder/shiftertrim
assemblyandremove.(Figure4)
Continue on the next page
Hummer H2 2003-2007
(Figure A)
(Figure B)
(Figure D)(Figure B)
(Figure C)(Figure A)

15
Dash Disassembly
5. Remove(6)Phillipsscrewsfromtopof
centerconsole.(FigureE)
6. Remove(2)Phillipsscrewsfrominsidepocketon
backofcenterconsole,thenunclipandremove.
(FigureF)
7. Remove(1)10mmbolttorightofshiftlever.
8. Remove(2)Phillipsscrewsfromunderconsolebox
ondriver’ssideand(2)Phillipsscrewsfromunder
consoletrim-toponpassengerside.
9. Slidecontrolassemblyrearwards.
10.Remove(2)T-30Torxboltsfromtopofradio/
climatecontroltrimandunclipandremove.
(FigureG)
11.Remove(3)9/32”screwsthatholdtheradioin.
(FigureG)
Continue to tab instructions
Hummer H2 2003-2007
(Figure E)
1. Opentheglovebox,pressinwardonthewalls
ofthegloveboxlinerandremovetheliner.
2. Remove(10)Torxheadscrewsfromtheglove
boxlocation.
3. Remove(2)9/32”hexheadscrewsunderthe
steeringcolumn.
4. Unclipthedashtrimbezel.(FigureA)
5. Removethescrewssecuringthefactoryheadunit
anddisconnectthewiring.
Continue to tab instructions
Oldsmobile Achieva
1996-1998
(Figure A)(Figure F) (Figure G)

16
Dash Disassembly
1. Uncliptheradiotrimbezelandremove.(FigureA)
2. Remove(2)9/32”hexheadscrewssecuringthe
factoryheadunitanddisconnectthewiring.
Continue to tab instructions
Oldsmobile Cutlass 1997-
1999, Cutlass Supreme
1995-1997
(Figure A)
1. Uncliptheradiotrimbezelandremovethebezel.
(FigureA)
2. Remove(2)7mmscrewssecuringthefactory
headunitanddisconnectthewiring.
Continue to tab instructions
Oldsmobile Aurora
1995-2003
1. Removeshiftknobbyusingasmall
screwdrivertoremoveU-clipfromfrontofshifter
andpullupward.
2. Unclipandremoveshiftertrimpanel.
3. Unclipandremoveradioandclimatecontrolpanel
bypullingfrombottom.(FigureA)
4. Remove(3)9/32”screwsfromradioandremove.
Continue to tab instructions
Oldsmobile Alero
1999-2004
(Figure A)
(Figure A)

17
Dash Disassembly
1. Uncliptheradiotrimbezelandremove.(FigureA)
2. Remove(2)9/32”hexheadscrewssecuringthe
factoryheadunitanddisconnectthewiring.
Continue to tab instructions
Oldsmobile Eighty Eight
1994-1999
1. Openthecenterconsolestoragecompartmentand
remove(2)9/32”hexheadscrewsexposed.
2. Removethecenterconsole.
3. Uncliptheradiotrimbezelandremove.(FigureA)
4. Remove(2)9/32”hexheadscrewssecuringthe
factoryheadunitanddisconnectthewiring.
Continue to tab instructions
Oldsmobile Intrigue
1998-2003
1. Openthegloveboxandremove(2)hexhead
screwssecuringthewoodtrim.
2. Unsnapthewoodtrimandremove.
3. Remove(2)hexheadscrewsbelowtheradio
trimbezel.
4. Liftuponthebezelandremove.(FigureA)
5. Remove(3)Phillipshexheadscrewssecuringthe
factoryheadunitanddisconnectthewiring.
Continue to tab instructions
Oldsmobile Ninety Eight
1994-1996
(Figure A)
(Figure A) (Figure A)

18
Dash Disassembly
1. Removetheashtrayand(1)Phillipsscrewexposedinthe
ashtraycavity.
2. Unclipandremovethetrimpanelsurroundingthefactoryradio.
(FigureA)
3. Remove(4)Phillipsscrewssecuringthefactoryradioand
disconnectthewiring.
Continue to tab instructions
Honda Passport 1998-2002,
Isuzu Amigo 1998-2000,
Rodeo 1998-2004,
Rodeo Sport 2001-2003
(Figure A)
1. Opengloveboxandremove(2)center
trimbezelsattachedbyscrews.(FigureA)
2. Unsnapandremoveradiotrimbezel.
(FigureA)
3. Remove(3)9/32”hexheadscrewsand
removeradio.(FigureB)
Continue to tab instructions
Oldsmobile LSS 1996-1999
Regency 1997-1998
(Figure A)
(Figure B)

1. Pulloutcupholderinserts.
2. Remove(1)Phillipsscrewexposedinsidebottom
cupholder.
3. Unsnapandremoveshiftertrimwithcupholders.
4. Remove(2)#15Torxatbottomof
radio/climatebezel.
Continue to tab instructions
Pontiac Aztec
2001-2005
19
Dash Disassembly
1. Remove(2)Phillipsscrewsfromtheinstrument
cluster.(FigureA)
2. Uncliptheignitiontrimandremove.(FigureB)
3. Uncliptheclimatecontrol/radiotrimbezel
andremove.
4. Depressthespringclipsoneachsideofthe
factoryheadunitandremove.(FigureC)
Continue to tab instructions
Pontiac Bonneville
2000-2005
(Figure B)
(Figure A)
(Figure C)

20
Dash Disassembly
1. Openthegloveboxandremove(2)Phillipsscrews
exposedontherightedgeoftheradiotrimbezel.
2. Unclipthebezelandremove.(FigureA)
3. Remove(2)7mmhexheadscrewssecuringthe
factoryheadunitanddisconnectthewiring.
Continue to tab instructions
Pontiac Sunfire
2000-2005
(Figure A)
1. Unsnapandremoveradiotrimbezel.
2. Remove(3)9/32”screwsfromradiobracketsand
removeradio.
Continue to tab instructions
Pontiac Grand Am
2001-2005
12
2
2
1. Unclipthebottomedgeoftheradiotrimpanelthen
liftupandouttoremove. (FigureA)
Toyota Matrix
2003-2004/Pontiac
Vibe 2003-2008
(Figure A)
