MG R3-NCIE1 User manual

EM-8287 Rev.6 P. 1 / 21
MG CO., LTD. www.mgco.jp
5-2-55 Minamitsumori, Nishinari-ku, Osaka 557-0063 JAPAN
INSTRUCTION MANUAL
BEFORE USE ....
Thank you for choosing us. Before use, please check con-
tents of the package you received as outlined below.
If you have any problems or questions with the product,
please contact our sales office or representatives.
■PACKAGE INCLUDES:
Network interface module ..................................................(1)
■MODEL NO.
Confirm Model No. marking on the product to be exactly
what you ordered.
■INSTRUCTION MANUAL
This manual describes necessary points of caution when
you use this product, including installation, connection and
basic maintenance procedures.
POINTS OF CAUTION
■CONFORMITY WITH EU DIRECTIVES
• The equipment must be mounted inside the instrument
panel of a metal enclosure.
• The actual installation environments such as panel con-
figurations, connected devices, connected wires, may af-
fect the protection level of this unit when it is integrated
in a panel system. The user may have to review the CE
requirements in regard to the whole system and employ
additional protective measures to ensure the CE conform-
ity.
■HOT SWAPPABLE MODULES
• The module can be replaced while the power is ON. Be
sure to replace it when the module is not communicat-
ing with a host, as it may affect the system. Replacing
multiple modules at once may greatly change line voltage
levels. We highly recommend to replace them one by one.
■GENERAL PRECAUTIONS
• DO NOT set the switches while the power is supplied.
The switches are used only for maintenance without the
power.
■ENVIRONMENT
• Indoor use.
• When heavy dust or metal particles are present in the
air, install the unit inside proper housing with sufficient
ventilation.
• Do not install the unit where it is subjected to continuous
vibration. Do not subject the unit to physical impact.
• Environmental temperature must be within -10 to +55°C
(14 to 131°F) with relative humidity within 30 to 90% RH
in order to ensure adequate life span and operation.
■WIRING
• Do not install cables close to noise sources (relay drive
cable, high frequency line, etc.).
• Do not bind these cables together with those in which
noises are present. Do not install them in the same duct.
• Be sure to attach the terminal cover for safety.
INSTALLATION
Use the Installation Base Model R3-BS, or Model R3-BSW
for free I/O address capability.
Before mounting the Network Interface Module onto the
Base, be sure to configure the module as explained below.
■DATA ALLOCATION
The setting determines the data area size assigned to each
I/O module mounted on the base.
The data sent/received via CC-Link IE Field is mapped ac-
cording to this setting.
See “COMPONENT IDENTIFICATION” and “TRANSMIS-
SION DATA DESCRIPTIONS”.
■STATION No., ETC.
See “COMPONENT IDENTIFICATION”.
■NETWORK SLOTS ON THE BASE
I/O 1 I/O 2 I/O n
With Model R3-BS base, mount the I/O Modules from the
left end (I/O 1) to the right in order that the Network Mod-
ule assigns data areas from I/O 1.
Network Module(s) and Power Module are mounted basi-
cally at the right end though technically they could be
mounted in any position.
With Model R3-BSW base, there is no limitation in mount-
ing positions as I/O address can be assigned freely to each
module using rotary switches equipped on the base.
NETWORK INTERFACE MODULE
(CC-Link IE Field network) MODEL R3-NCIE1

R3-NCIE1
EM-8287 Rev.6 P. 2 / 21
MG CO., LTD. www.mgco.jp
5-2-55 Minamitsumori, Nishinari-ku, Osaka 557-0063 JAPAN
COMPONENT IDENTIFICATION
RUN LED
■FRONT VIEW ■SIDE VIEW
ERR LED
SW2
ON
8
7
6
5
4
3
2
1
SW3
ON
4
3
2
1
ON
8
7
6
5
4
3
2
1
SW1
FUNCTION
1
2
3
4
5
6
CC-Link IE Field
Communication
RJ-45 Modular Jack
Station No. Rotary SW
D LINK LED
×10
×1
STATION No.
D LINK
CONFIG
CN1
CN2
LNK
L ER
LNK
L ER
PC Configurator Connector
■STATION NO. SETTING ROTARY SW
The upper side of station No. setting rotary SW set MSB, and the down side of it set LSB. (configurable range is 1 to 120)
Confirm configurable station number in the manual of master unit (Factory setting: 01H).
3
For setting MSB of Station No. (×10)
For setting LSB of Station No. (×1)
8
6
7
3
4
5
2
1
0
F
E
D
C
B
A
9
5
4
2
1
0
9
8
7
6
e.g. Setting station No.
Rotary SW of setting station MSB, Indicating A: 10, B: 11, C: 12. For example, in the case of setting station No. 115, Set the Station
MSB: B and LSB: 5.
NOT allowed to Set D, E, F they are unused.
■SIDE DIP SW
(*) Factory setting
• Data Allocation: SW1, SW2
Data Allocation Type* must be assigned to each I/O module
position to specify how many data areas (four types) are to
be occupied by each.
Two bits from SW1 and SW2 are assigned to each posi-
tion, and data areas can be specified from the module No. 1
through 8. Setting for No. 9 and later modules is identical
to No. 8.
SW ASSIGNMENT MODULE NO.
SW1-1 SW1-2 1
SW1-3 SW1-4 2
SW1-5 SW1-6 3
SW1-7 SW1-8 4
SW2-1 SW2-2 5
SW2-3 SW2-4 6
SW2-5 SW2-6 7
SW2-7 SW2-8 8
SW SETTING DATA ALLOCATION
OFF OFF 1
ON OFF 4
OFF ON 8
ON ON 16
* Refer to the specifications of the related series for the Data
Allocation Type of I/O modules.
• Dual Communication: SW3-1
When two network modules are mounted, one must be
‘Main’ (OFF) network and the other must be ‘Sub’ (ON) net-
work. For single communication, the network module must
always be set to ‘Main’ (OFF).
SW DUAL COMMUNICATION
MAIN (*)SUB
SW3-1 OFF ON
• Input Error Data: SW3-2
Hold: When the communication from an input module is lost
due to the input module error, the network module holds the
signal and stands by until the communication recovers.
Set to ‘0’: When the communication from an input module
is lost due to the input module error, the network module
outputs ‘0.’
SW INPUT ERROR DATA
HOLD (*)SET ‘0’
SW3-2 OFF ON
Note: Be sure to set unused SW3-3 and 3-4 to OFF.

R3-NCIE1
EM-8287 Rev.6 P. 3 / 21
MG CO., LTD. www.mgco.jp
5-2-55 Minamitsumori, Nishinari-ku, Osaka 557-0063 JAPAN
■STATUS INDICATOR LED
ITEM ID COLOR FUNCTION S TAT U S DESCRIPTION
Status
Indicator RUN Green Device State ON Normal
OFF Occurring device error
D LINK Green Data Link Transmitting
ON Data link in operation (cyclick transmitting)
Blinking
Data link in operation (stop cyclick transmitting)*1
OFF Not in operation, disconnected
ERR Red Error
ON Occurring major error*2
Blinking Occuring minor error*3
OFF Normal
CN1 LINK Green CN1 Linking Up ON Linking up
OFF Link-down
L ER Red CN1 Receiving Data ON Abnormality receiving data, loopback in operation
OFF
Normality receiving data, loopback not in operation
CN2 LINK Green CN2 Linking Up ON Linking up
OFF Link-down
L ER Red CN2 Receiving Data ON Abnormality receiving data, loopback in operation
OFF
Normality receiving data, loopback not in operation
*1. Setting as a reserved station, data link stop, etc.
*2. Upper communication error, and internal bus error etc.
*3. Non-volatile memory error, or station no. setting rotary SW has been changed after turning on the power.
PC CONFIGURATOR
The following parameter items can be set with using PC Configurator Software (model: R3CON).
Refer to the users manual for the R3CON for detailed operation of the software program.
■CC-Link IE SETTING
PARAMETER SETTING RANGE DEFAULT SETTING
NetWork No. 1 - 239 1
Main/Sub switching delay time (0 - 5000 msec) 0 - 5000 (msec.) 0
TERMINAL CONNECTIONS
Connect the unit as in the diagram below.
■EXTERNAL DIMENSIONS unit: mm [inch]
1
2
3
4
5
6
130 [5.12]
27.5 [1.08] 109 [4.29] POSITIONING
GUIDE
TERMINAL
COVER
6–M3
SCREW
6.2
[.24]

R3-NCIE1
EM-8287 Rev.6 P. 4 / 21
MG CO., LTD. www.mgco.jp
5-2-55 Minamitsumori, Nishinari-ku, Osaka 557-0063 JAPAN
■CONNECTION DIAGRAM
INTERNAL
POWER
INTERNAL
BUS
BUS CONNECTOR
Regarding CN1 and CN2 of RJ-45 connector for CC-Link IE Field network,
there is no restriction for connection order.
RJ-45 MODULAR JACK
RUN +
RUN –
RUN CONTACT OUTPUT
CC-Link IE Field CN2
CC-Link IE Field CN1
USB CONNECTOR
PC CONFIGURATOR
CONNECTOR
1
4
RJ-45 MODULAR JACK
WIRING INSTRUCTIONS
■M3 SCREW TERMINAL (RUN contact output)
Torque: 0.5 N·m
■SOLDERLESS TERMINAL
Refer to the drawing below for recommended ring tongue
terminal size. Spade tongue type is also applicable. Solder-
less terminals with insulation sleeve do not fit.
Recommended manufacturer: Japan Solderless Terminal
MFG.Co.Ltd, Nichifu Co.,ltd
Applicable wire size: 0.75 to 1.25 mm2
12max
6max
3max 4min
3.2 dia.
(mm)
TRANSMISSION DATA DESCRIPTIONS
Number of transmission data (data allocation) for each I/O module is set with the DIP switch on the side of the unit. Data
allocation is assigned from slot 1 in sequence.
Keep number of transmission data of I/O module under 64, because max. number of transmission data is 64 per a node.
Station type: Remote device station
Link device: RX/RY 128 points, RWw/RWr 64 points
E.g. I/O data is assigned as shown below in the case of following configuration.
BASE SLOT NO. MODEL NUMBER OF
TRANSMISSION DATA
R3-BS10 1 R3-DA16A 1
2 R3-DC16A 1
3 R3-SV4 4
4 R3-YV4 4
5 R3-RS8 8
6 R3-YV8 8
7 R3-PA16 16
8 R3-PC16A 16
9 R3-NCIE1 ----
10 R3-PS1 ----
